Oppo OPDV971H User Manual

Oppo digital dvd player user manual opdv971h.
Also See for OPDV971H:
Supplementary manual - 2 pages
User manual - 33 pages
®
DVD PLAYER
OPDV971H
USER MANUAL
READ CAREFULLY
BEFORE OPERATION

   Also See for Oppo OPDV971H

   Related Manuals for Oppo OPDV971H

   Summary of Contents for Oppo OPDV971H

  • Page 1

    ® DVD PLAYER OPDV971H USER MANUAL READ CAREFULLY BEFORE OPERATION...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents ... 1 Important Information ... 1 Important Safety Instructions ... 1 Cautions... 2 FCC Statement ... 2 Copyright Protection ... 3 Compatible Disc Types ... 3 INSTALLATION ... 4 Front Panel Controls ... 4 Front Panel Display Window ...

  • Page 4: Table Of Contents

    Speaker Setup Page ... 28 Audio Setup Page... 30 Video Setup Page... 31 Preference Page... 32 REFERENCES... 34 Useful Notes... 34 Troubleshooting ... 34 Specifications ... 35 Language Code List ... 36 LIMITED WARRANTY ... 37 OPPO Digital, Inc. Limited One Year Warranty... 37...

  • Page 5: Important Information, Important Safety Instructions

    Important Information CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT REMOVE THE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.

  • Page 6: Cautions, Fcc Statement

    I M P O R T A N T I N F O R M A T I O N Cautions • Please disconnect the power plug from the wall outlet if you are not going to use the player for a long time.

  • Page 7: Copyright Protection, Compatible Disc Types

    I M P O R T A N T I N F O R M A T I O N Any unauthorized changes or modifications to this equipment would void the user’s authority to operate this device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 8: Installation, Front Panel Controls, Front Panel Display Window, Rear Panel Connectors

    INSTALLATION Front Panel Controls 1. POWER Button 4. IR Sensor 7. STOP Button Front Panel Display Window 1. DVD or CD Disc Icon 4. Playback Status Indicator 7. Pause Rear Panel Connectors 2. Disc Tray 3. OPEN/CLOSE Button 5. Display Window 6.

  • Page 9: Remote Control

    DVD title menu 8. ARROW Buttons – Navigate menu selection 9. SELECT Button – Confirm menu selection 10. SETUP Button – Enter the DVD player setup menu 11. SUBTITLE Button – Change subtitle language / Switch picture display mode 12. AUDIO Button –...

  • Page 10: Battery Installation, Using The Remote Control

    I N S T A L L A T I O N Battery Installation 1. Remove the battery compartment cover Using the Remote Control When using the remote control, the front window of the remote control should be pointed to the infrared sensor on the front panel within an angle of ±30°...

  • Page 11: Connection To A Tv, Dvi Or Hdmi Connection

    DVI or HDMI Connection • If your TV has a DVI input, you can use the included DVI cable to connect the DVD player to the TV. This is the most preferred connection method since it delivers video in pure digital format.

  • Page 12: Other Connection Options

    Video Connection Depending on the input available on your TV, select one of the following methods to connect the video output of the DVD player to your TV. The video connections are listed in descending order of video quality. BEST If the TV has a DVI or HDMI input, please see page 7 for instructions on using the DVI or HDMI connection.

  • Page 13

    TV. Make sure the audio cables are connected to the same input terminal group on the TV as the video signals. • Please set the down-mix mode of the DVD player to “Stereo” or “V. SURR”. (Refer to page 28 for details.)

  • Page 14: Connection To An Audio System, Connection To A Stereo Or Surround Audio System

    I N S T A L L A T I O N Connection to an Audio System Connection to a Stereo or Surround Audio System • If the audio system does not have surround speakers, please set the down-mix mode to “Stereo”...

  • Page 15: Connection To A Receiver/amplifier With Dolby Digital Or Dts Decoder

    I N S T A L L A T I O N Connection to a Receiver/Amplifier with Dolby Digital or DTS Decoder • Please set the SPDIF Output of the DVD player to “RAW”. (Refer to page 30 for details.) NOTES •...

