IMPORTANT! Read “Safety and General Information” on page 169 before using your i80s phone. Introduction ... 7 Driving Safety Tips ...8 Getting Started... 11 i80s Phone Features ...12 Battery ...13 Turning Your i80s Phone On/Off...15 Enabling Security ...16 Receiving Over-the-Air Programming...16 SIM Card ...17 Keypad Lock ...23 Status of Your i 80s Phone...27...
Page 4
Emergency Calling ...63 Receiving a Phone Call ...63 Ending a Phone Call ...63 Recent Calls...63 Call Timers...66 Hands-Free Speakerphone...67 Mute...68 Call Waiting ...68 Call Hold ...70 Three-Way Calling ...71 Call Forwarding...72 Messages ... 77 Message Center ...79 Using Voice Mail ...80 www.motorola.com/iden...
Page 5
Using Text and Numeric Messaging ...81 Using Net Alert ...83 Using Your Phone as a Modem...84 Mobile Originated Text Messaging... 85 Message Center ...85 Text Msg Setup ...87 Text Message Inbox ...88 Text Message Outbox...90 Private and Group Calls ... 97 Private Calls ...97 Call Alerts...99 Group Calls...104...
Page 6
Data Accessories ...161 Other Important Information ... 167 Understanding Status Messages ...167 Safety and General Information ... 169 RF Operational Characteristics ...169 Electro Magnetic Interference/Compatibility...172 Medical Devices...172 Operational Warnings...174 Operational Cautions...175 Accessory Safety Information ...177 Limited Warranty Motorola Communication Products...185 www.motorola.com/iden...
Page 7
Limited Warranty Motorola Communication Products (International) ...189 Patent and Trademark Information...193 Index ... 195...
NOTE: This guide describes the features of the i80s phone as they were set up by Motorola. However, your carrier or your organization may have changed or added features. For more information, check with your carrier or your organization.
Get to know your Motorola wireless phone and its features such as speed dial and redial. If available, these features help you to place your call with- out taking your attention off the road.
Page 11
Use your wireless phone to help others in emergencies. If you see an auto accident, crime in progress or other serious emergency where lives are in danger, call 9-1-1 or other local emergency number, as you would want others to do for you. 10.
This section includes: i80s Phone Features Battery Turning Your i80s Phone On/Off Enabling Security Receiving Over-the-Air Programming SIM Card Keypad Lock Status of Your i80s Phone My Information Using T9® Text Input Getting Started Page 12 Page 13 Page 15 Page 15 Page 16 Page 17...
Battery Your i80s phone comes with a Lithium Ion battery. After attaching the battery, you must charge it before you use it for the first time. See “Charging Lithium Ion Batteries” on page 156 for the charging times for your phone’s battery. The first time you charge your phone’s battery, charge for 30 minutes more than the time shown on page 156.
When Using Phone Icon Display Battery Strength Battery NOTE: A short, chirp-like sound indicates a low battery. This indicates that you have approximately five minutes of talk time remaining. 11% - 40% 41% - 70% www.motorola.com/iden In Process Fully Charged (90% -100%)
When Charging Battery Icon Display 1 flashing bar Battery Strength Battery NOTE: During the charging process, the battery icon will be flashing. In addition, when the battery is fully charged, the battery icon will show a fully charged battery. Turning Your i80s Phone On/Off To power the phone on: For optimal signal strength, extend the antenna.
Telephone Number via a Net Alert message. In order to receive your programming, you must enable security (“Enabling Security” on page 16). Within 24 hours of enabling security, you will receive a Net Alert message containing your lists. under LATER, you under OK. It is www.motorola.com/iden...
To accept your phone programming: You will receive a Net Alert with the message New Browser Message - Receive Programming Info. Press B under GOTO. You are prompted to accept changes to your phone’s lists. Press B under OK. A confirmation screen displays. Press B under OK. You are prompted again to accept changes to your phone's lists.
After three consecutive incorrect attempts, the SIM card is blocked. The phone does not allow you to attempt to enter your PIN again, even after powering the phone off and back on. If this happens, see “Unblocking the PIN” on page 20. www.motorola.com/iden...
Page 21
Changing the PIN From the Ready screen, press m and then press R to scroll to Settings. Press B under SELECT. The Settings screen displays. Press R to scroll to Security. Press B under SELECT to access the Security screen. At the Security screen, press R to scroll to New Passwords.
When the PIN requirement is disabled, the phone can be used without entering a PIN. IMPORTANT: If you disable the PIN requirement, you remove protection of personal data on your SIM card. Anyone can then use your phone and access your personal data. www.motorola.com/iden...
Page 23
From the Ready screen, press m and then press R to scroll to Settings. Press B under SELECT. The Settings screen displays. Press R to scroll to Security. Press B under SELECT to access the Security screen. At the Security screen, press R to scroll to SIM PIN. Press B under SELECT to access the SIM PIN screen.
Page 24
With the back of the phone exposed and facing up, locate the SIM cover and gently push it to the right. Lift the cover up. • Call Filtering settings in Styles • Net Alert Notifications • Information stored in Memo • Browser Bookmarks www.motorola.com/iden...
To insert the SIM card, very carefully place it in its holder with the gold contact side facing down. To close the SIM card cover, push it down and slide forward. To remove the SIM card, slide the SIM card cover back and lift up (as in step 2).
Page 26
Keypad Lock and return to the Ready screen. Press under NO or press reactivate Keypad Lock. to answer the call. When you end the or press A under EXIT to to send the call to Voice Mail and www.motorola.com/iden...
