SERVICE MANUAL

Model Name : PD100/PD100D/PD120/
PD120D/XD1170D/XD1270D
Date
Revise Version
2005/8
V1.0
2006/7
V2.0
P/N#36.82V01G001 . Document#82V-G04-02A
Initial Issue(PD100/PD100D/PD120/PD120D)
add XD1170D&1270D models, add pages 2/5/7/15/49/80-111
Copyright July, 2006 . All Rights Reserved
Prepared by SI :
________________________________________
Prepared by TSE :
________________________________________
Check by :
________________________________________
Approved by :
________________________________________
Description

Advertisement

Table of Contents
loading

Related Manuals for Acer XD1170D

Summary of Contents for Acer XD1170D

  • Page 1: Service Manual

    V1.0 2006/7 V2.0 Copyright July, 2006 . All Rights Reserved P/N#36.82V01G001 . Document#82V-G04-02A Prepared by SI : ________________________________________ Prepared by TSE : ________________________________________ Check by : ________________________________________ Approved by : ________________________________________ Description Initial Issue(PD100/PD100D/PD120/PD120D) add XD1170D&1270D models, add pages 2/5/7/15/49/80-111...
  • Page 2 Preface This manual is applied to Acer PD100 0.55 inch 12 Projector / PD100D 0.55 inch 12 inch 12 DDR DMD SVGA Micro Portable Projector / PD120D 0.55 inch 12 Micro Portable Projector / XD1170D 0.55 inch 12 / XD1270D 0.55 inch 12 brief description of basic technical information to help in service and maintaining the product.
  • Page 3 PD100 PD100D PD120 PD120D XD1170D XD1270D Service Guide Service guide files and updates are available on the AIPG/CSD web; for more information, please refer to http://csd.acer.com.tw PRINTED IN TAIWAN...

  • Page 4: Revision History

    Revision History Please refer to the table below for the updates made on PD100, PD100D, PD120, PD120D, XD1170D, XD1270D service guide. Date Chapter Updates...
  • Page 5 Copyright Copyright © 2006 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 6 Conventions The following conventions are used in this manual: Screen messages NOTE WARNING CAUTION IMPORTANT Denotes actual messages that appear on screen. Gives bits and pieces of additional information related to the current topic. Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 7 DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 8: Table Of Contents

    Exploded Overview Exploded Overview Appendix Serial Number Definition System I. Serial Number System Definition II. PCBA Code Definition III. The Different Parts (PD100 / PD100D / PD120 / PD120D / XD1170D / XD1270D ) IV. Identification Method for “D” Model...

  • Page 9: System Introduction

    System Introduction Technical Specification Item Dimensions (WxHxD) 230 x 122.8 x 238 mm Tilt Angle 7 degree with elevator mechanism Keystone correction +/-16 degree (32 degree) (Horizontal) Lamp Door Projection Lamp power supply shut off automatically when door open Universal AC 100-240V ~ 50-60Hz with PFC input 200W for Philips UHP Lamp @ normal operation Power Supply Variance FAN speed control...
  • Page 10 1170 ANSI Lumens (Typical; Eco Mode) 38 dB(A) (Typical, Under 23 +/- 2 Acoustic noise level DVD/wireless) 30 dB(A) (Typical, Under 23 +/- 2 Technical Specification(XD1170D) Item Weight Approx. 5.3 lbs (2.4 Kg) Projection Lens F#2.35~2.47, f=21.83mm~23.81mm, 1.10X Mechanical Zoom Lens 1850 ANSI Lumens (Typical;...

  • Page 11: Product Overview

    Product Overview Main Unit Item Focus Ring Zoom Ring Zoom Lens Elevator Button Elevator Foot Remote Control Receiver Connection Ports Power Socket Control Panel Description Chapt er 1...

  • Page 12: Control Panel

    Control Panel Item Lamp Indicator LED Temp Indicator LED Power / Standby and Indicator LED (Power LED) Source Resync Four Directional Select Keys Menu Chapt er 1 Description...

  • Page 13: Connection Ports

    Remote Control IR Receiver (for PD100/PD100D/PD120/PD120D only) Composite Video Input Connector Kensington 5V DC Output Jack (dfor attached dongle device) (for PD100 only) (for PD120 only) RS232 Connector (for XD1170D only) (for XD1270D only) Description Lock Port Chapt er 1...

  • Page 14: Connecting The Projector

    Connecting the Projector Item Power Cord VGA Cable Composite Video Cable USB Cable VGA to Component / HDTV Adapter S-Video Cable Audio Cable Jack / Jack DVI Cable (Optional Accessory) 5V DC Output Jack for attached Dongle Device (for PD100 only) (for PD120 only) Chapt er 1 Description...

  • Page 15: Firware Upgrade

    Firmware Upgrade Equipment Needed Software : (DDP 2000- USB) - DLP Composer - Firmware (PD100 /PD100D / PD120 / PD120D/XD1170D/XD1270D) Hardware : Item Photo Projector (PD100 / PD100D) Power Cord USB Cable Item Photo Projector (PD120 / PD100D) Projector (XD1170D/XD1-...

  • Page 16: Installation Procedure

    Installation Procedure DLP Composer Lite Setup Procedure Step Procedure 1 Execute FW Choose "DLP Composer program Lite v3.6 Setup" program. Next Click "Next" button. Next 1. Reading the "License Agreement" rules. 2. Choose "I accept and agree to be bound by all the terms and conditions of this License Agreement"...
  • Page 17 Step Procedure Next 1. Choose "All" icon 2. Click "Next" button. Next Click "Next" button. Processing The program is executing "Initializing" status. Photo Chapt er 2...

  • Page 18: Usb Driver Upgrade Procedure

    USB Driver Upgrade Procedure Step Procedure 1 Set-up 1. Plug in USB Cable into the Projector. 2. Hold on "Menu" button and then plug in Power Cord. 3. Wait for about 5 seconds. (Note: The system fan will not function. The light will not function as well.) Execute Execute the C:\Program...
  • Page 19 Step Procedure Update Click "OK". The USB driver Successfully is updated successfully. Device 1. Right click "My computer" Manager on the desktop. 2. Select "Properties" on the popup menu to launch the "System Properties" window. 3. Choose "Hardware" and then click "Device Manager".