  • Page 16: Connection To A Receiver/amplifier With 5.1ch Audio Input

    I N S T A L L A T I O N Connection to a Receiver/Amplifier with 5.1ch Audio Input • Please set the audio down-mix mode of the DVD player to “5.1 CH”. (Refer to page 28 for details.) •...

  • Page 17: Basic Operations, Disc Playback, Pause Playback

    This is to minimize possible burn-in on plasma or CRT screens caused by displaying a static image for a prolonged period of time. 1. Press the POWER button to turn on the DVD player. 2. Press the OPEN/CLOSE (EJECT) button to eject the disc tray.

  • Page 18: Dvd Menu Playback, Volume Control, Mute

    2. The VOL +/- buttons on the DVD remote control is provided as an alternative way of controlling the audio volume. It is recommended that you use this control to make the audio volume from the DVD player the same as from other sources, such as TV programs or a VCR.

  • Page 19: Audio Tone Control, Osd (on-screen Display), Audio Language/channel Selection

    B A S I C O P E R A T I O N S Audio Tone Control OSD (On-Screen Display) Press the OSD button on the remote control to show disc information and operation function hints on the TV screen. The OSD display includes the followings: DVD disc: Audio Language/Channel Selection...

  • Page 20: Subtitle Selection, Angle Selection, Zooming The Displayed Frame

    This function is available only when the discs are recorded with multiple angles. • The angle mark on the screen can be turned off using the setup menu of the DVD player. Zooming the Displayed Frame The feature zooms in or out the displayed frame.

  • Page 21

    B A S I C O P E R A T I O N S 2. When the frame is magnified, press the ARROW buttons to move the visible area in the frame (Panning).

  • Page 22: Advanced Operations, Tv System Selection, Dvi Output Resolution

    2. Turn on the TV. Adjust the TV to use the DVI or HDMI input. 3. Turn on the DVD player with no disc in its tray, or if the DVD player is already on, make sure that playback is stopped.

  • Page 23: Fast Playback, Slow Playback, Repeat Playback

    O P E R A T I O N S • In case you are not able to get a display using the DVI output, please connect the DVD player to the TV using either the composite video or S-Video cable, and then use the setup menu to adjust the DVD player settings.

  • Page 24: Repeat The Selected Section, Random And Shuffle Playback, Playback By Track Number

    A D V A N C E D O P E R A T I O N S Repeat the Selected Section To repeatedly play a specified section, please follow these steps: 1. During normal playback, press the A-B button on the remote at the desired beginning point (Point A) for the repeat play.

  • Page 25: Playback From A Specific Location, Playing Dvd Discs, Playing Cd Discs

    A D V A N C E D O P E R A T I O N S Playback from a Specific Location Playing DVD discs You may specify a point to start playback by entering the title, chapter or time directly.

  • Page 26: Memory And Automatic Resume, Viewing Static Pictures On Dvd-audio Discs

    DVD player will save the current playing position. the disc. played back, the DVD player will recognize the saved playing position. Playback will automatically resume from the saved playing position. However if you wish to cancel the automatic resume and start playback from the beginning, you may press the STOP button when prompted.

  • Page 27: Power Spectrum Meter (psm), Virtual Keyboard

    A D V A N C E D O P E R A T I O N S Power Spectrum Meter (PSM) The Power Spectrum Meter is a graphical display of the audio signal. It can be used to assist adjusting sound field and equalization pattern setting. Press the PSM button on the remote to show the Power Spectrum Meter during playback.

  • Page 28: Playing Divx, Digital Audio And Picture Files

    A D V A N C E D O P E R A T I O N S Playing DivX, Digital Audio and Picture Files When you insert a disc which contains DivX® video*, XviD, digital audio or digital picture files, the TV screen displays a disc navigation menu as shown the in the figure: 1.