Receiving Private Calls When you receive an incoming Private call, Talkgroup call, or call alert (see “Private Calls” on page 97), Keypad Lock is temporarily disabled. Press and hold the Push-To-Talk (PTT) button on the side of the phone. Begin talking after the phone emits a chirping sound. Release the PTT button to listen.
Ready screen and reactivate Keypad Lock. Press B under GOTO. Press A under View. Press A under OK or Reply. Once you have finished, press s or press A under EXIT to reactivate Keypad Lock return to the Ready screen. www.motorola.com/iden...
Deactivating Keypad Lock From the Ready screen, press m *. The message Keypad Unlocked displays briefly. Status of Your i 80s Phone Your i80s phone has a status light that displays at the top of the phone. The status light indicates the status of your connection. Status Light Indicator Flashing Red...
T9 database. T9 Text Input is available when you are typing information into your Phonebook and Datebook. ® www.motorola.com/iden Text Input, that makes...
T9 Text Input Entry Modes Four text entry modes are available in T9 Text Input: Alpha, Word, Symbols, and Numeric. When you are using T9 Text Input, an icon in the top right corner of your phone’s display screen (next to the battery strength indicator icon) indicates the T9 Text Input entry mode you are using: Icon T9 Entry Mode...
A under DELETE to erase the entire text entry field. Space Press R once to accept a word and insert a space when entering text. Next Word in Database Press 0 to display more words in the database that match the keystroke sequence you entered. www.motorola.com/iden...
Page 33
Shift and Caps Lock Press # to make the next letter typed uppercase (Shift), to make all subsequent letters types uppercase (Caps Lock), or to go back to lowercase letters. These icons appear in the top row of your display screen: •...
Page 34
You cannot store alphanumeric combinations, such as Y2K. Choosing a Language To change the language of the T9 Text Input database: From any screen that requires text input, press Method menu. Press to scroll to Languages. www.motorola.com/iden to access the Entry...
Press under SELECT. Press to scroll to the language you want T9 Text Input to use. Press under SELECT. Using Numeric Mode To use Numeric text entry mode, choose Numeric as your text entry mode and press the number buttons on your keypad to enter numbers. Using Symbols Mode To use Symbols text entry mode: Choose Symbols as your text entry mode.
Your i80s phone’s display screen tells you what you need to know as you use your phone. This section includes: Display Screen Status Icons Text Display Area Call Information Icons Menu Icons Display Options Navigating Menus and Lists Main Menu Options Display Screen Any time your phone is powered on, the display screen provides you with information and options.
See “Call Forwarding” on page 72 for more information. Phone In Use — phone is connected on an active call. Private In Use — number being called is a Private ID. Talkgroup In Use — phone is active on a talkgroup call. www.motorola.com/iden...
Page 39
-[\* w#,! The icon of the main menu feature currently in use always appears in the top left of the status icon rows. For a list of the main menu icons, see “Main Menu Options” on page 40. Packet Data Ready — phone is ready to receive data through a data cable.
Incoming Call - phone is receiving an incoming all (not active). Outgoing Call - phone is placing an outgoing (not active). On Hold - phone has a call on hold. End Call - phone has ended the active call. below it. www.motorola.com/iden...
Navigating Menus and Lists The Ready screen display options provide quick access to two main menu features. By default, the Phonebook (PHBK) and Messages (MESG) display options appear on the Ready screen. You can control which display options appear on the Ready screen using the phone’s Personalize feature in the Settings menu (see “Changing Ready Screen Options”...
Receive, store, access and manage Voice Mail, Fax Mail, Text Messages, and Net Alerts. Settings for forwarding calls in various situations. Schedule and organize events, by the day or the month, such as appointments and meetings. Input and store numbers to access later. www.motorola.com/iden...
Page 43
z Call Timers j Recent Calls n Shortcuts U My Info v Styles : Call Alert To choose the highlighted Main Menu selection, press B under SELECT. To exit the Main Menu and return to the Ready screen, press A under EXIT or press Main Menu Options Display the duration of phone calls, private...
The Phonebook allows you to store up to 250 frequently used names and numbers. When you store information in your Phonebook, it is saved on your SIM card. If you move your SIM card to another SIM-based phone, you can access information in your Phonebook from that phone.
If you plan to use the information stored in your Phonebook with an i2000, i2000plus, or any other GSM phone, you must purchase CompanionPro. Go to www.motorola.com\iden or your service provider’s web site for more information. You can use CompanionPro to make the Phonebook information saved to your i80s phone’s SIM card accessible in this type of phone.
Phonebook Icons Icons that appear to the right of entries in your Phonebook convey information about those entries. When you enter a phone number in your Phonebook, you can designate the phone number’s type using any of the following icons: Mobile Private ID Work...
Joe Smith, the entry for Joe Smith’s home phone number would look like this: Joe Smith When the name is highlighted, press T to scroll to the icons representing each of the numbers assigned to that name. www.motorola.com/iden while...
To view any of the phone numbers assigned to a name: From the Phonebook screen, press S to scroll to the name associated with the phone number you want to see. Press T to view the icons representing the phone numbers assigned to that name.
After you have entered a phone number and any other information you wish to include, you can press A under DONE to save the Phonebook entry. To cancel a Phonebook entry at any time, press s to return to the Ready screen. www.motorola.com/iden...
Page 51
To add a Phonebook entry: Access the Entry Details screen: From the Main Screen screen, press m. Then press R to scroll to Phonebook. Press B under SELECT. To add a [New Entry], press B under SELECT. From the Phonebook screen, press m. Then press R to scroll to New and press B under SELECT.
Page 52
With the Speed # field highlighted, press B under CHANGE. Press A under DELETE to delete the current Speed Dial number. Type the new Speed Dial number using the alphanumeric keypad. When you are finished, press B under OK. www.motorola.com/iden...
