Cadillac 2011 CTS Coupe Owner's Manual

Cadillac 2011 cts/cts-v automobile owner's manual.



Summary of Contents

  • Page 7: Table Of Contents

    Instrument Panel ....1-2 Initial Drive Information ..1-4 Starting the Engine ... 1-4 Remote Keyless Entry (RKE) System .

  • Page 9

    (If Equipped). G. Navigation Button (If Equipped). See Navigation System Manual. (CTS V Model Only). Navigation Display Brightness Control (If Equipped). See Navigation System Manual. Navigation/Radio System (If Equipped). See Navigation System Manual. N. Parking Brake Release Lever. O. Hood Release. See (If Equipped).

  • Page 10

    X. Parking Brake Button. See Shift Lever. See This section provides a brief overview about some of the important features that may or may not be on your specific vehicle. For more detailed information, refer to each of the features which can be found later in this owner manual.

  • Page 11

    The keyless access transmitter is used to lock and unlock the doors from up to 60 m (195 feet) away from the vehicle. Press to unlock the driver door. Press again within five seconds to unlock all remaining doors. Press to lock all doors.

  • Page 12: Door Locks

    For vehicles with this feature, the engine can be started from outside of the vehicle. 1. Aim the Remote Keyless Entry transmitter at the vehicle. 2. Press 3. Immediately after completing Step 2, press and hold until the turn signal lamps flash, or for about 4 seconds if the vehicle is not in view.

  • Page 13: Liftgate, Trunk Release, Windows

    The vehicle must be in P (Park) to operate the power liftgate. To open the liftgate using the button on the driver door, select the mode then press the center of the button. See for more information on programming the height opening settings.

  • Page 14

    To adjust the seat: Move the seat forward or rearward by moving the horizontal control forward or rearward. Raise or lower the front or rear part of the seat cushion by moving the front or rear of the horizontal control up or down. Raise or lower the entire seat by moving the entire horizontal control up or down.

  • Page 15

    Press the top or bottom of control (C) to increase or decrease support in the seatback bolsters. for more information. On vehicles with the memory package, memory buttons 1 and 2 on the driver door are used to save and recall memory settings for the driver seat cushion and seatback, outside mirrors, and the steering column position, if the vehicle is...

  • Page 16: Seats

    If entry/exit recall is programmed on in the vehicle personalization menu, automatic seat and/or steering column movement occurs under the following conditions: The ignition key is removed on vehicles with Remote Keyless Entry (RKE). The ignition is turned to OFF and the driver door is opened on vehicles with Remote Keyless Access.

  • Page 17: Instrument Panel, Safety Belts, Passenger Airbag

    Refer to the following sections for important information on how to use safety belts properly. The passenger sensing system will turn off the right front passenger frontal airbag under certain conditions. The driver airbag, seat mounted side impact airbags and the roof rail airbags are not affected by the passenger sensing system.

  • Page 18

    Controls for the outside power mirrors are on the driver door. To adjust each mirrors: 1. Press to select the driver or passenger side mirror. 2. Press one of the four arrows to move the mirror. 3. Adjust each outside mirror so that a little of the vehicle and the area behind it can be seen.

  • Page 19

    For vehicles with the power tilt wheel, the control is on the left side of the steering column. Push the control up or down to tilt the steering wheel up or down. Push the control forward or rearward to move the steering wheel toward the front or rear of the vehicle.

  • Page 20

    Turns on the parking lamps, together with the sidemarker lamps, taillamps, license plate lamps, and instrument panel lights. Turns on the headlamps, together with parking lamps, sidemarker lamps, taillamps, license plate lamps, and instrument panel lights. For more information, see: The windshield wiper lever is on the right side of the steering column.

  • Page 21: Climate Controls

    wipers run for a few cycles to clear the windshield. Press and hold for more wash cycles. Pull the lever toward you to spray washer fluid on the windshield. The spray continues until the lever is released. The wipers will run a few times.

  • Page 22: Transmission, Radio(s)

    Driver Shift Control (DSC) allows shifting an automatic transmission similar to a manual transmission. DSC can be enabled through the shift lever or the Tap Shift controls, located on the back of the steering wheel (if equipped). See Under light acceleration, the transmission will only allow shifting from 1 (First) to 4 (Fourth).

  • Page 23: Adjustment, Adjustment, Satellite Radio, Bluetooth ®

    The analog clock is located on the instrument panel above the radio. The clock is not connected with any other vehicle system and runs by itself. To adjust the clock: 1. Locate the adjustment buttons directly below the clock face. 2.

  • Page 24

    Some audio steering wheel controls could differ depending on the vehicle's options. Controls that can be adjusted at the steering wheel may include: Press to switch between the radio AM, FM, XM (if equipped), CD, HDD (if equipped), auxiliary input jack, DVD (if equipped), and USB (if equipped).

  • Page 25: Cruise Control, Navigation System

    The cruise control buttons are located on the left side of the steering wheel. Press to turn the system on or off. The indicator light on the button turns on when cruise control is on. Press to make the vehicle accelerate or resume to a previously set speed.

  • Page 26: Center (dic)

    Press to scroll through the vehicle information displays. Press to customize the feature settings on your vehicle. See for more information. Press to reset certain DIC features and to acknowledge DIC warning messages and clear them from the DIC display. Press to scroll up and down the menu items.

  • Page 27: Power Outlets

    Press the bottom of the load floor handle assembly to lift the top on the handle. Pull up on the handle to open the cargo management system. for more information. Accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player.

  • Page 28: Sunroof

    The ignition must be in ON/RUN or ACC/ACCESSORY, or in Retained Accessory Power (RAP), to operate the sunroof and power sunshade. The sunroof switches are on the overhead console. The driver side switch operates the sunshade. Press the front or rear of the switch to open or close the sunshade.

  • Page 29: Tire Pressure Monitor, Compressor Kit

    StabiliTrak assists with directional control of the vehicle in difficult driving conditions. The system turns on automatically every time the vehicle is started. To turn off both traction control and electronic stability control, press and hold on the instrument panel (CTS) or steering wheel (CTS-V) until illuminates and the...

  • Page 30: Engine Oil Life System, Economy, Roadside Service

    TPC Spec number molded into the tire's sidewall near the size. Follow recommended scheduled maintenance. U.S. or Canada: TTY Users (U.S. or Canada): Mexico: As the owner of a new Cadillac, you are automatically enrolled in the Roadside Service program. more information.

  • Page 31: Onstar ®

    If you have an active OnStar subscription, press the button and the current GPS location will be sent to an OnStar advisor who will assess your problem, contact Roadside Service, and relay your exact location to get the help you need. The Online Owner Center is a complimentary service that includes online service reminders, vehicle...

  • Page 32

    Not all OnStar services are available on all vehicles. For more information, see the OnStar Owner's Guide; visit www.onstar.com (U.S.) or www.onstar.ca (Canada); contact OnStar at 1-888-4-ONSTAR (1 888 466 7827) or TTY 1 877 248 2080; or push button to speak with an OnStar Advisor 24 hours a day, 7 days a week.

