COLOR TELEVISION
USER'S GUIDE
In the spaces below, enter the model and serial number of your television (located at
the rear of the television cabinet). Staple your sales receipt or invoice to the inside
cover of this guide. Keep this user's guide in a convenient place for
future reference. Keep the carton and original packaging for future use.
Serial Number
IMPORTANT NOTE TO THE CUSTOMER
Illustration of AV-27F802 and RM-C301G
For models:
AV-32F802
AV-32F702
AV-27F802
AV-27F702
Model Number
LCT0821-001C-A
0301-TN-JII-JIM

Advertisement

Table of Contents
loading

Related Manuals for JVC AV-27F702

Summary of Contents for JVC AV-27F702

  • Page 1 Keep this user's guide in a convenient place for future reference. Keep the carton and original packaging for future use. Serial Number Illustration of AV-27F802 and RM-C301G For models: AV-32F802 AV-32F702 AV-27F802 AV-27F702 Model Number LCT0821-001C-A 0301-TN-JII-JIM...

  • Page 2: Important Safety Precautions

    Do not attempt to repair it yourself or remove the rear cover. Changes or modifications not approved by JVC could void the warr a n t y. * When you don’t use this TV set for a long period of time, be sure to disconnect both the power plug from the AC outlet and antenna for your safety.

  • Page 3: Important Safeguards

    Should it still fail to fit, contact your electrician. 2 Operate the TV set only from a power source as indicated on the TV set or refer to the operating instructions for this information. If you are not sure of the type of power supply to your home, consult your TV set dealer or local power company.
  • Page 4 Therefore: — Never block the bottom ventilation slots of a portable TV set by placing it on a bed, sofa, rug, etc. — Never place a TV set in a “built-in” enclosure unless proper ventilation is provided.
  • Page 5 13 For added protection of the TV set during a lightning storm or when the TV set is to be left unattended for an extended period of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to product due to lightning storms or power line s u rg e s .

  • Page 6: Quick Setup Guide

    Unpacking Your Television Thank you for your purchase of a JVC Color Television. Before you begin setting up your new television, please check to make sure you have all of the following items. In addition to this guide, your television...

  • Page 7: Quick Setup

    The right and left buttons will turn the volume up or down. These buttons are also marked with four arrows and are also used with JVC's onscreen menu system. You will need to use these buttons later in the Quick Setup.
  • Page 8 11 to 13. 1) Connect an RF cable out from the wall outlet in to the RFInput on the back of the TV. You may also wish to connect a VCR at this point. Abasic VCRconnection is shown below. For detailed instructions on connecting a other components or a home theater system, see pages 14 to 16.
  • Page 9 Your Quick Setup is now complete. You can now begin watching your television, or you can continue on in this guide for more information on connecting audio/video devices, programming your remote control, or using the JVC onscreen menu system to customize your television viewing experience. Quick Setup 3...

  • Page 10: Table Of Contents

    DVD Buttons ....43 TV/CATV Switch ... . . 43 VCR/DVD Switch ... . . 43 L i g h t.

  • Page 11: Connections

    6) Connect the red audio cable out from the VCR’s Right Audio Output, in to the TV’s Right Audio Input jack. • If your VCR is a mono sound unit, it will have only one Audio Out jack. Connect it to the TV’s Left Audio Input. •...
  • Page 12 VCR. 3) Connect an RF cable from the RF Output of the VCR, in to the RF Input on the back of the TV. 4) Connect the yellow video cable out from the VCR’s Video Output, in to the TV’s Video Input jack, OR connect an S-Video cable from the VCR’s S-Video output, to the TV’s S-Video input.
  • Page 13 Illustration of AV-27F802 1) Connect the antenna or cable TV wire from the wall outlet, in to the RFInput of the two-way splitter. 2) Connect an RFcable from the one of the RFOutputs on the splitter, in to the cable box RF I n p u t .

  • Page 14: Connecting To A Dvd Player

    “YES” for proper display of the DVD signal. • AV-32F702 & AV-27F702: If you use Input 2 (Component-In) for the DVDconnection, you must set the V2 COMPONENT-IN on the initial Setup Menu to “YES” for proper display of the DVD signal.

  • Page 15: Connecting To An External Amplifier

    Input jack, OR connect an S-Video cable from the Camcorder’s S-Video output, to the TV’s S-Video Input. 2) Connect the white audio cable out from the Camcorder’s Left Audio Output, in to the TV’s Left Audio Input jack. 3) Connect the red audio cable out from the Camcorder’s Right Audio Output, in to the TV’ s Right Audio Input jack.