Page 53
If you want to assign a voice name to the number: With the Voice Name field highlighted, press B under RECORD. As directed by the screen prompts, say and repeat the name you want to assign to the number. Speak clearly into the microphone.
Press C under STORE. This displays the Store To screen with [New Entry] highlighted. to scroll the list of names in your to scroll to the first Type to scroll to the 10-digit www.motorola.com/iden...
To store a new entry, press C under SELECT. The Entry Details screen displays with the number entered in the # field and the Type field highlighted. To store to an existing entry, press Phonebook. Or press the first letter of the entry to jump to the entry. Once the desired entry is highlighted, press C under SELECT.
Example: Let’s say you have a company voice mail account that you frequently check while traveling. To access that account you must do the following: • Dial your work number • Press # while the voice mail greeting is being played • Enter your PIN to access your messages www.motorola.com/iden...
You can program your phone to enter all of the above information for you. All you have to do is separate each entry with a pause. If you were to program your phone to automatically input the above information, the stored data would look like this 17035551234P#P1234.
The i80s phone enables you to make and receive domestic and international phone calls, make emergency calls, and be notified of a missed call. This section includes: Making Phone Calls Emergency Calling Receiving a Phone Call Ending a Phone Call Recent Calls Call Timers Hands-Free SpeakerPhone...
• Making Calls from the Phonebook After you have entered phone numbers into your Phonebook, you can use these numbers to make phone calls. For information on entering numbers into your Phonebook, see “Adding Phonebook Entries” on page 48. www.motorola.com/iden...
Page 61
To make calls from the Phonebook: From the Ready screen, if PHBK is one of your display options, press A under PHBK. From the Ready screen, press m, then press R to scroll to Phonebook. Press B under SELECT. Press R to scroll through the names in your Phonebook. Use the alphanumeric keypad to enter the first letter of the name and press R to scroll through the names beginning with that letter.
You can use the Speed Dial number to quickly place a call. From the Ready screen, enter the Speed Dial number assigned to the phone number you want to call. Press #. Press e to place the call. Press s to end the call. www.motorola.com/iden...
Using Turbo Dial Turbo Dial allows you to call the numbers in your Phonebook associated with Speed Dial numbers 1 through 9 by pressing and holding the corresponding numeric key on the keypad. Press and hold a number key (1 through 9). NOTE: Turbo Dial cannot be accessed while the browser is active, nor while Keypad Lock or SIM Lock is active.
NOTE: The network translates the “+” into the appropriate international access code needed to place the call. Enter the country code, city code, or area code, and phone number. Press e to place the call. Press s to end the call. www.motorola.com/iden Therefore, you must...
Emergency Calling Your phone supports emergency calling. Emergency calls can be made even when the SIM card is blocked or not in the phone. To place a call in an emergency, dial 911e. You will be connected to the nearest emergency dispatch center. If you are on an active call, you must end it before calling 911.
From the Recent Calls screen, press S to scroll to the call you want more information on. Press B under VIEW. Press m to access the Rec. Calls Menu. Then press R to scroll to View and press B under SELECT. www.motorola.com/iden...
The screen that appears displays information such as the name associated with the number of the recent call, the number, the date, time, and duration of the call. Storing a Recent Call Number to the Phonebook To store a number from the Recent Calls list to the Phonebook: From the Recent Calls screen, press S to scroll to the number you want to store.
Phone Reset — keeps a running total of your phone call minutes, until you reset it. • Phone Lifetime — displays the total minutes of all your phone calls. • Prvt/Grp Reset — keeps a running total of all of your Private and Group call minutes, until you reset it. www.motorola.com/iden...
• Prvt/Grp Lifetime — displays the total minutes of all your Private and Groups calls. • Circuit Reset — keeps a running total of all of your circuit data use, until you reset it. • Circuit Lifetime — displays the total minutes of all of your circuit data use.
Call Waiting allows you to receive a second call while you are talking on the phone. You can switch between calls so you never have to miss a call. By default, Call Waiting is always on unless you turn it off for a specific call. www.motorola.com/iden...
If you’re on a call and you receive a second call, you will: • Hear a tone; and • See a message on your display informing you of another incoming call. Accepting Calls Press B under YES. The first call is placed on hold. Switching Between Calls When you accept a second call while you are talking on the phone, your display shows the name or number of each call.
To place a second call while the first call is on hold: Enter the second phone number you want to call. Or select the number from your Phonebook by pressing Press to place the second call. and selecting Phonebook. www.motorola.com/iden...
To toggle between the two calls: Press B under SWITCH. To end the active call: Press s. The call on hold becomes active. Three-Way Calling Using Three-Way Calling, you can combine two ongoing phone calls into one conversation. While on an active call, you can make a second call and combine the two calls.
Line 1 is active; calls from Line 1 are being forwarded. Line 1 is active; calls from Line 2 are being forwarded. Line 1 is active; calls from Line 1 and Line 2 are being forwarded. Line 2 is active; calls from Line 1 are being forwarded. www.motorola.com/iden...
Page 75
NOTE: Call Forwarding must be set to Detailed with the Voice Mail access number to receive Voice Mail messages. This is the default setting. Turning On Call Forwarding Press m then press R to scroll to Call Forward. Press B under SELECT. At the Call Forward screen, the Forward field is highlighted.
Your calls will now be forwarded to the number that you selected. Turning Off Call Forwarding Press m then press R to scroll to Call Forward. Press B under SELECT. The Call Forward screen displays with the Forward field highlighted. www.motorola.com/iden...