  • Page 20: Firmware Upgrade Procedure

    Firmware Upgrade Procedure Step Procedure 1 Set-up 1. Plug in USB Cable into the Projector. 2. Hold on "Menu" button and then plug in Power Cord. 3. Wait for about 5 seconds. (Note: The system fan will not function. The light will not function as well.) 2 Set-up Link PC COM1 and...
  • Page 21 4. Click "Reset Bus" to erase the flash memory. (Note: If the error message "cannot open USB driver - No projectors found" appears, please unplug the USB Cable and replug, then re-do 4. Click "Reset Bus" to erase the flash memory.)
  • Page 22 Step Procedure Proceeding Proceeding Picture 1. When Firmware Upgrade Process is finished, the LED power 2. Unplug USB Cable and Power Cord. Re-plug in Power Cable after 3 mins. 11 Check Restart the unit and enter Firmware the Service Mode to check the Firmware Version.

  • Page 23: Edid Upgrade

    (Fixture: JP3 must be closed) Item RS-232 Cable (F - M) DVI Cable (for "D" Model) VGA Cable Projector (PD100 / PD100D) Projector (XD1170D/ XD1270D) Photo Item Power Adapter for Fixture Generic Fixture Power Cord One additional monitor (for checking the...

  • Page 24: Setup Procedure

    Setup Procedure Step 1 Connect All Ports 1. Power Adapter to Fixture JP1 2. Fixture P1 to PC COM1 Port 3. Fixture P2 to Projector Analog Port 4. Fixture P3 to Projector Digital Port 2. Power On Fixture Power on Fixture EDID Key-In Procedure Step Procedure...
  • Page 25 Step Procedure Key in Serial 1. Key in the Serial Number Number into the Barcode blank space. 2. In "White Source Select", make a check in "VGA" and "DVI". (Only for "D" Model.) 3. Check the COM Port is "COM 1". 4.
  • Page 26 Step Procedure Check the 1. In the "Read Item" whole process Selections, choose the Port that you use. Ex: If you use the Analog Port, choose "Analog" in the "Read Item". Note: If the code in the Serial Blank is scrambled, please make a check in "Trans".

  • Page 27: Mechanical Disassembly And Reassembly

    Mechanical Disassembly & Reassembly This section provides disassembly & Reassembly procedures for PD100 Micro Portable SVGA DMD Projector. Before you begin any of these procedures, be sure to turn off the power, computer system, and other attached devices; then disconnect the power cable from the electrical outlet. Moreover, when you disassemble the projector, be sure to put the screws in a safe place and separate them according to their category. Equipment Needed Item Photo Philips (+) : 107 Screw Bit Tweezers General Information Before You Begin Before proceeding with the disassembly procedure, make sure that you do the following procedures: 1. Turn off the power of the system and all the peripherals. 2. Unplug the AC adapter and all power and signal cables from the system.

  • Page 28: Mechanical Disassembly Procedure

    Mechanical Disassembly Procedure 1. Remove Lamp Module Procedure Unscrew 2 screws to remove the Lamp Cover. Unscrew 2 screws to remove the Lamp Module. Chapter 3 Photo...
  • Page 29 2. Remove IO Cover / Top Cover Procedure Unscrew 2 screws & 6 hex screws to remove the IO Cover. 1. Lift up the Top Cover first and then pull the Bottom Cover for easily separting the Top Cover. 2. Remove 1 FPC Cable to remove the Top Cover. Photo Chapter 3...
  • Page 30 3. Remove Keypad Board Procedure 1. Unscrew 4 screws to remove the Keypad Board. 2. Separate the Keypad Module. Unscrew 2 screws to remove the Top Cover Shielding. Chapter 3 Photo...

  • Page 31: Push Button

    4. Remove Front Cover / IR Sensor Board / Elevator Push Button Procedure 1. Unscrew 1 screw to remove the IR Receiver. 2. Unscrew 2 screws to remove the Front Cover. Unplug 1 connector (red color) to remove the Front Cover Module. Remove the Front IR Cover directly, and loosen 2 tenons to remove the IR Receiver Board. Loosen 2 tenons to remove the Elevator Push Button directly. Photo Chapter 3...
  • Page 32 5. Remove Bottom Cover Module Procedure Remove Bottom Cover Sponge. Remove Side Covers. (Right Cover & Left Cover) Note 1: When disassembing the Side Cover, push the side cover outside forwards and then pull it up directly. Note 2: When reassembing the Side Cover, please locate & align the tenons as the picture shows. Unplug 2 tenons in the shieldings to separate the Bottom Cover Module with the unit. Chapter 3 Photo...

  • Page 33: Remove Main Board

    6. Remove Main Board Procedure Unplug 8 connectors first and then unscrew 4 screws. Note: When Reassembling the Main Board with the Top Cover, please be aware of the wire arrangement. The wire arrangement should go as the picture shows (not exceeding 1/2 of the red blank space) to best allocate the Top Cover Sponge. 1. Lift up the front part of Main Board first; then, take off the Main Board. 2. Unplug 1 connector to remove the Main Board. Photo Chapter 3...
  • Page 34 7. Remove EMI Shielding / Speaker Procedure Unscrew 4 screws to remove the EMI Shielding Cover of units. Unscrew 2 screws to remove the Speaker. Note: The Speaker isn’t designed with error-proof. Please be aware of wire-arrangement as the picture shows. Chapter 3 Photo...
  • Page 35 8. Remove Axial Fan Module Procedure Unscrew 3 screws to remove Axial Fan Module. Unscrew 4 screws to remove the System Fan. Note: The System Fan isn’t designed with error-proof. Please be aware of the wire- arrangement. Photo Chapter 3...

  • Page 36: Remove Lamp Driver

    9. Remove Lamp Driver Procedure Unscrew 4 screws. Unplug 2 connectors to remove the Lamp Driver Module. Note: When assembling the LVPS, please be aware of the LVPS connector connection. (the shorter wire should be connected to the LVPS, and the longer wire should be connected to the Lamp Driver.) Unscrew 4 screws to separate the Lamp Driver Housing. Chapter 3 Photo...
  • Page 37 10. Remove LVPS / Interlock Swtich / Thermal Switch Procedure 1. Unscrew 4 screws 2. Unscrew 1 screw in the grounding wire. 3. Unplug 1 connector in the Interlock Swtich to remove the LVPS. 1. Unscrew 2 screws to remove the Interlock Switch. 2. Unscrew 1 screw to remove the Assy Thermal Switch Board. Photo Chapter 3...

