Acer
Aspire M5810
Service Guide
Service guide files and updates are available
on the ACER/CSD web; for more information,
please refer to
http://csd.acer.com.tw
PRINTED IN TAIWAN

   Also See for Acer Aspire M5810

   Summary of Contents for Acer Aspire M5810

  • Page 1

    Acer Aspire M5810 Service Guide Service guide files and updates are available on the ACER/CSD web; for more information, please refer to http://csd.acer.com.tw PRINTED IN TAIWAN...

  • Page 2

    Revision History Please refer to the table below for the updates made on this service guide. Date Chapter Updates...

  • Page 3

    Copyright Copyright © 2009 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without...

  • Page 4

    Any Acer Incorporated software described in this manual is sold or licensed "as is". Should the programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software.

  • Page 5

    Conventions The following conventions are used in this manual: SCREEN MESSAGES NOTE WARNING CAUTION IMPORTANT Denotes actual messages that appear on screen. Gives additional information related to the current topic. Alerts you to any physical risk or system damage that might result from doing or not doing specific actions.

  • Page 6

    Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer office may have a DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 7: Table Of Contents

    Removing the Memory Modules Removing the Mainboard System Troubleshooting Power-On Self-Test (POST) POST Error Messages List Error Symptoms List Undetermined Problems Jumper and Connector Information Jumper Setting FRU (Field Replaceable Unit) List Aspire M5810 Exploded Diagram Aspire M5810 FRU List Intel RAID SOP...

  • Page 8: System Tour, Features

    System Tour Features Below is a brief summary of the computer’s many feature: NOTE: The features listed in this section is for your reference only. The exact configuration of the system depends on the model purchased. Operating System Microsoft Windows 7 Home Premium 64bit •...

  • Page 9

    Optical disk Support one SATA 5.25" standard ODD • Support DVD-ROM, DVD-SuperMulti, BD-combo, BD-rewrite • Maximum ODD depth to 185mm with bezel • Models are listed on AVLC • Graphics card support No mechanical retriction to support for double slot, full length graphics cards in the single PSIe X16 slot •...

  • Page 10

    MS , MS-PRO , MS Duo , MS-PRO Due , Micro-MS(M2), xD type M and Type H card, CF type I and II, Microdrive) System BIOS Size: 4 ~ 8Mb • Phoenix Award or AMI Kernel with Acer skin • Power supply Up to 500watt power rating •...

  • Page 11: M/b Placement

    M/B Placement Label Description CPU Socket CPU Socket,0.914mm,15u",Black,SMD- 1,156 DIMM CONN,DIMM,DDR III,1.5V,VT,Blu,15u,G,DIP-240 CPU_FAN CPU fan power header PWR2 CPU Power connector REAR_FAN Rear Fan Header PCIE_16x PCIE_x16socket PCIE_1x PCIE_1x socket PCIE_4x PCIE_4x socket AUX_IN Audio Aux input connector F_AUDIO Front panel audio header SPEAKER Internal speaker header SPDIF1...

  • Page 12: Block Diagram

    Block Diagram POWER VREG SUPPLY VRD11.1 P CIE ( G E N2) x16 PCIE (GEN 2) X16 PCIE X1 P CI E XP RE SS P CI E XP RE SS PCIE X1 P CI E XP RE SS PCIE X4 P CI E XP RE SS JMB362 H DMI...

  • Page 13: System Components, Front Panel

    This section is a virtual tour of the system’s interior and exterior components. Front Panel Component USB 2.0 ports Micro SD/M2 slot CF I/II (CompactFlash Type I/II) slot XD(XD-PICTURE) slot Optical drive Acer logo Optical drive button SD(Secure Digital) solt Power button Memory stick PRO slot Headphone/Speaker-out/line-out jack Microphone-in jack Chapter 1...

  • Page 14: Rear Panel

    Rear Panel Component Power connector PS2 mouse port Line-out jack eSATA port USB 2.0 ports S/PDIF port Microphone/speaker-out/line-in jack Line-out jack Expansion slot (graphics card and TV tuner card and Mode card) Surround rear L/R Line-in jack USB 2.0 ports Center speaker/subwoofer jack LAN connector System FAN...