Press R to scroll to the To field and press B under CHANGE. Press S to scroll to Off and press B under SELECT. NOTE: You can use the Detailed setting to forward calls to other numbers if desired. However, it is recommended that you leave Detailed set to the Voice Mail access number and use the All Calls setting if you wish to forward your calls to another number.
Page 78
NOTE: You can use the Detailed setting to forward calls to other numbers if desired. However, it is recommended that you leave Detailed set to the Voice Mail access number and use the All Calls setting if you wish to forward your calls to another number. under EXIT. www.motorola.com/iden...
The main topics covered in this section are listed below: Message Alerts Message Center Using Voice Mail Using Text and Numeric Messaging Using Net Alert Using Your Phone as a Modem If your service provider supports mobile originated text messaging, NOTE: see “Mobile Originated Text Messaging”...
Page 80
Your phone screen displays message alerts as follows: Message Type Voice Mail Text Messages Net Alert These message alert screens appear if the new message is the only message you have. Display www.motorola.com/iden...
Dismissing Alerts When you dismiss a message alert, the message alert display disappears from the screen and your phone stops sounding alert tones, but the message is not deleted. You can access the message through the Message Center. See “Message Center”...
Your phone will alert you every 30 seconds until you press B under CALL • or A under EXIT. (If you are on a call, your phone will alert you once during the call.) icon will appear on the Ready screen to www.motorola.com/iden...
Accessing All Messages From the Message Center screen (see “Message Center” on page 79), press S to scroll down to Text Msgs. The number of new messages and the total number of messages are displayed. Press C under SELECT. The Text Msg Inbox screen appears. Press S to scroll to the message you want to read and press C under READ.
Page 84
Press S to scroll to the message you want to read and press B under READ. If the message fills more than one screen, use S to scroll through the rest of the message. icon will appear on the second line of the www.motorola.com/iden...
Press A under SAVE to save the message. Press B under DELETE to delete the message. Accessing All Messages From the Message Center screen (see “Message Center” on page 79), press S to scroll down to Text Msgs. The number of new messages and the total number of messages are displayed.
Wireless Data Services User’s Guide and contact your carrier. You can use your phone and computer in TTY mode. Your computer screen and keyboard replace the standard TTY device. For more information, please see the Wireless Data Services User’s Guide. TTY Users www.motorola.com/iden icon will...
Mobile originated text messaging allows you to communicate with other message cable devices to send and receive brief text messages. Received messages appear on your phone display or in your text message inbox. NOTE: This is a network suppositions dependent feature. Please consult with your service provider for availability.
Page 88
To access any message service: From the Message Center screen, press R to scroll to the message service you want to access. Press C under the display option on the right. This option varies depending on the message service selected. www.motorola.com/iden...
Message Icons The following icons appears depending on the type of message. Icon Text Msg Setup Before you begin sending and receiving messages, you must set up your signature, service center number and expiration information in the Text Msg Setup Form. Accessing Text Msg Setup From the Message Center screen, press S to scroll to Text Inbox, then press q to access the Msg Ctr Menu screen.
Press C under DONE when you are finished. You will be taken back to the Text Msg Setup screen. Press C under BACK to save the settings. Text Message Inbox The Text Message Inbox allows you to access, manage and create messages. www.motorola.com/iden...
NOTE: The Inbox memory space can hold 14 messages with a maximum length of 160 characters for each message. Receiving a Text Message When you receive a new message, your phone displays New Message and gives an alert. NOTE: You must set up the text message inbox before you can receive text messages.
NOTE: The Outbox and Drafts Folder share the same memory space and a maximum of 20 messages can be held. If you have reached the maximum, it will be necessary to delete old messages before sending out new messages. www.motorola.com/iden...
Creating Text Messages From the Message Center screen, press S to scroll to Text Outbox. Press C under SELECT. In the Text Outbox, [Create Msg] is highlighted. Press C under CREATE. With the To field highlighted, press C under CHNGE to access the To screen.
Page 94
Press R to scroll to Delete, then press C under SELECT. A transient screen appears. Press C under YES to delete the message. You will be returned to the Text Msg Outbox screen. Press C under NO. You will be returned to the New Message screen. www.motorola.com/iden...
Sending a Message From the New Msg Menu screen, with the Send field highlighted, press C under SELECT. Press s to send the message. A confirmation screen appears. Press C under YES to send the message. The message will be sent. Managing the Outbox The Text Message Outbox also allows you to manage your messages.
20 messages can be held. If you have reached the maximum, it will be necessary to delete old messages before sending out new messages. Accessing the Drafts Folder From the Message Center screen, press S to scroll to Drafts Folder.Press C under SELECT. www.motorola.com/iden...
In the Drafts Folder screen, [Create Msg] is highlighted. Press C under CREATE. Follow step 3 through step 6 for “Creating Text Messages” on page 91. Press R to scroll to Save as Draft. Press C under SELECT. A confirmation screen will appear stating the message has been stored. Press s to return to the idle screen.
Page 98
Press q to access the Msg Center Menu screen. Press S to scroll to Memory Meter. Press C under SELECT. In the Outbox/Drafts Meter screen, you will see how much memory is available. Press C under BACK to go back to the Message Center screen. www.motorola.com/iden...
The main topics covered in this section are listed below: Private Calls Call Alerts Group Calls Private Calls There are several ways to reach an individual using Private calls: • Enter the person’s Private ID from the keypad. • Select the person’s Private ID from the numbers in your Phonebook. •...
Page 100
For more information on the Recent Calls list, see “Recent Calls” on page 63. Making Private Calls Using Voice-Activated Dialing If you have recorded a voice name for a Private ID in your Phonebook, see “Voice Names” on page 45, you can use this voice name to call the number. www.motorola.com/iden...
