Chevrolet Silverado 2500HD User Manual

Chevrolet automobile user manual.


sILvEraDo 2500hD crEw cab 4wD work truck - 1wt
UpDAtES for 2011
new features
• ( LML) Duramax 6.6L turbo diesel V8, B20-Diesel compatible engine
• ( LGH) Duramax 6.6L turbo diesel V8, B20-Diesel compatible
engine (requires ZW9 pickup box delete)
• Exterior color (GGU) Steel Green Metallic
• ( ASf) Head curtain side-impact air bags
positions with rollover sensor
• ( AJ7) Seat-mounted side-impact air bags
passenger for thorax and pelvic protection
• (pYN) 17" (43.2 cm) steel wheels
changes
• New grille hood and front bumper appearance
• ( JL4) Stabilitrak, stability control system is now standard on all
models and includes electronic trailer sway control, intelligent
brake assist and hill start assist
deletions
• ( LY6) Vortec 6.0L variable valve timing V8 SfI engine
• ( LMM) Duramax 6.6L turbo diesel V8, B5-diesel
compatible engine
• ( QB5) 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug painted
steel wheels
• ( pY2) 4- 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug chrome-styled
steel wheels
• ( C6W) 9200 lbs. (4173 kg) GVWr
1. Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions.
Always use safety belts and the correct child restraints for your child's age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear
seat. See your vehicle Owner's Manual and child safety seat instructions for more information.
5. Gross Vehicle Weight Rating (GVWR). When properly equipped, includes vehicle, passengers, cargo and equipment.
1
, front outboard seating
1
, driver and right-front
5
• (pYp) 17" (43.2 cm) chrome-clad steel wheels
• (pYt) 18" (45.7 cm) painted steel wheels
• (QHQ) Lt245/75r17 all-season, blackwall tires
• (QGM) Lt265/70r18E all-terrain tires
• (QWf) Lt265/70r18E all-season tires
• (K40) Exhaust Brake
• (GEH) 9500 lbs. (4309 kg) GVWr
• (C4M) 9900 lbs. (4490 kg) GVWr
• (C7A) 10,000 lbs. (4536 kg) GVWr
• ( VYU) Snow plow prep package now available on all 4WD
engine and cab combinations
• New chassis and suspension
• Short and long box fuel tanks increased to 36 gallons
• ( pY0) 4- 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug polished
forged aluminum wheels
• ( QIZ) Lt 245/75r16E all-season, blackwall tires
• ( QIW) Lt245/75r16E on/off-road, blackwall tires
• E xterior color (58U) Black Granite Metallic
• ( VBJ) Lpo, Underseat storage, composite storage bin under
the rear seat
2011 Chevrolet Municipal Vehicles Technical Manual
| 1
5
5
5
Next page ->

Summary of Contents

  • Page 1

    2500hD crEw cab 4wD work truck - 1wt UpDAtES for 2011 new features • ( LML) Duramax 6.6L turbo diesel V8, B20-Diesel compatible engine • ( LGH) Duramax 6.6L turbo diesel V8, B20-Diesel compatible engine (requires ZW9 pickup box delete) • Exterior color (GGU) Steel Green Metallic • ( ASf) Head curtain side-impact air bags positions with rollover sensor • ( AJ7) Seat-mounted side-impact air bags passenger for thorax and pelvic protection • (pYN) 17” (43.2 cm) steel wheels changes • New grille hood and front bumper appearance • ( JL4) Stabilitrak, stability control system is now standard on all...

  • Page 2

    2500hD crEw cab 4wD work truck - 1wt note: This vehicle is noT designed nor intended for use in HiGH sPEED EMErGEnCy vEHiCLE oPEraTions CK20743 4-wheel drive 3/4 ton fleetside standard bed crew cab pickup CK20943 4-wheel drive 3/4 ton fleetside long bed crew cab pickup...

  • Page 3

    2500hD crEw cab 4wD work truck - 1wt air DaM Black BuMPEr, fronT Chrome BuMPEr, rEar Chrome, step-style with pad DayTiME runninG LaMPs Automatic exterior lamp control Door HanDLEs Black GLass Solar-Ray light-tinted, all windows GriLLE Chrome surround HEaDLaMPs...

  • Page 4

    Diesel Engines in vehicles over 14,000 lbs Gvwr: Different requirements apply to vehicles weighing over 14,000 lbs Gvwr that are equipped with diesel engines. These requirements impact the Chevrolet Express and GMC savana vans weighing over 14,000 lbs Gvwr that are equipped with the 6.6-liter Duramax diesel engine (LMM).

  • Page 5

    2500hD crEw cab 4wD work truck - 1wt DIMENSIONS (in./mm) LoCaTion Wheelbase Overall length Body width Overall height Head room, front Head room, rear Shoulder room, front Shoulder room, rear Hip room, front Hip room, rear Leg room, front...