  • Page 15: Power Management Function(acpi Support Function)

    Power Management Function(ACPI support function) Device Standby Mode Independent power management timer for hard disk drive devices(0-15 minutes,time step=1minute). • Hard Disk drive goes into Standby mode(for ATA standard interface). • Disable V-sync to control the VESA DPMS monitor. • Resume method:device activated (keyboard for DOS, keyboard &mouse for Windows.

  • Page 16: System Utilities, Cmos Setup Utility

    System Utilities CMOS Setup Utility CMOS setup is a hardware configuration program built into the system ROM, called the complementary metal- oxide semiconductor (CMOS) Setup Utility. Since most systems are already properly configured and optimized, there is no need to run this utility. You will need to run this utility under the following conditions. When changing the system configuration settings When redefining the communication ports to prevent any conflicts When modifying the power management configuration...

  • Page 17: Entering Cmos Setup, Navigating Through The Setup Utility

    Entering CMOS setup Turn on the server and the monitor. If the server is already turned on, close all open applications, then restart the server. During POST, press Delete. If you fail to press Delete before POST is completed, you will need to restart the server. The Setup Main menu will be displayed showing the Setup’s menu bar.

  • Page 18: Setup Utility Menus

    Setup Utility Menus The Setup Main menu includes the following main setup categories. Parameter Description Product Information This page shows the relevant information of the main board Standard CMOS Features This setup page includes all the items in standard compatible BIOS Advanced Chipset Features This setup page includes all the items of Award special enhanced features Advanced Chipset Features...

  • Page 19

    Product Information The Product Information menu displays basic information about the system. These entries are for your reference only and are not user-configurable. Parameter Description Processor Type Type of CPU installed on the system. Processor Speed Speed of the CPU installed on the system. System Memory Total size of system memory installed on the system.

  • Page 20

    Standard CMOS Features Parameter Description System Date Set the date following the weekday-month-day-year format. System Time Set the system time following the hour-minute-second format. AHCI Port 1/2/3/5/6 Press Enter to view detailed device information. Halt On Determines whether the system will stop for an error during the POST. Chapter 2 Option All, But Keyboard...

  • Page 21

    Advanced BIOS Feature Parameter Description Quick Boot Allows you to decrease the time it takes to boot the computer by shortening or skipping certain standard booting process. Quiet Boot When enabled, the BIOS splash screen displays during startup. When disabled, the diagnostic screen displays during startup. 1st/2nd/3rd/4th Boot Device Specifies the boot order from the available devices.

  • Page 22

    Advanced Chipset Features Parameter Description Intel EIST When enabled, this feature allows the OS to reduce power consumption. When disabled, the system operates at maximum CPU speed. Intel XD Bit When enabled, the processor disables code execution when a worm attempts to insert a code in the buffer preventing damage and worm propagation.

  • Page 23

    Integrated Peripherals Parameter Description Onboard ESATA Controller Enables or disables the onboard ESATA controller. Onboard SATA Controller Enables or disables the onboard SATA controller. Onboard SATA Mode Select an operating mode for the onboard SATA. Onboard USB Controller Enables or disables the onboard USB controller. Legacy USB Support Enables or disables support for legacy USB devices.

  • Page 24

    Power Management Setup Parameter Description ACPI Suspend Mode Select an ACPI state. High Performance Event Enables or disables High Performance Event Timer Timer Power On by RTC Alarm Enables or Disables to wake up the system by RTC Alarm Function Power On by PCIE Devices Enables or disables to wake up the system from a power saving mode through an event on PCI Express device.

  • Page 25

    PC Health Status Parameter Description Smart FAN Enables or disables the smart system fan control function. Option Enabled Disabled Chapter 2...

  • Page 26

    Frequency/Voltage Control Parameter Description Spread Spectrum Enables or disables the reduction of the mainboard’s EMI. Note: Remember to disable the Spread Spectrum feature if you are overclocking. A slight jitter can introduce a temporary boost in clock speed causing the overclocked processor to lock up. Chapter 2 Option Enabled...

  • Page 27

    BIOS Security Features Parameter Description Supervisor Password Indicates the status of the supervisor password. User Password Indicates the status of the user password. Change Supervisor Supervisor password prevents unauthorized access to the BIOS Setup Utility. Password Press Enter to change the Supervisor password. Setting a supervisor password Use the up/down arrow keys to select Change Supervisor Password menu then press Enter.

