MODEL H8241
120V ON/OFF
PADDLE SWITCH
INSTRUCTIONS
Motor
KEDU
Hot
Neutral
Out
Out
KJD17B
/120V
14
24
Rear View
13
23
of Switch
Hot
Neutral
In
In
Power Source
Figure 1. h8241 on/oFF paddle switch.
Figure 2. h8241 wiring diagram.
Introduction
Switch Disabling Padlock
the Model h8241 features a recessed on (–)
button that can be disabled with a padlock and a
The switch can be disabled and locked by insert-
large oFF paddle that ensures fast shut off. the
ing a padlock through the ON/START button, as
switch assembly will mount on a standard electri-
shown. Locking the switch in this manner can
cal box, or over a 1" x 2" opening.
prevent unauthorized operation of the machine,
which is especially important if the machine is not
Specifications
stored inside an access-restricted building.
rated hp ....................................................
hp
1
2
IMPORTANT: Locking the switch with a padlock
rated Voltage .............................................. 120V
only restricts its function. It is not a substitute
rated Current ................................................ 16A
for disconnecting power from the machine when
padlock shaft size .........................................
"
3
16
adjusting or servicing.
Installation
When installing the h8241 switch, use the wiring
diagram in Figure 2 to ensure proper wire con-
Padlock
nections.
Shaft
ON / START
Note: Only use insulated quick-disconnect crimp-
Button
type female wire terminals with a
" tab.
1
4
OFF / STOP
Paddle
Figure 3. switch disabled by a padlock.
If you need help with your new paddle switch, call our Tech Support at: (570) 546-9663.
Copyright © FEBrUAry, 2011 By grizzly indUstriAl, inC.
WARNINg: NO PORTION OF THIS INSTRUCTION SHEET MAy bE REPRODUCED IN ANy SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF gRIzzLy INDUSTRIAL, INC.
#ts13813 printEd in ChinA