USER TIP: If you have difficulty making calls using a voice name, try assigning a longer voice name to the number. For example, if the voice name “Joe” fails to place a call to Joe Smith’s number, try assigning the voice name “Joe Smith”...
Page 102
Ready to Alert is used to confirm your request for the alert and to prompt you to push the PTT button: • If you press the PTT button, the call alert is sent, and the phone displays the Recent Calls screen. www.motorola.com/iden...
For call alerts placed from the keypad, pressing A under CANCEL causes • the phone to return to the Dial screen with the previously entered number displayed. For call alerts placed from the Phonebook, pressing A under CANCEL • causes the phone to return to the Phonebook screen. •...
Page 104
From the Call Alert Queue screen, press m to access Call Alert Menu. Press S to scroll to Sort By. Press B under SELECT. Press S to scroll to First on Top or Last on Top. Press B under SELECT. www.motorola.com/iden...
Page 105
Responding to a Call Alert From the Queue From the Call Alert Queue screen, press S to scroll to the call alert you want to respond to. You can respond by sending a call alert or placing a Private call. To send a call alert, press B under ALERT and then press the PTT button.
Enter the information as you would any other Phonebook entry. (See “Adding Phonebook Entries” on page 48.) When you get to Type, make sure that you select Talkgroup. Enter the Talkgroup name or number. When you have completed the Entry Details, press A under DONE. www.motorola.com/iden...
You make Group calls just as you would Private call, with a few exceptions: when making Group calls from the keypad, press # before entering the • Talkgroup number. • when making Group calls from the Phonebook, scroll to the Talkgroup you want to call.
Page 108
Press R to scroll to Settings. Press B under SELECT. Press R to scroll to Tkgrp Settings. Press B under SELECT. With the Silent field highlighted, press B under CHANGE. Press S to scroll to On or Off. Press B under SELECT. www.motorola.com/iden...
The Datebook is a calendar in your i80s phone that enables you to schedule and organize events, such as appointments and meetings. Schedules can be created and viewed for specific days, and reminder alarms can be set so that you never miss important events.
When the events of a day are displayed, you can select an event to view and display details of that event. Description Event without a start/ end time More options are available Recurring Appointment Datebook Alarm Used to move through fields when setting a time and date. www.motorola.com/iden...
Viewing a Week When you access your Datebook, the current week is displayed. You can scroll to other weeks by pressing S. The dates of the displayed week appear at the top of the text area of your phone’s screen. Below the dates are letters indicating the days of the week.
An option to repeat the event in your Datebook. • An alarm to notify you of the event before it begins. • The style you want your phone to use when the event occurs. See “Styles” on page 145 for more information. www.motorola.com/iden...
Adding New Events Using the following instructions, you will enter the information in the order the items appear on the Event Form screen. However, you can enter this information in any order by pressing S to scroll through the items on the Event Form screen.
Page 114
From the Duration screen, press R to scroll to the desired duration. If you select None, the event will have a duration of zero minutes. Press B under SELECT. The Event Form screen returns with the StartDate field highlighted. www.motorola.com/iden...
Page 115
The default date assigned to an event is the day that was highlighted when you accessed the Event Form screen to add the event. To assign a different date: With the StartDate field highlighted, press B under CHANGE. From the StartDate screen, enter the date of the event: Type in the date, or press S to scroll through the months, days, and years.
Press the Datebook Menu. Press under SELECT. Follow the applicable instructions in “Adding New Events” on page 111, to edit the various fields. to scroll to Edit and then press www.motorola.com/iden to display...
Deleting Events View the day containing the event and press S to scroll to the event you want to delete. View the details of the event you want to delete. Press m. The Datebook Menu displays. Press R to scroll to Delete and press B under SELECT. If the event is a recurring event, the Delete Event screen appears: •...
While viewing a week in the Datebook, press m to access the Datebook Menu. Press S to scroll to Setup and then press B under SELECT Press R to scroll to any of the set-up features. Press B under CHANGE. Use the screens that appear to make your changes. www.motorola.com/iden...
The Memo application provides you with a place to store a numeric note (for example a phone number) in your i80s phone. This section includes: Adding a New Memo Viewing a Memo Editing a Memo Deleting a Memo Adding a New Memo From the Ready screen, press m.
A under DELETE. Press B under STORE. Deleting a Memo From the Ready screen, press m. Press R to scroll to Memo. Press B under SELECT. Press and hold A under DELETE. Press B under STORE. www.motorola.com/iden...
The Voice Record feature enables you to record and play back personal messages or the incoming portion of phone calls on your i80s phone. This section includes: About Voice Record Accessing Voice Record Recording a Voice Record Playing a Voice Record Adding to a Voice Record Labeling a Voice Record Deleting a Voice Record...
From the VoiceRecord screen, press R to scroll to the Voice Record you want to play. Press B under PLAY. To stop the Voice Record while it is playing, press A under BACK. NOTE: Voice Records are heard through the speaker. www.motorola.com/iden...
Adding to a Voice Record After you create a Voice Record, you can record more at the end of the existing Voice Record: From the VoiceRecord screen, press R to scroll to the Voice Record you want to add to. Press m to view the VoiceRecd Menu.
From the VoiceRecord screen, press R to scroll to the Voice Record you want to lock or unlock. Press m to view the VoiceRecd Menu. Press R to scroll to Lock or Unlock. Press B under SELECT. A confirmation screen displays. www.motorola.com/iden...
Voice Record Memory Typically, you can store 20 Voice Records with a total time of about three minutes. To check the amount of memory available for a Voice Record: From the VoiceRecord screen, press m to view the VoiceRecd Menu. Press R to scroll to Memory.