  • Page 28

    Load Default Settings The Load Default Settings menu allows you to load the default settings for all BIOS setup parameters. Setup defaults are quite demanding in terms of resources consumption. If you are using low-speed memory chips or other kinds of low-performance components and you choose to load these settings, the system might not function properly.

  • Page 29

    Save & Exit Setup The Save & Exit Setup menu allows you to save changes made and close the Setup Utility. Chapter 2...

  • Page 30

    Exit Without Saving The Exit Without Saving menu allows you to discard changes made and close the Setup Utility. Chapter 2...

  • Page 31: System Disassembly, Disassembly Requirements

    System Disassembly This chapter contains step-by-step procedures on how to disassemble the desktop computer for maintenance and troubleshooting. Disassembly Requirements To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge Flat-blade screwdriver Philips screwdriver Hex screwdriver Plastic flat-blade screwdriver...

  • Page 32: Pre-disassembly Procedure

    Pre-disassembly Procedure Before proceeding with the disassembly procedure, perform the steps listed below: Turn off the system and all the peripherals connected to it. Unplug the power cord from the power outlets. Unplug the power cord from the system. Unplug all peripheral cables from the system. Place the system unit on a flat, stable surface.

  • Page 33: Removing The Side Panel

    Removing the Side Panel Remove the two screws located on the rear edge of the side panel. Slide the side panel toward the back of the chassis until the tabs on the cover disengage with the slots on the chassis. Lift the side panel away from the server and put it aside for reinstallation later.

  • Page 34

    Removing the Heat Sink Fan Assembly WARNING:The heat sink becomes very hot when the system is on. NEVER touch the heat sink with any metal or with your hands. disconnect the fan cable from the mainboard. Use a long-nosed screwdriver to loosen the four screws on the heat sink, in the order as shown below. Lift the heat sink fan assembly away from the mainboard.

  • Page 35

    Removing the Processor IMPORTANT:Before removing a processor from the mainboard, make sure to create a backup file of all important data. WARNING:The processor becomes very hot when the system is on. Allow it to cool off first before handling. Release the load lever (1). Pull the load lever to the fully open, upright position (2) and lift the load plate (3).

  • Page 36

    Removing the VGA Card Release the Slot cover lock. Remove the screw from chassis. Disconnect the power cables from the VGA card. One finger Press the clip and the same time Gently pull the card to remove it from the mainboard. Chapter 3...

  • Page 37

    Removing the TV Card Gently pull the TV card to remove it from the mainboard. Removing the Mode Card Gently pull the Mode card to remove it from the mainboard. Chapter 3...

  • Page 38

    Removing the Hard Disk Drive Disconnect the data and power cables from the rear of the optical drive and the mainboard. Remove the HDD bracket Remove the screw that secures the HDD bracket to the ODD bracket. Lift the bracket up and turn it over. Chapter 3...

  • Page 39

    Remove the HDD module Remove the eight screws secure the HDD module to the HDD bracket. Slide the HDD out of the bracket. Chapter 3...

  • Page 40: Removing The Front Bezel

    Removing the Front Bezel Remove the side panel. Refer to the previous section for instructions. Disconnect the LED cable. Release the front bezel from the chassis interior. Pull the bezel away from the chassis. Chapter 3...

  • Page 41: Removing The Optical Drive

    Removing the Optical Drive Disconnect the data and power cables from the rear of the optical drive. Remove two screw from the optical drive. Pull the drive out of the drive. Chapter 3...

  • Page 42

    Remove Cables Remove power switch and LED cables from slot of M/B Remove HDD Data and ODD Data cables from slot of M/B. Remove USB1/2/3 cable from M/B. Remove Card reader cable and Audio cable from M/B Chapter 3...

  • Page 43

    Remove System FAN Remove System FAN cable from M/B. Release four screws according to the following picture. Take off the system fan from chassis. Chapter 3...

  • Page 44: Removing The Power Supply

    Removing the Power Supply Disconnect the 4-pin and 24-pin power supply cables from the mainboard. Remove the four screw that secures the power supply to the chassis. Lift the power supply module out of the chassis. Chapter 3...

