Consolidated "e" Series
Hardware Installation Guide
Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
(888) 257-3000
http://www.extremenetworks.com
Published: September 22, 2004
Part number: 123010-00 Rev
01

Advertisement

Table of Contents
loading

Related Manuals for Extreme Networks Summit 200-24

Summary of Contents for Extreme Networks Summit 200-24

  • Page 1 Consolidated “e” Series Hardware Installation Guide Extreme Networks, Inc. 3585 Monroe Street Santa Clara, California 95051 (888) 257-3000 http://www.extremenetworks.com Published: September 22, 2004 Part number: 123010-00 Rev...
  • Page 2 Solution Partners Logo, ServiceWatch, Summit, the Summit7i Logo, and the Color Purple, among others, are trademarks or registered trademarks of Extreme Networks, Inc. or its subsidiaries in the United States and other countries. Other names and marks may be the property of their respective owners.

  • Page 3: Table Of Contents

    Contents Preface Introduction Conventions Related Publications About This Guide How To Use This Guide Part 1 Preparing for Installation Chapter 1 Overview of the “e” Series of Switches Summit “e” Series and Models Summit 200 Features Summit 300 Features Summit 400 Features Port Connections Following Safety Information Software Images...
  • Page 4 Summit 300-24 Switch Summit 300-24 Front View Summit 300-24 Switch LEDs Summit 300-48 switchConsole Port Port Connections Summit 300-24 RearSummit 300-48 switch View Redundant Power Supply Summit 300-48 Switch Summit 300-48 Front View LED Behavior Consolidated "e" Series Hardware Installation Guide...
  • Page 5 Part 3 Switch Installation Chapter 6 “e” Switch Installation Installing the Switch Rack Mounting Removing the Switch from a Rack Free-Standing Desktop Mounting of Multiple Switches Installing or Replacing a Mini-Gigabit Interface Connector (Mini-GBIC) Removing and Inserting a Mini-GBIC Connecting Equipment to the Console Port...
  • Page 6 Important Safety Information Power Power Cable Optical Safety Lithium Battery Appendix B “e” Series Technical Specifications Common Switch Specifications Summit 200 Series Switch Specifications Summit 300 Series Switch Specifications Summit 400 Series Switch Specifications Index Consolidated "e" Series Hardware Installation Guide...

  • Page 7: Preface

    This preface provides an overview of this guide, describes guide conventions, and lists other publications that might be useful. NOTE To ensure proper operation of your Extreme Networks equipment, read this guide before you install any Extreme Networks equipment. Introduction This guide provides the required information to install an Extreme Networks contains information about site location, switch functionality, and switch operation.

  • Page 8: Conventions

    Italics emphasize a point of information or denote new terms at the place where they are defined in the text. Related Publications The Extreme Networks switch documentation set includes: • Consolidated “e” Series Hardware Installation Guide (this guide) • ExtremeWare Software User Guide •...

  • Page 9: About This Guide

    • Archives About This Guide This guide describes how to prepare your site and how to install, maintain, and operate your Extreme Networks switch. It contains information on features that are common to all switches, as well as switch-specific features. This guide contains six parts: •...
  • Page 10 61 for specific details for cabling combination ports. Common Information For items applicable to any Extreme Networks switch, make sure you read the appropriate chapter. For example, to learn how to prepare your site for installing your Extreme Networks equipment, see Chapter 2, “Site Preparation.”...

  • Page 11: Part 1 Preparing For Installation

    Part 1 Preparing for Installation...

  • Page 13: Overview Of The "E" Series Of Switches

    — Summit 300-24 switch — Summit 300-48 switch • The Summit 400-48t switch For installation information on other Summit switches, refer to the Extreme Networks Consolidated “i” Series Hardware Installation Guide. Summit 200 Features This section summarizes the hardware and software features of the Summit 200. See “Summit 200 Series Switch Overview”...
  • Page 14 • 24 autosensing 10BASE-T/100BASE-TX ports using RJ-45 connectors • Two 10/100/1000BASE-T Gigabit Ethernet uplink ports using RJ-45 connectors • Two optical ports that allow Gigabit Ethernet uplink connections through Extreme 1000BASE-SX, 1000BASE-LX, or 1000BASE-ZX Small Form Factor pluggable (SFP) Gigabit Interface Connectors (GBICs)—also known as mini-GBICs—using LC optical fiber connectors.