  • Page 33

    for information regarding Part 15 of the Federal Communications Commission (FCC) rules and Industry Canada Standards RSS-210/220/310. This vehicle may have Talk/Mute button that can be used to interact with OnStar Hands-Free calling. See for more information. On some vehicles, the button can be used to dial numbers into voice mail systems, or to dial phone...

  • Page 143: Windshield Wiper/washer

    Instruments and Controls Controls Steering Wheel Adjustment . . . 5-2 Steering Wheel Controls (Audio) ..... . 5-3 Heated Steering Wheel ..5-4 Horn .

  • Page 144: Universal Remote System

    Instruments and Controls Anti-Theft Alarm System Messages ....5-43 Service Vehicle Messages . . . 5-43 Tire Messages ....5-44 Transmission Messages .

  • Page 145

    Steering Wheel Controls (Audio) Some audio steering wheel controls could differ depending on the vehicle's options. Controls that can be adjusted at the steering wheel may include: SRCE (Source): Press to switch between the radio AM, FM, (if equipped), CD, DVD (if equipped), HDD (if equipped), auxiliary input jack, and USB (if equipped).

  • Page 146

    Instruments and Controls Heated Steering Wheel For vehicles with a heated steering wheel. : Press to turn the heated steering wheel on or off. A light on the button displays when the feature is turned on. The steering wheel takes about three minutes to start heating.

  • Page 147

    If the windshield wipers are in use for about six seconds while you are driving, the exterior lamps come on automatically if the exterior lamp control is in AUTO. See Wiper Activated Headlamps for more information. Clear snow and ice from the wiper blades before using them.

  • Page 148

    Instruments and Controls Rear Window Wiper/Washer For vehicles with a rear window wiper/washer, the controls are on the end of the windshield wiper lever. Press the upper or lower portion of the button to control the rear wiper and rear wiper delay. The system turns off when the button is returned to the middle position.

  • Page 149

    The headlamps must be on to be washed. If the headlamps are off, only the windshield will be washed when the washer button is pressed. If the washer fluid is low, the headlamp washers will not work. for more information. Compass The vehicle may have a compass in the Driver Information Center (DIC).

  • Page 150

    Instruments and Controls If the DIC display does not show a heading, for example, N for North, or the heading does not change after making turns, there may be a strong magnetic field interfering with the compass. Interference may be caused by a magnetic antenna mount, magnetic note pad holder, or any other magnetic item.

  • Page 151

    Power Outlets Accessory power outlets can be used to plug in electrical equipment, such as a cell phone or MP3 player. There are three accessory power outlets. The power outlets located below the climate control system, inside the center console storage bin, and on the rear of the center console are powered while the vehicle is in ON/RUN, START or...

  • Page 152: Storage Compartments

    5-10 Instruments and Controls Ashtrays The vehicle may have two removable ashtrays. One ashtray can be placed into the instrument panel storage compartment and the other into the center console rear compartment. To empty the ashtrays, hold on to the edges of the bin and pull straight out.

  • Page 153

    Instruments and Controls 5-11 Instrument Cluster English shown, Metric similar...

  • Page 154

    5-12 Instruments and Controls English V-Series shown, Metric and Manual similar...

  • Page 155

    Speedometer The speedometer shows the vehicle's speed in either kilometers per hour (km/h) or miles per hour (mph). Odometer The odometer shows how far the vehicle has been driven, in either kilometers or miles. This vehicle has a tamper resistant odometer.

  • Page 156

    5-14 Instruments and Controls The Fuel Level Low message appears in the Driver Information Center (DIC) and a single chime sounds. See for more information. Normal operation of the fuel gauge includes: At the service station, the fuel pump shuts off before the gauge reads full.

  • Page 157

    For the CTS-V, the tachometer tracer lights flash prior to reaching engine speed limit. The tracer lights also flash on automatic transmission vehicles while in the DSC or Tap Shift modes. Engine Oil Pressure Gauge Metric Instruments and Controls English For vehicles with an engine oil pressure gauge, it shows the engine oil pressure in kPa (kilopascals)

  • Page 158

    5-16 Instruments and Controls Engine Coolant Temperature Gauge Metric English This gauge shows the engine coolant temperature. If the engine coolant overheats, the engine coolant temperature warning light comes on. See for more information. Safety Belt Reminders Driver Safety Belt Reminder Light There is a driver safety belt reminder light on the instrument...

  • Page 159

    If the driver safety belt is already buckled, neither the light nor the chime comes on. Passenger Safety Belt Reminder Light Several seconds after the engine is started, a chime sounds for a number of seconds to remind the front passenger to buckle their safety belt.

  • Page 160

    5-18 Instruments and Controls Passenger Airbag Status Indicator The vehicle has a passenger sensing system. See important safety information. The instrument panel has a passenger airbag status indicator. United States Canada and Mexico When the vehicle is started, the passenger airbag status indicator will light the words ON and OFF, or the symbols for on and off, for several seconds as a system check.

  • Page 161

    Charging System Light The charging system light comes on briefly when the ignition is turned on, but the engine is not running, as a check to show the light is working. It should go out when the engine is started. If the light stays on, or comes on while driving, there may be a problem with the electrical charging...

  • Page 162

    5-20 Instruments and Controls Malfunctions often are indicated by the system before any problem is apparent. Being aware of the light can prevent more serious damage to the vehicle. This system assists the service technician in correctly diagnosing any malfunction. If the vehicle is continually driven with this light on, after a while, the emission...

  • Page 163

    Make sure the electrical system is not wet. The system could be wet if the vehicle was driven through a deep puddle of water. The condition is usually corrected when the electrical system dries out. A few driving trips should turn the light off. Make sure to fuel the vehicle with quality fuel.

  • Page 164

    5-22 Instruments and Controls The diagnostic system evaluates critical emission control systems during normal driving. This can take several days of routine driving. If this has been done and the vehicle still does not pass the inspection, your dealer can prepare the vehicle for inspection.

  • Page 165

    For vehicles with the Electric Park Brake (EPB), this park brake status light should come on briefly when ignition is placed in ON/RUN. If it does not come on then, have it fixed so it will be ready to warn if there is a problem.

  • Page 166: System (tcs)

    5-24 Instruments and Controls For the CTS-V, the tracer lights function as a performance up-shift light. The tracers flash to indicate when to shift to the next higher gear to avoid the engine speed limit. for more information. Traction Control System ®...

  • Page 167

    When the Light is On Steady This indicates that one or more of the tires are significantly underinflated. A tire pressure message can accompany the light. See for more information. Stop as soon as possible, and inflate the tires to the pressure value shown on the Tire and Loading Information label.