  • Page 38: Remove Engine Module

    11. Remove Engine Module Procedure Unscrew 3 screws to remove the Engine Module. 1. Unscrew 1 screw to remove the Light Cut. 2. Unscrew 1 screw to remove the Thermal Sensor. Unscrew 1 screw to remove Photo Sensor Board. 1. Unscrew 4 screws and tear off 1 EMI tape to remove the Heatsink. 2. Unscrew 4 big hex screws to remove the DMD Board. 3. Separate the DMD Board. Chapter 3 Photo...
  • Page 39 Procedure When reassembling the DMD Module, please be aware of the following Notes. Note1: The DMD Heasink Spring Plate should be placed as the picture shows. Note 2: The DMD Insulator Mylar & DMD Heatsink Backer Plate should be placed as the picture shows. Note 3: The DMD Chip should be reassembled as the picture shows. Unscrew 1 screw to remove the Color Wheel. 1. Unscrew 2 screws to remove the Zoom Ring & Stopper. 2. Unscrew 3 screws to remove the Focus Ring. Photo Zoom Ring Zoom Ring Stopper Chapter 3...
  • Page 40 12. Remove Elevator / Blower Fan Procedure Unscrew 4 screws to remove the Elevator. Unscrew 3 screws to remove the Blower Fan. Chapter 3 Photo...

  • Page 41: Mechanical Reassembly Procedure

    Mechanical Reassembly Procedure 1. Assemble Elevator / Blower Fan Procedure Screw 4 screws to assemble the Elevator. Screw 3 screws to assemble the Blower Fan. Photo Chapter 3...

  • Page 42: Assemble Engine Module

    2. Assemble Engine Module Procedure 1. Screw 2 screws to assemble the Zoom Ring & Stopper. 2. Screw 3 screws to assemble the Focus Ring. Screw 1 screw to assemble the Color Wheel. When reassembling the DMD Module, please be aware of the following Notes. Note1: The DMD Heasink Spring Plate should be placed as the picture shows. Note 2: The DMD Insulator Mylar & DMD Heatsink Backer Plate should be placed as the picture shows. Note 3: The DMD Chip should be reassembled as the picture shows. Chapter 3 Photo Zoom Ring Zoom Ring Stopper...
  • Page 43 Procedure 1. Assemble the DMD Board Components. 2. Screw 4 big hex screws to assemble the DMD Board. 3. Screw 4 screws and put on 1 EMI tape to assemble the Heatsink. Screw 1 screw to assemble the Photo Sensor Board. 1. Screw 1 screw to assemble the Light Cut. 2. Screw 1 screw to assemble the Thermal Sensor. Assemble 3 screws to assemble the Engine Module. Photo Chapter 3...
  • Page 44 3. Assemble Interlock Swtich / Thermal Switch / LVPS Procedure 1. Screw 2 screws to assemble the Interlock Switch. 2. Screw 1 screw to assemble the Assy Thermal Switch Board. 1. Screw 4 screws 2. Screw 1 screw in the grounding wire. 3. Plug 1 connector in the Interlock Swtich to assemble the LVPS. Chapter 3 Photo...
  • Page 45 4. Assemble Lamp Driver Procedure Screw 4 screws to assemble the Lamp Driver Housing. Plug in 2 connectors. Note: Please be aware of the wire arrangement of the LVPS with the Lamp Driver. (The shorter wire should be connected to the LVPS; while the longer wire should be connected to the Lamp Driver.) Screw 4 screws to assemble the Lamp Driver Module. Photo Chapter 3...
  • Page 46 5. Assemble Axial Fan Module Procedure Screw 4 screws to assemble the System Fan. Screw 3 screws to assemble Axial Fan Module. Note: Please be aware of the wire arrangement of the system fan. (the wire should be in the upper left side.) Chapter 3 Photo...
  • Page 47 6. Assemble Speaker / EMI Shielding Procedure Screw 2 screws to assemble the Speaker. Note: Please be aware of the wire arrangement of the speaker. Screw 4 screws to assemble the EMI Shielding Cover of Units. Photo Chapter 3...
  • Page 48 7. Assemble Main Board Procedure 1. Plug 1 connector. 2. Locate the front part of Main Board. Screw 4 screws and plug in 8 connectors to assemble the Main Board. Note: When Reassembling the Main Board with the Top Cover, please be aware of the wire arrangement. The wire arrangement should go as the picture shows (not exceeding 1/2 of the red blank space) to best allocate the Top Cover Sponge. Chapter 3 Photo...

  • Page 49: Assemble Bottom Cover Module

    8. Assemble Bottom Cover Module Procedure Assemble the shieldings with the Main Unit based on the 2 tenons. Assemble Side Covers. (Right Cover & Left Cover) Note: When reassembing the Side Cover, please locate & align the tenons as the picture shows. Assemble the Bottom Cover Sponge. Photo Chapter 3...
  • Page 50 9. Assemble Front Cover / IR Sensor Board / Elevator Push Button Procedure Assemble the Elevator Push Button directly. Assemble the IR Receiver Board and put on the Front IR Cover directly. Plug in 1 connector (red color) to assemble the Front Cover Module. 1. Screw 1 screw to assemble the IR Receiver. 2. Screw 2 screws to assemble the Front Cover. Chapter 3 Photo...
  • Page 51 10. Assemble Keypad Board Procedure Screw 2 screws to assemble the Top Cover Shielding. 1. Assemble the Keypad Module. 2. Screw 4 screws to assemble the Keypad Board. Photo Chapter 3...
  • Page 52 11. Assemble Top Cover / IO Cover Procedure 1. Put on 1 FPC Cable to assemble the Top Cover. 2. Push the Bottom Cover first; then, push down the Top Cover to assemble the Top Cover. Screw 2 screws & 6 hex screws to assemble the IO Cover. Chapter 3 Photo...

  • Page 53: Assemble Lamp Module

    12. Assemble Lamp Module Procedure Screw 2 screws to assemble the Lamp Module. Screw 2 screws to assemble the Lamp Cover. Photo Chapter 3...

  • Page 54: Troubleshooting

    Troubleshooting Equipment Needed - PC or Pattern Generator - DVD Player (Video, S-Video, Audio) - Quantum Data 802B or CHROMA 2327 LED Lighting Message Message Standby State (Input power cord) Lamp lighting Power on Power off (Cooling) Error (Lamp fail) Error (Thermal fail) Error (Fan lock fail) Error (Over Temp.)

