Coby CX CD377 Instruction Manual

Coby micro cd player stereo system with am/fm tuner instruction manual cx-cd377.
CX-CD377
Micro CD Player Stereo System with
AM/FM Tuner
INSTRUCTION MANUAL
Please read this manual carefully before operation.

   Related Manuals for Coby COBY CX CD377

   Summary of Contents for Coby COBY CX CD377

  • Page 1

    CX-CD377 Micro CD Player Stereo System with AM/FM Tuner INSTRUCTION MANUAL Please read this manual carefully before operation.

  • Page 2: Precautions

    The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magni- tude to constitute a risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and servicing instruc- tions in the literature accompanying the appliance.

  • Page 3

    ON PROTECTION AGAINST LASER ENERGY EXPOSURE As the laser beam used in this compact disc player is harmful to the eyes, do not attempt  to disassemble the casing. Stop operation immediately if any liquid or solid object should fall into the cabinet. ...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be read before the product is operated. Retain Instructions: The safety and operating instructions should be retained for future reference. Heed Warnings: All warnings on the product and in the operating instructions should be adhered to.

  • Page 5

    IMPORTANT SAFETY INSTRUCTIONS Grounding or Polarization: This product may be equipped with a polarized alternating-current line plug that has one blade wider than the other. This plug will only fit into the power outlet in one direction. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the direction of the plug.

  • Page 6

    IMPORTANT SAFETY INSTRUCTIONS Lightning: For added protection for this product, unplug it from the wall outlet and disconnect the antenna or cable system during a light- ning storm or when it is left unattended and unused for long periods of time. This will prevent damage to the product due to lightning or power-line surges.

  • Page 7

    IMPORTANT SAFETY INSTRUCTIONS Wall or Ceiling Mounting: The product should be mounted to a wall or ceiling only as recommended by the manufacturer. Heat: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including ampli- fiers) that produce heat.

  • Page 8: Compliance With Fcc Regulations

    COMPLIANCE WITH FCC REGULATIONS This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 9: Cd Care & Maintenance, Handling Cds, Cleaning Cds, Cleaning The Cd Player Lens

    Do not place stickers or labels on either side of the CD.  Cleaning the CD Player Lens A dirty lens can cause CD playback to skip. If the lens is very dirty, the CD may not work at all. Unplug the power supply, open the CD door,...

  • Page 10: Table Of Contents

    COMPLIANCE WITH FCC REGULATIONS ... 8 CD CARE & MAINTENANCE ... 9 Handling CDs ... 9 Cleaning CDs ... 9 Cleaning the CD Player Lens ... 9 TABLE OF CONTENTS ... 10 PACKAGE CONTENTS ... 12 FEATURES ... 13 GETTING STARTED ... 14 CX-CD377 at a Glance ...

  • Page 11

    TABLE OF CONTENTS AUX MODE ... 21 Basic Operation ... 21 SETUP MODE ... 22 Clock/Display ... 22 TROUBLESHOOTING... 23 SPECIFICATIONS ... 25 www.cobyusa.com Page 11...

  • Page 12: Package Contents

    PACKAGE CONTENTS Please make sure the following items are included in the package. If any items are missing, contact your local dealer. CX-CD377 Main Unit  Stereo Speakers (x 2)  Remote Control  3.5mm male-to-male Line-in Cable  Mounting Plate with Screws (3 x 10 PWA) ...

  • Page 13: Features

    Vertical Loading CD Player  Multi-Function Backlit LCD Display  Electronic Volume Control  Analog AM/FM Stereo Tuner (Rotary Tuning, Digital Readout)  Dynamic Bass Boost System (DBBS)  Full-Range Speaker System  110/220V Dual Voltage  www.cobyusa.com FEATURES Page 1...

  • Page 14: Getting Started, Cx-cd377 At A Glance

    GETTING STARTED CX-CD377 at a Glance Page 1 Coby Electronics Corporation...

