McCall L4-4001 Specifications

L4-4001
McCall Refrigeration specification sheets are available online
@ www.mccallrefrigeration.com
Cabinet - Cabinets are all metal, inside and out. The top,
back, and bottom are made of galvanized steel. In
addition, all seams are closed and sealed, with metal
edges turned away from the exposed surface. The result
is an integrated structural frame. Internal corners are
coved to conform to NSF standards. Automatic interior
lighting is controlled by a light switch concealed in the
door hinge, except glass door models employ a
manual switch.
Doors - Constructed of metal, refrigerator doors are self-
closing and fully insulated. Their cam-lift hinges are
chrome-plated and self-lubricating. Hinges also have a
safety stop that holds the door open, preventing
overswing. Chrome-plated pull handles have built-in
cylinder locks. The full-perimeter, magnetic vinyl gaskets
are removable without the use of tools. The bottoms of
Phone (731) 847-5570 / Fax (731) 847-9012 / 1-888-REACH-IN (1-888-732-2446) / www.mccallrefrigeration.com
R
(65" C
Cabinet Interior / Exterior Specifications
1000 Series - Stainless interior and exterior.
2000 Series - Stainless exterior and floors, with aluminum interior.
4000 Series - Anodized aluminum exterior. Stainless steel front and floor,

Standard Features

• Top mounted compressor
• Expansion valve
• Cord and plug (see electrical section)
• R-134a refrigerant
• Exterior digital thermometer (1000 series) dial thermometer (2000-4000 series)
• Self-closing cam-lift hinges
• Chrome-plated door handles with security locks
• Magnetic door gaskets
• Removable stainless steel ramp, each door opening
• Windrunner gradient air displacement process
• Adjustable doorstops
CLASSIFIED TO
NSF (STD-7-1999)

SPECIFICATIONS

all door openings are supplied with full-width sweeper
gaskets. Doors easily lift off, and door perimeters have a
built-in, low wattage, and anti-condensate heater. Door
openings are protected by an impact-resistant,
nonconductive PVC breaker strip with no exposed
screws or fasteners. (Except bottom of door opening.)
Insulation - Cabinet body, doors, and evaporator coil
housings are filled with pressure-injected polyurethane
foam.
Self-Contained Refrigeration - The complete
refrigeration assembly is mounted on top of the cabinet
behind a removable hatch cover, except three door has
interior mounted coil. Refrigeration components include
a hermetically sealed compressor, the thermostatic
expansion valve, thermostatic temperature control, high-
McCall Refrigeration / 81 West Holly Street / Parsons, TN 38363
January 2007 / Printed in U.S.A.
ITEM #
MODEL #
PROJECT NAME
-I R
OLL N EFRIGERATORS
C
ART APACITY
with mill finish aluminum interior.
Approval :
humidity evaporator coil and hot gas condensate
evaporator. The refrigerator system is balanced to
maintain 38°F average internal air temperature.
Windrunner gradient air displacement process in the
refrigerator model provides even air flow and
temperature control throughout the cabinet. All
components are factory installed and tested, and
supplied with an attached cord and plug, master switch,
and exterior digital thermometer (1000 series) dial
thermometer (2000-4000 series).
Remote Cabinets - Standard remote units are provided
with capped refrigeration lines, expansion valve,
solenoid valve, electric condensate evaporator, and
temperature control. Condensing unit is not included.
All other features are the same as self-contained units.
AIA #
SIS #
) 1 S
ECTION
