IMPORTANT: READ AND SAVE THIS SAFETY AND INSTRUCTION MANUAL. SAVE THESE INSTRUCTIONS – The SE series chargers offer a wide range of features to accommodate your needs. This manual will show you how to use your charger safely and effectively. Please read, understand and follow these instructions and precautions carefully, as this manual contains important safety and operating instructions.
Do not expose the charger to rain or snow. Use only recommended attachments. Use of an attachment not recommended or sold by Schumacher® Electric Corporation may result in a risk of fire, electric shock or injury to persons or damage to property. To reduce the risk of damage to the electric plug or cord, pull by the plug rather than the cord when disconnecting the charger.
Use this charger for charging LEAD-ACID batteries only. It is not intended to supply power to a low voltage electrical system other than in a starter-motor application. Do not use this battery charger for charging dry-cell batteries that are commonly used with home appliances. These batteries may burst and cause injury to persons and damage to property.
6.5. If the positive post is grounded to the chassis, see step 6.6. For a negative-grounded vehicle, connect the POSITIVE (RED) clip from the battery charger to the POSITIVE (POS, P, +) ungrounded post of the battery. Connect the NEGATIVE (BLACK) clip to the vehicle chassis or engine block away from the battery.
For a positive-grounded vehicle, connect the NEGATIVE (BLACK) clip from the battery charger to the NEGATIVE (NEG, N, -) ungrounded post of the battery. Connect the POSITIVE (RED) clip to the vehicle chassis or engine block away from the battery. Do not connect the clip to the carburetor, fuel lines or sheet- metal body parts.
Recommended minimum AWG size for extension cord: AC input rating, amperes* But less least than *If the input rating of a charger is given in watts rather than in amperes, the corresponding ampere rating is to be determined by dividing the wattage rating by the voltage rating - for example: 1200 watts/120 volts = 10 amperes ASSEMBLY INSTRUCTIONS...
Page 11
Gel Batteries are best used in VERY DEEP cycle application and may last a bit longer in hot weather applications. If the incorrect battery charger is used on a Gel Cell battery, poor performance and premature failure is certain.
(Automatic chargers only). Power On • – When lit, this LED indicates that there is AC power supplied to the battery charger. • Check Battery – When lit, this LED indicates there is something wrong with the battery. Check the DC connections for an improper connection; otherwise the battery may be bad.
Page 13
Using the Engine Start feature (If equipped) Your battery charger can be used to jump start your car if the battery is low. Follow these instructions on how to use the ENGINE START feature. Follow all safety instructions and precautions for charging your battery.
MAINTENANCE INSTRUCTIONS 13.1 After use and before performing maintenance, unplug and disconnect the battery charger (see Sections 6, 7 and 8). 13.2 Use a dry cloth to wipe all battery corrosion and other dirt or oil from the terminals, cords, and the charger case.
TROUBLESHOOTING PROBLEM No reading on the ammeter. Ammeter reading stays high. Charger will not turn on when properly connected. The battery is connected and the charger is on, but is not charging. The measured current is much lower than what was selected.
Page 16
PROBLEM The charger is making an audible clicking sound. Charger makes a loud buzz or hum. POSSIBLE CAUSE Circuit breaker is cycling. Battery is defective. Shorted battery cables or clips. Severely discharged battery, but otherwise it is a good battery. Reverse connections at battery.
PROBLEM Short or no start cycle when cranking engine. BEFORE RETURNING FOR REPAIRS 16.1 When a charging problem arises, make certain that the battery is capable of accepting a normal charge. Use a good battery to double check all connections, AC outlet for a full 120-volts, charger clips for correct polarity and the quality of the connections from the cables to the clips and from the clips to the battery system.
Manufacturer does not provide any warranty for any accessories used with this product that are not manufactured by Schumacher Electric Corporation and approved for use with this product. This Limited Warranty is void if the product is misused, subjected to careless handling, repaired, or modified by anyone other than Manufacturer or if this unit is resold through an unauthorized retailer.
Page 19
IMPORTANTE: LEA Y GUARDE ESTE MANUAL DE INSTRUCCIONES Y SEGURIDAD. GUARDE ESTAS INSTRUCCIONES: Los SE cargadores ofrece una amplia gama de características para satisfacer sus necesidades. Este manual le mostrará cómo utilizar su cargador en forma segura y efectiva. Por favor, lea, comprenda y siga estas instrucciones y precauciones cuidadosamente, ya que este manual contiene instrucciones operativas y de seguridad de importancia.
No exponga el cargador a la lluvia o a la nieve. Utilice solamente accesorios recomendados. El uso de un accesorio no recomendado o suministrado por Schumacher® Electric Corporation puede provocar riesgo de incendio, descarga eléctrica o lesiones a personas o daño a la propiedad.
PRECAUCIONES PERSONALES Riesgo de gases explosivos. Resulta peligroso trabajar en forma cercana a una batería de plomo. Las baterías generan gases explosivos durante su normal funcionamiento. Por este motivo, resulta de suma importancia que siga las instrucciones cada vez que utiliza el cargador. Para reducir el riesgo de explosión de una batería, siga estas instrucciones y aquellas publicadas por el fabricante de la batería y por el fabricante de cualquier equipo que intente utilizar en la proximidad de la batería.