The Java feature of your i80s phone runs applications written in the Java 2 Micro Edition programming language. The phone comes with Java applications downloaded and ready for installation. You can choose to order or purchase Java applications and download them into your phone via the Internet.
From the Java Apps screen, press R to scroll to the application you want to run. Press B under RUN or SELECT. NOTE: If you receive an incoming phone call, the Java application will be suspended. To suspend a running application: Press www.motorola.com/iden...
Downloading Java Applications You can customize your phone by ordering additional Java applications via the iDEN Update Website. Please go to www.motorola.com/idenupdate for a selection of applications available and downloading instructions. You can download these applications by connecting your phone to a PC using a data cable and the iDEN Update Software Application.
Press m. Press R to scroll to DEINSTALL. Press B under SELECT. A confirmation screen displays. Press A under YES. A warning screen displays. Press A under OK. When your phone has finished deinstalling the application, press A under DONE. www.motorola.com/iden...
Customizing the i80s Phone You can customize your i80s phone to fit the way you want to use it. The phone’s Settings menu enables you to control many of the phone’s features and functions, including display properties, message handling, and security features.
Page 132
Ring/Vibe enables you to control how your phone rings and vibrates when you receive calls and messages. You can set ring volume, choose ring styles, and use ® the VibraCall Alert feature which enables you to set your phone to alert you to calls and messages by vibrating. www.motorola.com/iden...
Page 133
Main Options Ring/Vibe provides these main options: • Ringer Vol — sets ring volume. • Keypad Vol — sets volume of sounds associated with keypad actions. • Mail Vol — sets volume of Text Message, Voice Mail, and Net Alert notifications.
Page 134
VibeAll option is On. Vibrate On - phone is set to vibrate when you receive phone calls. Vibrate Then Ring - phone is set to vibrate and then ring when you receive phone calls. Silent - phone is set not to ring. www.motorola.com/iden...
USER TIP: To hear the ring style you have selected, press the volume button on the side of your phone. Notification Types When you set a notification type, you have these options: • Ring — the phone rings to notify you. •...
Master Reset — allows your service provider to reset your service in the event of a security or provisioning problem. Using Phone Lock The Phone Lock feature enables you to prevent your phone from being used unless an Unlock code is typed into the keypad. www.motorola.com/iden...
The Unlock code is required to enable the phone lock feature, to unlock the phone, and to set a new Unlock code. Contact your service provider for your default Unlock code. Phone lock provides two options for locking the phone: •...
Page 138
You can assign any Main Menu option you want to the option keys. From the Personalize screen, press R to scroll to Keys. Press B under SELECT. The Keys screen shows the option assigned to each option key (Left and Right). www.motorola.com/iden...
To change the option assigned to the left option key, press B under CHANGE while Left is highlighted. Press R to scroll to the option you want to assign to the left option key. Press B under SELECT. To change the option assigned to the right option key, press R to highlight Right and press B under CHANGE.
24-hour-clock format (0:00 through 23:59). It displays dates in month/ day format or day/month format. NOTE: If you turn the time and date display off, no times are associated with calls on your Recent Calls list, and the alarm feature of your Datebook is disabled. www.motorola.com/iden...
Page 141
To set the time and date format, or turn time and date display on or off: From the Initial Setup screen with Time/Date Format highlighted, press B under SELECT to access the Time/Date Format screen. To change the time format: With Time Format highlighted, press B under CHANGE to access the Time Format screen.
The status light is located on the top of the phone. It illuminates when the phone is on. See “Status of Your i 80s Phone” on page 27. You can turn the status light feature on or off from the Initial Setup screen. www.motorola.com/iden...
Setting Scrolling You can set your phone to scroll through menus and lists in either of two ways: • Up/Down — when you reach the bottom or top of list or menu scrolling stops until you scroll in the other direction. •...
Timeout” on page 143.) NOTE: TTY device manufacturer’s proprietary feature such as Turbo-Code, High- Speed, and Interruption are not supported by your phone. These features must be turned off or disabled to use your TTY device with your phone. www.motorola.com/iden...
Page 145
Setting TTY Baud Rate NOTE: This feature may not be offered by your service provider. By default, your phone’s TTY baud rate is set to 45.45, the baud rate required for TTY calls within the US. To make calls outside the US, set your TTY baud rate to 50.0.
Tkgrp Settings enables you to set certain Talkgroup options. See “Group Calls” on page 104 for more information. Service Status The Service Status screen shows the status of your phone’s services. This screen is for information only; no options can be set. www.motorola.com/iden...
Styles This feature enables you to save a group of settings for call and message notification, screen display, and call answering features. You save your selections as a “style” and access them at any time. You can store up to ten styles.
Page 148
To change any style option: Press R to highlight the option. Press B under CHANGE or SELECT. Use the screens that appear to make your changes. When all the style options have the settings you want, press A under DONE. www.motorola.com/iden...
Page 149
Editing a Style To change the settings of a style: From the Styles Menu screen, press R to scroll to the name of the style you want to edit. Press m to access the Styles Action menu. Press R to scroll to Edit and press B under SELECT. To change any style option: Press R to highlight the option.
Alerts — sets filtering options for call alerts. • Notifications — sets filtering options for messages. Setting Phone Call Filtering Call Filter enables you to set your phone to respond to all calls, no calls, or only calls from some or all numbers in your Phonebook: www.motorola.com/iden...
Page 151
• Off sets your phone notify you of all calls. • All sets your phone to ignore all calls. • All Phonebook sets your phone to notify you only of calls from the numbers stored in your Phonebook. • Some Phonebook sets your phone to notify you only of calls from numbers you select from your Phonebook.
