American Dynamics DG4004 User Manual

American dynamics dg4004 multiplexers: users manual.
Hide thumbs

User's Manual
Addendum
DigiMux DG4000 Series
This document contains supplemental information that is not provided in the DigiClient User's Manual. Please read this
Addendum for the most recent information.
The information in this document applies to this DigiMux DG4000 series:
Release:
SP1D
Hardware Version:
0A5-10A60x04 or 0A6-10A60x04
OSD Software Version:
1.0.6.20-16 (or newer)
DigiClient Version:
1.4.62.0
DigiAlert Version:
1.0.0.6
DigiPlayer Version:
1.0.24.0
Topics
Topic
Section in this Addendum
Using the Keyboard Setup Menu
See
on this page.
Using the Keyboard Setup Menu
ADTT16E Touch Tracker Use with DigiMux
See
on page 2.
Touch Tracker Operation
Improved ControlCenter200/300 Keyboard Operation
See
Improved Control Center 200/300
on page 3.
Keyboard use
Call Monitor Control
See
on page 4.
Call Monitor Control
Integrated Digital Signature Verification: DigiVerify
See
on
Integrated Digital Signature
page 5.
Verification: DigiVerify
Alarm List Deletion Behavior
See
on page 5.
Alarm List Deletion Behavior
Using the Keyboard Setup Menu
NOTE: Before you use this menu, connect your keyboard using the instructions in this addendum.
Select 10 Keyboard Setup from the Main Menu:
Main Menu
Date/Time
1
Monitor
2
Camera
3
Record
4
Event Manager
5
Save/Load Configuration
6
Administrator Setup
7
Export
8
System Information
9
Keyboard Setup
10
DigiMux User's Manual Addendum
8200-0494-9900 A1
1
© 2005 Sensormatic Electronics Corporation

   Also See for American Dynamics DG4004

   Related Manuals for American Dynamics DG4004

   Summary of Contents for American Dynamics DG4004

  • Page 1

    DigiMux DG4000 Series This document contains supplemental information that is not provided in the DigiClient User’s Manual. Please read this Addendum for the most recent information. The information in this document applies to this DigiMux DG4000 series: Release: Hardware Version: OSD Software Version: DigiClient Version: DigiAlert Version:...

  • Page 2: Software Requirements

    ADTT16E Touch Tracker Use with DigiMux DigiMux supports the use of the ADTT16E Touch Tracker as an American Dynamics dome control device. You can use the Touch Tracker to control domes directly through Sensornet, or control domes from the DigiMux front panel or remote DigiClient software.

  • Page 3

    Installation Dome Touch Tracker RS232-USB Converter • The RS232-USB converter connects the RS232 DB9 port on the Touch Tracker’s EIM and the USB port on the DigiMux unit. • Domes connect directly to the Touch Tracker’s EIM using Sensornet. Setup and Configuration •...

  • Page 4

    Installation +12Vdc Keyboard RS485-RS232 Converter RS232-USB Converter • The RS485 data lines from the keyboard’s KMI terminals would go through the RS485-RS232 converter, the RS232-USB converter, and then the USB port of DigiMux. Note that the RS485-RS232 requires 12VDC. • Domes are connected directly to RS485 terminals on the DigiMux external I/O board, using RS485.

  • Page 5

    3. Press ESCAPE to exit. 4. Select Monitor #1 on the keyboard to return to the Main monitor control mode. Integrated Digital Signature Verification: DigiVerify When you export video from a DigiMux with Digital Signature, the exported file package includes a public key file (.GPG), an encrypted audio video file (.AVI), and a signature file (.SIG) for later authentication.
