WARNING
Navigation based solely on one method or
one instrument should never be practiced.
While the Color Twinscope can be quite
useful in showing underwater structure and
changing bottom conditions both below and
in front of your vessel, there are many
situations and conditions which can cause
erroneous or distorted readings.
In addition, there are many situations that
can cause "blind spots" in the Color
Twinscope's field of view including the
presence of temperature inversion layers
(thermoclines), water turbulence, and high
concentrations of suspended particles in the
water.
While the Color Twinscope can be
considered as a useful aid to navigation, it
should never be the only means of
navigation.
General Information
T
hank you for your selection of the Interphase Color
Twinscope Forward Scanning Sonar. The Color Twinscope's
ruggedly built, compact design makes it ideal for installation
on nearly any boat. It will display water depth, bottom
conditions and submerged objects such as fish, or objects in
your path, on its high resolution display. The Color
Twinscope is available with either a thru-hull or two transom-
mount scanning sonar depth transducers.
To ensure that you receive the maximum benefits available
from the outstanding features of the Interphase Color
Twinscope, please carefully follow the steps outlined in this
manual. An instructive demonstration simulator has been
designed into the Color Twinscope and we highly recommend
that you spend some time using the demo mode prior to actual
use of the unit. We also recommend that you read this entire
manual before attempting to either install or operate your
Color Twinscope.
Warranty Information
Interphase provides a limited warranty on the Color
Twinscope Forward Scanning Sonar which is printed on the
inside rear cover of this manual. We recommend that you save
all packing materials so that if you should need to send the unit
in for repair, it can be fully protected. Should you experience
a problem with your Color Twinscope, first refer to the
Troubleshooting section (Page 38) of this manual. Most
common problems and their solutions are described here. If
problems persist, call Interphase Product Support at (831)
477-4944. We will be happy to try to assist you, and if
required, we will give you instructions on how to quickly get
your set repaired.
The enclosed warranty registration card must be completed
and returned to Interphase within 15 days of purchase so that
your unit may be protected under the warranty. Failure to
return the warranty card may cause unnecessary delays in
processing your unit for warranty repair. (See warranty, page
43).
4