  • Page 6

    2500hD crEw cab 4wD work truck - 1wt AVAILABLE EXTERIOR COLORS Taupe Gray Sheer Silver Imperial Blue Metallic Metallic CoLor DEsCriPTion 228a Light autumnwood Metallic 253a wheatland yellow 334D Dark Toreador red 382E Pewter 454n Blue 769H Blue 770H...

  • Page 7

    2500hD crEw cab 4wD work truck - 1wt ALTERNATOR, 160 AMPS - Included with VYU Snow Plow Prep Package when L96 Vortec 6.0L V8 SFI engine is ordered; requires L96 Vortec 6.0L V8 SFI engine ALTERNATOR, DuAL, 125 AMPS EACH - Requires LML/LGH Duramax 6.6L turbo diesel V8 engine AuDIO SYSTEM - AM/FM stereo with MP3 compatible CD player, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume and theftlock, required with U2K XM Radio.

  • Page 8

    2500hD crEw cab 4wD work truck - 1wt LAMPS, SMOKED AMBER ROOF MARKER - (Not available with YF5 California state emissions requirements) LICENSE PLATE BRACKET, FRONT - (Will be forced on orders with “ship to” states that require a front license plate) FLOOR MATS, ALL-WEATHER - Ebony deep ribbed rubber (extended and crew cab models also include rear floor mats);...

  • Page 9

    2500hD crEw cab 4wD work truck - 1wt PAINT, SOLID, SPECIAL - one color all normally body-colored non-sheet metal parts will be Flat Black. Door handles and mirrors will be Flat Black. This deletes the standard/packaged body-side moldings; requires 01U Special Paint with any special paint selection. May require an extended lead time. RPO B85 body-colored body side moldings, will be deleted when SEO TGK special paint is ordered.

  • Page 10

    2500hD crEw cab 4wD work truck - 1wt 10 | TIRES - LT265/70R18E all-terrain, blackwall; requires PYT 18" (45.7 cm) painted steel wheels TIRES - LT265/70R18E all-season, blackwall; requires PYT 18" (45.7 cm) painted steel wheels TRAILERING EquIPMENT, HEAvY-DuTY - Includes trailering hitch platform and 2.5-inch receiver with 2-inch adapter, 7-wire harness (harness includes wires for:...

  • Page 11

    2500hD crEw cab 4wD work truck - 1wt CREW CAB SPECIFICATIONS SPEcIFIcATIONS Front shock absorber diameter, in. (mm) Front stabilizer bar diameter, in. (mm) Rear shock absorber diameter, in. (mm) Turning diameter, curb-to-curb, ft. (m) cAPAcITIES Front axle, L96, lbs. (kg) Front axle, LML/LGH, lbs.

  • Page 12

    Some GM passenger air bag systems, like the system in the Chevrolet Impala, deploy from beneath the instrument panel top pad. These are considered 3/4-mount air bag systems with a “deployable top pad.”...

  • Page 13

    Even if you’re in a vehicle that has air bags, you still have to buckle up to get the most protection. That’s true not only in frontal collisions but especially in side and other collisions. 2011 Chevrolet Municipal Vehicles Technical Manual | 13...

  • Page 14

    Children are safer when properly secured in a rear seat. See your vehicle Owner’s Manual and child safety seat instructions for more information. 2011 Chevrolet Municipal Vehicles Technical Manual ToP viEw of insTruMEnT PanEL anD aPProxiMaTE...

  • Page 15

    F. I nflated air bag – vertical dimension approximate 9.3 in (490 mm) G. Inflated air bag – instrument panel H. Passenger air bag deployment zone Note: All dimensions are approximate and subject to change. 2011 Chevrolet Municipal Vehicles Technical Manual | 15...

  • Page 16

    Children are safer when properly secured in a rear seat. See your vehicle Owner’s Manual and child safety seat instructions for more information. 2011 Chevrolet Municipal Vehicles Technical Manual PassEnGEr siDE sHown, DrivEr siDE siMiLar Tahoe/Suburban 3rd Row Seats M.

  • Page 17

    In other states the discount varies from insurance company to insurance company. When buying auto insurance, always ask your insurance agent if his/her company gives a discount for vehicles equipped with anti- lock brakes. 2011 Chevrolet Municipal Vehicles Technical Manual | 17...

  • Page 18

    Each time the vehicle is started, the StabiliTrak system is fully ON. StabliliTrak can be controlled by a StabiliTrak button on the instrument panel. The 2011 Chevrolet Municipal Vehicles Technical Manual iMPorTanT DrivinG safETy TiPs Always drive carefully—...

  • Page 19

    For Information 1-800-FLEET-OP (353-3867) www.gmfleet.com GM Fleet and Commercial Specialty Vehicles • 100 Renaissance Center, 20th Floor • Detroit, MI 48265-1000...