  • Page 15: Bottom View, Top View, Remote Control, Digital Display

    GETTING STARTED Bottom View AC Power Cord Speaker Out Jacks (Left, Right) Voltage Selector (110/220V) Mounting Slots FM Antenna Lead Top View Power (On/Off) Power Indicator Function Switch (CD/Aux/Radio) Bass Switch (On/Off) Auxiliary Line-In Jack Volume Down / Up Remote Sensor Play/Pause Stop Repeat/Random...

  • Page 16: Mounting The Cx-cd377

    GETTING STARTED Mounting the CX-CD377 To mount your CX-CD377 to either a wall or the pedestal base: Using 4 screws, affix the mounting plate to either a wall or to the pedestal base. Align the 4 mounting slots on the bottom of the main unit to hang on the hooks of the mounting plate.

  • Page 17: Connections, Speakers, Auxiliary (optional), Power

    GETTING STARTED Connections Speakers Always connect the speakers before connecting the power supply. Connect the black wire of the left speaker to the black terminal  marked “L-” on the rear of the main unit. Connect the red wire of the left speaker to the red terminal ...

  • Page 18: Basic Operation, Cd Functions, Play/pause/stop, Previous/next (skip), Reverse/forward (scan)

    Basic Operation Press POWER to turn the player on. To open the CD Door, press facing up. Close the CD Door (it will click into place). Set the FUNCTION switch to the “CD” position. Press to start CD playback. CD Functions Play/Pause/Stop Press to start playback.

  • Page 19: Repeat/random Mode, Program (memory)

    Repeat/Random Mode Press to set the repeat/random mode of the player. Each suc- cessive press of Repeat One: repeat the current track (flashing REPEAT display)  Repeat All: repeat the entire CD (steady REPEAT display)  Random: play all tracks in random sequence (steady RANDOM ...

  • Page 20: Radio Mode, Basic Operation, Tuning, Reception

    Basic Operation Press POWER to turn the player on. Set the FUNCTION switch to the “Radio” position. Set the BAND SELECTOR switch to: AM: Listen to AM broadcasts.  FM: Listen to FM Mono broadcasts (use this set-  ting if reception is weak). FM ST: Listen to FM Stereo broadcasts.

  • Page 21

    Auxiliary (Aux) mode allows you to play any audio device (e.g., MP3, cassette player, etc.) through your CX-CD377 system. Basic Operation Use a 3.5mm male-to-male line-in cable to connect the Line-out or Headphone out jack of an audio device to the CX-CD377 Auxiliary Line-In jack.

  • Page 22

    Clock/Display Place in the player in Standby mode (press POWER if the player is currently on). The time will be displayed when the player is in Standby. Press flash. Press 12H: Displays the time in 12-hour time.  24H: Displays the time in 24-hour time. ...

  • Page 23

    TROUBLESHOOTING If you have a problem with this device, please read the troubleshooting guide below and check our website at www.cobyusa.com for Frequently Asked Questions (FAQs) and firmware updates. If these resources do not resolve the problem, please contact Technical Support. COBY Electronics Technical Support Address: 56-65 Rust St.

  • Page 24

    TROUBLESHOOTING The sound is distorted. The unit may be positioned too closely to a large appliance (e.g, a  TV or refrigerator). If possible, turn the appliance off or move the unit to another location. Ensure that the radio is in broadcast reception range. ...

  • Page 25

    Power Supply Tuning System Audio Output Audio Input Output Power Speaker Dimensions Unit Dimensions Net Weight Specifications and manual are subject to change without notice. www.cobyusa.com SPECIFICATIONS AC 110/220V 60/50Hz (Dual Voltage) AM: 530 - 1710kHz FM: 88 - 108MHz Stereo Speakers (x2) 3.5mm Aux Line-In 2.2W RMS x 2...

  • Page 26

    NOTES Page  Coby Electronics Corporation...

  • Page 27

    NOTES www.cobyusa.com Page ...

  • Page 28

    COBY Electronics Corp. 56-65 Rust Street Maspeth, NY 11378 www.cobyusa.com www.ecoby.com...