  • Page 45: Removing The Memory Modules

    Removing the Memory Modules IMPORTANT:Before removing any DIMM from the memory board, make sure to create a backup file of all important data. Press the holding clips on both sides of the DIMM slot outward to release the DIMM. Gently pull the DIMM upward to pull it away from the M/B. Chapter 3...

  • Page 46: Removing The Mainboard

    Removing the Mainboard Remove the eight screws that secure the mainboard to the chassis. Lift the board from the chassis. Chapter 3...

  • Page 47: System Troubleshooting

    System Troubleshooting Please refer to generic troubleshooting guide for troubleshooting information relating to following topics: Power-On Self-Test (POST) POST Check Points POST Error Messages List Error Symptoms List Chapter 4 Chapter 4...

  • Page 48: Power-on Self-test (post)

    Power-On Self-Test (POST) Each time you turn on the system, the Power-on Self Test (POST) is initiated. Several items are tested during POST, but is for the most part transparent to the user. The Power-On Self Test (POST) is a BIOS procedure that boots the system, initializes and diagnoses the system components, and controls the operation of the power-on password option.

  • Page 49

    Bootblock Recovery Code Checkpoints Checkpoint Initialize the floppy controller in the super I/O. Some interrupt vectors are initialized. DMA controller is initialized. 8259 interrupt controller is initialized. L1 cache is enabled. Set up floppy controller and data. Attempt to read from floppy. Enable ATAPI hardware.

  • Page 50

    Checkpoint Early CPU Init Start -- Disable Cache ?C Init Local APIC Set up boot strap processor Information Set up boot strap processor for POST Enumerate and set up application processors Re-enable cache for boot strap processor Early CPU Init Exit Initializes the 8042 compatible Key Board Controller Detects the presence of PS/2 mouse.

  • Page 51

    Checkpoint Updates CMOS memory size from memory found in memory test. Allocates memory for Extended BIOS Data Area from base memory. Initializes NUM-LOCK status and programs the KBD typematic rate. Initialize Int-13 and prepare for IPL detection. Initializes IPL devices controlled by BIOS and option ROMs. Initializes remaining option ROMs.

  • Page 52

    DIM Code Checkpoints Checkpoint Initialize different buses and perform the following functions: Reset, Detect, and Disable (function 0); Static Device Initialization (function 1); Boot Output Device Initialization (function 2). Function 0 disables all device nodes, PCI devices, and PnP ISA cards. It also assigns PCI bus numbers.

  • Page 53: Post Error Messages List

    POST Error Messages List If you cannot run the diagnostics program tests but did receive a POST error message, use "POST Error Messages List" to diagnose system problems. If you did not receive any error message, look for a description of your error symptoms in "Error Symptoms List"...

  • Page 54

    Message Displayed B: Drive Error The BIOS attempted to configure the B: drive during POST, but was unable to properly configure the device. This may be due to a bad cable or faulty diskette drive. Insert BOOT The BIOS attempted to boot from the A: drive, but could not find a proper boot diskette. diskette in A: Reboot and BIOS could not find a bootable device in the system and/or removable media drive does...

  • Page 55

    Message Displayed 5th Slave Hard The IDE/ATAPI device configured as Slave in the 5th IDE controller could not be properly Disk Error initialized by the BIOS. This message is typically displayed when the BIOS is trying to detect and configure IDE/ATAPI devices in POST. 6th Master The IDE/ATAPI device configured as Master in the 6th IDE controller could not be properly Hard Disk...

  • Page 56

    Message Displayed 6th Slave Drive The IDE/ATAPI device configured as Slave in the 6th IDE controller failed an ATAPI - ATAPI compatibility test. This message is typically displayed when the BIOS is trying to detect and Incompatible configure IDE/ATAPI devices in POST. S.M.A.R.T.

  • Page 57

    Message Displayed Microcode BIOS could not find or load the CPU Microcode Update to the CPU. This message only Error applies to INTEL CPUs. The message is most likely to appear when a brand new CPU is installed in a motherboard with an outdated BIOS. In this case, the BIOS must be updated to include the Microcode Update for the new CPU.

  • Page 58

    Message Displayed CMOS CMOS settings are invalid. This error can be resolved by using AMIBIOS Setup. Settings Wrong CMOS CMOS contents failed the Checksum check. Indicates that the CMOS data has been Checksum changed by a program other than the BIOS or that the CMOS is not retaining its data due to malfunction.

