Lorex SG7555RB Quick Setup Manual

4. Camera Specifications
Image Device 1/4" Color Image Sensor
Effective Pixels 656H x 492V
Scanning System 2:1 Interlace
NTSC: 525 Lines
Resolution Horizontal 480 TV lines
AES Shutter Speed 1/60 ~ 1/50,000 sec.
S/N Ratio More than 48dB (AGC off)
Sync. System Internal
Min. Illumination 3 LUX @F1.2 (no LED)
0 LUX (with LED)
IR Night Vision 24 IR LED / 850nm / 50'
(15m)
Video Output 1.0 Vp-p (75 ohms)
White Balance AWB
Termination 6 Pin DIN
Lens Fixed Lens (3.6mm)
Viewing Angle H: 59°; V:44°; D: 73°
FOV (Diagonal) 70 Degrees
±
Power Requirement DC 12V
With IR: Max 330mA
Power Consumption
W/o IR: Max 90mA
°
Operating Temp 14 F ~ 122°F
°
(-10 ~ 50
Operating Humidity Within 90% RH
Weight (With Stand) 0.81lb / 0.36 kg
Dimensions:
It's all on the web
Product Information
User Manuals
Quick Start Guides
10%
°
C)
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2008 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
H O M E & B U S I N E S S S E C U R I T Y
HIGH RESOLUTION
WEATHERPROOF COLOR CAMERA
WITH NIGHT VISION AND AUDIO
Model: SG7555RB Series
Refer to the Product Package or online
Spec Sheet for specific product
configuration.
Quick Set-up Guide
English Revision 1.0