Press B under SELECT. Ring/Vibe is now highlighted in the Settings screen. Press and hold m for about 2 seconds. A confirmation screen displays showing the name of the menu item to which you want to create a shortcut. To proceed with assigning the shortcut, press under YES. www.motorola.com/iden...
A screen displays showing the assigned shortcut number. If you want to change the shortcut number: Press under CHANGE. Press under DELETE to erase the assigned number. Enter the desired number on your keypad and press If you want to record a voice name for that shortcut: Press R to highlight the Voice field.
Reorder — assign existing shortcuts to a different key number. • Delete — delete any highlighted Shortcut. • Delete All — delete all stored Shortcuts. To access the Shortcut menu: From the Ready screen, press Press to scroll to Shortcuts. www.motorola.com/iden...
Page 155
Press under SELECT. Press to scroll to the desired shortcut. Press Shortcuts...
To order additional accessories, log on to our Web site at: www.motorola.com/ store/iden or contact your Motorola Authorized Retailer. This section includes the following topics: Batteries Travel Chargers Carrying Solutions Data Accessories Accessories Page 156 Page 157 Page 156 Page 161...
Charging Lithium Ion Batteries The following table provides the approximate time to fully charge a battery using a Motorola iDEN Approved Lithium Ion battery charger. Check the kit number on your battery and charger to determine the appropriate charging time.
• The Motorola iDEN Approved Lithium Ion chargers will provide optimum performance. Other chargers may not fully charge your iDEN Lithium Ion battery or may yield reduced number of lifetime charge cycles. • If the battery appears inoperative, the internal protection circuitry may have been activated.
Using the Travel Charger While holding the phone with its keypad facing up, insert the accessory connector (with the Motorola logo facing you) into the bottom of the phone until you hear a click. If you have either the Mid-Rate Multi-Voltage Travel Charger or the Rapid Multi-Voltage Travel Charger, flip open the prongs, and plug the Travel Charger transformer into an AC wall outlet.
Page 161
Using the Swivel Carry Clip Ensure that the phone is powered off before attempting to detach the battery. Attach the Phone Clip to the phone by removing the battery. Holding the phone face down, remove the battery by sliding the battery release button backwards, while lifting in an upward and outward motion.
Page 162
Holding the phone face down, remove the battery by sliding the battery release button backwards, while lifting in an upward and outward motion. Battery Release Button Slide the Phone clip in a downward motion. This will unclip the assembly from the phone.. www.motorola.com/iden...
Using the Data Cable While holding the phone with its keypad facing up, insert the accessory connector (with the Motorola logo facing you) into the bottom of the phone until you hear a click. Insert the data plug directly into your PC or one of the many other data compatible iDEN accessories.
Using the Dual Port Adapter Cable Insert the flat end of the Dual Port Adapter Cable cord into the bottom connector of the i80s phone. Make sure the Motorola logo is facing upward. Insert the round end of the RS232 Data Cable into the receptacle on the Dual Port Adapter Cable labeled “Data”.
Page 165
Using the PDA Converter Plug While holding the phone with its keypad facing up, insert the accessory connector (with the Motorola logo facing you) into the bottom of the phone until you hear a click. Connect the opposite end of the data cable to the PDA converter.
Page 166
No other action is required by the user in order to select between USB or RS232 serial communications. The USB cable is authorized for use with the following operating systems only when used in conjunction with Motorola/iDEN created or approved PC applications: •...
Page 167
PC Applications Supported • RSS (Radio Srvice Software) • Tethered Circuit Data • iDEN CompanionPro • SDK (Windows only, Palm SDK not supported) • iDEN Update ~ after first upgrade • iDEN Packet Data Applet Data Accessories...
Other Important Information This section includes the following topics: Understanding Status Messages Safety and General Information Additional Health and Safety Limited Warranty Information Patent and Trademark Information Understanding Status Messages The following table lists and describes the status messages. Status Messages Number Not in Service User Not Available User Not Authorized...
Page 170
SIM Card. Please check your SIM Card to make sure it has been inserted properly. You have entered an incorrect PIN number. Your phone will not accept a SIM card that is not from your carrier. www.motorola.com/iden...
PORTABLE RADIO PRODUCT OPERATION AND EME EXPOSURE Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations;...
To maintain compliance with FCC RF exposure guidelines, if you wear a radio product on your body when transmitting, always place the radio product in a Motorola approved clip, holder, holster, case or body harness for this product. Use of non-Motorola-approved accessories may exceed FCC RF exposure guidelines.
PORTABLE RADIO PRODUCT OPERATION AND EME EXPOSURE Approved Accessories For a list of approved Motorola accessories call 1-800-453-0920, visit our website at www.mot.com/iden, or look in the accessory section of this manual. THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Other Medical Devices If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information. www.motorola.com/iden...
Use While Driving Check the laws and regulations on the use of radio products in the area where you drive. Always obey them. When using the radio product while driving, please: • Give full attention to driving and to the road •...
Blasting Caps and Areas To avoid possible interference with blasting operations, turn off your radio product when you are near electrical blasting caps, in a blasting area, or in areas posted: “Turn off two-way radio”. Obey all signs and instructions. www.motorola.com/iden...
Operational Cautions C a u t i o n Antennas Do not use any portable radio product that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. Batteries All batteries can cause property damage and/or bodily injury, such as burns if a conductive material such as jewelry, keys, or beaded chains touches exposed terminals.
Page 178
Clean the external surfaces of the radio product with a damp cloth, using a mild solution of dishwashing detergent and water. Some household cleaners may contain chemicals that could seriously damage the radio product. Avoid the use of any petroleum-based solvent cleaners. Also, avoid applying liquids directly on the radio product. www.motorola.com/iden...