  • Page 59

    USB eModule Error Messages Message Displayed Warning! This message is displayed when a non-bootable USB device is enumerated and disabled Unsupported by the BIOS. USB device found and disabled! Warning! Port This message is displayed to indicate that port 60h/64h emulation mode cannot be enabled 60h/64h for this USB host controller.

  • Page 60: Error Symptoms List

    Error Symptoms List NOTE: To diagnose a problem, first find the error symptom in the left column. If directed to a check procedure, replace the FRU indicated in the check procedure. If no check procedure is indicated, the first Action/ FRU listed in right column is the most likely cause.

  • Page 61

    Error Symptom Diskette drive does not work. Diskette drive read/write error. Diskette drive LED comes on for more than 2 minutes when reading data. Diskette drive LED fails to light, and the drive is unable to access for more than 2 minutes. Diskette drive test failed.

  • Page 62

    Error Symptom CD/DVD-ROM drive LED doesn't come on but works normally. CD/DVD-ROM drive LED flashes for more than 30 seconds before LED shutting off. Software asks to reinstall disc.Software displays a reading CD/DVD error. CD/DVD-ROM drive cannot load or eject when the system is turned on and its eject button is pressed and held.

  • Page 63

    Error Symptom Video memory test failed.Video adapter failed. Display problem: -Incorrect colors No high intensity Missing, broken, or incorrect characters Blank monitor (dark) Blank monitor (bright) Distorted image Unreadable monitor Other monitor problems Display changing colors. Display problem not listed above (including blank or illegible monitor).

  • Page 64

    Error Symptom Executing software shutdown from Windows98 Start menu does not turn off the system. (Only pressing power switch can turn off the system). No system power, or power supply fan is not running. Any other problems. Action/FRU 1.Load default settings. 2.Reload software from Recovery CD.

  • Page 65: Undetermined Problems

    Check all cables and connectors for proper installation. If the jumpers, switches and voltage settings are correct, remove or disconnect the following, one at a time: 10. Non-Acer devices External devices Any adapter card (modem card, LAN card or video card, if installed)

  • Page 66: Jumper And Connector Information, Jumper Setting

    Jumper and Connector Information Jumper Setting The section explains how to set jumper for correct configuration of the mainboard. Setting Jumper Use the motherboard jumpers to set system configuration options. Jumpers with more numbered. When setting the jumpers, ensure that the jumper caps are System Board Jumper Setting CLR_CMOS •...

  • Page 67

    Front USB • Chapter 5...

  • Page 68

    Front Audio (HDA) • Front 1394 • Chapter 5...

  • Page 69

    SATA Connector • 4 Pin FAN HEADER • 3 Pin FAN HEADER • Chapter 5...

  • Page 70

    CLEAR CMOS HEADER • CLR_SRTC • INTR • SPDIF Header • Chapter 5...

  • Page 71

    AUX-IN • 2 Pin HEADER • Chapter 5...

  • Page 72: Fru (field Replaceable Unit) List

    To scrap or to return the defective parts, follow the local government ordinance or regulations on how to dispose it properly, or follow the rules set by your regional Acer office on how to return it. This document will be updated as more information about the FRU list becomes available.

  • Page 73: Aspire M5810 Exploded Diagram

    Aspire M5810 Exploded Diagram NOTE: This section will be updated when more information becomes available. Chapter 6...

  • Page 74

    ITEM NAME PANEL_TOP-X2 COVER_TOP-X1 MYLAR-COVER-TOP MYLAR-DOOR-TOP DOOR_TOP-X1 LED_3 BTN_PWR_DCR-X1 BTN_PWR_V2-X1 MCR_HOLDER-X4 BKT_PWR-BTN-X1 MCR-KYE-M5-D224 CONTACT_SWITCH IO-PANEL_TOP-X2 TOP-BRKT_USB FIO-AM520 ACER-M330-MAIN- CHASSIA LED-A1 HDD_LENS-X1 PANEL_MAIN_M5-X1 DOOR_ODD_ARM_UP- Chapter 6 TYPE Q’TY ITEM PART DOOR_ODD_ARM_LO- PART DOOR_ODD_UP_M5-X2 BTN_ODD_LO-X1 BTN_ODD_DCR_UP-X1 PART SPRING_ODD_BTN-2 PART LOGO_ASPIRE_M5-X1 ELECT LOGO-AM530...