Si resulta necesario extraer la batería del vehículo para cargarla, siempre retire el terminal con descarga a tierra en primer lugar. Asegúrese de que todos los accesorios en el vehículo se encuentren apagados para evitar la formación de arcos eléctricos. Asegúrese de que el área que rodea a la batería se encuentre bien ventilada mientras se carga la batería.
SIGA ESTOS PASOS CUANDO LA BATERÍA ESTÉ COLOCADA EN EL VEHÍCULO. Ubique los cables de CA y CC para reducir el riesgo de daños a la cubierta, a la puerta y a las piezas móviles o calientes del motor. NOTA: Si es necesario cerrar el cofre durante el proceso de carga, asegúrese que el cofre no toque parte metálica de la batería o pele los cables.
Conecte el gancho POSITIVO (ROJO) del cargador al borne POSITIVO (POS, P, +) de la batería. Ubíquese junto con el extremo libre del cable que previamente sujetó al borne NEGATIVO (NEG, N, -) de la batería a la mayor distancia posible de la batería.
Tamaño AWG mínimo recomendado para alargadore: Consumo nominal de CA, Amperios* Pero menos menor a *Si el consumo nominal del cargador se expresa en vatios en lugar de amperios, el consumo en amperios correspondiente se determinará dividiendo el consumo en vatios por el consumo en tensión, por ejemplo: 1200 watts/120 volts = 10 amperes INSTRUCCIONES DE MONTAJE Sin necesidad de montaje...
Page 26
• Porcentaje de carga El porcentaje de la escala de carga tiene el propósito de servir como una ayuda visual para contribuir en la lectura del estado de carga. Se encuentra establecido en escala para utilizar solamente con el índice de carga de 6, 10, 12, 15 o 30 amperios.
Page 27
• : La batería de gel es similar al estilo AGM ya que el electrolito se suspende, pero resulta diferente debido a que técnicamente la batería AGM aún se considera una batería de celda húmeda. El electrolito en una batería de GEL posee un aditivo de sílice que provoca su fijación o endurecimiento. Las tensiones de recarga en este tipo de baterías son menores a las tensiones del resto de los estilos de batería de plomo-ácido.
INSTRUCCIONES DE OPERACIÓN Visión general Conectar la batería teniendo en cuenta las precauciones que figuran en las Secciones 6 y 7. Seleccione las configuraciones apropiadas para la batería. Conecte la energía eléctrica de CA teniendo en cuenta las precauciones que figuran en la Sección 8. Modo de carga automática Si el cargador posee un Modo de carga automática, puede llevar a cabo una carga automática.
IMPORTANTE Si utiliza la función ENGINE START SIN que la batería esté colocada en el vehículo podría dañar el sistema eléctrico del vehículo. Coloque el interruptor de índice de carga y el temporizador (en caso de tenerlo) a la posición OFF (apagado). Con el cargador desenchufado del tomacorriente de CA, conecte el cargador a la batería siguiendo las instrucciones que figuran en la Sección 6 (SIGA ESTOS PASOS CUANDO LA BATERÍA ESTÉ...
TAMAÑO/ÍNDICE DE LA BATERÍA BATERÍAS Motocicleta, PEQUEÑAS tractor de jardín, etc. AUTOS/ 200 - 315 CCA CAMIONES 315 - 550 CCA 550 - 1000 CCA MARINA/CICLO PROFUNDO INSTRUCCIONES DE MANTENIMIENTO 13.1 Después de usar y antes de realizar mantenimiento, desenchufe y desconecte el cargador de la batería (ver Secciones 6, 7 y 8).
LOCALIZACIÓN Y SOLUCIÓN DE PROBLEMAS PROBLEM No se manifiesta la lectura en el amperímetro. La lectura en el amperímetro permanece elevada. El cargador no se enciende incluso al estar bien conectado. La batería se encuentra conectada y el cargador encendido, pero no carga. La corriente medida es mucho menor a la seleccionada.
Page 32
PROBLEM El amperímetro lee una cantidad menor al índice de carga seleccionado cuando se carga una batería descargada Se escucha un sonido seco en el cargador (“clic”). El cargador realiza un fuerte zumbido. POSSIBLE CAUSE El alargador es demasiado largo o el calibre del cable es demasiado pequeño.
PROBLEM Ciclo reducido o sin inicio al arrancar el motor. ANTES DE DEVOLVER A REPARACIONES 16.1 Cuando surja un problema de carga, asegúrese de que la batería puede recibir una carga normal. Utilice una buena batería para verificar dos veces todas las conexiones, el toma de CA para obtener 120-voltios completos, los ganchos del cargador para lograr una polaridad correcta y la calidad de las conexiones de los cables a los ganchos y de los ganchos al sistema de la batería.
ésta se pueda reparar o reemplazar. El Fabricante no presta garantía por lo accesorios utilizados con este producto que no sean los fabricados por Schumacher Electric Corporation y que no estén aprobados para su uso con este producto. La presente Garantía Limitada será...