  • Page 15: Summit 300 Features

    Summit 300 Features This section summarizes the hardware and software features of the Summit 300. See “Summit 300 Switch Overview” on page 47 for details of the front panel, rear panel, and LEDs. Hardware Features The Summit 300-48 supports the following features: •...

  • Page 16: Summit 400 Features

    Summit 400 Features This section summarizes the hardware and software features of the Summit 400-48t. See “Summit 400-48t Switch Overview” on page 57 for details of the front panel, rear panel, and LEDs. Hardware Features The Summit 400 series switch supports the following ExtremeWare features: •...
  • Page 17 • Quality of Service (QoS) including support for IEEE 802.1P, MAC QoS, and eight hardware queues • Policy-Based Quality of Service (PB-QoS) • Wire-speed Internet Protocol (IP) routing • Extreme Standby Router Protocol (ESRP) • Virtual Router Redundancy Protocol (VRRP) • Ethernet Automated Protection Switching (EAPS) support (RFC 3619) •...

  • Page 18: Port Connections

    Following Safety Information WARNING! Read the safety information in Appendix A thoroughly before installing your Extreme Networks switch. Failure to follow this safety information can lead to personal injury or damage to the equipment. • All service to components of an “e” series switch should be performed by trained service personnel only.

  • Page 19: Software Images

    Release Notes. Full-Duplex Support Extreme Networks switches provide full-duplex support for all ports. This means that frames can be transmitted and received simultaneously, which, in effect, doubles the bandwidth that is available on a link. Most ports on an Extreme Networks switch autonegotiate for half-duplex or full-duplex operation.
  • Page 20 Overview of the “e” Series of Switches Consolidated "e" Series Hardware Installation Guide...

  • Page 21: Site Preparation

    Site Preparation This chapter describes how to prepare your site for installing Extreme Networks equipment. It contains information on environmental and cabling requirements, power requirements, and building and electrical code organizations. This chapter includes these sections: • Planning Your Site on page 22 •...

  • Page 22: Planning Your Site

    After you have established your fiber cable requirements, you should ensure that your mini-GBICs support the distance and media types you are planning to install. Step 4: Meeting Power Requirements To run your equipment safely, you must meet the specific power requirements for the Extreme Networks equipment that you plan to install. NOTE Review and follow the safety information before you install your equipment.
  • Page 23 • Ensure that your system is easily accessible for installation and service. See “Rack Specifications and Recommendations” on page 25 for specific recommendations. • Use appropriate AC power for your switch, as described in Table 2. Table 2: AC power requirements...
  • Page 24 Extreme Networks recommends that you consult an electrical contractor for commercial building and wiring specifications. Temperature. Extreme Networks equipment generates a significant amount of heat. It is essential that you provide a temperature-controlled environment for both performance and safety. Install the equipment only in a temperature- and humidity-controlled indoor area that is free of airborne materials that can conduct electricity.

  • Page 25: Rack Specifications And Recommendations

    (12.7 cm) recommended) for proper airflow. The airflow of the “e” series of switches moves from the left side of the switch to the right side of the switch, or from the right side of the switch to the left side of the switch depending on the model.
  • Page 26 Space Requirements for the Rack Provide enough space in front of and behind the switch so that you can service it easily. Allow a minimum of 48 inches (122 cm) in front of the rack and 24 inches (61 cm) behind the rack. When using a relay rack, provide a minimum of 24 inches (61 cm) of space behind the mounted equipment.

  • Page 27: Evaluating And Meeting Cable Requirements

    Evaluating and Meeting Cable Requirements Figure 1: Properly secured rack (SPG_007 redraw with e series in the rack) Secure to floor with 3/8 inch lag screws or bolts SPG_007 Brace open distribution racks if the channel thickness is less than 1/4 inch (6.4 mm). Evaluating and Meeting Cable Requirements This section addresses requirements for the that cable you should use when installing your network equipment.