  • Page 75: Aspire M5810 Fru List

    Aspire M5810 FRU List Category MAINBOARD CPU Cooler Memory Description MB Kit aBulldogII Intel P55 Intel 82578DC PCI-E Gbt Lan ATX W/ 1394 V1.0 LF w/i DolbyIII, w/o GPU Lynnfield LGA1156 2.93GHz 4cores/8threads,95W Lynnfield LGA1156 2.8GHz 4cores/8threads,95W Lynnfield LGA1156 2.66GHz 4cores/4threads,95W Cooler Intel LGA1156 AVC ZGUL00A201 w/i duc M378B2873EH1-CH9 LF 128*8 0.055um...

  • Page 76

    Category Card Reader Modem Chapter 6 Description HD4870 1GB DDR 5 (256BITS) HYNIX 6 LAYER DUAL DVI NEW COOLER NEW PCB W/ATX BKT ROHS HD4850 1GB DDR 3 (256bits) SAMSUNG 6 LAYER DUAL DVI W/ ATX BKT ROHS HD4650 1GB DDR 2 (128BITS) SAMSUNG DVI HDMI VGA W/ ATX BKT ROHS HD4350 512MB DDR 2 (64BITS) SAMSUNG DVI HDMI VGA W/ ATX BKT ROHS...

  • Page 77

    Category Wireless LAN Power Supply Mouse KEYBOARD Description HPE56L6, Modem PCI-Ex1 card, LSI Universal Modem (PCI-E) 56K V.92 - Concorde (C40) VD56UL, Modem USB dongle 56K modem W/O brand logo D-1156E#/A10A, Modem PCI-Ex1 card, LSI Universal Modem (PCI-E) 56K V.92 - Concorde (C40) PE988-A TV Tuner Card PCIe Hybrid ATSC with S/W Encoder PE988-D TV Tuner Card PCIe Hybrid DVB-T with S/W Encoder WU61RL WLAN USB dongle 802.11 b/g, Ralink RT2571WF, W/O...

  • Page 78

    Category Chapter 6 Description Keyboard LITE-ON SK-9625 USB Standard 105KS Black Portuguese with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 105KS Black Canadian French with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 107KS Black Brazilian Portuguese with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 109KS Black Japanese with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 105KS Black German...

  • Page 79

    Category Description Keyboard LITE-ON SK-9625 USB Standard 105KS Black Romanian with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 105KS Black Turkish with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 105KS Black Spanish Latin with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 105KS Black Turkish- Q with new color AC-MT-018 Keyboard LITE-ON SK-9625 USB Standard 105KS Black Arabic/ French with new color AC-MT-018...

  • Page 80

    Category Chapter 6 Description Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black UK with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black Dutch with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black Swiss/G with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black Belgium with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black...

  • Page 81

    Category Description Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black US with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black Traditional Chinese with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black Simplified Chinese with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black US International with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black...

  • Page 82

    Category Chapter 6 Description Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black Slovenian with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black Slovak with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black Russian with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 105KS Black Hungarian with new silver color Keyboard CHICONY KG-0766 RF2.4 Standard 104KS Black Greek...

  • Page 83: Intel Raid Sop

    Intel RAID SOP 1.INTEL® MATRIX STORAGE TECHNOLOGY CHECK(DOS) 1-1: Create SATA RAID 0 Step 1:Shut down the EUT, unplug the power cable,connect two SATA HDDS to EUT , check the EUT all devices are connect/plug ok. Step 2:Press "PWR-BTTN" to power on the EUT,Load BIOS default setting . Step 3:At "Integrated_Peripherals"...

  • Page 84

    Step 7:Select "RAID0(Stripe)" at "RAID Level". Picture3 Step 8:You can select the "Strip Size" and define RAID capacity in "Capactity". Picture4 Chapter 7...

