Coby 907-DP74-0S01-00R Instruction Manual

Coby electronics 7" digital photo frame instruction manual

Advertisement

Quick Links

COBY Electronics Corp.
56-65 Rust Street
Maspeth, NY 11378
www.cobyusa.com
7″ Widescreen Digital Photo Frame
www.ecoby.com
DP740
INSTRUCTION MANUAL
Please read this manual carefully before operation
Please make sure that the items shown below are included in the package. Should
7" widescreen TFT LCD color display
an item be missing, please contact the local retailer from which you purchased this
product.
Displays JPEG, JPG photo files
Photo slideshow mode
Calendar and clock with alarm timer
SD, MMC, MS, XD card slot
Full-size USB port for use with flash memory drives
Wall-mountable design with detachable stand
1.
DP Frame x 1
2.
AC Adapter x 1
Manual x 1
3.
Kickstand and Screw x 1
4.
TROUBLESHOOTING
If you have a problem with this device, please read the troubleshooting guide
below and check our website at www.cobyusa.com for Frequently Asked
Questions (FAQs) and firmware updates. If these resources do not resolve the
problem, please contact Technical Support.
ADDRESS
COBY Electronics Technical Support
150 Knowlton Way
Savannah, GA 31407
EMAIL
techsupport@cobyusa.com
WEB
www.cobyusa.com
PHONE
800-727-3592: Weekdays 8:30AM–9:00PM EST
Saturdays 9:00AM–5:30PM EST
718-416-3197: Weekdays 8:00AM–5:30PM EST
The player does not turn on.
Make sure the unit has been powered on manually (i.e., the Power Switch has
been physically set to the ON position).
Ensure that the power cord has been properly connected to the power outlet.
I cannot select a memory card.
Ensure that a memory card has been installed.
Ensure that the memory card is properly installed.
Ensure that the memory card is not defective.
The alarm does not work.
Make sure the Alarm Setting is set properly in Calendar Setup in Setup Menu.
20
WARNING:
To prevent fire or shock hazard, do not expose this device to rain or moisture. Dangerous high
voltage is present inside the enclosure. Do not open the cabinet.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot of outlet and fully
insert.
Protect your hearing: Hearing experts advise against the constant use of personal stereos
played at high volume. Constant exposure to high volumes can lead to hearing loss. If you should
experience ringing in the ears or hearing loss, discontinue use and seek medical advice.
FCC Statement:
this device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for Class B digital
devices, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a par-
ticular installation. If this equipment does cause harmful interference to radio or televi-
DP740
sion reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of
the FCC rules.
Do not make any changes or modifications to the equipment unless otherwise specified
in the manual. If such changes or modifications should be made, you could be required
to stop operation of the equipment.
GETTING STARTED
UNIT VIEW
Installing a Memory Card
Your picture frame supports the following types of memory cards:
Memory Stick (MS)
XD-Picture (XD)
Secure Digital (SD)
Multi Media Card (MMC)
USB Flash Storage Drive
Simply insert the memory card of your choice into its corresponding card slot lo-
cated on the left panel of the photo frame. Take care to orient the card in the proper
direction.
Getting photos and files onto your picture frame for viewing couldn’t be easier!
Powering your Digital Picture Frame
Your Picture Frame should be connected to
an AC 100-240V wall outlet.
DC OUT: 5V 1A
4. Menu
Using the supplied power adapter,
Function Buttons
Press for exit.
plug one end of the adapter into
On the Main Menu Screen, press this button to
1. -/+ Button
your photo frame’s Power In jack
move the cursor to the memory device list.
Press to move the cursor left/right in
5. Down/Up button
and plug the other end into an AC
menu setting and also can be used to
Press to move the cursor down/up during
turn pages in the full screen display.
100-240V wall outlet.
menu selection.
2. Enter/Slidshow
On the Main Menu Screen, select the desired
Press for enter during menu selection.
In photo (full-screen) display mode,
memory device, and then press Enter button to
press and hold this button to start / stop
confirm.
photo slideshow.
6. Card slot
3. Change View
Connect the SD/MMC/MS/XD card.
Do not connect the power plug to a power outlet other than that
Press this button to shift between the
7. Power switch
which is indicated here or on the label as this may result in the risk
view modes Crop to Fill, Full Screen
To turn the photo frame on/off.
of fire or electric shock.
and Fit to Screen in photo (full-screen)
8. Full-size USB port
display mode.
Do not handle the power plug with wet hands. Doing so may cause
To connect with USB flash drives..
In Calendar Mode: press this button
to change the calendar mode.
9. Mini-size USB port
electric shock.
To connect with computer.
Use only AC adapters of the type specified here. Failure to do so
10. Power Jack