  • Page 28: Cable Labeling And Record Keeping

    • Assign a unique block of sequential numbers to the group of cables that run between each pair of wiring closets. • Assign a unique identification number to each distribution rack. • Identify all wiring closets by labeling the front panel of your Extreme Networks equipment and other hardware. • Keep accurate and current cable identification records.
  • Page 29 Unshielded twisted pair (UTP) cable can build up ESD charges when being pulled into a new installation. Before installing category 5 UTP cables, discharge ESD from the cable by plugging it into a port on a switch or any network device that is not powered on. Figure 2: Properly installed and bundled cable...
  • Page 30 Site Preparation NOTE Kinks and sharp bends can destroy or impair the cable’s ability to convey light pulses accurately from one end of the cable to the other. Use care in dressing the optical-fiber cables: provide satisfactory strain relief to support the cable and maintain an adequate bend radius at all cable turns, particularly where the cable connects to the I/O module.

  • Page 31: Evaluating And Meeting Mini-Gbic Requirements

    Evaluating and Meeting Mini-GBIC Requirements All “e” series switches support the small form pluggable (SFP) GBIC, also known as the mini-GBIC. The switches identify the type of mini-GBIC that is installed and verifies that the mini-GBIC is an Extreme Networks-certified mini-GBIC.

  • Page 32: Long Range Mini-Gbic System Budgets

    Measure cable plant loses with a 1550 nm light source and verify this to be within budge. When calculating the maximum distance attainable suing optical cable with a specified loss per kilometer (for example 0.25 dB/km), Extreme Networks recommends that 3 dB of the total budget be reserved for Typical...

  • Page 33: Rj-45 Connector Jackets

    loses induced by cable splices, connectors, and operating margin. Table 7 lists the minimum attenuations that are required by each long range mini-GBIC to prevent saturation of the receiver. Table 7: Minimum attenuation requirements GBIC Type LX70 LX100 ZX (prior to Transceivers Rev 03) ZX Rev 03...

  • Page 34: Radio Frequency Interference

    In areas or applications where these situations cannot be avoided, use fiber optic cabling or shielded twisted pair cabling (STP). NOTE Because harmonics can appear on the neutral line of a typical three-phase power circuit, Extreme Networks recommends using a harmonics meter in new installations. Making Network Interface Cable Connections Use the appropriate type of cable to connect the ports of your switch to another switch or router.

  • Page 35: Power Supply Requirements

    • AC Power Cable Requirements • Uninterruptable Power Supply Requirements For more information about the power specifications of the Extreme Networks family of switches, see Appendix B, “e” Series Technical Specifications. Power Supply Requirements Adhere to the following requirements in order to operate your Extreme Networks equipment safely: •...

  • Page 36: Uninterruptable Power Supply Requirements

    An uninterruptible power supply (UPS) is a device that sits between a power supply (such as a wall outlet) and a device (such as a switch) to prevent outages, sags, surges, and bad harmonics from adversely affecting the performance of the device.

  • Page 37: Applicable Industry Standards

    UPS Transition Time Transition time is the time that is necessary for the UPS to transfer from utility power to full-load battery power. For Extreme Networks products, a transition time of less than 20 milliseconds is required for optimum performance.
  • Page 38 Site Preparation Consolidated "e" Series Hardware Installation Guide...

  • Page 39: Part 2 Switch Overview

    Part 2 Switch Overview...

  • Page 41: Summit 200 Series Switch Overview

    Summit 200 Switch Front View The 24 port version of the Summit 200 is the Summit 200-24. Figure 5 shows the Summit 200-24 switch front view. The 48 port version is the Summit 200-48, which is shown in Figure 6.

  • Page 42: Summit 200 Switch Rear View

    See “Evaluating and Meeting Mini-GBIC Requirements” on page 31 for information about supported GBIC types. Summit 200 Switch Rear View Figure 7 shows the rear view of the Summit 200-24 switch, while Figure 8 shows the rear view of the Summit 200-48 switch. Figure 7: Summit 200-24 switch rear view...

