Today we market our patented speaker systems worldwide and the high quality of the Bazooka brand is well respected by consumers and dealers of all nationalities. When properly installed, Bazooka subwoofer speaker systems will give you years of clean uninterrupted sound reproduction.
Efficiency Dimensions Weight Impedance BASS TUBES * The efficiency levels of all Bazooka subwoofer speaker systems are measured in the typical environment: In the low bass region with one watt of power. SYSTEM FEATURES 5”, 6.5”, or 8” SUBWOOFER ®...
Figure 1 Figure 2 Figure 3 INSTALLATION T R U C K I N S T A L L A T I O N tube size is exagerated for emphasis S E D A N I N S T A L L A T I O N tube size is exagerated for emphasis H A T C H B A C K I N S T A L L A T I O N tube size is exagerated for emphasis...
Page 6
Locate an area in the rear of the vehicle where you would like to place the Bazooka speaker systems. The location you have selected must meet the follow- ing requirements in order for the Bazooka to be properly installed in the vehicle: The woofer (grill end) should be facing into a corner.
Figure 4 MOUNTING THE BAZOOKA Bottom Figure 5 Figure 6 With the top side of the buckle facing up (see figure 4), lace the strap through mounting base as illus- trated in figure 5. After the strap is com- pletely laced through...
Page 8
MOUNTING THE BAZOOKA Figure 7 Figure 8 Place each mount- ing base under the Bazooka so that the apex at the bottom of the tube sits inside the mounting base as in figure7. Move the bases so that they are spaced...
Due to the jarring and shifting that can occur in a vehicle, the mounting straps may stretch or loosen. We recommend that you check the straps regularly to assure that your Bazooka is mounted securely in place. MOUNTING THE BAZOOKA...
When using high level inputs, take the time after you make all wiring con- nections to run through the AM I IN PHASE procedure of this manual to confirm that your inputs are in correct electrical phase and the proper bass response is being produced.
The power wire carries substantial currents and could induce noise. DO NOT substitute the 7.5 amp fuse included with the Amplified Bazooka with anything other than the same fast blow current rated fuse. Substitution or deletion will void the product's warranty and may cause damage to your car or the amplifier.
12 Volts positive when the source is turned on. The SAS On/Off Switch allows you to demonstrate to others the difference the Amplified Bazooka makes in your system, or you can turn the Amplified Bazooka off whenever you desire. When you are using this configuration, the Quick Disconnect YELLOW On/Off Jumper Loop MUST be disconnected from the wiring harness.
Page 13
The ORANGE wire should not be connected to anything if this feature is being used. Be sure to insulate the end of the ORANGE wire so that it will not short to ground, as this may damage the Amplified Bazooka.
Amplified Bazooka. Connect the GREEN wire from the 14-pin Molex plug of the Amplified Bazooka to the source units left (+) positive speaker output. Connect the GREEN W /BLACK stripe wire of the plug to the source units left (-) negative speaker output.
Bass Tubes ® only from SAS. , SAS, BAZOOKA, BASS TUBES, and LISTEN TO YOUR EARS are registered trademarks of Southern Audio Services, Inc. SIGNAL CONNECTIONS CONT. WARRANTY dealers to install this product.
