Table of Contents
Related Manuals for Burnham SM-6
Summary of Contents for Burnham SM-6
- Page 1 8140312R13-6/06 Price - $3.00...
- Page 2 PLEASE READ THIS PAGE CAREFULLY This boiler has a limited warranty, a copy of which is printed on the back page of this manual. All heating systems should be designed by competent contractors and only persons knowledgeable in the layout and installation of hydronic heating systems should attempt installation of any boiler.
-
Page 3: Table Of Contents
Table of Contents General Installation Requirements ... 4 Installation Instructions ... 7 III. Operating Instructions ... 13 Service ... 23 Repair Parts ... 26 APPENDIX Low Water Cut Off ... 27... -
Page 4: General Installation Requirements
(See Figure 2). Figure 2 f. If boiler is to be installed above the level of the radiation, a low water cutoff must be installed. PROVIDE CLEARANCE between boiler jacket, mounting bracket and vent system and combustible material in accordance with local fi... - Page 5 In utility room installations, the door must be wide enough to allow boiler to enter or to permit replacement of another appliance in this room. VENTILATION AND COMBUSTION AIR.
- Page 6 TABLE I TABLE II " 3 " 5 *NOTE – For all practical purposes, each 90° elbow can be considered as the following equivalent in length of straight pipe: ½” – 1.6 ft. 1” – 2.6 ft. ¾” – 2.1 ft. TABLE III i t l...
-
Page 7: Installation Instructions
II. Installation Instructions DETERMINE BEST MOUNTING LOCATION for boiler which meets site requirements outlined in Section I, pages 4 through 6. INSTALLING BOILER MOUNTING WALL BRACKET (See Figure 5). a. Locate wall bracket packed in miscellaneous parts carton. b. Hold wall bracket in desired location. On studded walls, mounting bracket must be secured directly to main vertical support studs. - Page 8 Figure 4 VENT SYSTEM CROSS SECTION h. Secure boiler to boiler mounting wall bracket with fi ve (5) ¼”-20 x ¾” long machine screws and washers provided. NOTE: Tools required — 7/16” socket, extension bar(s) and drive ratchet i. Secure interior telescoping intake air duct to back plate of boiler.
- Page 9 (4) #10-32 x ¼” long stainless steel machine screws provided. DO NOT REPLACE ENCLOSURE COVER until boiler piping is completed and system is fi lled, vented and checked for water leaks. CONNECT SUPPLY AND RETURN PIPING TO heating system.
- Page 10 Use a boiler bypass if the boiler is to be operated in a system which has a large volume or excessive radiation where low boiler water temperature may be encountered (i.e., converted...
- Page 11 Figure 7 RECOMMENDED PIPING FOR COMBINATION HEATING & COOLING (REFRIGERATION) SYSTEMS Figure 9 EXPLODED JACKET ASSEMBLY...
- Page 12 The circuit should be run to the junction box mounted on the front of the boiler back plate in the control compartment (See Figure 1), and connected to the proper leads therein. Wires from the low voltage thermostat should be run to terminals R and G on the transformer.
-
Page 13: Operating Instructions
III. Operating Instructions Safe lighting and other performance criteria were met with the gas manifold and control assembly provided on the boiler when the boiler underwent tests specifi ed in ANSI Z21.13. INSPECT INSTALLATION BEFORE STARTING. INITIAL START a. FILL ENTIRE HEATING SYSTEM WITH WATER and vent air from system. - Page 14 NOTE: YOUR BOILER IS EQUIPPED WITH A HONEYWELL VR8204 OR VR8304 GAS VALVE. PLEASE FOLLOW THESE OPERATING INSTRUCTIONS:...
- Page 16 Figure 12 LADDER WIRING DIAGRAM...
- Page 17 (The circulator will continue to operate as long as the thermostat is calling for heat). When the boiler water temperature drops to a point where the high limit switch closes, the fan will restart (via 2M) and the ignition module will be energized to repeat the sequence in Steps 4 through 7 above.
- Page 18 Water manometer or water column gauge should be connected to a shutoff valve installed in the 1/8” pipe tapping in the gas valve - boiler off. By installing gas valve up stream of manometer, gas pressure can be introduced gradually - without shutoff valve, surge of pressure when boiler is turned on, could blow liquid out of manometer.
- Page 22 Orange-yellow streaks caused by dust should not be confused with true yellow tipping. CHECK LWCO OPERATION (if so equipped). Drain boiler water below LWCO set point. Burners should shutdown. If burners do not shut down determine cause of malfunction and repair.
-
Page 23: Service
Section III, paragraphs 7, 8, 9, 11 and 12. MAINTENANCE OF LOW WATER CUTOFF — During the heating season, if an external fl oat type low water cutoff is on the boiler, the blow off valve should be opened once a month (use greater frequency... - Page 24 Inspect connecting lines to boiler for accumulation of mud, scale, etc. and clean as required. Examine all visible wiring for brittle or worn insulation and make sure electrical contacts are clean and that they function properly.
- Page 25 Warning: This product contains refractory ceramic fi bers (RCF). RCF has been classifi ed as a possible human carcinogen. After this product is fi red, RCF may, when exposed to extremely high temperature (>1800F), change into a known human carcinogen. When disturbed as a result of servicing or repair, RCF becomes airborne and, if inhaled, may be hazardous to your health.
-
Page 26: Repair Parts
V. Repair Parts All Spacemaster™ Repair Parts may be obtained through your local Burnham Wholesale distributor. Should you require assistance in locating a Burnham distributor in your area, or have questions regarding the availability of Burnham products or repair parts, please contact Burnham Customer Service at (717) 481-8400 or Fax (717) 481-8408. -
Page 27: Low Water Cut Off
The minimum safe water level of a water boiler is at the uppermost top of the boiler; that is, it must be full of water to operate safely. -
Page 28: Limited Warranty
NOTE: If the heat exchanger model involved is no longer available due to product obsolescence or redesign, the value used to establish the retail price will be the published price as shown in the Burnham Hydronics Repair Parts Price Sheet where the heat exchanger last appeared or the current retail price of the then nearest equivalent heat exchanger.