  • Page 43: Summit 200 Switch Leds

    See “Evaluating and Meeting Mini-GBIC Requirements” on page 31 for mini-GBIC types and distances. Summit 200 Switch LEDs Table 9 describes the light emitting diode (LED) behavior for both models of the Summit 200 switch. Table 9: Summit 200 switch LED behavior...

  • Page 44: Console Port

    The switch also has four Gigabit Ethernet uplink ports, of which only two can be used at any one time. These combination ports are labeled 25 and 26 on the front panel of the Summit 200-24 and labeled 49 and 50 on the front panel of the Summit 200-48. Two of the ports are 10/100/1000BASE-T ports using RJ-45 connectors.
  • Page 45 On the Summit 200-24, ports 25 and 26 are the Gigabit Ethernet ports that have the redundant PHY interfaces. On the Summit 200-48, it is ports 49 and 50. Each port has one mini-GBIC and 1000BASE-T connection. To set up a redundant link on either port 25 or on port 49, connect the active fibre and 1000BASE-T links to both the RJ-45 and mini-GBIC interfaces of that port.

  • Page 46: Full-Duplex

    Both models of the Summit 200 provide full-duplex support for all ports. Full-duplex allows frames to be transmitted and received simultaneously and, in effect, doubles the bandwidth available on a link. All 10/100 Mbps ports on the Summit 200 switch autonegotiate for half- or full-duplex operation. Consolidated "e" Series Hardware Installation Guide...

  • Page 47: Summit 300 Switch Overview

    1000BASE-LX, or 1000BASE-ZX Small Form Factor pluggable (SFP) Gigabit Interface Connectors (GBICs)—also known as mini-GBICs—using LC optical fiber connectors. Summit 300-24 Front View The 24-port version of the Summit 300 is the Summit 300-24. Figure 9 shows the Summit 300-48 switch front view. Consolidated "e" Series Hardware Installation Guide...

  • Page 48: Summit 300-24 Switch Leds

    Indicates Green, solid The Summit switch is operating normally. Green, blinking The Summit switch POST is in progress. Amber, The Summit switch has failed its POST or an overheat condition blinking is detected. There is no power. Fan LED Color...

  • Page 49: Summit 300-48 Switchconsole Port

    The switch determines whether the port is the primary or redundant port based upon the order in which the cables are inserted into the switch. When the switch senses that cables are in both the fiber and corresponding copper port, the switch enables the uplink redundancy feature. For further information, see “Summit 300 Automatic Failover”...

  • Page 50: Summit 300-24 Rearsummit 300-48 Switch View

    Diagram ES4K028A Summit 300-48 switchPower Socket The Summit 300-24 switch automatically adjusts to the AC supply voltage, with a range of 90V to 254V.. The Summit 300-24 applies power when a power cable is attached. Summit 300-48 switchSerial Number Use this serial number for fault-reporting purposes.

  • Page 51: Redundant Power Supply

    48 autosensing10BASE-T/100BASE-TX ports using RJ-45 connectors. The Summit 300-48 also provides two 10/100/1000BASE-T Gigabit Ethernet uplink ports using RJ-45 connectors and four optical ports. These optical ports allow Gigabit Ethernet uplink connections through Extreme 1000BASE-SX, 1000BASE-LX, or 1000BASE-ZX Small Form Factor pluggable (SFP) Gigabit Interface Connectors (GBICs)—also known as mini-GBICs—using LC optical fiber connectors.

  • Page 52: Led Behavior

    See “Evaluating and Meeting Mini-GBIC Requirements” on page 31 for information about supported mini-GBIC types and distances. LED Behavior The light emitting diode (LED) behavior for the Summit 300-48 is shown in Figure 11. Table 11: Summit 300-48 switch LED behavior Unit Status LED (MGMT LED) Color Indicates Blinking Green The Summit switch is operating normally.