  • Page 168

    5-26 Instruments and Controls Security Light This light flashes when the security system is activated. For more information, see High-Beam On Light The high-beam on light comes on when the high-beam headlamps are in use. for more information. Front Fog Lamp Light The front fog lamp light comes on when the fog lamps are in use.

  • Page 169

    Cruise Control Light This light comes on whenever the cruise control is active. The light goes out when the cruise control is turned off. See for more information. Instruments and Controls Information Displays Driver Information Center (DIC) The Driver Information Center (DIC) provides status of many vehicle systems.

  • Page 170

    5-28 Instruments and Controls (Vehicle Information): Press to scroll through the vehicle information displays. See Vehicle Information Display Menu Items following for more information. (Customization): Press to scroll through each of the customization features. See more information. (Set/Reset): Press to reset certain DIC features and to acknowledge and clear DIC warning messages.

  • Page 171

    To turn off the timer, press the set/reset button again. The timer displays the end timing value. To reset the timer to zero, press and hold the set/reset button. Inst (Instantaneous) Economy Displays the current fuel economy in either liters per 100 kilometers (L/100 km) or miles per gallon (mpg).

  • Page 172

    5-30 Instruments and Controls Parking Assist If the vehicle has the Ultrasonic Rear Parking Assist (URPA) system, this display allows the system to be turned on or off. Once in this display, press the set/reset button to select between On or Off. The URPA system automatically turns back on after each vehicle start.

  • Page 173

    Lateral Acceleration (CTS-V Only) Lateral Acceleration measures the force of a turn or corner. For example, when turning right, it forces to the left. This gauge displays the g force from 0.0 g to 2.0 g. Blank Display This display shows no information. DIC Compass The vehicle may have a compass in the Driver Information Center (DIC).

  • Page 174: Starting The Engine, System

    5-32 Instruments and Controls BATTERY VOLTS LOW This message displays when the electrical system is charging less than 10 volts or the battery has been drained. If this message appears immediately after starting the engine, it is possible that the generator can still recharge the battery.

  • Page 175

    PRESS BRAKE TO START ENGINE (AUTOMATIC TRANSMISSION ONLY) If the vehicle has the keyless access system, this message displays if you try to start the engine without having the brake pressed. The brake needs to be pressed when starting the engine. See more information.

  • Page 176

    5-34 Instruments and Controls STEP ON BRAKE TO RELEASE PARK BRAKE For vehicles with the Electric Parking Brake, this message displays if you try to release the park brake system without first pressing the brake pedal. See the Electric Parking Brake information under for more information.

  • Page 177

    TRUNK OPEN (Sedan and Coupe) This message displays when the trunk is not closed completely. Make sure that the trunk is closed completely. Engine Cooling System Messages ENGINE HOT A/C (AIR CONDITIONING) OFF This message displays when the engine coolant becomes hotter than the normal operating temperature.

  • Page 178

    5-36 Instruments and Controls ENGINE OIL LOW ADD OIL If the vehicle has an oil level sensor, this message displays if the oil level in the vehicle is low. Check the oil level and correct it as necessary. You may need to let the vehicle cool or warm up and cycle the ignition to be sure this message clears.

  • Page 179

    TIGHTEN GAS CAP This message displays when the fuel cap has not been fully tightened. Recheck the fuel cap to ensure that it is on and tightened properly. Key and Lock Messages ACCESSORY MODE ACTIVE If the vehicle has the keyless access system, this message displays when the accessory mode is active.

  • Page 180

    5-38 Instruments and Controls If moving the transmitter to different locations within the vehicle does not help, place the transmitter in the center console transmitter pocket with the buttons facing the front of the vehicle and then start the vehicle. The vehicle's battery voltage is low.

  • Page 181

    PRESS START CONTROL TO LEARN KEYS If the vehicle has the keyless access system, this message displays when matching new transmitters to the vehicle. See the Keyless Access information for for more information. READY TO LEARN ELECTRONIC KEY # X If the vehicle has the keyless access system, this message displays while matching new...

  • Page 182

    5-40 Instruments and Controls AUTOMATIC LIGHT CONTROL OFF This message displays when the automatic headlamps are turned off. AUTOMATIC LIGHT CONTROL ON This message displays when the automatic headlamps are turned on. TURN SIGNAL ON This message displays as a reminder to turn off the turn signal if you drive the vehicle for more than about 1.6 km (1 mile)

  • Page 183

    SERVICE ALL WHEEL DRIVE This message displays if a problem occurs with the All-Wheel Drive (AWD) system. The vehicle will run in 2WD. This could be caused by: An electronics problem An AWD system oil overheat Worn out or overheated clutch plates Various electrical issues If this message appears, stop as...

  • Page 184

    5-42 Instruments and Controls STABILITRAK COMPETITIVE MODE This message displays when the Competitive Driving mode is selected. When in this mode, the Traction Control System (TCS) will not be operating and the TCS/ StabiliTrak warning light will turn on. Adjust your driving accordingly. See Competitive Driving Mode under for more information.

  • Page 185

    SUSPENSION MODE TOUR (CTS-V ONLY) This message will be displayed when touring mode is selected using the Magnetic Ride Control button in the center of the instrument panel. See for more information. Airbag System Messages SERVICE AIR BAG This message displays when there is a problem with the airbag system.

  • Page 186

    5-44 Instruments and Controls SERVICE VEHICLE SOON This message displays when a non-emissions related malfunction occurs. Have the vehicle serviced by your dealer as soon as possible. Tire Messages SERVICE TIRE MONITOR SYSTEM This message displays if a part on the Tire Pressure Monitor System (TPMS) is not working properly.

  • Page 187

    Transmission Messages DIFFERENTIAL HOT, REDUCE SPEED (CTS-V ONLY) This message displays and a chime sounds if the differential fluid temperature exceeds 150°C (300°F). Driving aggressively or at high speeds can cause the differential fluid temperature to be higher than normal. If this message appears, you may continue to drive at a slower speed.

  • Page 188

    5-46 Instruments and Controls SPEED LIMITED TO XXX KM/H (MPH) This message displays when the vehicle speed is limited to 128 km/h (80 mph) because the vehicle detects a problem in the speed variable assist steering, magnetic ride control, or automatic leveling control systems.

  • Page 189

    Press the customization button until the Display Language screen appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the menu up/down button to scroll through the following settings: English (default): All messages will appear in English.

  • Page 190

    5-48 Instruments and Controls Press the customization button until Auto Door Unlock appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the menu up/down button to scroll through the following settings: Off: None of the doors will automatically unlock.

  • Page 191

    To select a setting, press the set/reset button while the desired setting is displayed on the DIC. Remote Door Unlock Feedback This feature allows you to select the type of feedback you will receive when unlocking the vehicle with the Remote Keyless Entry (RKE) or keyless access transmitter, or when the vehicle is automatically...

