INSTALLATION
INSTRUCTIONS
27² ² ² ² SINGLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 200 lbs.)
DIMENSIONS
inches
A
27 MIN
B
24 MIN
C
29 1/16 + 1/16
D
24 MIN
E
25 1/2 + 1/16
F
29 1/2
G
26 3/4
H
25 7/16
I
4 to 31
27² ² ² ² DOUBLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 310 lbs.)
DIMENSIONS
inches
A
27 MIN
B
24 MIN
C
51 7/8 + 1/16
D
24 MIN
E
25 1/2 + 1/16
F
52 1/4
G
26 3/4
H
25 1/2
I
4 to 10
NOTES
Z
Do not blockair exhaust slots along bottom
of oven.
Y
Gas or electric cooktops may be installed
over ovens. See cooktop installation
instructions for cutout size.**
W
Electrical connection for electric cooktop
must in adjacent accessible location. Cook
top and wall oven must be on separate
120/240 or 120/208 volt 60 Hz AC circuits.
CAUTION
For European style cabinets (flush
front) the required clearance for
operation of the oven door is
minimum spacing of 7/8² between
the cutout and the door, hinge or
drawer of the cabinet.
Some built-in cabinets may not be
wide enough, due to their construc-
tion, to allow this installation.
*
NOTE:
Hole must be cut as close to corner of cabinet as possible.
**
See dealer for approved cooktops.
Built-In 27² ² ² ² & 30² ² ² ²
Electric Wall Ovens
30² ² ² ² SINGLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 200 lbs.)
DIMENSIONS
cm
inches
68.58
A
30 MIN
60.96
B
24 MIN
73.82
C
29 1/16 + 1/16
60.96
D
24 MIN
64.77
E
28 1/2 + 1/16
74.93
F
29 1/2
67.95
G
29 3/4
64.61
H
25 7/16
10.2 to 78.7
I
4 to 31
30² ² ² ² DOUBLE WALL OVEN
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 310 lbs.)
DIMENSIONS
cm
inches
68.58
A
30 MIN
60.96
B
24 MIN
131.76
C
51 7/8 + 1/16
60.96
D
24 MIN
64.77
E
28 1/2 + 1/16
132.72
F
52 1/4
67.95
G
29 3/4
64.77
H
25 1/2
10.2 to 25.4
I
4 to 10
30² ² ² ² WALL OVEN UNDER COUNTER
1
1 1/4² Dia. Conduit Access Hole*
2
5/8² Plywood Floor (Must Support 200 lbs.)
DIMENSIONS
inches
A
B
24 MIN
C
29 1/16 + 1/16
D
24 MIN
E
28 1/2
F
29 1/2
G
29 3/4
H
25 7/16
I
J
1 1/2
30² ² ² ² WALL OVEN
K
All JA Cooktops
cm
76.20
60.96
73.82
60.96
72.39
74.93
75.57
64.61
10.2 to 78.7
cm
76.20
60.96
131.76
60.96
72.39
132.72
75.57
64.77
10.2 to 25.4
cm
25
63.50
60.96
73.82
See pages 5, 6 and 7 for detailed installation
60.96
instructions.
72.39
74.93
75.57
64.61
36
91.44
I
3.81
inches
cm
3 MAX
7.62 MAX
403 WEST FOURTH STREET, NORTH
NEWTON, IA 50208
SINGLE WALL OVEN
D
C
E
A
B
DOUBLE WALL OVEN
B
A
D
C
1
2
I
E
Art #: 9220-026
UNDER COUNTER WALL OVEN
J
Y
W
1
D
C
B
E
Art #: 9220-027
K
1
H
2
F
I
G
Z
Art #: 9220-025
H
F
Z
G
A
H
2
G
Z
8101P602-60
(11-03-00)
F
