1009IFD
Carton contents:
Instruction sheet, a Satmeter, a wall plug charger, a car charger and a protective case and download lead (Computer
Interface Cable) These instructions will guide you through the operation and care of you meter. Thermometer is con-
trolled using the three button panel and these instructions will show which to press and what you should see on the
screen when you do.
Getting started ......
To turn the meter ON, press and release the Up and Down buttons at the same time.
The start-up screen will display 4 modes.
At the SET BACKLIGHT option, choose to suit conditions by pressing Up then mode for on, and just mode to leave it off.
DSB Sat. Locator
Software version
5.0.1
America
To turn the meter OFF, press and hold the Up button. The sounder will beep.
mode
Charge the battery
The battery will need to be charged for about 12 hours before its first use and whenever it fails to last enough time to
perform installations.
Plug the charger into the Satmeter and electrical outlet. Then turn the meter on. The meter will analyze the state of the
battery and BOOST or TRICKLE charge until the battery is ready for use. During normal charging, the charger and meter
may become warm. After several charge and discharge cycles, the battery will reach full capacity.
Analyzing charge..
Use only the charger supplied with the Satmeter. The warranty will be invalidated if the meter is damaged through the
use of a different charger.
The meter protects the battery from over charging. Spare batteries for extended use in the field can be supplied by your
distributor.
Data Presets and languages
The meter has data stored for your region with operating instructions in two languages - English and Spanish.
The meter will be supplied with the English option selected but it is very easy to change over to Spanish or any
other data that has been programmed. Immediately after the meter is started, press and hold the mode and Up but-
tons together, for about three seconds. The current language or data group setting will display.
mode
Satmeter Operating Instructions
Battery Contents
93%
Boost charging
SET BACKLIGHT
<Mode exits>
Trickle charging
mode
Searching
101 Find
SS
00
PQ
00
Shutting off. . .
Charging complete
ENGLISH