may cause a fire or damage the player.
Connect with the power source.
11. TFT Display.
12
13
GETTING STARTED
GETTING STARTED
Turning Your Photo Frame On/Off
Inserted: A card icon that is in-color indicates that a memory card has been
inserted(installed) in the corresponding slot.
To turn your photo frame on, set the Power Switch to the “On” position.
No card: A card icon that is grayed-out indicates that a memory card has not been
To turn your photo frame off, set the Power Switch to the “Off” position.
installed in the corresponding slot and is not available for use.
Selected: A higlighted frame indicates that the card slot is selected. Only card slots with
Connecting to a Computer
an installed memory card may be selected.
a
Connect the photo frame to your computer with
USB cable. Upon connection:
• Your computer will automatically recognize
the memory cards
installed in
The demo slideshow will automatically start in approximately 8 seconds if you don’t press
your photo frame.
Icons
representing your installed memory cards will appear
any button.
as “Removable Disk ” when you open “My Computer”.
USB Port
(computer)
Select the Photo icon on the main menu screen and press Enter button to enter the Photo mode.
If your photo frame is set to slideshow in photo setup, it will display the photo in slideshow
USB Port (mini)
mode.You can press Menu button to enter thumbnail mode, and press Menu button again to exit.
If your photo frame is set to thumbnail in photo setup, it will display in thumbnail mode. In this
mode, to display a photo(full screen), use the direction button to select a thumbnail and press
enter button to confirm.
Make sure that there’s no USB flash drive connecting to the DP frame
before connecting the DP frame to a computer.
Changing View
Main Menu Screen
Press the CHANGE VIEW button to change between the screen ratio modes Full Screen, Fit to Screen and Crop
to Fill.
Upon turning on the power, your photo frame will display the “Main menu” screen shown below:
To view the previous/next photo, press Down/Up button.
Press the MENU button and then press the UP/DOWN button to select an available card.
Zoom
To zoom in the pictures, press “+” button.
Each successive press of “+” button will change the level of magnification as shown below:
ZOOM OFF
125%
150%
175%
200%
225%
250%
Note: You can only press the “-” button to zoom out the amplified pictures, but can’t zoom out the
original pictures.
To the amplified picture(only), press Up/Down button to move it up/down;
press and hold “-/+” button to move it left/right.
The Photo List will display supported Photo files, only.
Your photo frame can display baseline JPEG / JPG files.
14
15
CALENDAR
SETUP
Photo Setup
Calendar
To view time and data, select Calendar on the main menu screen and press Enter button to
Sets the photo display mode for
confirm. Then the calendar will shown as below.
Slideshow
Display Mode
entering the Photo Mode from the
Main Menu.
Display Ratio
Sets the photo display ratio.
Fit to Screen
Sets the time interval of slideshow
5Sec.
Slideshow Duration
photos.
Sets the photo slideshow effect.
Transition Effect
Random
Sets the photo slideshow repeat
Slideshow Repeat
On
function on/off
Calendar Setup
Calendar+
Display Mode
Sets the Calendar display mode
Time+Slideshow
Set Date
To set Date: Press the UP / DOWN button to select
the number of the date and year, and press the
LEFT/RIGHT button to adjust.
1. You can adjust the time and data in Calendar setup menu, please refer to Calendar setup in
Clock Mode
Sets the Clock Mode
24-Hour
the Setup menu.
2. There are three display mods available, you can press Change View button to select the
To set the Clock Time: Press the UP / DOWN
Set Time
desired mode.
button to select the the time, and press the
LEFT/RIGHT button to select the desired time.
3. Press “-/+” button to view the previous/next month.
4. If there are available pictures, it will be displayed on the right of the window in slideshow mode,
On
Sets the Alarm
Alarm Set
press Up/Down button to turn the pictures.
To set an Alarm Time: Press the UP / DOWN
Alarm Time
5. Press Menu button to exit.
button to select the Off/On and time and press the
LEFT/RIGHT button to select the desired time and
On.
To delay the alarm timer, when the alarm timer
sounds, press the ENTER button to turn it off
completely, press any other buttons to delay it. The
alarm timer will sound again 9 minutes, 18 mintues
and 27 minutes later. The alarm will then turn off
automatically.
Mon to Fri.
Alarm Frequency
Sets the Alarm Frequency
Snooze
Sets Snooze Mode
Repeat
16
17
SPECIFICATION
PRECAUTIONS..............................................................................................................................................................2
7″ Full-Color TFT LCD
Display Type
IMPORTANT SAFETY INSTRUCTION......................................................................................................................... 4
Display Resolution
800×480