  • Page 192

    5-50 Instruments and Controls Approach Lighting This feature allows you to select whether or not to have the exterior lights turn on briefly during low light periods after unlocking the vehicle using the Remote Keyless Entry (RKE) or keyless access transmitter. Press the customization button until Approach Lighting appears on the DIC display.

  • Page 193

    For example, if there are two keyless access transmitters in the vehicle and one is removed, the other will be locked in. The keyless access transmitter locked in the vehicle can still be used to start the vehicle or unlock the doors, if needed.

  • Page 194

    5-52 Instruments and Controls Press the customization button until Keyless Unlock appears on the DIC display. Press the set/reset button once to access the settings for this feature. Then press the menu up/down button to scroll through the following settings: Entry Door Only: Only the driver door will automatically unlock when you approach the vehicle with the...

  • Page 195

    Entry/Exit Recall Off (default): No automatic Entry/Exit Recall will occur when entering or leaving the vehicle. The Exit recall will only occur after pressing the door mounted EXIT button. This button will cause the drivers seat to move rearward a certain distance, and the steering column to move full up and full forward, if equipped.

  • Page 196

    5-54 Instruments and Controls Exiting the Feature Settings Menu The feature settings menu will be exited when any of the following occurs: The vehicle is no longer in ON/RUN. The trip/fuel or vehicle information DIC buttons are pressed. The end of the feature settings menu is reached and exited.

  • Page 197

    When programming a garage door, park outside of the garage. Park directly in line with and facing the garage door opener motor-head or gate motor-head. Be sure that people and objects are clear of the garage door or gate that is being programmed.

  • Page 198

    5-56 Instruments and Controls 4. The indicator light on the Universal Home Remote will flash slowly at first and then rapidly after Universal Home Remote successfully receives the frequency signal from the hand-held transmitter. Release both buttons. 5. Press and hold the newly-trained Universal Home Remote button and observe the indicator light.

  • Page 199

    To program the remaining two Universal Home Remote buttons, begin with Step 2 of Programming the Universal Home Remote System. Do not repeat Step 1, as this will erase all previous programming from the Universal Home Remote buttons. Gate Operator and Canadian Programming If you have questions or need help programming the Universal...

  • Page 200

    5-58 Instruments and Controls Erasing Universal Remote Buttons All programmed buttons should be erased when the vehicle is sold or the lease ends. To erase all programmed buttons on the Universal Remote device: 1. Press and hold down the two outside buttons until the indicator light begins to flash, after 20 seconds.

  • Page 323

    General Information ..10-3 California Proposition 65 Warning ....10-3 California Perchlorate Materials Requirements ..10-3 Accessories and Modifications .

  • Page 324

    Rear Compartment Fuse Block (CTS Coupe and Sedan) ....10-55 Rear Compartment Fuse Block (CTS-V Coupe and Sedan) ....10-57 Rear Compartment Fuse Block (CTS Wagon) .

  • Page 325

    For service and parts needs, visit your dealer. You will receive genuine GM parts and GM-trained and supported service people. Genuine GM parts have one of these marks: Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

  • Page 326

    GM Accessories are designed to complement and function with other systems on the vehicle. Your GM dealer can accessorize the vehicle using genuine GM Accessories. When you go to your GM dealer and ask for GM Accessories, you will know that GM-trained and supported service technicians will perform the work using genuine GM Accessories.

  • Page 327

    To open the hood: 1. Pull the hood release lever with this symbol on it. It is located inside the vehicle on the lower side of the instrument panel. 2. Go to the front of the vehicle and find the secondary hood release lever.

  • Page 329

    A. Windshield Washer Fluid Reservoir. See C. Remote Positive (+) Terminal. D. Remote Negative ( ) Terminal. E. Passenger Compartment Air Filter. See Engine Cooling Fan (Out of View). See G. Power Steering Fluid Reservoir. H. Engine Oil Fill Cap. See Engine Oil Dipstick (Out of View).

  • Page 331

    A. Windshield Washer Fluid Reservoir. See C. Remote Positive (+) Terminal. D. Remote Negative ( ) Terminal. E. Engine Oil Fill Cap (Out of View). See Engine Oil Dipstick. See G. Passenger Compartment Air Filter. See H. Intercooler System Pressure Cap.

  • Page 332

    To remove: 1. Remove the oil fill cap (A). 2. Raise the right front corner of the engine cover (B) to release it from the ball stud. 3. Pull the engine cover (B) forward to slide the rear tabs (C) out from under the retainers.

  • Page 333

    Change the engine oil at the appropriate time. See Always dispose of engine oil properly. See What to Do with Used Oil in this section. It is a good idea to check the engine oil level at each fuel fill. In order to get an accurate reading, the vehicle must be on level ground.

  • Page 334

    Selecting the right engine oil depends on both the proper oil specification and viscosity grade: Use and ask for engine oils with the dexos certification mark. Oils meeting the requirements of the vehicle should have the dexos certification mark on the container. This certification mark indicates that the oil has been approved to the dexos...

  • Page 335

    Cold Temperature Operation: In an area of extreme cold, where the temperature falls below 29°C ( 20°F), an SAE 0W-30 oil should be used. An oil of this viscosity grade will provide easier cold starting for the engine at extremely low temperatures.

  • Page 336

    This vehicle has a computer system that indicates when to change the engine oil and filter. This is based on engine revolutions and engine temperature, and not on mileage. Based on driving conditions, the mileage at which an oil change is indicated can vary considerably.

  • Page 337

    done at the dealer service department. Contact your dealer for additional information or refer to the procedure in the service manual. To purchase a service manual, see Change the fluid and filter at the intervals listed in , and be sure to use the fluid listed in It is not necessary to check the manual transmission fluid level.

  • Page 338

    The engine air cleaner/filter is in the engine compartment on the driver side of the vehicle, near the front. for more information on location. Inspect the air cleaner/filter at the scheduled maintenance intervals and replace it at the first oil change after each 80 000 km (50,000 mile) interval.

  • Page 339

    6. Remove the three air cleaner 7. Move the air cleaner housing 8. Remove the air cleaner filter housing cover screws. cover and remove the cover from the air cleaner housing. from the air cleaner housing.

  • Page 340

    1. Install the air cleaner into the air cleaner housing. The outer air cleaner filter seal must be fitted properly in the air cleaner housing. 2. Align the air cleaner housing cover tabs to the air cleaner housing. 3. Install the air cleaner housing cover.

  • Page 341

    An electric engine cooling fan under the hood can start up even when the engine is not running and can cause injury. Keep hands, clothing, and tools away from any underhood electric fan. Heater and radiator hoses, and other engine parts, can be very hot.

  • Page 342

    Adding only plain water or some other liquid to the cooling system can be dangerous. Plain water and other liquids, can boil before the proper coolant mixture will. The coolant warning system is set for the proper coolant mixture. With plain water or the wrong mixture, the engine could get too hot but you would not get the overheat warning.