  • Page 55: Main Procedure

    Main Procedure Symptom No Power Auto Shut Down No Image No Light On Mechanical Noise Line Bar / Line Defect Image Flicker Color Abnormal Procedure - Ensure the Power Cord and AC Power Outlet are securely connected - Check Lamp Cover and Interrupt Switch - Ensure all connectors are securely connected and aren't broken - Check DC-DC - Check Ballast...
  • Page 56 Symptom Poor Uniformity / Shadow Dead Pixel / Dust (Out of spec.) Garbage Image Remote Controll or Control Panel Failed Function Abnormal Chapt er 4 Procedure - Ensure the Projection Screen without dirt - Ensure the Projection Lens is clean - Ensure the Brightness is within spec.

  • Page 57: Function Test And Alignment Procedure

    Function Test & Alignment Procedure Product - PD100 / PD100D/ PD120D / PD120 / XD1170D / XD1270D Test Equipment - IBM PC with XGA resolution (Color Video Signal & Pattern Generator) - DVD player with Multi-system (NTSC/PAL/SECAM), equipped “Component” “S-Video” and “Composite”...

  • Page 58: Inspection Procedure

    Inspection Procedure Step Specification Frequency Eliminate visual and Tracking wavy noise by Rsync, Frequency or Tracking selection. Boundary Horz. And Vert. position of video should be adjustable to be the screen frame. Focus The text in the corner should be clear after adjust the focus ring.
  • Page 59 Step Specification Light Leak The unit can't accept the leakage is brighter than Gray 10 pattern Calibration Calibration Pattern should be in full screen mode Contrast / Gray level should Brightness distinguishable and without color abnormal 10 R, G, B and Each R, G, B White Color color should be...
  • Page 60 Step Specification 11 Dead Pixel Cannot accept (Bright pixel) any bright pixel Dead Pixel The numbers of (Dark pixel) dead pixel should be smaller or amount to 6 pixel. 12 Blemish The bright (Bright) blemish cannot be accepted if the problem appear with Gary 30 pattern 13 Blemish...

  • Page 61: Guide To Entering Service Mode And Factory Reset (Pd100)

    Guide to Entering Service Mode and Factory Reset Item Service Mode Please do the following steps to enter Service Mode: 1. Turn on the projector. 2. Press "Power", "Left" button, "Left" button and "Menu" by order to enter the Power Factory Reset After final QC step, we have to erase all saved change again and restore the factory defaults.