  • Page 53: Console Port

    Port Connections The Summit 300-48 switch uses a combination of 10BASE-T/100BASE-TX ports using RJ-45 connectors and Small Form Factor Plugable (SFP) Gigabit Interface Connectors (GBICs), also known as mini-GBICs. Ports 1 through 48 are 10/100 ports with RJ45 connectors.

  • Page 54: Summit 300-48 Rear View

    1:49 and 1:51 on the Summit 300-48, and then connect copper ports 1:1 and 1:3, the switch assigns ports 1:1 and 1:3 as redundant ports. On the Summit 300-24, if you inserted a SFP connector into port 24 and then a Ethernet cable connector into port 1, fiber becomes the primary uplink port and port 1 becomes the redundant port.

  • Page 55: Load Sharing Power Supplies

    The Summit 300-48 switch automatically adjusts to the supply voltage. The power supply operates down to 90 V. Power Switch The Summit 300-48 switch has a power switch. Do not turn on power to the switch until instructed in the installation procedures. NOTE Summit 300-48 switch number and MAC address labels are located on the bottom of the switch.
  • Page 56 Summit 300 Switch Overview Consolidated "e" Series Hardware Installation Guide...

  • Page 57: Summit 400-48T Switch Overview

    • Port Connections on page 61 Summit 400-48t Switch The Summit 400-48t switch is a compact enclosure (see Figure 14) one rack unit in height (1.73 inches or 44.0 mm) that provides 48 autosensing 10/100/1000BASE-T ports using RJ-45 connectors. The switch also has four fiber ports that allow Gigabit Ethernet uplink connections through Extreme 1000BASE-SX, 1000BASE-LX, or 1000BASE-ZX SFP mini-GBICs using LC connectors.

  • Page 58: Summit 400 Rear View

    VLAN and attempts to route traffic through it. Extreme Networks does not recommend that you use the management port to route traffic to any front panel port on the switch. The management port is designed only for switch management purposes.

  • Page 59: Summit 400 Switch Leds

    The FAN LED indicates the status of the cooling fans. • Power The Summit 400-48t comes with an internal power supply and can be connected to the Extreme External Power Supply tray. The status of the internal power supply is indicated by the PSU-I LED.
  • Page 60 Green, fast The Summit switch POST is in progress. blinking Green, solid POST passed; ExtremeWare is booting. Amber, The Summit switch has failed its POST or an overheat condition blinking is detected. The Summit switch has no power. Fan Status Color...

  • Page 61: Port Connections

    The Summit 400-48t switch has 48 copper 10/100/1000BASE-T ports using RJ-45 connectors for communicating with end stations and other devices over 10/100/1000 Mbps Ethernet. The switch also has four fiber ports that allow Gigabit Ethernet uplink connections through Extreme 1000BASE-SX, 1000BASE-LX, or 1000BASE-SX SFP mini-GBICs using LC connectors. Fiber and mini-GBIC specifications are covered in “Evaluating and Meeting Cable Requirements”...
  • Page 62 Summit 400-48t Switch Overview NOTE To support automatic failover between the fiber and copper ports, you must use an Extreme mini-GBIC connector. Consolidated "e" Series Hardware Installation Guide...

  • Page 63: Part 3 Switch Installation

    Part 3 Switch Installation...

  • Page 65: Installing The Switch

    “e” Switch Installation You can mount an “e” series switch in a rack or place it free-standing on a tabletop. This chapter describes: • Installing the Switch on page 65 • Installing or Replacing a Mini-Gigabit Interface Connector (Mini-GBIC) on page 67 •...

  • Page 66: Rack Mounting

    “e” Switch Installation Rack Mounting CAUTION Do not use the rack mount kits to suspend the switch from under a table or desk, or to attach the switch to a wall. To rack mount the Summit 200 series switch: 1 Place the switch upright on a hard flat surface, with the front facing you.

  • Page 67: Removing The Switch From A Rack

    This relates only to stacking the devices directly one on top of one another. Apply the pads to the underside of the device by sticking a pad at each corner of the switch. Place the devices on top of one another, ensuring that the corners align.

