HAI Omni-Bus 6-Channel Keyfob Remote Control
Model 125A00-1
®
User's Guide
SPECIFICATIONS
DELETING A REMOTE CONTROL
A Remote Control channel programmed into an Omni-Bus receiving
o
6 Channels
device may be deleted from that device via the OMNIBUS Installation
o
For use with HAI Omni-Bus Output devices
Software or by following the procedure below:
o
Requires an HAI Omni-Bus RF Transceiver on an Omni-Bus
network
1.
Place the receiving device into the programming mode. This is
o
Frequency: 433.92MHz
normally done by pressing and holding the button on the
o
Range: Up to 30m (indoors), up to 100m (outdoors)
receiving device until the receiving device LED starts flashing
continuously (see receiving device user guide).
REMOTE CONTROL FUNCTIONS
2.
To switch a device ON or OFF
Press and hold the appropriate button
on the remote control until the remote
sounds 3 beeps followed by another
set
of
4
beeps.
Check
for
a
Press and release the button on the
confirmation signal from the receiving
Remote Control. The remote control
device. (See receiving device user
will toggle between the ON and OFF
manual for more information).
commands each time the button is
pressed.
3.
Exit the programming mode on the receiving device.
To DIM a light (when used with an Omni-Bus Dimmer unit)
DELETE ALL
All remote control channels programmed into ANY Omni-Bus
Enter DIM/BRIGHT mode on the Remote control by pressing
RECEIVING device can be deleted entirely by using any Omni-Bus
buttons 1 and 2 simultaneously.
Remote Control. The remote control used for this does not
necessarily need to be one that was previously programmed into the
Press and hold the appropriate
device. This allows a lost or stolen remote control to be deleted
button on the Remote Control to dim
before reprogramming the new remote control.
or brighten the light.
1.
Place the receiving device into the programming mode. This is
normally done by pressing and holding the button on the
receiving device until the receiving device LED starts flashing
The Remote Control will exit the DIM/BRIGHT mode automatically
continuously (see receiving device user guide).
if no buttons are pressed for 7 seconds.
2.
A forced exit can be achieved by pressing buttons 1 and 2
Press and hold any button on the
simultaneously again.
remote control until the remote sounds
3 beeps, then 4 beeps and then 5
beeps (approximately 17 seconds).
OMNIBUS PROGRAMMING
Check for a confirmation signal from
See the HAI OMNIBUS Software User Guide for more information
the receiving device. (See receiving
on how to program the remote control into an Omni-Bus output
device
user
manual
for
more
devices using the OMNIBUS Installation Software.
information).
MANUAL PROGRAMMING
3.
Exit the programming mode on the receiving device.
1.
Place the receiving device into the programming mode. This is
KEYPAD LOCK FUNCTION
normally done by pressing and holding the button on the
receiving device until its LED starts flashing continuously.
The keypad lock function can be used to prevent accidental remote
(See receiving device user guide for more information).
control activation.
Enabling the Keypad Lock Function
2.
Before the keypad lock function can be used, it has to be enabled as
Press and hold the DESIRED
follows: Press and hold button 3 and 4 simultaneously until the
channel button on the Remote
remote sounds a burst of beeps (after approximately 5 seconds).
Control until the remote sounds 3
beeps (approx.10 seconds). Check
for a confirmation signal from the
Disabling the Keypad Lock Function
receiving device. (See receiving
Press and hold button 3 and 4 simultaneously until the remote
device user manual for more
sounds a short beep (after approximately 5 seconds).
information).
Locking/Unlocking the Keypad
3.
Exit the programming mode on the receiving device.
Lock or Unlock the Keypad on the Remote Control by pressing
buttons 3 and 4 simultaneously. The Remote Control will sound a
REMOTE CONTROL BATTERY REPLACEMENT
long beep when the Keypad is locked and any key is pressed on the
remote control.
If the remote control does not respond to any key presses or the
LED fails to come on when a key is held in, the battery may need
replacement.
The remote control uses one type 23A 12V battery.
© 2010 Home Automation, Inc.
www.homeauto.com
Document: 125I00-1, Rev1.0 May 2010
