Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-09H03/(BP)1 HSU-12H03/(BP)1 Please read this operation manual before using the air conditioner. No.0010552238... -
Page 2: Table Of Contents
Contents Cautions Parts and functions Operation Maintenance Trouble shooting 10-11... -
Page 3: Cautions
Cautions The machine is adaptive in following situation I. Applicable ambient temperature range: Indoor Cooling Outdoor Indoor Heating Outdoor 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similar qualified person. The type of connecting wire is H05RN-F or H07RN-F 3. -
Page 4: Parts And Functions
Parts and Functions Indoor Unit Inlet grille Air filter Vertical flap Power indicator Use remote controller to Lights up when unit starts. adjust up and down air flow. (Don't adjust it manually.) Outdoor Unit OUTLET INLET Timer mode indicator Lights up when Timer operation is selected. - Page 5 Parts and Functions Operation ON/OFF TEMP MODE SWING LOCK Clock set When unit is started for the first time and after replacing batteries in remote controller, clock should be adjusted as follows: Press CLOCK button, "AM" or "PM" flashes. Press to set correct time.
-
Page 6: Operation
Operation Remote controller's operation When in use, put the signal transmission head directly to the receiver hole on the indoor unit. The distance between the signal transmission head and the receiver hole should be within 7m without any obstacle as well. Don't throw the controller, prevent it from being damaged. -
Page 7: Cool,Heat And Dry Operation
Operation COOL,HEAT and DRY operation Recommendations: (1) Unit start Press ON/OFF button, unit starts. Previous operation status appears on display. (Not Timer setting) Power indicator on indoor unit lights up. (2) Select operation mode Press MODE button. For each press, operation mode changes as follows: COOL Unit will run in operation mode displayed on LCD. - Page 8 Operation (5) Air flow direction adjustment After operation mode is selected, vertical flap will open automatically according to the mode. Referring to the Fig. COOL About 10 Up and down (Use remote controller) Press SWING button, vertical flap will move within the range shown in the Fig.
-
Page 9: Power/Soft Operation
Operation POWER/SOFT Operation POWER Operation When you need rapid heating or cooling, you can use this funciton. Selecting of POWER operation Press POWER/SOFT button. Every time the button is pressed,display changes as follows: POWER Stop the display at In POWER operation status: In COOL mode, when room temperature is lower 4 temperature setting ,compressor runs high-frequency for 15 min then returns to original status setting. -
Page 10: Timer Operation
Operation TIMER Operation Set Clock correctly before starting Timer operation You can let unit start or stop automatically at following times: Before you wake up in the morning, or get back from outside or after you fall asleep at night. TIMER ON/OFF (1)After unit start, select your desired operation mode. - Page 11 More than 23 Less than 23 If an air conditioner is a model for both cooling and heating. Cooling when the room temperature at the start of operation is above 23 Heating when the room temperature at the start of operation is below 23...
-
Page 12: Maintenance
Maintenance Different models have different appearance Cleaning of unit casing Cleaning of remote controller Cleaning of air filter 1.Open inlet grille by pulling it upward. 3.Clean the filter Use a vacuum cleaner to remove dust,or wash the filter with water. After washing, dry the filter completely in the shade. - Page 13 Maintenance Replacement of Air purifying Filter Open the Inlet grille Open the Inlet grille by pushing each ends of the Inlet grille upward.(use thumbs to push up) Detach the standard air grille Slide the knob slightly upward to release the filter, then withdraw it.
- Page 14 Maintenance Better use of air conditioner Proper room temperature. Closing of doors and windows during operation Never fail to observe the followings Do not sprinkle water over the unit. Do not pull power plug. Cleaning of the air filter. Proper temperature Effective use of the timer.
-
Page 15: Trouble Shooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