  • Page 68: Removing And Inserting A Mini-Gbic

    If you see an amber blinking Mini-GBIC port status LED on your Summit 200 or Summit 300 series switch, the mini-GBIC installed in your switch is one that is not approved or supported by Extreme Networks. To correct this problem, ensure that you install a mini-GBIC that is approved and supported by Extreme Networks.

  • Page 69: Connecting Equipment To The Console Port

    • Flow control — None NOTE If you set the switch console port flow control to XON/XOFF rather than None, you will be unable to access the switch. Do not set the switch console port flow control to XON/XOFF. The terminal connected to the console port on the switch must be configured with the same settings.

  • Page 70: Powering On The Switchsummit 300-48 Switch

    The MGMT LED flashes until the switch successfully passes the POST. If the switch passes the POST, the MGMT LED blinks at a slow rate (one blink per second). If the switch fails the POST, the MGMT LED shows a solid amber light.

  • Page 71: Logging In For The First Time

    5 Assign an IP address and subnetwork mask for VLAN default by typing config vlan default ipaddress 123.45.67.8 255.255.255.0 Your changes take effect immediately. 6 Save your configuration changes so that they will be in effect after the next switch reboot, by typing save NOTE For more information on saving configuration changes, see the ExtremeWare Software User Guide.
  • Page 72 “e” Switch Installation Consolidated "e" Series Hardware Installation Guide...

  • Page 73: Part 4 Accessory Installation

    Part 4 Accessory Installation...

  • Page 75: Summit 300 Optional Features

    10 feet or less and at least 16-gauge copper wire. CAUTION The Extreme EPS-LD unit must only be installed or removed by trained service personnel in accordance with the installation instructions. Before servicing this system, please read the safety information provided in Appendix A.

  • Page 76: Rack-Mounting The Eps-Ld Unit

    EPS-LD facing either the front or the back of the rack. For this reason, each unit has two sets of mounting holes; two on each end. Mounting the EPS-LD so that the unit’s output connectors are on the same side as the external connector on the connecting switch. CAUTION Do not use the rack-mount kits to suspend the EPS-LD from under a table or desk, or to attach the switch to a wall.

  • Page 77: Connecting The Eps-Ld Unit

    If you mount the EPS-LD with the connectors facing in the opposite direction as the Extreme switch connector, leave at least 1 U between the switch and the EPS-LD through which to slide the cables. Do not route the cables around the equipment rack.
  • Page 78 3 Connect the AC input power cable to the AC connector on the EPS-LD unit. CAUTION The EPS-LD unit does not have a switch for turning the unit on and off. You disconnect power to the EPS-LD unit by removing the plug from the electrical outlet. Ensure that this connection is easily accessible to you.

  • Page 79: Removing An Eps-Ld Unit

    Power over Ethernet (PoE) devices connected to the 48 primary PoE ports. Refer to the Summit 300-48 Release Notes and “Redundant Power Supply” on page 51 to determine the total available power at each port. You can obtain copies of these documents at the Extreme Networks web site at: http://www.extremenetworks.com/services/...

  • Page 80: Removing And Installing Summit 300-48 Power Supplies

    Removing an Internal Power Supply To remove an internal Summit 300-48 power supply: 1 Turn off the power supply by setting the power switch to the OFF position. 2 Remove the power cable from the power source, remove the power cable retaining bracket (if installed), and then remove the power cable from the power supply.
  • Page 81 To install an internal Summit 300-48 power supply: 1 Confirm that the power supply switch on the power supply to be installed is set to the OFF position. 2 Remove the power supply cable (if connected) from the power supply to be installed.

  • Page 82: Installing And Removing Power Cable Retaining Brackets

    Installing the Power Cable Retaining Bracket To install a power cable retaining bracket: 1 Turn off the power supply by setting the power switch to the OFF position. 2 Disconnect the power cable from the power source and then disconnect the Summit 300-48.
  • Page 83 Figure 27. 6 Tighten the retaining bracket screw. If your switch has two power supplies, align the retaining brackets, as shown in Figure 28, so that the retaining bracket screws do not interfere with each other. 7 Connect the power cable to the power source.