Accessory Safety Information IMPORTANT: SAVE THESE ACCESSORY SAFETY INSTRUCTIONS • Before using any battery or battery charger, read all the instructions for and cautionary markings on (1) the battery, (2) the battery charger, which may include a separate wall-mounted power supply or transformer, and (3) the radio product using the battery.
Page 180
AC receptacle. • To reduce risk of electric shock, unplug any battery charger from the outlet before attempting any maintenance or cleaning. For optimum charging performance, turn off the radio product while charging it in any battery charger. www.motorola.com/iden...
Page 181
Accessory Safety Information The U.S. Food and Drug Administration's Center for Devices and Radiological Health Consumer Update on Mobile Phones FDA has been receiving inquiries about the safety of mobile phones, including cellular phones and PCS phones. The following summarizes what is known-- and what remains unknown--about whether these products can pose a hazard to health, and what can be done to minimize any potential risk.
Page 182
In fact, the risk actually decreased with cumulative hours of mobile phone use. Most cancer causing agents increase risk with increased exposure. An ongoing study of brain cancers by the National Cancer Institute is expected to bear on the accuracy and www.motorola.com/iden...
Page 183
RF except for the micronucleus assay, which detects structural effects on the genetic material. The cells in this assay showed changes after exposure to simulated cell phone radiation, but only after 24 hours of exposure. It is possible that exposing the test cells to radiation for this long resulted in heating.
Page 184
Although the existing scientific data do not justify FDA regulatory actions at this time, FDA has urged the mobile phone industry to take a number of steps to assure public safety. The agency has recommended that the industry: www.motorola.com/iden...
Page 185
• support needed research into possible biological effects of RF of the type emitted by mobile phones; • design mobile phones in a way that minimizes any RF exposure to the user that is not necessary for device function; and •...
Page 186
Int. J. Radiat. Biol., April 8, 1999. 4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cel- lular telephones and the risk for brain tumors: a case-control study. Int. J. Oncol., 15: 113-116, 1999. http://www.fcc.gov/oet/rfsafety http://www.fda.gov/cdrh/consumer/ www.motorola.com/iden http://www.who.int/emf http:// http://...
80% of rated capacity, or b. the battery develops leakage. MOTOROLA, at its option, will at no charge either repair the Product (with new or reconditioned parts), replace it (with a new or reconditioned Product), or refund the purchase price of the Product during the warranty period provided it is returned in accordance with the terms of this warranty.
Page 188
Product. MOTOROLA cannot be responsible in any way for any ancillary equipment not furnished by MOTOROLA which is attached to or used in connection with the Product, or for operation of the Product with any ancillary equipment, and all such equipment if expressly excluded from this warranty.
Page 189
Product item, transportation and insurance prepaid, to an authorized warranty service location. Warranty service will be provided by MOTOROLA through one of its authorized warranty service locations. If you first contact the company which sold you the Product (e.g., dealer or communication service...
Page 190
VI. PATENT AND SOFTWARE PROVISIONS: MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a United States patent, and Motorola will pay those costs and damages...
Page 191
80% of rated capacity, or b. the battery develops leakage. MOTOROLA, at its option, will at no charge either repair the Product (with new or reconditioned parts), replace it (with a new or reconditioned Product), or refund the purchase price of the Product during the warranty period provided it is returned in accordance with the terms of this warranty.
Page 192
Product. MOTOROLA cannot be responsible in any way for any ancillary equipment not furnished by MOTOROLA which is attached to or used in connection with the Product, or for operation of the Product with any ancillary equipment, and all such equipment if expressly excluded from this warranty.
Page 193
V. PATENT AND SOFTWARE PROVISIONS: MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a patent, and Motorola will pay those costs and damages finally...
Page 194
MOTOROLA software, such as the exclusive rights to reproduce in copies and distribute copies of such MOTOROLA software. MOTOROLA software may be used in only the Product in which the software was originally embodied and such software in such Product may not be replaced, copied, distributed, modified in any way, or used to produce any derivative thereof.
Page 197
Accessories 155 batteries 156 Data cable 84 Dual Port Adapter Cable 162 Swivel Carry Clip 158 Travel Charger 157 Accessory safety information 177 Adapter cable 162 Additional Health and Safety 179 Alpha mode, text entry 30 Auto Redial 139 Backlight timer 140 Battery 156 attaching 13 charge strength 14...
Page 198
Menu icon 38 Menus 38 main menu 41 Settings 129 Styles Actions menu 148 Styles menu 145 Message Center 79 Messages 77 alerts 77 also see mobile originated text Net Alert 83 text and numeric 81 www.motorola.com/iden messaging 95 messaging...
Page 199
Quick Notes 89 reading messages 89 receiving messages 88 sending messages 93 set up 87 SIM card 95 Modem, phone as 84 Motorola 7 Mute 68 My Information 27 Net Alert 83 Notifications 134 setting 132 Numeric mode, text entry 33...
Page 200
Speed Dial numbers 44 Status light 27 Status messages 167 Status of connection 27 storing numbers Recent Calls list 52 Styles activating 147 creating 146 turning off 148 Swivel Carry Clip 158 Symbols mode, text entry 33 T9 Text Input 28 www.motorola.com/iden...
Page 201
also see Text entry Talkgroups 104 joining 105 Text and numeric messages 81 Text display area 38 Text entry Alpha mode 30 Numeric mode 33 Symbols mode 33 Word mode 30 Three-Way Calling 71 Time and date format 138 Trademark information 193 Travel Charger 157 TTY devices 84 making calls 61...