  • Page 343

    DEX-COOL coolant at the coolant surge tank, but be sure the cooling system is cool before this is done. If the engine is warm or hot, the coolant level should be at or above the FROID/FULL COLD line on the side of the coolant surge tank.

  • Page 344

    2. Then keep turning the pressure cap slowly and remove it. 3. Fill the coolant surge tank with the proper mixture, to slightly above the FROID/FULL COLD line on the side of the coolant surge tank. 4. With the coolant surge tank pressure cap off, start the engine and let it run until you can feel the upper radiator hose...

  • Page 345

    The vehicle must be on a level surface when checking the coolant level. The super charged engine intercooler coolant fill neck is located in the engine compartment on the passenger side of the vehicle. See On the coolant fill neck, there is a cold fill region between the two horizontal lines shown.

  • Page 346

    4. Then replace the pressure cap. Be sure the pressure cap is hand-tight and fully seated. If the coolant is not at the proper level when the system cools down again, see your dealer. The vehicle has several indicators to warn of engine overheating. There are two engine hot messages that may be displayed in the Driver Information Center (DIC).

  • Page 347

    If an engine overheat warning is displayed but no steam can be seen or heard, the problem may not be too serious. Sometimes the engine can get a little too hot when the vehicle: Climbs a long hill on a hot day. Stops after high-speed driving.

  • Page 348

    It is not necessary to regularly check power steering fluid unless you suspect there is a leak in the system or you hear an unusual noise. A fluid loss in this system could indicate a problem. Have the system inspected and repaired. To check the power steering fluid: 1.

  • Page 349

    This vehicle has disc brakes. Disc brake pads have built-in wear indicators that make a high-pitched warning sound when the brake pads are worn and new pads are needed. The sound can come and go or be heard all the time the vehicle is moving, except when applying the brake pedal firmly.

  • Page 350

    Every time the brakes are applied, with or without the vehicle moving, the brakes adjust for wear. The braking system on a vehicle is complex. Its many parts have to be of top quality and work well together if the vehicle is to have really good braking.

  • Page 351

    If too much brake fluid is added, it can spill on the engine and burn, if the engine is hot enough. You or others could be burned, and the vehicle could be damaged. Add brake fluid only when work is done on the brake hydraulic system.

  • Page 352

    The battery is in the trunk, behind the trim panel, on the passenger side of the vehicle. Refer to the replacement number shown on the original battery label when a new battery is needed. Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive...

  • Page 353

    If your vehicle is equipped with all-wheel-drive, this is an additional system that needs lubrication. It is not necessary to regularly check the transfer case fluid unless you suspect there is a leak or you hear an unusual noise. A fluid loss could indicate a problem.

  • Page 354

    Do not use the accelerator pedal, and be ready to turn off the engine immediately if it starts. 3. For automatic transmission vehicles, try to start the engine in each gear. The vehicle should start only in P (Park) or N (Neutral).

  • Page 355

    While parked, and with the parking brake set, try to turn the ignition to LOCK/OFF in each shift lever position. The ignition should turn to LOCK/OFF only when the shift lever is in P (Park). With the key access ignition system, the ignition key should come out only in LOCK/OFF.

  • Page 356

    Windshield wiper blades should be inspected for wear or cracking. It is a good idea to clean or replace the wiper blade assembly on a regular basis or when worn. For proper windshield wiper blade length and type, see To replace the wiper blade assembly: 1.

  • Page 357

    The vehicle has a visual optical headlamp aiming system. The aim has been preset at the factory and should need no further adjustment. However, if the vehicle is damaged in a crash, the headlamp aim may be affected and adjustment may be necessary.

  • Page 358

    2. Locate the aim dot on the lens of the low beam headlamp. 3. Record the distance from the ground to the aim dot on the low beam headlamp. 4. At a wall, measure from the ground upward (A) to the recorded distance from Step 3 and mark it.

  • Page 359

    Turn it clockwise or counterclockwise to raise or lower the angle of the beam. The top edge of the cut-off should be positioned at the bottom edge of the horizontal tape line. 9. Make sure that the light from the headlamp is positioned at the bottom edge of the horizontal tape line.

  • Page 360

    To replace a front fog lamp bulb: 1. Pull out the push-pins located on the underside of the protection shield to remove the shield. 2. Reach up behind the front bumper area from under the vehicle to access the lamp housing.

  • Page 361

    To replace one of these bulbs: 1. Open the liftgate. See for more information. 2. Push the left end of the lamp assembly towards the right. 3. Turn the lamp assembly down to remove it from the liftgate. A. Bulb Socket B.

  • Page 362

    The vehicle has fuses and circuit breakers to protect against an electrical system overload. When the current electrical load is too heavy, the circuit breaker opens and closes, protecting the circuit until the current load returns to normal or the problem is fixed. This greatly reduces the chance of circuit overload and fire caused by electrical problems.

  • Page 363

    The wiring circuits in the vehicle are protected from short circuits by a combination of fuses and circuit breakers. This greatly reduces the chance of damage caused by electrical problems. To check a fuse, look at the silver-colored band inside the fuse. If the band is broken or melted, replace the fuse.

  • Page 364

    Not Used Antilock Braking System (ABS) Display Not Used Body Control Module 1 Automatic Forward Lighting System (HID Only) Body Control Module 5 Body Control Module 4 Navigation Motor All-Wheel Drive Transmission Control Module Battery Horn Left Low Beam Headlamp (Domestic Non HID Only) Pedestrian...

  • Page 365

    Headlamp Washer (HID Only) Right Low Beam Headlamp (Domestic Non HID Only) Air Conditioning Compressor Clutch Low Beam Daytime Running Lamps (non HID), Left Daytime Running Lamps (HID), Left Trailer Turn Signal (Export Only) Left High Beam Headlamp Right High Beam Headlamp Right Daytime Running Lamp,...

  • Page 366

    Front Fog Lamps (HID Only) Body Control Module 6, Body Control Module 7 Emissions 1 Even Ignition Coils Engine Control Module Emissions 2 Odd Ignition Coils Transmission Output Speed Sensor, Brake Vacuum Relay Spare Spare Spare Spare Spare Spare Cooling Fan 2 Cooling Fan 1 Starter Brake...

  • Page 367

    Cooling Fan (Series/Parallel) Air Conditioning Compressor Clutch Windshield Washer Pump Right Daytime Running Lamp, Trailer Turn Signal Low Beam (non HID), Left Daytime Running Lamps (HID), Left Trailer Turn Signal (Export Only) Front Fog Lamps (HID Only) High Beam Headlamps Daytime Running Lamps (Non HID), Low Beam...

  • Page 368

    Not Used Antilock Braking System (ABS) Display Sunroof Body Control Module 1 Automatic Forward Lighting System (HID Only) Body Control Module 5 Body Control Module 4 Navigation Motor Not Used Transmission Control Module Battery Horn Not Used Pedestrian Protection System (Export Only) Body Control Module 3...