  • Page 62: Exploded Overview

    Exploded Overview PD100 Exploded Overview Exploded Parts List Item Part Number 70.82V22G001 ASSY FRONT COVER MODULE PD100 70.82V24G001 ASSY TOP COVER MODULE PD100 70.82V15G001 ASSY BOTTOM HOUSING MODULE PD100 70.82G09G001 ASSY LAMP MODULE EP7190 70.82V23G001 ASSY BACK COVER DC MODULE PD100 70.82V33G001 ASSY LAMP COVER MODULE PD100 85.1A323.100...
  • Page 63 PD120 Exploded Overview Exploded Parts List Item Part Number 70.82V03G001 70.82V07G001 70.82V01G001 70.82G09G001 70.82V14G001 70.82V32G001 85.1A323.100 85.005AGG040 85.5A323.060 61.00079G001 61.00018G002 Note: Please refer to RSPL for updated Part Number. ASSY FRONT COVER MODULE PD120 ASSY TOP COVER MODULE PD120 ASSY BOTTOM HOUSING MODULE PD120 ASSY LAMP MODULE EP7190 ASSY BACK COVER DC MODULE PD120 ASSY LAMP COVER MODULE PD120...
  • Page 64 PD100 Assy Bottom Housing Module Exploded Parts List Item Part Number 70.82V09G001 70.82V17G001 61.82G12G001 70.82V10G001 70.82V04G001 80.82V51G001 51.82V19G001 70.82V25G001 52.82V04G001 51.82G16G001 42.87120G001 85.1A123.050 85.1A626G050 70.82G19G001 41.82G03G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 ASSY BOTTOM BASE MODULE PD120 ASSY ENGINE MODULE PD100 LAMP LIGHTCUT TOP FOR E19 AL 0.6t EP7190 ASSY AXIAL FAN MODULE PD120...
  • Page 65 PD120 Assy Bottom Housing Module Exploded Parts List Item Part Number 70.82V09G001 70.82V11G001 61.82G12G001 70.82V10G001 70.82V04G001 80.82V01G001 51.82V19G001 70.82V02G001 52.82V04G001 51.82G16G001 42.87120G001 85.1A123.050 85.1A626G050 70.82G19G001 41.82G03G001 Note: Please refer to RSPL for updated Part Number. ASSY BOTTOM BASE MODULE PD120 ASSY ENGINE MODULE PD120 LAMP LIGHTCUT TOP FOR E19 AL 0.6t EP7190 ASSY AXIAL FAN MODULE PD120...
  • Page 66 PD100 Assy Bottom Cover Module Exploded Parts List Item Part Number 51.82V02G002 51.82V17G001 51.82V18G001 52.89601.001 86.03123.035 52.82V10G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 BOTTOM COVER PC+ABS PD100 LEFT COVER PC+ABS PD120 RIGHT COVER PC+ABS PD120 ADJUST FOOT RUBBER EP759 HEX CAP HEAD NUT M3*0.5P L3.5 NI BOTTOM COVER SPONGE-2 PD120...
  • Page 67 PD120 Assy Bottom Cover Module Exploded Parts List Item Part Number 51.82V02G001 51.82V17G001 51.82V18G001 52.89601.001 86.03123.035 52.82V10G001 Note: Please refer to RSPL for updated Part Number. BOTTOM COVER PC+ABS PD120 LEFT COVER PC+ABS PD120 RIGHT COVER PC+ABS PD120 ADJUST FOOT RUBBER EP759 HEX CAP HEAD NUT M3*0.5P L3.5 NI BOTTOM COVER SPONGE-2 PD120 Description...
  • Page 68 PD120 Assy Bottom Base Module Exploded Parts List Item Part Number 49.88604.002 85.1A123.050 52.82G11G001 61.82V01G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 SPEAKER 8ohm 2W X16 EP759 SCREW PAN MECH M3*5 Ni SPEAKER SPONGE EP7190 EMI SHIELDING AL PD120 Description...
  • Page 69 PD100 Assy Top Cover Module Exploded Parts List Item Part Number 51.82V03G001 61.82V04G001 51.82Q03G001 51.82Q05G001 51.82Q06G001 80.82Q03G001 61.82V03G001 85.WA123.040 42.82V02G001 51.82Q04G011 41.82V05G001 41.82V04G001 41.81M02G001 Note: Please refer to RSPL for updated Part Number. TOP COVER PC+ABS PD120 TOP COVER SHIELDING SPTE PD120 KEYPAD MAIN BUTTON PC+ABS PD322 LED HOUSING PC PD322 POWER LED HOUSING PC PD322...
  • Page 70 PD120 Assy Top Cover Module Exploded Parts List Item Part Number 51.82V03G001 61.82V04G001 51.82Q03G001-B 51.82Q05G001 51.82Q06G001-B 80.82Q03G001 61.82V03G001 85.WA123.040 42.82V02G001 51.82Q04G011 41.82V05G001 41.82V04G001 41.81M02G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 TOP COVER PC+ABS PD120 TOP COVER SHIELDING SPTE PD120 KEYPAD MAIN BUTTON PC+ABS PD322 LED HOUSING PC PD322...
  • Page 71 PD120 Assy Bottom Base Module Exploded Parts List Item Part Number 61.82G01G001 51.85816.001 51.85824.001 75.88514.002 85.1A62G.050 70.82V34G001 61.00029.001 61.87340G001 85.3A122.040 41.82V01G001 76.82G01G001 61.85913.001 80.82V04G001 51.82G24G001 70.82V26G001 85.1C224G050 85.1A123.050 70.82V31G001 52.88504G001 Note: Please refer to RSPL for updated Part Number. BASE PLATE Mg ALLOY AZ91D EP7190 LIMIT SWITCH HOLDER PPS XB31 LIMIT SWITCH BOTTOM HOLDER PPS XB31 ASSY LIMIT SWITCH CHERRY DB3C A1LB-5A...
  • Page 72 PD120 Assy Axial Fan Module Exploded Parts List Item Part Number 49.80N01G001 61.82V02G001 85.1F123.260 52.82V07G001 51.00075.001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 SUNON 70*20 R-TYPE AXIAL FAN, GM1207PKVX-A 70*70*20mm, JST CONNECTOR,GREEN SUMITUDE FAN-LAMP BRACKET AL PD120 SCREW PAN MECH E/SF M3*26 Ni LAMP BRACKET SPONGE PD120 WIRE MOUNTS PG-FW-4D XB31...
  • Page 73 PD100 Assy Engine Module Exploded Parts List Item Part Number 70.82V27G001 70.82V18G001 85.1A123.050 41.82V02G001 Note: Please refer to RSPL for updated Part Number. ASSY ENGINE BOTTOM COVER MODULE PD120 ASSY ENGINE TOP MODULE PD100 SCREW PAN MECH M3*5 Ni EMI TAPE W30*L30mm PD120 Description Chapt er 5...
  • Page 74 PD120 Assy Engine Module Exploded Parts List Item Part Number 70.82V27G001 70.82V12G001 85.1A123.050 41.82V02G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 ASSY ENGINE BOTTOM COVER MODULE PD120 ASSY ENGINE TOP MODULE PD120 SCREW PAN MECH M3*5 Ni EMI TAPE W30*L30mm PD120 Description...
  • Page 75 PD100 Assy Engine Top Cover Module Exploded Parts List Item Part Number 11.009F0G005-C 23.82G01G002 48.859DMGD13 51.80B31G002 51.82V09G001 51.82V10G001 51.82G08G001 51.82G22G001 52.82G03G002 52.82G10G001 52.87130G001 52.87319G001 52.89627G002 61.80J48G002 61.82G02G001 61.83A03G001 61.88608G001 61.88611G001 61.89643G001 00.82V02G001 85.1A123.050 85.1A123.060 85.YA321G051 Note: Please refer to RSPL for updated Part Number. CNNT F 166P FOR 0.55"...
  • Page 76 PD120 Assy Engine Top Cover Module Exploded Parts List Item Part Number 11.009F0G005 23.82G01G002 48.82GDMGD01 51.80B31G002 51.82V09G001 51.82V10G001 51.82G08G001 51.82G22G001 52.82G03G002 52.82G10G001 52.87130G001 52.87319G001 52.89627G002 61.80J48G002 61.82G02G001 61.83A03G001 61.88608G001 61.88611G001 61.89643G001 00.82V02G001-B 85.1A123.050 85.1A123.060 85.YA321G051 Note: Please refer to RSPL for updated Part Number. Chapt er 5 CNNT F 166P FOR 0.55"...
