Clothes dryer
Hide thumbs Also See for DV5471AEP/XAA:

Advertisement

Due to possibility of personal injury or property damage, always contact an authorized
technician for servicing or repair of this unit.
Refer to Service Manual (DV5471, DV5451) for detailed installation, operating, testing,
troubleshooting, and disassembly instructions.
All safety information must be follwed as provided in Service Manual of DV 5471, DV5451.
To avoid risk of electrical shock, personal injury or death; disconnect power to dryer
before servicing, unless testing requires power.
Technical_information-03044A-02.indd 1
CLOTHES DRYER

Technical Information

CAUTION
WARNING
1
Code No. : DC68-03044A_EN-02
2011-12-12
5:38:23

Advertisement

Table of Contents
loading

Summary of Contents for Samsung DV5471AEP/XAA

  • Page 1: Technical Information

    • Due to possibility of personal injury or property damage, always contact an authorized technician for servicing or repair of this unit. • Refer to Service Manual (DV5471, DV5451) for detailed installation, operating, testing, troubleshooting, and disassembly instructions. All safety information must be follwed as provided in Service Manual of DV 5471, DV5451. To avoid risk of electrical shock, personal injury or death;...
  • Page 2: Alignment And Adjustments

    ALIGNMENT AND ADJUSTMENTS To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. ERROR ITEMS AND DIAGNOSTIC CODES An occurrence of an Error will make a sound of error melody for 5sec and continuously show one of the Error Displays from the following errors.
  • Page 3: Test Mode

    ALIGNMENT AND ADJUSTMENTS To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. TEST MODE Continuous Run Mode: Press Wrinkle Prevent + Dry Level for 7 sec during Power On State (Normal User Mode) . Once in Continuous Run Mode, display “CC”...
  • Page 4: Data Display Mode

    ALIGNMENT AND ADJUSTMENTS To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. Data Display Mode Definition of Temperature Display Mode: Display Mode 0 : Temperature data(Celsius) Display Mode 1 : Average Touch Sensor data for 1 minute Display Mode 2 : Average Temperature(Celsius) data for 1minute How to Enter: With Power On, press AdjustUp Key + AdjsutDown Key for 7 seconds until it sends out a...
  • Page 5: Trouble Diagnosis

    ALIGNMENT AND ADJUSTMENTS To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. TROUBLE DIAGNOSIS As the micom dry machine is configured of the complicate structure, there might be the service call.
  • Page 6: Trouble Shooting

    TROUBLE SHOOTING To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. No Problem Will Not Start or Run Motor runs/ tumbler will not turn Runs a few minutes and then stops Blows fuses or trips circuit breaker Blows fuses or trips...
  • Page 7 TROUBLE SHOOTING To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. No Problem The igniter does not glow Igniter glows - No gas ignition The gas is ignited but the flame goes out Improper drying clothes wrinkled...
  • Page 8: Component Testing Procedures

    TROUBLE SHOOTING To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. COMPONENT TESTING PROCEDURES Component Electrical Testing (with ohmmeter) Thermistor resistance 10K Ω @ 25°C 77°F  Thermostat 1 resistance < 1Ω ...
  • Page 9: Gas Model

    TROUBLE SHOOTING To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. GAS MODEL Radiant Sensor(10RS) Resistance value < 1 Ω If resistance is infinite, replace Radiant sensor Igniter(101D) Resistance value 40~400 Ω If resistance is infinite, replace Igniter Technical_information-03044A-02.indd 9 WARNING...
  • Page 10 TROUBLE SHOOTING To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. AC Power Port Door Detection Sensor Motor Switch Sensor Sensor Bars & temperature sensor check Technical_information-03044A-02.indd 10 WARNING Motor Relay Switch Sensor Bars - Disconnect harness and test Pink wire Pin 4 to Orange wire Pin 5.
  • Page 11 TROUBLE SHOOTING To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. 3-WIRE system connections A. External ground connector B. Neutral grounding wire (green/yellow) C. Center silver-colored terminal block screw D.
  • Page 12: Wiring Diagram

    WIRING DIAGRAM To avoid risk of electrical shock, personal injury or death; disconnect power to dryer before servicing, unless testing requires power. WIRING DIAGRAM Technical_information-03044A-02.indd 12 WARNING 2011-12-12 5:38:28...