  • Page 369

    Left Daytime Running Lamps (HID) Left High Beam Headlamp Right High Beam Headlamp Right Daytime Running Lamp, Windshield Washer Pump Airbag System Ignition Switch Engine Control Module Ignition, Transmission Control Module Ignition Power Moding (Immobilizer Module, Ignition Switch) Intercooler Pump Windshield Wipers Right Low Beam (HID Only)

  • Page 370

    Cooling Fan 2 Cooling Fan 1 Starter Not Used Antilock Brake System Motor Not Used Electric Parking Brake Not Used Not Used Blower Motor Rear Window Defogger Magnetic Ride/ Suspension Control Cooling Fan 2 Cooling Fan 1 Starter Rear Window Defogger Instrument Panel Auxiliary Power...

  • Page 371

    Lift the fuse block cover to access the fuses. The vehicle may not be equipped with all of the fuses and relays shown. Not Used Antilock Braking System (ABS) Display Not Used Body Control Module 1 Automatic Forward Lighting System (HID Only) Body Control Module 5...

  • Page 372

    Body Control Module 4 Navigation Motor All-Wheel Drive Transmission Control Module Battery Horn Left Low Beam Headlamp (Domestic Non HID Only) Pedestrian Protection System (Export Only) Body Control Module 3 Body Control Module 2 Headlamp Washer (HID Only) Right Low Beam Headlamp (Domestic Non HID Only)

  • Page 373

    Instrument Panel Auxiliary Power Outlet Air Quality Sensor, Inside Rear View Mirror, Rear Camera Ignition Steering Wheel Illumination Front Fog Lamps (HID Only) Body Control Module 6, Body Control Module 7 Emissions 1 Even Ignition Coils Engine Control Module Emissions 2 Odd Ignition Coils Transmission Output Speed...

  • Page 374

    Instrument Panel Auxiliary Power Outlet Horn Headlamp Washer (HID Only) Cooling Fan (Series/Parallel) Air Conditioning Compressor Clutch Not Used Right Daytime Running Lamp, Trailer Turn Signal Low Beam (non HID), Left Daytime Running Lamps (HID), Left Trailer Turn Signal (Export Only) Front Fog Lamps (HID Only) High Beam...

  • Page 375

    Not Used Antilock Braking System (ABS) Display Sunroof Body Control Module 1 Automatic Forward Lighting System (HID Only) Body Control Module 5 Body Control Module 4 Navigation Motor Not Used Transmission Control Module Battery Horn Not Used Pedestrian Protection System (Export Only) Body Control Module 3...

  • Page 376

    Left Daytime Running Lamp (HID) Left High Beam Headlamp Right High Beam Headlamp Right Daytime Running Lamp Airbag System Ignition Switch Engine Control Module Ignition, Transmission Control Module Ignition Power Moding (Immobilizer Module, Ignition Switch) Intercooler Pump Windshield Wipers Right Low Beam (HID Only) Left Low Beam (HID Only)

  • Page 377

    Not Used Antilock Brake System Motor Not Used Electric Parking Brake Not Used Not Used Blower Motor Rear Window Defogger Magnetic Ride/ Suspension Control Cooling Fan 2 Cooling Fan 1 Starter Rear Window Defogger Instrument Panel Auxiliary Power Outlet Horn Headlamp Washer (HID Only) Cooling Fan...

  • Page 378

    Stop Lamps (Export Only) Door Lock Door Unlock Fuel Door Unlock (Export Only) Right Position Lamp (Export Only) Console/Auxiliary Power Outlet Sedan Trunk Release/Coupe Rear Fog (Export Only) Side Marker Lamps Left Position Lamps Right Position Lamp Left Position Lamp Door Lock Console/Auxiliary Power Outlet...

  • Page 379

    Right Position Lamp (Export Only) Regulated Voltage Control Sensor Audio System (Radio) Airbag System Remote Keyless ® Entry/PASS Key Theft Deterrent Module Audio Speakers/ Subwoofer ® OnStar System (If Equipped) Engine Control Module Canister Vent Fuel Pump Stop Lamps (Export Only) Theft Deterrent System/Universal Garage Door...

  • Page 380

    Stop Lamps (Export Only) Door Lock Door Unlock Fuel Door Unlock (Export Only) Right Position Lamp (Export Only) Console/Auxiliary Power Outlet Sedan Trunk Release/Coupe Rear Fog (Export Only) Side Marker Lamps Left Position Lamps Right Position Lamp Left Position Lamp Door Lock Console/Auxiliary Power Outlet...

  • Page 381

    Right Position Lamp (Export Only) Regulated Voltage Control Sensor Audio System (Radio) Airbag System Remote Keyless ® Entry/PASS Key Theft Deterrent Module Audio Speakers/ Subwoofer ® OnStar System (If Equipped) Engine Control Module Canister Vent Rear Differential Cooling Pump Stop Lamps (Export Only) Theft Deterrent System/Universal...

  • Page 382

    Stop Lamps (Export Only) Door Lock Door Unlock Fuel Door Unlock (Export Only) Right Position Lamp (Export Only) Console/Auxiliary Power Outlet Not Used Side Marker Lamps Left Position Lamps Right Position Lamp Left Position Lamp Door Lock Console/Auxiliary Power Outlet Rear Fog/Export Body Control Module...

  • Page 383

    Right Position Lamp (Export Only) Regulated Voltage Control Sensor Audio System (Radio) Airbag System Remote Keyless ® Entry/PASS Key Theft Deterrent Module Audio Speakers/ Subwoofer ® OnStar System (If Equipped) Engine Control Module Canister Vent Fuel Pump Stop Lamps (Export Only) Theft Deterrent System/Universal Garage Door...

  • Page 384

    Stop Lamps (Export Only) Door Lock Door Unlock Fuel Door Unlock (Export Only) Right Position Lamp (Export Only) Console/Auxiliary Power Outlet Not Used Side Marker Lamps Left Position Lamps Right Position Lamp Left Position Lamp Door Lock Console/Auxiliary Power Outlet Rear Fog/Export Body Control Module...

  • Page 385

    Right Position Lamp (Export Only) Regulated Voltage Control Sensor Audio System (Radio) Airbag System Remote Keyless ® Entry/PASS Key Theft Deterrent Module Audio Speakers/ Subwoofer ® OnStar System Engine Control Module Canister Vent Rear Differential Cooling Pump Stop Lamps (Export Only) Theft Deterrent System/Universal Garage Door...

  • Page 386

    Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever have questions about your tire warranty and where to obtain service, see your vehicle Warranty booklet for details. For additional information refer to the tire manufacturer. Poorly maintained and improperly used tires are dangerous.

  • Page 387

    If you expect to drive on snow or ice covered roads often, you may want to get winter tires for your vehicle. All season tires provide good overall performance on most surfaces but they may not offer the traction you would like or the same level of performance as winter tires on snow or ice covered roads.