  • Page 77 PD120 Assy Back Cover DC Module Exploded Parts List Item Part Number 51.82V12G001 51.82V21G001 41.82V12G001 51.82V04G011 Note: Please refer to RSPL for updated Part Number. BACK IR LENS PC PD120 BACK IO OVERLAY-DC PC PD120 EMI TAPE W41*L129mm PD120 BACK COVER-DC PC+ABS PD120 Description Chapt er 5...
  • Page 78 PD100 Assy Back Cover DC Module Exploded Parts List Item Part Number 51.82V12G001 51.82V21G001 41.82V12G001 51.82V04G012 Note: Please refer to RSPL for updated Part Number. Chapt er 5 BACK IR LENS PC PD120 BACK IO OVERLAY-DC PC PD120 EMI TAPE W41*L129mm PD120 BACK COVER-DC PC+ABS PD100 Description...
  • Page 79 FRONT PUSH BUTTON PC+ABS PD100 FRONT IR LENS PC PD120 FRONT IR COVER RUBBER PD120 PCBA IR SENSOR BD FOR PD120 MODEL NAME LABEL PC PD100 ACER LOGO LABEL PD120 FRONT COVER SPONGE PD120 MYLAR LIGHT CUT PD120 Description Chapt er 5...
  • Page 80 PD120 Assy Blower Fan Module Exploded Parts List Item Part Number 49.83A01G001 52.82G08G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 DELTA 4520 BLOW BLOWER 4520 RUBBER EP7190 Description...
  • Page 81 PD120 Assy Engine Bottom Cover Module Chapt er 5...
  • Page 82 Exploded Parts List Item Part Number 23.82G02G001 23.82G06G001 23.82G10G001 23.82G20G001 23.82G20G011 43.80N01G001 51.82G13G001 52.82G04G002 52.82G09G001 52.82G12G001 52.82G13G001 52.82G14G001 61.82G03G001 61.82G11G001 51.82G25G001 61.82G19G001 61.82G21G001 61.82G22G001 70.82G15G001 70.83S05G001 75.82G08G001 85.0A122G030 85.1A123.050 85.1A523G080 Note: Please refer to RSPL for updated Part Number. Chapt er 5 MIRROR WITH ONE COATING SURFACE ASPHERICAL ZEONEX RELAY LENS SQUARE UV-IR 17*17mm^2 T=2.75mm...
  • Page 83 PD120 Assy Lens Cap Module Exploded Parts List Item Part Number 52.82V01G001 61.82V08G001 51.83150G001 Note: Please refer to RSPL for updated Part Number. LENS COVER RUBBER PD120 LENS COVER PLATE PD120 CAP STRAP TDP-T90 Description Chapt er 5...
  • Page 84 PD120 Assy LVPS Module Exploded Parts List Item Part Number 42.80S07G001 42.81G01.001 75.80W19G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 W.A. 14P 190mm LVPS TO M/B TDP-T90 '' W.A. 2P #20 160mm LAPS/BALLAST H31 ASSY LVPS LITEON 200W 2300MP Description...
  • Page 85 PD100 Assy Lamp Cover Module Exploded Parts List Item Part Number 51.82V13G002 61.82V09G001 52.82V08G001 Note: Please refer to RSPL for updated Part Number. LAMP COVER NORYL 9406P PD100 LAMP COVER PLATE SPTE PD120 LAMP COVER SPONGE PD120 Description Chapt er 5...
  • Page 86 PD120 Assy Lamp Cover Module Exploded Parts List Item Part Number 51.82V13G001 61.82V09G001 52.82V08G001 Note: Please refer to RSPL for updated Part Number. Chapt er 5 LAMP COVER NORYL 9406P PD120 LAMP COVER PLATE SPTE PD120 LAMP COVER SPONGE PD120 Description...
  • Page 87 PD120 Assy Elevator Module Exploded Parts List Item Part Number 51.82V06G001 51.82V07G001 51.86809.001 61.86814.001 61.85913.001 Note: Please refer to RSPL for updated Part Number. ELEVATOR HOLDER PC+ABS PD120 ELEVATOR PUSH PC+ABS PD120 ELEVATOR BODY NYLON+GF DP725 ELEVATOR EXTEND SPRING DP725 ELEVATOR SPRING SUS304 SB21 Description Chapt er 5...
  • Page 88 Appendix A Exploded Overview D.C. XD1170D Chapt er 5...
  • Page 89 85.5A323G060 61.00079G001 61.00018G002 51.00001G001 Chapt er 5 Description ASSY FRONT COVER MODULE XD1170D ASSY TOP COVER MODULE-1 XD1270D ASSY BOTTOM HOUSING MODULE XD1170D ASSY LAMP MODULE XD1270D ASSY BACK COVER MODULE XD1270D BUY ASSY LAMP COVER MODULE XD1270D SCREW PAN MECH M3*10 BLACK...
  • Page 90 ASSY FRONT COVER MODULE XD1170D Item 51.82V01G011 51.82V08G011 51.82V11G001 52.82V02G001 80.82V05G001 35.82V01G032 52.82V11G001 51.82V22G001 41.82V18G001 52.82V09G001 Chapt er 5 Description FRONT COVER NORYL 9406P XD1270D FRONT PUSH BUTTON PC+ABS XD1270D FRONT IR LENS PC PD120 FRONT IR COVER RUBBER PD120...
  • Page 91 ASSY ENGINE MODULE XD1170D Item 70.82V52G001 70.82V54G001 85.1A123G050 41.82K09G001 Chapt er 5 Description ASSY ENGINE BOTTOM COVER MODULE XD1270D ASSY ENGINE TOP COVER MODULE XD1170D SCREW PAN MECH M3*5 Ni EMI TAPE 30*50mm...
  • Page 92 ASSY BOTTOM HOUSING MODULE XD1170D Chapt er 5...
  • Page 93 ASSY ENGINE MODULE XD1170D LAMP LIGHTCUT TOP FOR E19 AL ASSY AXIAL FAN MODULE PD120 ASSY BOTTOM EMI SHIELDING MODULE XD1270D PCBA MAIN BOARD FOR XD1170D ZOOM RING MYLAR XD1270D ASSY BOTTOM COVER MODULE XD1270D BOTTOM COVER SPONGE-2 PD120 ELEVATOR FOOT PC+ABS EP719 W.A.
  • Page 94 ASSY ENGINE TOP COVER MODULE XD1170D Chapt er 5...
  • Page 95 PART NUMBER LIST Item 11.009F0G005 23.85R01G001 48.859DMGD13 51.80B31G002 51.82G22G001 52.82G03G002 52.82G10G001 52.87130G001 52.87319G001 52.89627G002 61.80J48G002 61.82G02G001 61.83A03G001 61.88608G001 61.88611G001 61.89643G001 80.82V02G001 85.1A123G050 85.1A123G060 Chapt er 5 Description CNNT F 166P FOR 0.55" SVGA LGA DMD SOCKET;FOXCONN PROJECTION LENS YM09H DMD 800*600 PIXEL DDR FTP 0.55" SVGA DMD INSULATOR MYLAR 0.435t T90 ZOOM ANTI-ABRASION TEFLON EP7190 "GREEN"...
  • Page 96 XD1170D PROJECTION DISPLAY PROJECTOR ASSY SYSTEM FAN 80x25 MODULE Chapt er 5...
  • Page 97 42.53506G002 42.83620G002 Chapt er 5 Description D.C. XD1170D USER'S GUIDE MULTILINGUAL (CD) ACER PD127 CABLE VGA 15P 1.8M BLK 2100MP ADAPTER D-SUB TRANSFORM RCA JACK PD120 INFRARED REMOTE CONTROLLER PD100 ACER QUICK START CARD MULTILINGUAL ACER PD127 WARRANTY CARD ,EUROPE FOR ACER CABLE COMPOSITE VIDEO 1.8M 3200MP...
  • Page 98 Appendix A Exploded Overview D.C. XD1270D Chapter 5...
  • Page 99 Item 70.82V45G001 70.82V63G001 70.82V41G001 70.82V61G001 70.82V48G001 75.82V09G011 85.1A323G100 85.005AGG040 85.5A323G060 61.00079G001 61.00018G002 51.00001G001 Chapter 5 Description ASSY FRONT COVER MODULE XD1270D ASSY TOP COVER MODULE-1 XD1270D ASSY BOTTOM HOUSING MODULE XD1270D ASSY LAMP MODULE XD1270D ASSY BACK COVER MODULE XD1270D BUY ASSY LAMP COVER MODULE XD1270D SCREW PAN MECH M3*10 BLACK SCREW I/O STEEL #4-4UNC*H4*L5...
