AdobeAir MasterCool MMB10 Frequently Asked Questions

FREQUENTLY ASKED QUESTIONS
1. What is Mobile MasterCool ?
Mobile MasterCool is a line of completely portable evaporative coolers that require no installation or wiring. This high-velocity, high-efficiency line of
coolers provides spot cooling for areas ranging from 700 sq. ft. to 3,000 sq. ft. and can be used in settings from residential to commercial and industrial.
2. How will Mobile MasterCool save me money?
First, Mobile MasterCool saves you money by putting cool air exactly where you need it. Spot cooling saves you money because you're not cooling your
entire facility. Second, keeping employees cool helps reduce the risk of heat exhaustion or fatigue and the potential for lost work time, workers'
compensation costs for heat-related illness and can help increase productivity.
3. Where should a mobile cooler be placed within a space?
The cooler should be placed where there is plenty of fresh air and it is best positioned adjacent to an external door (or open window) with additional
openings on the opposite side of the room for relief air. Placing the cooler this way allows the cooler to draw fresh air from the outside to be drawn through
the pad, cooled, filtered and circulated through the room while the hot, stale air is forced out through the openings on the other side of the room.
4. How much maintenance does a mobile cooler require?
Minimal. We recommend emptying the water reservoir once a week to reduce scale or mineral deposits on the pad. Periodically during extended periods
of use, or at least once per year depending on the usage, it is important to perform some simple cleaning to maintain its efficiency. This involves cleaning
the water system and filters. Refer to the Owner's Manual for detailed instructions and a maintenance schedule for each particular model.
5. Are evaporative coolers more suitable to specific climates?
While evaporative cooling is especially well-suited to dry, desert climates, it is also effective in areas of higher humidity. Even in areas of high humidity,
there are many cost effective uses for evaporative cooling, making it the right choice for spot cooling inside or out.
6. How do evaporative coolers save energy?
On average, an evaporative cooler consumes about one-fourth of the electrical energy required to operate a refrigerated air conditioning unit. As an
example, to cool approximately 2,400 sq. ft.(the average size of a home in the U.S.), a refrigeration unit would require three electric motors with a
combined horsepower of 3 ½. To cool the same space, a MasterCool unit would only require a ¾ horsepower motor, drawing only 11.3 amps.
Why Evaporative Cooling?
Evaporative cooling is cool the way nature intended, like the cooling sensation
you feel when you get out of a swimming pool. Water evaporates from your skin,
taking heat with it. The Mobile MasterCool units draw hot air through wet pads,
using a blower or fan. As the water evaporates, it takes heat with it, resulting in
the discharge of air that is up to 30 degrees cooler.
Isn't Evaporative Cooling just for dry desert climates?
While evaporative cooling is especially suited to dry desert climates, it is also
effective in more humid areas. As temperatures rise throughout the day,
relative humidity levels drop. Usually by midday, humidity levels have dropped
to well within the range where the Mobile MasterCool units can provide relief
from the heat.
Temperature drop possible (degrees of cooling):
Temperature
80°
90°
100°
110°
City Temperature
Chicago, IL
Baltimore, MD
Los Angeles, CA
Orlando, FL
Phoenix, AZ
Burley, ID
The world leader in evaporative cooling technology, AdobeAir, Inc. is continually involved in the process of product
improvement. AdobeAir, Inc. therefore reserves the right to change specifications and/or design without prior notice. To
obtain the most current product information and/or specifications, visit the AdobeAir, Inc. web site at www.AdobeAir.com.
1450 E. Grant Street
Phoenix, Arizona 85034
877-595-EVAP (3827)
L910702A – March 2007
MOBILE EVAPORATIVE COOLERS
• Increased Productivity • Maximum Cooling Efficiency • Industrial & Commercial Use
• Airports • Assembly Lines • Athletic Events • Auto Body Shops • Auto Repair
Relative Humidity (RH)
Shops • Barns • Construction Sites • Dog Kennels • Dry Cleaners/Laundry •
10% 30% 50%
Emergency & Disaster Sites • Exercise Areas • Factories • Garages • Garden
22° 16° 10°
25° 18° 12°
Centers • Golf Courses • Greenhouses • Gymnasiums • Hangars • Horse Stables •
29° 21° 14°
Hotels & Resorts • Loading Docks • Manufacturing Facilities • Outdoors •
32° 23° 15°
Paddocks • Retail Spaces • Service Bays • Storage Rooms • Tents • Warehouses
Relative Temperature
Humidity Drop
94° 40% 16° Cooling
91° 48% 13° Cooling MMF36
83° 47% 12° Cooling
10° Cooling
95° 60%
25° Cooling
105° 23%
99° 5% 31° Cooling
MMB14
The World Leader in
Evaporative Cooling Technology
MMF24
MMB12 MMB10
