Summary of Contents for IRiver iGP-100
-
Page 1: Instruction Manual
Instruction Manual PORTABLE STORAGE DEVICE & MULTI - CODEC JUKE BOX Model iGP-100 Model iGP-100 Model iMP-350 Thank you for your purchase. Please read this manual carefully before using your new player. http://www.iRiverAmerica.com http://www.iRiverAmerica.com... - Page 2 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
- Page 3 Limited does not assume any responsibility for errors or omissions in this document or make any commitment to update the information contained herein. iRiver is a registered trademark of iRiver Limited in the Republic of Korea and/or other countries and is used under license.
-
Page 4: Table Of Contents
1. Locating the Controls Front View, Side View... Side View... LCD Window... 2. Getting started Using AC POWER ADAPTER... Installing the iGP Device Driver... Connecting the iGP to the Host PC... Using as a Portable Storage Device... Disconnecting the iGP from the Host PC... Listening to Music... -
Page 5: Side View
SIDE VIEW EARPHONES Volume + / - RESET USB Connection DC IN 5.0 V Port LCD Window TRACK NUMBER PLAYBACK MODE HOLD BATTERY INDICATOR FOLDER NAME ARTIST NAME TITLE NAME PROGRESSIVE BAR LEVEL METER LEVEL METER PLAYBACK PLAY TIME INFORMATION FILE FORMAT BIT RATE SAMPLE RATE... -
Page 6: Using Ac Power Adapter
Using AC POWER ADAPTER Use only the AC Power Adapter supplied with the player. The AC operating voltage of this player is 100~240V, 50~60Hz. Connect the adapter to the 5.0V DC jack on the player and into an AC outlet. Recharging Method The player will charge automatically when the AC adapter is connected to the player. - Page 7 Once installed, open Windows Explorer and an additional drive should be listed called “iGP-100”. TO USE AS A PORTABLE STORAGE DEVICE If the player is not connected to the host PC, connect it to the host PC.
- Page 8 Click the 'Safely Remove Hardware" icon in the System Tray. Click “Stop iRiver iGP-100-Driver(X)” or “Safely Remove CORNICE Inc. Storage-Drive(X:)”. (Where X is the drive letter assigned to the iGP) Click OK after confirming the “Safe To Remove Hardware” massage.
- Page 9 EQ File Format displayed as below To activate Menu To activate Navigation 1. Operating light is illuminated when the iGP-100 is turned on. 2. Charging light is illuminated during charging. To increase volume. 4. A-B repeat / MODE : 5.
-
Page 10: Basic Operation
Basic Operation To adjust the volume Press + on volume button to increase volume and press – on button to decrease volume. File playback receiving (Refer to page 19) NAVIGATION Press NAVI/MENU button and find the desired track by pressing NAVI/MENU button. -
Page 11: Operating The Fm Tuner
Navigation mode is useful for quickly searching your files by using file name. NAVIGATION Press the NAVI/MENU button to display the list of audio tracks. The current track will also be displayed. Push the NAVI/MENU switch toward or folder to play. Press the NAVI/MENU button to play the selected track or display the contents of a folder. - Page 12 MEMORY FUNCTION (Save stations manually) After cancelling the PRESET mode, select a station by pushing the switch to the left or the right. Push and select the desired station to save the station to. Select CH02 Up to 20 stations can be stored. AUTO MEMORY FUNCTION (Save stations automatically) Automatically select station and save them in sequential order.
-
Page 13: Playback Mode
The iGP has various playback modes. Please refer to the function controls (see page 30 for details) for user-defined configurations. REPEAT Play a single track repeatedly. Press or next track. Play all tracks in the folder and stop. Play all tracks in the folder repeatedly. Play all tracks in the player repeatedly. -
Page 14: Menu Operation
CONFIGURATION Function Control is subject to change with different firmware versions. Users can configure their own settings. Display General Beep Volume Back Light (Battery) Resume Back Light (Adapter) Fade In LCD Contrast(Main) Language Tag Information Tuner Region Time Load Default Firmware Upgrade Control Mode... -
Page 15: Firmware Upgrade
GENERAL BEEP VOLUME Set beep volume level to 0 / 1 / 2 / 3 step. RESUME When ON, player resumes to previous place in song after STOP or Power OFF. FADE IN When activated, volume increases gradually at playback mode to prevent sudden loudness. LANGUAGE (Supports 38 languages) Song title and ID3 tag information is dependent on the version of the PC operating system that was... - Page 16 TAG INFORMATION ON : Displays track with ID3 tag information and you can change the configuration of Tag information. OFF : Displays track with file name. The change will take affect when the next track is played. TIME Normal : display elapsed time. Remain : display remaining time.
- Page 17 MODE (PLAYBACK MODE) REPEAT MODE / SHUFFLE MODE You can select a file or directory to listen to repeatedly. You can play the selected mode simultaneously by setting REPEAT MODE / SHUFFLE MODE respectively. (Refer to page 22 for details about each mode) INTRO MODE INTRO MODE plays the beginning 10 seconds of each track.
- Page 18 2. Click "LIST OPTS" located on the right bottom and click "SAVE LIST" Click the SAVE LIST button. 3. Name the file name (ex: iriver.m3u) and click "SAVE" to save the list. Save to the player with the .M3U and the files added to the playlist.
- Page 19 Upgrade your firmware at www.iriveramerica.com. What is FIRMWARE? It is the operating system that works in the iGP series. iRiver provides you with the latest and best features through Firmware Upgrade. Visit www.iriveramerica.com to upgrade your Firmware. How to UPGRADE? 1.
- Page 20 Keep the volume at a moderate level. This will allow you to hear outside sound and to be considerate of the people around you. Should any problem persist after you have checked these symptoms, consult your iRiver dealer or contact support at iRiverAmerica.com. Check whether the battery is discharged. No Power Check the operation after connecting AC Adapter.
- Page 21 Installation CD Headphones and foam covers User Manual/ AC Adapter Warranty card USB Cable Carrying Case Accessories subject to change without notice and may vary from image shown. Category Item Specifications Frequency/Range 20Hz~20KHz 20mW(L) +20mW(R) at 16 Headphone output 11.6mW(L) +11.6mW(R) at 32 Audio Max.
- Page 22 Federal Communications Commission (FCC) The device manufactured and found to comply with limits for a Class B computing device according to the specifications in FCC rules Part 15. Operation is subject to the following two conditions; 1. This device may not cause harmful interference, and 2.