  • Page 100 ASSY LVPS MODULE XD1270D Item 42.82V04G001 42.81G01G001 75.80W18G002 Chapter 5 Description W.A. 14P/16P 190mm LVPS TO M/B XD1270D W.A. 2P #20 160mm LAPS/BALLAST PD120 ASSY LVPS MATRITEK 200W EP719(CT2300-B)
  • Page 101 ASSY BOTTOM HOUSING MODULE XD1270D Chapter 5...
  • Page 102 PART NUMBER LIST Item 70.82V42G001 70.82V50G001 61.82G12G001 70.82V10G001 70.82V59G001 80.82V31G002 51.82V19G011 70.82V60G001 52.82V04G002 51.82G16G001 42.87120G001 85.1A123.050 85.1A626G050 70.82V44G001 43.80N01G001 51.82V09G011 85.YA321G052 51.82V10G011 51.82G08G002 Chapter 5 Description ASSY BOTTOM BASE MODULE XD1270D ASSY ENGINE MODULE XD1270D LAMP LIGHTCUT TOP FOR E19 AL ASSY AXIAL FAN MODULE PD120 ASSY BOTTOM EMI SHIELDING MODULE XD1270D PCBA MAIN BOARD FOR XD1270D...
  • Page 103 ASSY BOTTOM BASE MODULE XD1270D Chapter 5...
  • Page 104 PART NUMBER LIST Item 61.82G01G002 51.85816G001 51.85824G001 75.88514G002 85.1A626G050 70.82V64G001 61.00029G001 61.87340G001 85.3A122G040 41.82V01G001 42.82G05G001 61.85913G001 80.82V04G001 51.82G24G001 70.82V26G001 85.1C224G050 85.1A123G050 70.82V43G001 52.88504G001 41.80W02G001 51.00001G001 Chapter 5 Description BASE PLATE Mg ALLOY AZ91D EP719H/EP716P LIMITS SWITCH HOLDER PPS XB31 LIMIT SWITCH BOTTOM HOLDER PPS XB31 ASSY LIMIT SWITCH CHERRY DB3C A1LB-5A SCREW PAN MECH M2.6*5 BLACK NYLOK ASSY ELEVATOR MODULE XD1270D...
  • Page 105 ASSY LAMP DRIVER MODULE XD1270D Item 42.82G01G001 51.82G17G011 51.82G23G001 75.85W04G001 85.WA123G060 Chapter 5 Description W.A. 5P #28 200mm LAMP DRIVER TO MAIN BD EP719 "GREEN" LAMP DRIVER HOLDER PC MN3600H XD1270D LAMP DRIVER INSULATION MYLAR EP7190 ASSY PHILIPS LAMPDRIVER 200W EUC 200D/V11 913700822269 SCREW PAN TAP M3*6 Ni...
  • Page 106 ASSY FRONT COVER MODULE XD1270D Item 51.82V01G011 51.82V08G011 51.82V11G001 52.82V02G001 80.82V05G001 35.82V01G031 52.82V11G001 51.82V22G001 41.82V18G001 52.82V09G001 Chapter 5 Description FRONT COVER NORYL 9406P XD1270D FRONT PUSH BUTTON PC+ABS XD1270D FRONT IR LENS PC PD120 FRONT IR COVER RUBBER PD120 PCBA IR SENSOR BD FOR PD120 MODEL NAME LABEL PC XD1270D FRONT COVER SPONGE PD120 MYLAR LIGHT CUT PD120...
  • Page 107 ASSY BACK COVER MODULE XD1270D ASSY SYSTEM FAN 80x25 MODULE Item 51.86B01G011 35.86B01G001 41.86B01G001 41.82V21G001 Chapter 5 Description BACK COVER PC+ABS XD1280D BACK IO OVERLAY PC XD1280D EMI TAPE W41*L129mm XD1280D EMI TAPE W10*H1*L35 MM...
  • Page 108 ASSY ENGINE MODULE XD1270D Item 70.82V52G001 70.82V51G001 85.1A123G050 41.82K09G001 Chapter 5 Description ASSY ENGINE BOTTOM COVER MODULE XD1270D ASSY ENGINE TOP COVER MODULE XD1270D SCREW PAN MECH M3*5 NI EMI TAPE 30*50mm...
  • Page 109 ASSY ENGINE TOP COVER MODULE XD1270D Chapter 5...
  • Page 110 Item 11.009F0G005 23.85R01G001 48.82GDMGD01 51.80B31G002 51.82G22G001 52.82G03G002 52.82G10G001 52.87130G001 52.87319G001 52.89627G002 61.80J48G002 61.82G02G001 61.83A03G001 61.88608G001 61.88611G001 61.89643G001 80.82V02G001 85.1A123G050 85.1A123G060 Chapter 5 Description CNNT F 166P FOR 0.55" SVGA LGA DMD SOCKET;FOXCONN PROJECTION LENS YM09H DMD 1024X768 PIXEL DDR FTP 0.55" XGA DMD INSULATOR MYLAR 0.435t T90 ZOOM ANTI-ABRASION TEFLON EP7190 "GREEN"...
  • Page 111 ASSY ENGINE BOTTOM COVER MODULE XD1270D Chapter 5...
  • Page 112 Item 23.82G02G001 23.82G06G001 23.82G10G004 23.82G20G001 23.82G20G011 52.82V12G001 51.82G13G001 52.82G04G002 52.82G09G001 52.82G12G001 52.82G13G001 52.82G14G001 61.82G03G003 61.82G11G001 51.82G25G001 61.82G19G001 61.82G21G001 61.82G22G001 70.85R19G001 70.83S05G001 75.82G08G001 85.0A122G030 85.1A123G050 85.1A523G080 85.1A123G080 Chapter 5 Description MIRROR WITH ONE COATING ASPHERICAL ZEONEX RELAY LENS EP719 SQUARE UV-IR 17*17mm^2 T=2.75mm(ROAST) BK7 CONDENSER LENS 13mm BK7 CONDENSER LENS 15mm ENGINE BOTTOM SPONGE PD120...
  • Page 113 ASSY BOTTOM EMI SHIELDING MODULE XD1270D Item 49.88604.002 85.1A123.050 52.82G11G001 61.82V01G005 51.82V29G001 Chapter 5 Description SPEAKER 8ohm 2W %%C16EP759 SCREW PAN MECH M3*5 NI SPEAKER SPONGE EP7190 EMI SHIELDING AL5052 0.6t XD1270D MYLAR FOR EMI SHIELDING XD1270D...
  • Page 114 ASSY BOTTOM COVER MODULE XD1270D Item 51.82V02G011 51.82V17G011 51.82V18G002 52.89601G003 86.03123G035 52.82V10G001 Chapter 5 Description BOTTOM COVER PC+ABS XD1270D LEFT COVER PC+ABS XD1270D RIGHT COVER PC+ABS XD1280D ADJUST FOOT RUBBER 65 DEGREE PD120 HEX CAP HEAD NUT M3*0.5P L3.5 NI BOTTOM COVER SPONGE-2 PD120...
  • Page 115 ASSY LAMP MODULE XD1270D Item 70.82G10G001 70.82V62G001 85.1A126G040 Chapter 5 Description ASSY LAMP HOLDER MODULE EP7190 ASSY LAMP CHANGE PLATE MODULE XD1270D SCREW PAN MECH M2.6*4 Ni...
  • Page 116 ASSY LAMP CHANGE PLATE MODULE XD1270D Item 51.82G14G001 61.80511G001 61.82G29G002 61.87125G001 Chapter 5 Description LAMP CHANGE PLATE PPS EP7190 SCREW PAN MECH M3*8-4 BLACK LAMP CHANGE PLATE FOIL AL 0.2t EP7190 LAMP HADNLER SUS304...
  • Page 117 ASSY TOP COVER MODULE-1 XD1270D Item 51.82V03G003 70.82V58G001 51.82Q03G011 51.82Q05G001 51.82Q06G001 80.82Q03G003 61.82V03G001 85.WA123G040 42.86B02G001 51.82Q04G021 41.82V13G001 51.86B02G001 80.83K04G001 Chapter 5 Description TOP COVER PC+ABS XD1270D ASSY TOP COVER SHIELDING MODULE XD1270D KEYPAD MAIN BUTTON PC+ABS XD1270D LED HOUSING PC PD322 POWER LED HOUSING PC PD322 PCBA KEYPAD BOARD PD322 KEYPAD SHIELDING AL PD120...
  • Page 118 ASSY ELEVATOR MODULE XD1270D Item 51.82V06G001 51.82V07G001 51.86809G011 61.86814G001 61.82V10G001 Chapter 5 Description ELEVATOR HOLDER PC+ABS PD120 ELEVATOR PUSH PC+ABS PD120 ELEVATOR BODY PC+ABS C6600 EP7190 ELEVATOR EXTEND SPRING PD120 ELEVATOR SPRING SUS304 XD1270D...
  • Page 119 XD1270D PROJECTION DISPLAY PROJECTOR Chapter 5...
  • Page 120 42.53506G002 42.83620G002 Chapter 5 Description D.C. XD1270D USER'S GUIDE MULTILINGUAL (CD) ACER PD127 CABLE VGA 15P 1.8M BLK 2100MP ADAPTER D-SUB TRANSFORM RCA JACK PD120 REMOTE CONTROLLER FOR PD523PW QUICK START CARD MULTILINGUAL ACER PD127 WARRANTY CARD ,EUROPE FOR ACER CABLE COMPOSITE VIDEO 1.8M 3200MP...