  • Page 84: Removing The Power Cable Retaining Bracket

    Removing the Power Cable Retaining Bracket To remove a power cable retaining bracket from a power cable: 1 Turn off the power supply by setting the power switch to the OFF position. 2 Disconnect the power cable from the power source.
  • Page 85 DC power supplied by the power supply to the switch. When the output power is satisfactory the OUT LED is green, otherwise it is off. Figure 29: Power supply LEDs Table 17: Summit 300-48 power supply LED behavior...

  • Page 86: Environmental And Safety Specifications

    Summit 300 Optional Features Environmental and Safety Specifications Table 18: Summit 300-48 power supply specifications Safety Agency Certifications and North American Safety of ITE Standards • • CSA 22.2#60950-00 • NOM/NYCE (Mexico Safety) European Safety of ITE • • 73/23/EEC Low Voltage Directive International Safety of ITE •...
  • Page 87 Power Supply Specifications Nominal Input Voltage Input Voltage Range AC Line Frequency Power Supply Input Connection Maximum Input Current Total Output Power Temperature Power-off Environmental Operating Conditions Operating Temperature Storage Temperature Operating Humidity Operational Shock Standards Consolidated "e" Series Hardware Installation Guide 100/115/200/208/230 VAC 85 VAC to 264 VAC 47 Hz to 63 Hz...
  • Page 88 Summit 300 Optional Features Consolidated "e" Series Hardware Installation Guide...

  • Page 89: Summit 400-48T Optional Features

    Summit XEN Card is an additional card that adds one or two 10 Gigabit uplink modules through the back of the Summit 400-48t. The Extreme External Power System (EPS) allows you to add a redundant power supply to the Summit 400 switch to protect against a power supply failure. Both of these products are additional offerings and available from your sales representative.
  • Page 90 LR XENPAK and the ER XENPAK appear and install the same. An example of an XENPAK module is shown in Figure 30. Figure 30: XENPAK Modules The XENPAK module is a Class 1 Laser device that operates at 5 V. Use only Extreme-approved devices on all Extreme switches. CAUTION The XENPAK module can emit invisible laser radiation.

  • Page 91: Installing The External Power System

    Summit 400 switch to protect against a power supply failure. It consists of a tray (EPS-T) that holds one or two EPS-160 power supplies. Each EPS-160 provides one-to-one redundancy to an attached Extreme switch. Please check the Extreme website or with your local sales representative for a list of compatible Extreme switches.

  • Page 92: Rack Mounting The Eps-T

    Summit 400-48t Optional Features CAUTION The Extreme External Power System must only be installed or removed by trained service personnel in accordance with the installation instructions. Before servicing this system, please read the safety information provided in. Not following these precautions can result in equipment damage or shock.
  • Page 93 See Figure 32 for details on the connector key and Figure 33 to locate the connectors on the EPS-160 and the switch. Table 20 gives the wire-to-pin connections for the connector on the rear panel of the EPS-160.

  • Page 94: Adding A Second Eps-160 To The Eps-T

    Diagram ES4K028 8 Connect the other end of each EPS-160 power supply cable to the Extreme switch. This connector end can only be inserted into the switch with the end marked TOP facing up. 9 Using the supplied cable, connect the AC cable to the AC supply for each unit. For countries other than the USA, you might require a different AC cable that is not supplied.

  • Page 95: Removing An Eps-160 From The Eps-T

    Installing Optional Features 1 Remove the EPS-160 from the packing material. 2 Insert the EPS-160 into the front of the EPS-T. 3 Tighten the provided thumbscrews to secure the power supply to the tray. 4 Follows steps 7 through 9 on page 93. Removing an EPS-160 from the EPS-T To remove an EPS-160 from an EPS-T: 1 Disconnect the AC by removing the plug from the wall...
  • Page 96 Summit 400-48t Optional Features Consolidated "e" Series Hardware Installation Guide...

  • Page 97: Part 5

    Part 5 Appendixes...