TABLE OF CONTENTS..................................................................................................................................................8
..
PACKAGE CONTENTS...................................................................................................................... . ...........................9
Memory
MS Card
FEATURES...................................................................................................................................................................10
SD/MMC/XD Card
Full-size USB
UNIT VIEW....................................................................................................................................................................11
Function Buttons.....................................................................................................................................................11
GETTING STARTED.....................................................................................................................................................12
JPG
Photo Format
JPEG
Installing a Memory Card.........................................................................................................................................12
Powering your Digital Picture Frame........................................................................................................................12
USB Host
USB 2.0 High-Speed
Turning Your Photo Frame ON/OFF..................................................................................................................... ..13
Connecting to a computer........................................................................................................................................13
Photo...........................................................................................................................................................................14
Change View............................................................................................................................................................14
Power Supply
DC 5V, 1A,
Zoom........................................................................................................................................................................14
100-240V AC Adapter
CALENDAR...................................................................................................................................................................15
SETUP ..........................................................................................................................................................................16
P/N: 907-DP74-0S01-00R
Photo Setup.................................................................................................................................................................................................................................16
Specifications and manual are subject to change without prior notice.
Calendar Setup...........................................................................................................................................................................................................................16
System Setup...............................................................................................................................................................................................................................17
KICKSTAND..................................................................................................................................................................18
Using the Kickstand................................................................................................................................................18
TROUBLE SHOOTING...................................................................................................................................................19
SPECIFICATION..........................................................................................................................................................20
KICKSTAND
SETUP
System Setup
Using the Kickstand
English
language
Sets the menu language of the photo frame.
Brightness
Sets the brightness of the screen.
7
1
Sets the Contrast of the screen.
Conrast
7
Sets the Saturation of the screen.
Saturation
7
Sets the Hue of the screen.
Hue
50
Sets the power on
Power On
Off
Power Off
Sets the power off
Off
Sets the auto boot/shut time for the photo frame.
Auto boot time
1. Make sure the Power switch on the DP frame is set to ON.
2. Press the UP/DOWN button to select On / Off and time.
Auto Shut time
3. Press the LEFT/RIGHT button to select the desired time..
Auto-power
Attach the kickstand to the DP frame.
Mon. to Fri.
Sets the Auto-Power On / Off Frequency.
frequency
Reset
Resets all settings to their factory default state.
2
Turn the screw to the right to tighten the kickstand.
18 0
19

Advertisement

loading

This manual is also suitable for:

Dp740Dp740 ib