  • Page 121: Appendix

    Serial Number Definition System Serial Number System Definition Serial No. (Acer Barcode rule), 22 digits (Barcode Type: Code 128) The coding rule of the Bard Code: (1) PPPPPPPPPP (10 digitals) : Part Number excluded “dot” Ex: EY.J1401.001. (2) WWW (3 digitals) : Week Code The first digit is the last letter of the year;...

  • Page 122: Pcba Code Definition

    PCBA Code Definition PCBA Code for Projector XXXXXXXXXX C Vendor Code Revision Date Code C: M/B B: DMD/ B EEEE Appendix...

  • Page 123: The Different Parts (Pd100 / Pd100D / Pd120 / Pd120D / Xd1170D / Xd1270D )

    III. The Different Parts PD100 / PD100D / PD120 / PD120D / XD1170D / XD1270D The Different Parts between PD100 and PD120 Ver. 48.859DMGD13 A DMD 800*600 PIXEL DDR FTP 0.55 48.82GDMGD01 A DMD 1024*768 PIXEL DDR FTP 0.5 51.82V02G002 BOTTOM COVER PC+ABS PD100 51.82V02G001...
  • Page 124 The Different Parts between PD100D and XD1170D Ver. 42.82V04G001 W.A. 14P/16P 190mm LVPS TO M/B 42.80S07G001 W.A. 14P 190mm LVPS TO M/B TDP 75.80W18G002 ASSY LVPS MATRITEK 200W EP719(CT2300-B) 75.80W19G001 ASSY LVPS LITEON 200W 2300MP 23.85R01G001 PROJECTION LENS YM09H 23.82G01G002 PROJECTION LENS BARREL CHA 61.82G03G003...
  • Page 125 ENGINE BOTTOM COVER Mg ALLOY AZ91D EP7190 23.85W19G001 R90Y30G80W86B74 COLOR WHEEL,UNAXIS 23.82G19G001 R92G83B75W110 COLOR WHEEL 80.82V31G001 PCBA MAIN BD FOR XD1270D 80.82V11G001 PCBA MAIN BD PD120D 75.85W04G001 ASSY PHILIPS LAMPDRIVER 200W EUC 200D/V11 913700822269 75.82G09G002 ASSY PHILIPS LAMPDRIVER 200W(TOPVALUE 913700816569) Appendix Description XD1170D PD100D...
  • Page 126 The Different Parts between XD1170D and XD1270D Ver. 36.82V50G001 USER MANUAL CS ACER PD100 36.82V01G001 USER MANUAL CS ACER PD120 45.82V01G101 INFRARED REMOTE CONTROLLER PD100 ACER 45.83J02G001 INFRARED REMOTE CONTROLLER 45.83J03G001 INFRARED REMOTE CONTROLLER 45.83J02G101 REMOTE CONTROLLLER FOR PD523PW 48.859DMGD13 A DMD 800*600 PIXEL DDR FTP 0.55...

  • Page 127: Identification Method For "D" Model

    IV. Identification Method for “D” Model: Model PD100 EY.J2101.001~006 ; EY.J2101.W01~W05 PD100D EY.J2101.007~012 ; EY.J2101.W06~W10 PD120 EY.J2201.001~006 ; EY.J2201.W01~W05 PD120D EY.J2201.007~012 ; EY.J2201.W06~W10 Note: The “D” indicates the model equiped with “DVI-In” function. Appendix Serial Number...