  • Page 99: Appendix A Safety Information

    Important Safety Information WARNING! Read the following safety information thoroughly before installing your Extreme Networks switch. Failure to follow this safety information can lead to personal injury or damage to the equipment. Installation, maintenance, and removal of a switch, chassis, or its components must be done by qualified service personnel only.

  • Page 100: Power Cable

    Fiber Optic ports. To protect your eyes, never look at the transmit LED/laser through a magnifying device while it is powered on. Never look directly at a fiber port on the switch or at the ends of fiber cable when they are powered on.

  • Page 101: Lithium Battery

    Mini-GBICs. Remove the LC fiber-optic connector from the mini-GBIC prior to removing the mini-GBIC from the switch. Lithium Battery The battery in the “e” series is encapsulated and not user-replaceable.
  • Page 102 Safety Information Consolidated "e" Series Hardware Installation Guide...

  • Page 103: Appendix B "E" Series Technical Specifications

    “e” Series Technical Specifications This appendix describes the hardware technical specifications for “e” series of Extreme Network switches. The appendix is organized into the following sections: • Common Switch Specifications on page 103 • Summit 200 Series Switch Specifications on page 105 •...
  • Page 104 “e” Series Technical Specifications Country Specific Mexico NOM/NYCE (Product Safety and EMC Approval) Australia/New Zealand AS/NZS 3260 (ACA DoC, Safety of ITE) Argentina S-Mark GOST (Russia) Laser Safety North America FCC 21 CFR subpart (J) (Safety of Laser Products) CDRH Letter of Approval (US FDA Approval) Europe •...

  • Page 105: Summit 200 Series Switch Specifications

    Power Supply AC Line Frequency: Input Voltage Options: Current Rating: AC Line Frequency: Table 23: Summit 200-24 Unique Specifications Physical and Environmental Dimensions Weight Consolidated "e" Series Hardware Installation Guide C-Tick (Australian Communication Authority) Underwriters Laboratories (USA and Canada)

  • Page 106: Summit 300 Series Switch Specifications

    “e” Series Technical Specifications Table 23: Summit 200-24 Unique Specifications Physical and Environmental Heat Dissipation, Watts/BTU 24.1 W Table 24: Summit 200-48 Unique Specifications Physical and Environmental Dimensions Height: 1.75 inches (4.44 cm) Width: 17.3 inches (43.94 cm) Depth: 12.2 inches (31.00 cm) Weight Weight: 9.7 lbs (4.4 kg)

  • Page 107: Summit 400 Series Switch Specifications

    Summit 300-48 switchSummit 300-48 switchDimensions Summit 300-48 switchSwitch Power-Off Temperature power-off Summit 400 Series Switch Specifications The Summit series has a single model, the Summit 400-48t, which has these characteristics: Table 28: Summit 400-48t specifications Physical and Environmental Dimensions Weight...
  • Page 108 “e” Series Technical Specifications Consolidated "e" Series Hardware Installation Guide...
  • Page 109 Summit 300-48 switch Summit 300-48 switch power switch agency certifications airflow requirements amperage, calculating ANSI standards automatic failover setting up Summit 200-24 rules Summit 200-48 rules Summit 300 rules Summit 400-48t rules bend radius fiber optic building codes bundling cable cable...
  • Page 110 Summit 200-24 switch Summit 300-48 power supply electrostatic discharge environmental requirements planning for Summit 200-24 switch Summit 200-48 switch Summit 400-48t switch EPS-160 EPS-T ER XENPAK External Power Supply EPS-LD External Power System fan status LED...
  • Page 111 LEDs Summit 300-24 Summit 300-48 Summit 400 Summit 400 switch powered device power-off specifications Summit 200-24 switch rack mounting the switch rack specifications grounding mechanical recommendations mounting holes securing to floor space requirements radio frequency interference...
  • Page 112 Summit 200-24 rules Summit 200-48 rules Summit 300 switches Summit-400 switch UPS, See uninterruptable power supply weight Summit 200-24 Summit 200-48 Summit 400 switch wiring closet airflow requirements grounding humidity planning wiring terminals XENPAK optical transceivers...
