1
.
1
.
3
F
r
o
n
t
a
n
1
.
1
.
3
F
r
o
n
t
a
LED
WLAN
QoS
Firewall
ADSL2+
ACT (Activity)
LAN (1, 2, 3, 4)
Interface
PWR
ON/OFF
ISDN
Factory Reset
ADSL 2+
LAN 4 – 1
4
d
R
e
a
r
V
i
e
w
f
o
n
d
R
e
a
r
V
i
e
w
f
o
Status
On
Blinking
Off
On
Off
On
Blinking
On (Green)
Blinking (Green)
Blinking (Orange)
On
Blinking
Green
Blinking
Description
Connecter for a power adapter with 12~15VDC.
Power Switch.
Connecter for NT1 (or NT1+) box provided by ISDN service provider.
Restore the default settings.
Usage: Turn on the router (ACT LED is blinking). Press the hole and keep for
more than 5 seconds. When you see the ACT LED begins to blink rapidly than
usual, release the button. Then the router will restart with the factory default
configuration.
Connecter for accessing the Internet through ADSL2/2+.
Connecter for local networked devices.
r
V
i
g
o
r
2
7
0
0
G
i
r
V
i
g
o
r
2
7
0
0
G
i
Explanation
Wireless access point is ready.
Ethernet packets are transmitting over wireless LAN.
The WLAN function is inactive.
The QoS function is active.
The QoS function is inactive.
The DoS function is enabled.
When encountered DoS attacks.
ADSL is show time.
The device starts handshaking.
The data is transmitting.
The router is powered on.
The router is powered on and running properly.
A normal connection is through its corresponding port.
Ethernet packets are transmitting.
for Annex B
Vigor2700 Series User's Guide