  • Page 29: Digital Picture Play Operations, Digital Music Play Operations

    A D V A N C E D O P E R A T I O N S Digital Picture Play Operations When a picture is displayed in full screen slide show mode, the following operations are available: • • •...

  • Page 30: Setup Menu Options

    SETUP MENU OPTIONS The SETUP menu of the DVD player presents many setup and configuration options. For most users, the default configuration works well enough and there is no need to change the settings. However if you need to configure the DVD player to perfectly match your home theater settings and watching preference, please follow these instructions.

  • Page 31: General Setup

    S E T U P M E N U O P T I O N S General Setup Page 1. TV Display: To set the aspect ratio of the player’s output image to match your TV. The options are : •...

  • Page 32: Speaker Setup

    8. Subtitle Font: To select the subtitle font size for DivX video. There are three font sizes available. This setting applies only to DivX video files with a text subtitle. DivX video files with a graphic subtitle do not use the DVD player’s built-in font, so the font size cannot be adjusted. Speaker Setup Page 1.

  • Page 33

    S E T U P M E N U O P T I O N S • Small – Choose if the center speaker is small. Bass frequencies are not passed to the center speaker to reduce possible distortion. • Off –...

  • Page 34: Audio Setup

    S E T U P M E N U O P T I O N S Audio Setup Page 1. SPDIF Output: To set the bit stream type of the digital audio output. The options are: • RAW – Passes the encoded multi-channel digital audio unaltered. Choose this setting if your receiver/amplifier is capable of decoding Dolby Digital and DTS.

  • Page 35: Video Setup

    S E T U P M E N U O P T I O N S E. Center Width: To control the width of the center channel sound effect by blending the center speaker to the left and right speakers. As the level number increases, the center channel sound moves toward the left and right speakers.

  • Page 36: Preference

    S E T U P M E N U O P T I O N S • Medium – Medium edge enhancement. Video details are sharper but it may cause slight white line etching around objects. • Low – Low edge enhancement. This setting produces slightly sharpened video details. •...

  • Page 37

    The Preference Page can only be accessed when playback is completely stopped, or when there is no disc in the DVD player. 1. TV Type: To set the output video system (PAL/NTSC) to match the type of TV. The options are: •...

  • Page 38: References, Useful Notes, Troubleshooting

    REFERENCES Useful Notes • In order to prolong the service life of your DVD player, it is recommended to wait at least 30 seconds before you turn it on again after switching it off. • Remove disc and turn off power after operation.

  • Page 39: Specifications

    R E F E R E N C E S Specifications Designs and specifications are subject to change without notice. Disc Types* DVD-Video, DVD-Audio, CD, HDCD, Kodak Picture CD DivX® (DivX® Certified Home Theater Profile) CD-R/RW, DVD±R/RW, DVD+R DL Output Analog Audio: Stereo, 5.1ch Digital Audio: Coaxial, Optical Analog Video: Composite, S-Video (Y/C), Component Video (YCbCr, 480i/576i...

  • Page 40: Language Code List

    R E F E R E N C E S Language Code List Code Language Name 6565 Afar 6566 Abkhazian 6570 Afrikaans 6577 Ameharic 6582 Arabic 6583 Assamese 6588 Aymara 6590 Azerbaijani 6665 Bashkir 6669 Byelorussian 6671 Bulgarian 6672 Bihari 6678 Bengali, Bangla 6679...

  • Page 41: Limited Warranty, Oppo Digital, Inc. Limited One Year Warranty

    This warranty does not apply to products purchased or shipped outside of the U.S.A. and Canada. OPPO Digital, Inc. may at its sole discretion, refuse to honor the warranty of any such unauthorized product that may be presented for service.

  • Page 42

    Send the package postpaid and insured to the OPPO service center to obtain warranty service. Thank you for choosing OPPO. Your satisfaction is our highest priority. 5194137 V3.02 OPPO Digital, Inc. 453 Ravendale Dr. Suite D Mountain View, CA 94043, U.S.A. www.oppodigital.com service@oppodigital.com...
