This product can be set up
using Internet Explorer 6.x
or above
Before You Begin
You must have at least the following:
• Windows 98/Me/2000/XP
• A CD-ROM drive
• An available Ethernet connection
Check Your Package Contents
These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of
their respective holders. Software and specifications subject to change without notice. DCS-950G.11172004
DCS-950G Wireless Internet Camera
CD-ROM with Manual and Installation Wizard
Antenna
Mounting Bracket and Stand
CAT5 Ethernet Cable
5V 2.5A AC Power Adapter
DCS-950G
SECURICAM Network
802.11g Wireless
Audio Internet Camera
Using a power supply
with a different voltage
rating will damage this
product and void the warranty.
Advertisement
Table of Contents
Related Manuals for D-Link DCS-950G
Summary of Contents for D-Link DCS-950G
-
Page 1: Before You Begin
Mounting Bracket and Stand CAT5 Ethernet Cable 5V 2.5A AC Power Adapter ©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DCS-950G.11172004 DCS-950G SECURICAM Network 802.11g Wireless... -
Page 2: System Requirements
Internet Camera’s back panel and attach it to the network. If you connect this camera directly to a PC, the DCS-950G has an MDI/X port that will allow you to use either a straight through (included) or cross- over cable. - Page 3 Installing the Installation Wizard Insert the DCS-950G CD into the CD-ROM drive. Click on Install Software. Click on Installation Wizard. Click Next.
- Page 4 Installing the Installation Wizard (continued) Click Yes. Click Next. Click Next.
- Page 5 Installing the Installation Wizard (continued) Click Finish. Click OK. Click Next.
- Page 6 Installing the Installation Wizard (continued) Click I Agree. Click Next. Click Install.
- Page 7 Installing the Installation Wizard (continued) Click Next. Click Finish.
- Page 8 Configuring Your Camera with the Setup Wizard To run the Setup Wizard, click on Start->Programs->DCS-950 Series Setup Wizard. Your camera’s IP Address will be displayed here. Click the Wizard button to begin. By default, the Admin ID and Password are “admin” (lower case). Enter this in both fields.
- Page 9 Configuring Your Camera with the Setup Wizard (continued) The Connection Mode depends on how your camera is connected to your network. Click Infrastructure for use with a router or Adhoc for a peer-to- peer connection. The Network Name, Wireless Channel, Security Mode and Authentication MUST correspond with your wireless network settings for the camera to work.
- Page 10 Configuring Your Camera with the Setup Wizard (continued) Wait until the Link LED on the camera begins to flash. Click Link to launch your Web browser and view your images. Click Link.
-
Page 11: Viewing Your Internet Camera
After you click the Link button, the Installation Wizard will automatically open your Web browser to the IP address of the DCS-950G and prompt you for a user name and password. Enter “admin” into both fields. If you changed the user name and password in the setup wizard, enter the new values and click Apply. -
Page 12: Echni Cal Support
You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link Technical Support through our website, or by phone.