  • Page 16: Connecting To Jvc Av Compu Link

    • The AV Compu Link cable has a male 3.5 mm (mono) plug on each end. • If your JVC-brand V C R has “ A Code/B Code Remote Control Switching” (see your V C R ’s instruction book), using V C R A Code will switch the T V to input 1.

  • Page 17: Remote Control

    Tap the CH+ or CH- button to move through the channels one channel at a time. • To move rapidly through the channels using JVC’s Hyperscan feature, press and hold CH+ or CH-. The channels will zip by at a rate of five channels per second.

  • Page 18: Remote Programming

    Remote Programming Setting the CATV, VCR and DVD Codes You can program your remote to operate your cable box, satellite receiver, VCR or DVD player by using the instructions and codes listed below. If the equipment does not respond to any of the codes listed below or to the code search function, use the remote control supplied by the manufacturer.

  • Page 19: Vcr Codes

    1) Find the VCR brand from the list of codes shown below. 2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR”. 3) Press and hold down the D button.

  • Page 20: Dvd Codes

    1) Find the DVD player brand from the list of codes shown below. 2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “DVD”. 3) Press and hold down the D 4) With the D button held down, enter the first code number listed with the 10 key pad.

  • Page 21: Using The Guide

    The “Plug In Menu” will appear the first time the TV is plugged in. Notes: Menus shown in this book are illustrations, not exact replications of the television’s onscreen displays.

  • Page 22: Plug In Menu

    Descriptions of each of the Plug In Menu features appear on this page and the next. We recommend you complete the Plug In Menu setup first so your TV is set up just the way you want, right away. Language You can choose to view your onscreen menus in three languages: English, French, or Spanish.

  • Page 23: Auto Clock Set

    Auto Clock Set Before you use any of your TV’s timer functions, you must first set the clock. You may precisely set your clock using the XDS time signal broadcast by most Public Broadcasting stations. To set the clock using the XDS signal:...

  • Page 24: Manual Clock Set

    Finish option to save your settings. To FINISH To save settings and exit • You can change the preferences you set in the Plug In Menu at any time using the regular JVC onscreen menu system. NOTES: You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

  • Page 25: Channel Summary

    Channel Summary Channel Summary allows you to customize the line-up of channels received by your TV. You can add or delete channels from the line-up or prevent any unauthorized viewers from watching any or all 181 channels. Press the M...

  • Page 26: V- C H I

    V-Chip Your TV is equipped with V-Chip technology which enables TV Parental Guidelines (for United States and Canada) and Movie (MPAA) Guideline controls. V-Chip technology allows you to pro- gram your TVto receive, or not to receive, programs based on content according to the guidelines.

  • Page 27: Viewing Guidelines

    These programs are specifically for adults and may be unsuitable for anyone under 17 years of age. TV MAprograms may have extensive V, S, L, or D. In addition to the ratings categories explained above, information on specific kinds of content are also supplied with the V-Chip rating.

  • Page 28: Setting Us V-Chip Ratings

    “—”. For example. To block viewing of all TV 14 shows, move the cursor to the top row of that column and add a lock icon. Once you've put a lock on the top row, everything in that column is automatically locked.

  • Page 29: Setting Ratings With The V-Chip Button

    All Programming above TV PG- V (with Violence) will be blocked. • For Children's programming you can block TV-Y and Y7 programs by Pressing “0” when Y is displayed during a program. Programming for audiences other than children’s audiences will not be affected.

  • Page 30: Movie Ratings

    V-Chip Movie Ratings NR - Not Rated. This is a film which has no rating. In many cases these films were imported from countries which do not use the MPA A ratings system. Other NRfilms may be from amateur producers who didn’t intend to have their film widely released.

  • Page 31: Directions To Set Canadian V-Chip Ratings

    Canadian V-Chip Ratings E - Exempt. Exempt programming includes: news, sports, documentaries and other information programming, talk shows, music videos, and variety programming. C – Programming Intended for Children. Violence Guidelines: There will be no realistic scenes of violence. Depictions of aggressive behavior will be infrequent and limited to portrayals that are clearly imaginary, comedic or unrealistic in nature.

  • Page 32: Unrated Programs

    Religious Programs Sports Weather Some Commercials • TV programs or movies that do not have rating signals will be blocked if the Unrated Category is set to BLOCK. Directions to Block Unrated Programs: You can block programs that are not rated.