  • Page 388

    Many General Motors high performance models come factory equipped with tires that are optimized for maximum dry and wet road performance while still retaining satisfactory tread life, excellent durability, and low noise levels. In severe winter climates where snowfall may be significant, these tires may be found to provide less traction.

  • Page 389

    The letters and numbers following the DOT (Department of Transportation) code is the Tire Identification Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured. The TIN is molded onto both sides of the tire, although only one side may have the date of manufacture.

  • Page 390

    Maximum load that can be carried and the maximum pressure needed to support that load. temporary use tire or compact spare tire should be inflated to 420 kPa (60 psi). For more information on tire pressure and inflation see A combination of letters and numbers define a tire's width, height, aspect ratio, construction type, and service...

  • Page 391

    Diameter of the wheel in inches. These characters represent the load index and speed rating of the tire. The load index represents the load carrying capacity a tire is certified to carry. The speed rating is the maximum speed a tire is certified to carry a load.

  • Page 392

    A code molded into the sidewall of a tire signifying that the tire is in compliance with the U.S. Department of Transportation (DOT) motor vehicle safety standards. The DOT code includes the Tire Identification Number (TIN), an alphanumeric designator which can also identify the tire manufacturer, production plant, brand, and date of production.

  • Page 393

    tire used on passenger cars and some light duty trucks and multipurpose vehicles. Vehicle manufacturer's recommended tire inflation pressure as shown on the tire placard. See A pneumatic tire in which the ply cords that extend to the beads are laid at 90 degrees to the centerline of the tread.

  • Page 394

    A label permanently attached to a vehicle showing the vehicle capacity weight and the original equipment tire size and recommended inflation pressure. See Tire and Loading Information Label under Tires need the correct amount of air pressure to operate effectively. A vehicle-specific Tire and Loading Information label is attached to the vehicle.

  • Page 395

    Use a good quality pocket-type gauge to check tire pressure. You cannot tell if the tires are properly inflated simply by looking at them. Radial tires may look properly inflated even when they are underinflated. Check the tire's inflation pressure when the tires are cold.

  • Page 396

    Example: You will find the maximum load and inflation pressure molded on the tire's sidewall, in small letters, near the rim flange. It will read something like this: Maximum load 690 kg (1521 lbs) 300 kPa (44 psi) Max. Press. For this example, you would set the inflation pressure for high speed driving at 44 psi (300 kPa).

  • Page 397

    When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly.

  • Page 398

    A DIC warning message to check the pressure in a specific tire is also shown on the DIC display screen. The low tire pressure warning light and the DIC warning message come at each ignition cycle until the tires are inflated to the correct inflation pressure.

  • Page 399

    the road tire containing the TPMS sensor and the sensor matching process is performed successfully. See TPMS Sensor Matching Process later in this section. The TPMS sensor matching process was not done or not completed successfully after rotating the vehicle's tires. The malfunction light and the DIC message should go off after successfully completing the...

  • Page 400

    There are two minutes to match the first tire/wheel position, and five minutes overall to match all four tire/wheel positions. If it takes longer, the matching process stops and must be restarted. The TPMS matching process is outlined below: 1. Set the parking brake. 2.

  • Page 401

    The tire has a puncture, cut, or other damage that cannot be repaired well because of the size or location of the damage. Tire rotation is not recommended if the vehicle has P235/50R18, 245/45ZR19 or 255/40R19 size tires on the front wheels and P265/45R18, 275/40ZR19 or 285/35R19 size tires on the rear wheels.

  • Page 402

    After the tires have been rotated, adjust the front and rear inflation pressures as shown on the Tire and Loading Information label. See Reset the Tire Pressure Monitor System. See Make certain that all wheel nuts are properly tightened. See Wheel Nut Torque under Rust or dirt on a wheel, or on the parts to which it is fastened, can...

  • Page 403

    additional information. The rubber in tires age over time. This is also true for the spare tire, if the vehicle has one, even if it is not being used. Multiple conditions affect how fast this aging takes place, including temperatures, loading conditions, and inflation pressure maintenance.

  • Page 404

    Replacing less than a full set of tires can affect the braking and handling performance of your vehicle. See Tires could explode during improper service. Attempting to mount or dismount a tire could cause injury or death. Only your dealer or authorized tire service center should mount or dismount the tires.

  • Page 405

    Your vehicle's original equipment tires are listed on the Tire and Loading Information label. See for more information about the Tire and Loading Information label and its location on your vehicle. If you add wheels or tires that are a different size than your original equipment wheels and tires, this could affect the way your vehicle performs, including its braking,...

  • Page 406

    The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1½) times as well on the government course as a tire graded 100.

  • Page 407

    The grade C corresponds to a level of performance which all passenger car tires must meet under the Federal Motor Safety Standard No. 109. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law.

  • Page 408

    If you need to replace any of the wheels, wheel bolts, wheel nuts, or Tire Pressure Monitor System (TPMS) sensors, replace them only with new GM original equipment parts. This way, you will be sure to have the right wheel, wheel bolts, wheel nuts, and TPMS sensors for the vehicle.

  • Page 409

    Follow that manufacturer's instructions. To help avoid damage to the vehicle, drive slowly, re adjust or remove the device if it is contacting the vehicle, and do not spin the wheels. If you do find traction devices that will fit, install them on the rear tires.

  • Page 410

    Lifting a vehicle and getting under it to do maintenance or repairs is dangerous without the appropriate safety equipment and training. If a jack is provided with the vehicle, it is designed only for changing a flat tire. If it is used for anything else, you or others could be badly injured or killed if the vehicle slips off the jack.

  • Page 411

    When the vehicle has a flat tire (B), use the following example as a guide to assist you in the placement of wheel blocks (A). A. Wheel Block B. Flat Tire The following information explains how to repair or change a tire. Idling a vehicle in an enclosed area with poor ventilation is dangerous.

  • Page 412

    The tire sealant and compressor can be used to temporarily seal punctures up to 6 mm (¼ in) in the tread area of the tire. It can also be used to inflate an under inflated tire. If the tire has been separated from the wheel, has damaged sidewalls, or has a large puncture, the tire is too severely damaged for the tire...

  • Page 413

    There is only enough sealant to seal one tire. After usage, the sealant canister and sealant/air hose assembly must be replaced. See Removal and Installation of the Sealant Canister following. Follow the directions closely for correct sealant usage. When using the tire sealant and compressor kit during cold temperatures, warm the kit in a heated environment for five minutes.

  • Page 414

    3. Place the kit on the ground. Make sure the tire valve stem is positioned close to the ground so the hose will reach it. 4. Remove the valve stem cap from the flat tire by turning it counterclockwise. 5. Attach the sealant/air hose (F) onto the tire valve stem.

  • Page 415

    The tire is not sealed and will continue to leak air until the vehicle is driven and the sealant is distributed in the tire, therefore, Steps 12 through 18 must be done immediately after Step 11. Be careful while handling the tire sealant and compressor kit as it could be warm after usage.