  • Page 85

    Step 9:Press "Create Volume" to create RAID0,it will pop the warning message that all data will be lost,"press "Y" to confirm it. Step 10:It will back to create RAID interface,then press "ESC" or select 4 to exit and install OS. 1-2: Create SATA RAID 1 Step 1:Shut down the EUT, unplug the power cable,connect two SATA HDDS to EUT , check the EUT all devices are connect/plug ok.

  • Page 86

    Step 8:You can select the "Strip Size" and define RAID capacity in "Capactity". Step 9:Press "Create Volume" to create RAID1,it will pop the warning message that all data will be lost,"press "Y" to confirm it. Step 10:It will back to create RAID interface,then press "ESC" or select 4 to exit and install OS. 1-3: Create SATA RAID 5 Step 1:Shut down the EUT, unplug the power cable,connect three SATA HDDS to EUT , check the EUT all devices are connect/plug ok.

  • Page 87

    Step 7:Select "RAID0(Stripe)" at "RAID Level". Step 8:Select two HDDs in "Disk" by space key. Picture8 Step 9:Press "Enter" to finish HDD selection and it will back to RAID creation interface. Step 10:Repeat RAID1 creation step and exit,then install OS. Chapter 7...

  • Page 88

    Intel RAID SOP (Windows for WIN7) 2.Intel(R) Matrix Storage Console 2-1:Create a“RAID Ready” System into" RAID 0" with two Hard Drives by‘Create RAID Volume from Existing HDD Drive ’. Step 1:Install Win7 OS with one SATA HDD. Step 2:Shut down the system,then add one Serial ATA hard drive in the system. Step 3:Boot to OS desktop, open the Intel®...

  • Page 89

    Step 5:Click "Next" at create a RAID volume window. Picture3 Step 6:Key the name in "Volume Name" and select "RAID 0" in RAID Level. Picture4 Step 7:Select minimum HDD as "Source Hard Drive". Picture5 Chapter 7...

  • Page 90

    Picture6 Step 8:Select Menber Hard Drive(s). Picture7 Chapter 7...

  • Page 91

    Step 9:Specify Volume Size then press "next". Step 10:Press "next" to finish setup and start create RAID0. Step 11:It may takes half and hours to create RAID0.After create completely,it will ask to reboot to finish create RAID0. 2-2:Create a“RAID Ready” System into" RAID 1" with two Hard Drives by‘Create RAID Volume from Existing HDD Drive ’.

  • Page 92

    Step 6:Key the name in "Volume Name" and select "RAID 1" in RAID Level. Step 7:Select minimum HDD as "Source Hard Drive". Step 8:Select Menber Hard Drive(s). Step 9:Specify Volume Size then press "next". Step 10:Press "next" to finish setup and start create RAID1. Step 11:It may takes half and hours to create RAID1.After create completely,it will ask to reboot to finish create RAID1.

  • Page 93

    Step 6:Key the name in "Volume Name" and select "RAID 5" in RAID Level. Picture11 Step 7:Select minimum HDD as "Source Hard Drive". Picture12 Chapter 7...

  • Page 94

    Step 8:At least select two HDD as Menber Hard Drive(s). Step 9:Specify Volume Size then press "next". Step 10:Press "next" to finish setup and start create RAID5. Step 11:It may takes half and hours to create RAID5.After create completely,it will ask to reboot to finish create RAID5.

  • Page 95

    Step 7:Select two HDDs as "Source Hard Drive". Step 8:At least select two HDD as Menber Hard Drive(s). Step 9:Specify Volume Size then press "next". Step 10:Press "next" to finish setup and start create RAID 10. Step 11:It may takes half and hours to create RAID 10.After create completely,it will ask to reboot to finish create RAID10.

  • Page 96

    Step 5:Click "Next" at create a RAID volume window. Step 6:Key the name in "Volume Name" and select "RAID 0" in RAID Level. Step 7:At least select two HDDs as "Volume Location". Picture17 Step 8:Specify Volume Size then press "next". Picture18 Step 9:Press "next"...

  • Page 97

    2-6:Create a“RAID Ready” System into" RAID 1" with two Hard Drives by ‘Create RAID Volume ’. Step 1:Install WIN7 OS with one SATA HDD. Step 2:Shut down the system,then add another two serial ATA hard drives in the system. Step 3:Boot to OS desktop, open the Intel® Matrix Storage Console. Step 4:Click on the by‘Create RAID Volume’...