  • Page 33: Set Lock Code

    Set Lock Code Channel Guard and V-Chip settings are protected by a four-digit Lock Code. Your TV comes pre-set with a Lock Code of "0000". You may change the code to any four-digit number you wish. To change the Lock Code, follow the steps below.

  • Page 34: Picture Settings

    To make the colors more subdued To move to the next setting Picture Picture allows you to adjust the levels of black and white on the TV screen, giving you a darker or brighter picture overall. Press the M b u t t o n...

  • Page 35: Noise Muting

    Noise Muting This feature inserts a blank blue screen over channels which are not broadcasting or are too weak to be received clearly. Press the M b u t t o n E N U To NOISE MUTING To turn Noise Muting ON or OFF •...

  • Page 36: Sound Settings

    (The ON AIR arrow tells you if a broadcast is in Stereo and/or contains an SAP). • Keep the TV in STEREO mode to get the best sound quality. The sound will work in STEREO mode even if a certain broadcast is in MONO sound only.

  • Page 37: General Items

    To move to minutes To set the minutes To accept ON TIME and move to OFF TIME (the time the TV will turn off). Set the OFF TIME the same way as ONTIME To accept OFFTIME and move to CHANNEL...

  • Page 38: Tv Speaker

    General Items TV Speaker If your TV is connected to a stereo system, you can turn off the T V speakers and listen to the audio through your stereo. Press the M b u t t o n E N U...

  • Page 39: V4 Component-In

    • This option should be used with DVD players only. For information on connecting VCR’s see page 11. For more information on connecting a DVD player, see page 14. • AV-32F702 & AV-27F702 note: These models do not have Input 4. Closed Caption Many broadcasts now include an onscreen display of dialog called Closed Captions.

  • Page 40: Button Functions

    Button Functions Menu The M button allows you to access JVC’s onscreen menu system. Press M E N U onscreen menu system. • See individual topics (like “Sound Settings) for specific information on using menus. Exit and PIP Off Press the E button to leave a menu screen.

  • Page 41: Video Status

    Press the V IDEO Sleep Timer The Sleep Timer can turn the TV off for you after you fall asleep. Program it to work in intervals of 15 minutes, for a total time of up to 180 minutes. Press the S...

  • Page 42: Return

    • Return+ does not affect the PIP channel (AV-32F802 & AV-27F802 only). Input Selects the signal input source for the television: TV (for Antenna or Cable) or Video-1, 2, 3, or 4 for video devices like VCR’s, DVD players, or camcorders.

  • Page 43: Vcr Buttons

    Move the selector switch to V C R to operate. • The remote is preset with the code 000 to control JVC-brand VCR’s. For any other manufacturer’s brand VCR, please see the code chart and instructions on page 19.

  • Page 44: O N / M O V

    Turn PIP on by pressing the O (PIP) O PIP O to turn PIP off Once PIP is turned on, you can move the PIPwindow to any of the TV’s main picture’s four corners with the O button. • Each press of O will shift the PIP window to a different corner.

  • Page 45: F Re E Z

    Freeze Use the F button to lock a single, still image onto the PIP window. REEZE • If PIP is off when F REEZE PIPwindow. • If PIPis on when F is pressed, the image in the window when the button was pressed is h e l d . R E E Z E Swap You can exchange the channel displayed on the main screen for the one shown in the PIP window...

  • Page 46: Troubleshooting

    Troubleshooting...

  • Page 47: Warranty

    JVC Factory Service Center, the name and location which will be given to you by the toll free number.
  • Page 48 THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILTY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE, OR ANY OTHER DAMAGES,WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUD-...

  • Page 49: Authorized Service Centers

    Please refer to qualified service personnel for repairs. Accessories To purchase accessories for your JVC product, you may contact your local JVC Dealer. From the 48 Continental United States call toll free: 1 (800) 882-2345 or on the web at www.JVC.com...

  • Page 50: Search Codes

    5) Press R + to exit. ETURN VCR Search Codes Function: 1) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR”. 2) Press the VCR P and R OWER 3) Press VCR P , see if the VCR responds.

  • Page 51: S P E C I F I C A T I O N

    Specifications Specifications subject to change without notice.
  • Page 52 JVC COMPANY OF AMERICA JVC CANADA, INC. Division of JVC Americas Corp. 21 Finchdene Square 1700 Valley Road Scarborough, Ontario Wayne, New Jersey, 07470 Canada, M1X 1A7...