  • Page 416

    21. Dispose of the used sealant canister (E) and sealant/air hose (F) assembly at a local dealer or in accordance with local state codes and practices. 22. Replace it with a new canister available from your dealer. 23. After temporarily sealing the tire using the tire sealant and compressor kit, take the vehicle to an authorized dealer...

  • Page 417

    4. Remove the tire valve stem cap from the flat tire by turning it counterclockwise. 5. Attach the air only hose (G) onto the tire valve stem by turning it clockwise until it is tight. 6. Plug the power plug (H) into the accessory power outlet in the vehicle.

  • Page 418

    14. Replace the air only hose (G) and the power plug (H) and cord back in its original location. 15. Place the equipment in the original storage location in the vehicle. The tire sealant and compressor kit has an accessory adapter located in a compartment on the bottom of its housing that may be used to inflate air mattresses, balls, etc.

  • Page 419

    It is not necessary to remove the subwoofer (C) to access the tire sealant and compressor kit, however, if you want to remove it see for instructions. To store the tire sealant and compressor kit, reverse the steps. The tire sealant and compressor kit is located in the trunk.

  • Page 420

    4. Remove the tire sealant and compressor kit (A) from the foam container (B). To store the tire sealant and compressor kit, reverse the steps. A. Wing Nut B. Spare Tire C. Jack D. Wheel Wrench E. Extension Strap To access the spare tire and jacking equipment: 1.

  • Page 421

    A. Wing Nut B. Spare Tire C. Jack D. Subwoofer E. Wheel Wrench Extension G. Cable To access the spare tire and jacking equipment: 1. Remove the spare tire cover. 2. Remove the subwoofer (D), if the vehicle has one. To remove the subwoofer: 2.1.

  • Page 422

    3. Find the jacking location using the diagram above and corresponding V-shaped locating notches located in the plastic molding. 4. Insert the hooked end of the extension handle through the jack and the flat end through the wheel wrench. Getting under a vehicle when it is jacked up is dangerous.

  • Page 423

    5. Turn the wheel wrench counterclockwise to lower the jack lift head until the jack fits under the vehicle. 6. Raise the jack by turning the wheel wrench clockwise until the slots in the jack head fit into the metal flange located behind the V shaped locating notches on the plastic molding as shown.

  • Page 424

    Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident. When changing a wheel, remove any rust or dirt from places where the wheel attaches to the vehicle.

  • Page 425

    15. Tighten the wheel nuts firmly in a crisscross sequence as shown. Storing a jack, a tire, or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place.

  • Page 426

    7. Route the hook end of the strap through the wheel. 8. Attach the hook to the cargo tie-down in the rear of the vehicle. 9. Slide the buckle to tighten the cargo tie-down strap. Use the following diagram as a guide for storing the compact spare tire in the trunk.

  • Page 427

    Use the following diagram as a guide for storing the compact spare tire and tools in the trunk: A. Wing Nut B. Compact Spare Tire or Flat Tire C. Jack D. Wheel Wrench E. Extension Strap Reverse the instructions for removing the spare tire and tools to store the compact spare tire.

  • Page 428

    Driving with more than one compact spare tire at a time could result in loss of braking and handling. This could lead to a crash and you or others could be injured. Use only one compact spare tire at a time. If your vehicle is equipped with a compact spare tire it was fully inflated when the vehicle was new, it...

  • Page 429

    1. Check the other vehicle. It must have a 12-volt battery with a negative ground system. 2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles are not touching each other. If they are, it could cause a ground connection you do not want.

  • Page 430

    Your vehicle has a remote negative ( ) ground location, as shown in the illustration. It is located on the left side of the engine compartment. See . You should always use this remote ground location, instead of the terminal on the battery.

  • Page 431

    Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running. 5. Check that the jumper cables do not have loose or missing insulation. If they do, you could get a shock.

  • Page 432

    9. Connect the other end of the negative ( ) cable at least 45 cm (18 in) away from the dead battery, but not near engine parts that move. The electrical connection is just as good there, and the chance of sparks getting back to the battery is much less.

  • Page 433

    Consult your dealer or a professional towing service if the disabled vehicle must be towed. To tow the vehicle behind another vehicle for recreational purposes, such as behind a motor home, see Recreational Vehicle Towing in this section. Recreational vehicle towing means towing the vehicle behind another vehicle such as behind a...

  • Page 434

    The vehicle was not designed to be towed with all four wheels on the ground. If a rear-wheel-drive vehicle must be towed, a dolly or a trailer should be used. If an all-wheel-drive vehicle must be towed, a trailer should be used. See Dolly Towing following for more information.

  • Page 435

    4. Put the vehicle in P (Park) for an automatic transmission or in 1 (First) for a manual transmission. 5. Securely attach the vehicle being towed to the dolly. 6. Clamp the steering wheel in a straight-ahead position with a clamping device designed for towing.

  • Page 436

    If the vehicle has a basecoat/ clearcoat paint finish, the clearcoat gives more depth and gloss to the colored basecoat. Always use waxes and polishes that are non-abrasive and made for a basecoat/clearcoat paint finish. Foreign materials such as calcium chloride and other salts, ice melting agents, road oil and tar, tree sap, bird droppings, chemicals from...

  • Page 437

    Rinse the vehicle well, before washing and after, to remove all cleaning agents completely. If they are allowed to dry on the surface, they could stain. Dry the finish with a soft, clean chamois or an all-cotton towel to avoid surface scratches and water spotting.

  • Page 438

    Clean the outside of the windshield with glass cleaner. Clean the rubber blades using a lint free cloth or paper towel soaked with windshield washer fluid or a mild detergent. Wash the windshield thoroughly when cleaning the blades. Bugs, road grime, sap, and a buildup of vehicle wash/wax treatments may cause wiper streaking.

  • Page 439

    At least every spring, flush these materials from the underbody with plain water. Clean any areas where mud and debris can collect. Dirt packed in close areas of the frame should be loosened before being flushed. Your dealer or an underbody car washing system can do this.

  • Page 440

    Do not clean the interior using the following cleaners or techniques: Never use a knife or any other sharp object to remove a soil from any interior surface. Never use a stiff brush. It can cause damage to the interior surfaces.

  • Page 441

    A paper towel can be used to blot excess moisture from the fabric or carpet after the cleaning process. Leather, and lighter colored leather in particular, will need more frequent cleaning to prevent the buildup of dust, dirt, and colors transferred from other items so that these do not become permanent stains.

  • Page 442

    If a floor mat is the wrong size or is not properly installed, it can interfere with the accelerator pedal and/or brake pedal. Interference with the pedals can cause unintended acceleration and/or increased stopping distance which can cause a crash and injury.

Comments to this Manuals

Symbols: 0

Latest comments:

×

Select the desired size and copy embed code

Copy your embed code and put on your site:
