Abit AL8 User Manual

Al8 series intel pentium 4 system board socket 775
Hide thumbs
Table of Contents

Advertisement

Quick Links

AL8 Series
(AL8, AL8-V)
Intel Pentium 4 System Board
Socket 775
User's Manual
4200-0455-01
Rev. 1.00

Advertisement

Table of Contents
loading

Related Manuals for Abit AL8

Summary of Contents for Abit AL8

  • Page 1 AL8 Series (AL8, AL8-V) Intel Pentium 4 System Board Socket 775 User’s Manual 4200-0455-01 Rev. 1.00...
  • Page 2 No part of this manual may be reproduced, transmitted or transcribed without the expressed written permission of the manufacturer and authors of this manual. If you do not properly set the motherboard settings, causing the motherboard to malfunction or fail, we cannot guarantee any responsibility. AL8 Series...

  • Page 3: Table Of Contents

    Introduction ... 1-1 1-1. Features & Specifications ...1-1 1-2. Layout Diagram ...1-3 Chapter 2. Hardware Setup... 2-1 2-1. Install The Motherboard...2-1 2-2. Install CPU, Heatsink and Fan Assembly ...2-2 2-3. Install System Memory ...2-4 2-4. Connectors, Headers and Switches ...2-6 (1).
  • Page 4 Appendix C. Install Audio Driver ... C-1 Appendix D. Install BCM LAN Driver ...D-1 Appendix E. Install Sil3132 SATA Driver (AL8) ... E-1 Appendix F. Install USB 2.0 Driver ... F-1 Appendix G. Install ABIT µGuru Utility ...G-1 Appendix H.

  • Page 5: Chapter 1. Introduction

    Supports auto jack sensing and optical S/PDIF In/Out (For model AL8 only) 8. IEEE 1394a • Supports 2 Ports IEEE 1394a at 100/200/400 Mb/s transfer rate (For model AL8 only) 9. Gigabit LAN • Onboard PCI-E Gigabit LAN controller supports 10/100/1000M Ethernet 10.
  • Page 6 • 4x SATA connectors • 1x Ultra DMA 100/66/33 connector • 2x USB 2.0 headers • 1x IEEE 1394 header (For model AL8 only) • 1x FP-Audio header • 1x CD-IN header 12. Back Panel I/O • 1x PS/2 Keyboard, 1x PS/2 Mouse •...

  • Page 7: Layout Diagram

    Introduction 1-2. Layout Diagram User’s Manual...
  • Page 8 Chapter 1 Chapter 1 AL8 Series AL8 Series...

  • Page 9: Chapter 2. Hardware Setup

    ATTENTION: To prevent shorting the PCB circuit, please REMOVE the metal studs or spacers if they are already fastened on the chassis base and are without mounting-holes on the motherboard to align with. User’s Manual...

  • Page 10: Install Cpu, Heatsink And Fan Assembly

    3. Use your right thumb on the bottom-right side of the load plate and lift it up to fully open position. AL8 Series 4. Use your right thumb and forefinger to grasp the CPU package. Be sure to grasp on the edge of the substrate, and face the Pin-1 indicator toward the bottom-left side.
  • Page 11 9. Place the heatsink and fan assembly onto the socket. Align the four fasteners toward the four mounting holes on the motherboard. For detailed information on how to install your heatsink and fan assembly, please refer to the instruction manual came packed with the heatsink and fan assembly you bought.

  • Page 12: Install System Memory

    There are several methods of different DDR2 configurations depending on how the DIMMs are populated on each system memory channel: • [Single Channel]: only one channel is populated. Method DIMM1 512MB 512MB AL8 Series Channel A DIMM2 512MB 512MB Channel B DIMM3 DIMM4...
  • Page 13 • [Dual Channel Asymmetric]: both channels are populated, but each channel has a different amount of total memory. (Channel A≠Channel B) Method DIMM1 512MB 512MB 256MB 256MB 256MB 256MB 256MB • [Dual Channel Symmetric]: both channels are populated where each channel has the same amount of total memory.

  • Page 14: Connectors, Headers And Switches

    WARNING: Always power off the computer and unplug the AC power cord before adding or removing any peripheral or component. Failing to so may cause severe damage to your motherboard and/or peripherals. Plug in the AC power cord only after you have carefully checked everything.

  • Page 15: Fan Power Connectors

    (2). FAN Power Connectors These connectors each provide power to the cooling fans installed in your system. • CPUFAN1: CPU Fan Power Connector • NBFAN1: Chipset Fan Power Connector • SYSFAN1: System Fan Power Connector • AUXFAN1: Auxiliary Fan Power Connector WARNING: These fan connectors are not jumpers.

  • Page 16: Cmos Memory Clearing Header

    Pin 1-2 shorted (default): Normal operation. • Pin 2-3 shorted: Clear CMOS memory. WARNING: Turn the power off first (including the +5V standby power) before clearing the CMOS memory. Failing to do so may cause your system to work abnormally or malfunction. AL8 Series...

  • Page 17: Wake-Up Header

    (4). Wake-up Header These headers use a jumper cap to enable/disable the wake-up function. • USB-PWR2: Pin 1-2 shorted (default): Disable wake-up function support at USB1 port. Pin 2-3 shorted: Enable wake-up function support at USB1 port. • USB-PWR3: Pin 1-2 shorted (default): Disable wake-up function support at USB2 port. Pin 2-3 shorted: Enable wake-up function support at USB2 port User’s Manual...

  • Page 18: Front Panel Audio Connection Header

    (5). Front Panel Audio Connection Header This header provides the connection to audio connector at front panel. AL8 Series Pin Assignment MIC2 L MIC2 R FRO-R F_IO_SEN FRO-L Pin Assignment AGND AVCC MIC2_JD LINE2_JD...

  • Page 19: Front Panel Switches & Indicators Headers

    (6). Front Panel Switches & Indicators Headers This header is used for connecting switches and LED indicators on the chassis front panel. Watch the power LED pin position and orientation. The mark “+” align to the pin in the figure below stands for positive polarity for the LED connection.

  • Page 20: Additional Ieee1394 Port Headers

    (7). Additional IEEE1394 Port Headers This header provides one additional IEEE1394 port connection through an extension cable and bracket. AL8 Series Pin Assignment TPA0 + Ground TPB0 + +12V Pin Assignment TPA0 - Ground TPB0 - +12V Ground...

  • Page 21: Additional Usb Port Headers

    (8). Additional USB Port Headers These headers each provide 2 additional USB 2.0 ports connection through an USB cable designed for USB 2.0 specifications. Pin Assignment Data0 - Data0 + Ground Pin Assignment Data1 - Data1 + Ground User’s Manual...

  • Page 22: Guru Clock Connection Header

    2-14 Chapter 2 (9). GURU Clock Connection Header This header is reserved for connecting ABIT’s exclusive GURU Clock. (10). Internal Audio Connectors This connector connects to the audio output of internal CD-ROM drive or add-on card. AL8 Series...

  • Page 23: Floppy And Ide Disk Drive Connectors

    Hardware Setup 2-15 (11). Floppy and IDE Disk Drive Connectors The FDC1 connector connects up to two floppy drives with a 34-wire, 2-connector floppy cable. Connect the single end at the longer length of ribbon cable to the FDC1 on the board, the two connectors on the other end to the floppy disk drives connector.

  • Page 24: Post Code Display

    POST Code in address 80h to find out where the problem lies. This LED device also displays the “POST” Code of AC2005, an “uGuru” chipset developed exclusively by ABIT computer. NOTE: The decimal point lights up when executing the AC2005 POST action.

  • Page 25: Serial Ata Connectors

    Intel ICH7/ICH7R chipset. You may configure a disk array by the Intel Matrix Storage Technology RAID Driver option ROM utility. For model “AL8”, two additional SATA connectors (SATA5 and SATA6) are provided. You may configure a disk array by the Sil3132 SATA Driver option ROM utility.

  • Page 26: Pci Express X16 Slot

    2-18 Chapter 2 (14). PCI Express x16 Slot This slot is used to attach the next generation of graphics architecture. (15). PCI Express x1 Slots These slots are used to attach the next generation of I/O architecture. AL8 Series...

  • Page 27: Back Panel Connectors

    Line-In: Connects to the line out from external audio sources. Line-Out: Connects to the front left and front right channel in the 7.1-channel or regular 2-channel audio system. • IEEE1394: Connects to devices of IEEE1394 protocol. (For model AL8 only) • LAN: Connects to Local Area Network. •...
  • Page 28 2-20 Chapter 2 AL8 Series...

  • Page 29: Chapter 3. Bios Setup

    BIOS Setup Chapter 3. BIOS Setup This motherboard provides a programmable EEPROM that you can update the BIOS utility. The BIOS (Basic Input/Output System) is a program that deals with the basic level of communication between processor and peripherals. Use the BIOS Setup program only when installing motherboard, reconfiguring system, or prompted to “Run Setup”.

  • Page 30: Μguru Utility

    This item displays the CPU model name installed on this motherboard. Frequency: This item displays the processor speed of the CPU installed on this motherboard. CPU Operating Speed: This item displays the CPU operating speed according to the type and speed of your CPU. You can also select the [User Define] option to enter the manual option.
  • Page 31 External Clock: This item selects the external clock frequency. Due to the specification limit of the CPU you installed, the speed you set over its standard bus speed is supported, but not guaranteed. PCIe Clock Adjust This item determines the PCIe frequency. This option allows you to keep your PCIe clock at some fixed frequency to improve system stability.
  • Page 32 These items display the power cycle statistics for each element. ABIT EQ: Click right-arrow <→> key to switch from OC Guru setup menu to ABIT EQ setup menu: ABIT EQ Beep Control: This item allows you to enable or disable ABIT EQ Beep Control function.

  • Page 33: Temperature Monitoring

    Temperature Monitoring: Click <Enter> key to enter its submenu: CPU Temperature/System Temperature/PWM Temperature: These items display the temperature of CPU, System, and Power Module. Shutdown Enable: Use <Space> key to enable system shutdown function. If the CPU/System/PWM’s temperature exceeds the shutdown temperature limit, the system would shutdown automatically. Shutdown Temp.: This items sets the temperature that would shutdown the system automatically in order to prevent system overheats.
  • Page 34 Use <Space> key to enable warning beeps function. If the voltage of corresponding element is higher/lower than the high/low limit, warning beeps will sound. High/Low Limit: These items set the high and low voltage limit. NOTE: The value of high limit must be set above the one of low limit. AL8 Series...

  • Page 35: Fan Speed Monitoring

    Fan Speed Monitoring: Click <Enter> key to enter its submenu: CPU/NB/SYS/AUX FAN Speed: These items display the speed of the fans connected to CPU, NB, SYS, and AUX FAN headers. Shutdown Enable: Use <Space> key to enable system shutdown function. Once the system has detected that the fan speed is lower than the low limit value, system will shutdown automatically.
  • Page 36 DC Fan Voltage High/Low: These items set the high and low voltage limit that you want to provide the fan with. NOTE: The value of high limit must be set above the one of low limit. AL8 Series FanEQ Group):...
  • Page 37 FanEQ Control: Click <Enter> key to enter its submenu (2 AUX FanEQ Control: When set to [Enabled], these items control the AUX fan speed by the following setting combinations. Reference Temperature: This item selects the reference point for taking temperature among the available options of CPU, SYS, and PWM Temperature, but there is only one “CPU Temperature”...

  • Page 38: Standard Cmos Features

    “On-Chip Serial ATA” in the “OnChip IDE Device” menu is set to [Enhanced Mode], or set to [Auto Mode] when SATA ports are connected with devices. IDE HDD Auto-Detection: This item allows you to detect the parameters of IDE drives by pressing <Enter> key. The parameters will be shown on the screen automatically. AL8 Series...
  • Page 39 BIOS Setup 3-11 IDE Channel 0 Master/Slave, IDE Channel 1 Master/Slave, Extended IDE Drive: When set to [Auto], the BIOS will automatically check what kind of IDE drive you are using. If you want to define your own drive by yourself, set it to [Manual] and make sure you fully understand the meaning of the parameters.
  • Page 40 Base Memory: This item displays the amount of base memory installed in the system. The value of the base memory is typically 640K for system with 640K or more memory size installed on the motherboard. Extended Memory: This item displays the amount of extended memory detected during system boot-up.

  • Page 41: Advanced Bios Features

    BIOS Setup 3-13 3-3. Advanced BIOS Features CPU Feature: Click <Enter> key to enter its submenu: Thermal Management This item selects the type of thermal monitoring. TM2 Bus Ratio This item represents the frequency (bus ratio) of the throttled performance state that will be initiated when the on-die sensor goes from not hot to hot).
  • Page 42 When set to [Enabled], the BIOS will check whether the floppy disk drive is installed or not. Boot Up NumLock Status: This item determines the default state of the numeric keypad at system booting up. [On]: The numeric keypad functions as number keys. [Off]: The numeric keypad functions as arrow keys. AL8 Series...
  • Page 43 CMOS before you can start up the system. But by doing this, you will have to reset all previously set options. MPS Version Ctrl For OS: This item specifies which version of MPS (Multi-Processor Specification) this motherboard will use. Leave this item to its default setting. Report No FDD For OS: When set to [Yes], this item allows you to run some older operating system without floppy disk drive.

  • Page 44: Advanced Chipset Features

    When set to [Enabled], the memory address space at 15M-16M will be reserved for ISA expansion cards that specifically requires this setting. This makes the memory from 15MB and up unavailable to the system. Leave this item to its default setting. AL8 Series...
  • Page 45 PCI Express Root Port Func: Click <Enter> key to enter its submenu: PCI Express Slot 1 ~ PCI Express Slot 3: This option enables or disables the PCI Express port function. PCI-E Compliancy Mode: This item selects the mode for PCI Express add-on card. Back to Advanced Chipset Features Setup Menu: PEG Force X1 When set to [Enabled], this item forces the PEG port down to x1 mode.

  • Page 46: Integrated Peripherals

    This item allows you to enable the transfer access of the IDE DMA. On-Chip Primary PCI IDE: This item selects whether to enable or disable the Primary PCI IDE controller. On-Chip Secondary PCI IDE: This item selects whether to enable or disable the Secondary PCI IDE controller. AL8 Series...
  • Page 47 SATA Mode: This item determines the mode for on-chip Serial ATA. [IDE]: The on-chip Serial ATA served as IDE mode. [RAID]: The on-chip Serial ATA served as RAID mode. [AHCI]: The on-chip Serial ATA served as AHCI (Advanced Host Controller Interface) mode for advanced performance and usability.

  • Page 48: Onboard Device

    USB 2.0 Controller This option enables or disables the USB 2.0 controller. USB Keyboard Support This item allows you to select [BIOS] for using USB keyboard in DOS environment, or [OS] in OS environment. AL8 Series Channel Channel Channel 1 Master...

  • Page 49: Superio Device

    BIOS Setup 3-21 USB Mouse Support This item allows you to select [BIOS] for using USB mouse in DOS environment, or [OS] in OS environment. Onchip Audio Controller This option enables or disables the audio controller. IEEE 1394 Controller: This option enables or disables the IEEE 1394 controller. SuperIO Device: Click <Enter>...
  • Page 50 [EPP]: (Enhanced Parallel Port) Allows bi-directional parallel port operation at maximum speed. [ECP]: (Extended Capabilities Port) Allows bi-directional parallel port operation at a speed faster than the normal mode’s data transfer rate. [ECP+EPP]: Allows parallel port operation at ECP and EPP mode. AL8 Series...
  • Page 51 BIOS Setup 3-23 EPP Mode Select: This item selects the EPP mode. ECP Mode Use DMA: This item selects the DMA channel of the parallel port. PWRON After PWR-Fail This item sets the system action after a power failure. Back to Integrated Peripherals Setup Menu: Onboard Lan Boot ROM This item allows you to use the boot ROM (instead of a disk drive) to boot-up the system and access the local area network directly.

  • Page 52: Power Management Setup

    Run VGABIOS if S3 Resume Three options are available: Auto $ Yes $ No. The default setting is Auto. This item can let you choose when S3 resume active, the VGA BIOS need to be initiative or not. AL8 Series...
  • Page 53 Soft-Off by PWR-BTTN This item selects the method of powering off your system: [Hold 4 Sec.]: Pushing the power button for more than 4 seconds will power off the system. This will prevent the system from powering off in case you accidentally hit or pushed the power button. [Instant-Off]: Pressing and then releasing the power button at once will immediately power off the system.

  • Page 54: Pnp/Pci Configurations

    This item determines whether the MPEG ISA/VESA VGA cards can work with PCI/VGA or not. [Enabled]: MPEG ISA/VESA VGA cards work with PCI/VGA. [Disabled]: MPEG ISA/VESA VGA cards do not work with PCI/VGA. Maximum Payload Size This item sets the maximum TLP payload size for the PCI Express devices. AL8 Series...

  • Page 55: Load Fail-Safe Defaults

    BIOS Setup 3-27 3-8. Load Fail-Safe Defaults This option loads the BIOS default values for the most stable, minimal-performance system operations. 3-9. Load Optimized Defaults This option loads the BIOS default values that are factory settings for optimal-performance system operations. 3-10.
  • Page 56 3-28 Chapter 3 AL8 Series...

  • Page 57: Appendix A. Install Intel Chipset Software Installation Utility

    Appendix A. Install Intel Chipset Software Installation Utility NOTE: Please install this Intel Chipset driver first after having installed the Windows operating system. The installation procedures and screen shots in this section are based on Windows XP operating system. For those of other OS, please follow its on-screen instruction.
  • Page 58 Appendix A Appendix A AL8 Series AL8 Series...

  • Page 59: Appendix B. Install Intel Matrix Storage Technology Raid Driver

    Appendix B. Install Intel Matrix Storage Technology RAID Driver The installation procedures and screen shots in this section are based on Windows XP operating system. For those of other OS, please follow its on-screen instruction. Insert the Driver & Utility CD into CD-ROM drive, it should execute the installation program automatically.
  • Page 60 Appendix B 5. Click [Next]. 6. Click [Finish] to complete setup. AL8 Series...

  • Page 61: Configuration Utility

    Intel SATA RAID Configuration Utility The on-chip Serial ATA RAID supports RAID 0/1/5/10. Main Menu Reboot your system. Press <CTRL> + <I> key while booting up the system to enter the main menu of RAID Configuration Utility: To select the option in this menu, you may: •...
  • Page 62 Reset Disks to Non-RAID This item allows you to reset all RAID data. Type <Y> if you want to reset all RAID data. AL8 Series Exit This item allows you to exit the Intel Serial ATA RAID Configuration Utility. Type <Y> if...

  • Page 63: Appendix C. Install Audio Driver

    Install Audio Driver Appendix C. Install Audio Driver The installation procedures and screen shots in this section are based on Windows XP operating system. For those of other OS, please follow its on-screen instruction. Insert the Driver & Utility CD into CD-ROM drive, it should execute the installation program automatically.
  • Page 64 Appendix C Appendix C AL8 Series AL8 Series...

  • Page 65: Appendix D. Install Bcm Lan Driver

    Install BCM LAN Driver Appendix D. Install BCM LAN Driver The installation procedures and screen shots in this section are based on Windows XP operating system. For those of other OS, please follow its on-screen instruction. Insert the Driver & Utility CD into CD-ROM drive, it should execute the installation program automatically.
  • Page 66 Appendix D AL8 Series...

  • Page 67: Appendix E. Install Sil3132 Sata Driver (Al8

    Appendix E. Install Sil3132 SATA Driver (AL8) The installation procedures and screen shots in this section are based on Windows XP operating system. For those of other OS, please follow its on-screen instruction. Insert the Driver & Utility CD into CD-ROM drive, it should execute the installation program automatically.
  • Page 68 Appendix E 7. Choose [I accept the terms in the license 10. Click [Finish] to complete setup.. agreement], and click [Next]. 8. Click [Next]. 9. Click [Finish]. AL8 Series...

  • Page 69: Raid Configuration Utility Menu

    BIOS Setup for SATA RAID (AL8) The Silicon Serial ATA controller supports RAID 0/1. RAID Configuration Utility Menu Main Menu Reboot your system. Press <CTRL> + <S> or <F4> key while booting up the system to enter the BIOS setting menu. The main menu of...
  • Page 70 Low Level Format This item allows you to do the “Low Level Format” for each single HDD one at a time. Option 5 Logical Drive Info This item displays the drive information of the RAID type you had built. AL8 Series...

  • Page 71: Appendix F. Install Usb 2.0 Driver

    Install USB 2.0 Driver Appendix F. Install USB 2.0 Driver NOTE: The “USB 2.0 Driver” packed in the “Driver & Utility CD” is currently available for Windows 9x and ME only. To install this driver for Windows XP or Windows 2000, you have to download their latest service pack first from Microsoft’s web site.
  • Page 72 Appendix F Appendix F AL8 Series AL8 Series...

  • Page 73: Appendix G. Install Abit Μguru Utility

    If not, double-click the execution file at the main directory of this CD to enter the installation menu. After entering the installation menu, move your curser to [ABIT Utility] tab. Click [ABIT uGuru]. The following screen appears. 1. Click [Next]. 2. Click [Next].
  • Page 74 Appendix G AL8 Series...

  • Page 75: Appendix H. Post Code Definition

    Appendix H. POST Code Definition AWARD POST Code Definition: POST Description (hex) Test CMOS R/W functionality Early chipset initialization: -Disable shadow RAM -Disable L2 cache (socket 7 or below) -Program basic chipset registers Detect memory -Auto-detection of DRAM size, type and ECC -Auto-detection of L2 cache (socket 7 or below) Expand compressed BIOS code to DRAM Call chipset hook to copy BIOS back to E000 &...
  • Page 76 4. On MP platform, adjust the cacheable range to smaller one in case the cacheable ranges between each CPU are not identical Initialize USB Test all memory (clear all extended memory to 0) Clear password according to H/W jumper (Optional) AL8 Series...
  • Page 77 Display number of processors (multi-processor platform) Display PnP logo Early ISA PnP initialization -Assign CSN to every ISA PnP device Initialize the combined Trend Anti-Virus code (Optional Feature) Show message for entering AWDFLASH.EXE from FDD (optional) 1. Initialize Init_Onboard_Super_IO 2. Initialize Init_Onbaord_AUDIO Okay to enter Setup utility;...
  • Page 78 Update keyboard LED & typematic rate 1. Build MP table 2. Build & update ESCD 3. Set CMOS century to 20h or 19h 4. Load CMOS time into DOS timer tick 5. Build MSIRQ routing table Boot attempt (INT 19h) AL8 Series...
  • Page 79 AC2005 POST Code Definition: POST Description (hex) 8.1. Start power on sequence 8.2. Enable ATX power supply 8.3. ATX power supply ready 8.4. DDR voltage ready 8.5. Setup PWM for CPU core voltage 8.6. Assert PWM for CPU core voltage 8.7.
  • Page 80 Appendix H AL8 Series...

  • Page 81: Appendix I. Troubleshooting (Need Assistance

    Appendix I. Troubleshooting (Need Assistance?) Q & A: Q: Do I need to clear the CMOS before I use a new motherboard to assemble my new computer system? A: Yes, we highly recommend that you clear the CMOS before installing a new motherboard. Please move the CMOS jumper from its default 1-2 position to 2-3 for a few seconds, and then back.
  • Page 82 If you have a problem during operation, in order to help our technical support personnel quickly determine the problem with your motherboard and give you the answers you need, before filling in the technical support form, eliminate any peripheral that is not related to the problem, and indicate it on the form.
  • Page 83 To fill in this “Technical Support Form”, refer to the step-by-step instructions given below: . MODEL: Note the model number given in your user’s manual. Example: AL8 Series . Motherboard model number (REV): Note the motherboard model number labeled on the motherboard as “REV:*.**”. Example: REV: 1.00 .

  • Page 84: Technical Support Form

    " Contact Person: * E-mail Address: Model Motherboard Model No. OS/Application Hardware Name IDE1 IDE2 IDE1 CD-ROM-Drive IDE2 System Memory ADD-ON CARD Problem Description: AL8 Series ) Phone Number: # Fax Number: BIOS ID # DRIVER REV Brand Specifications Appendix I...

  • Page 85: Appendix J. How To Get Technical Support

    Also please make sure you have the latest drivers from your peripheral cards makers! 3. Check the ABIT Technical Terms Guide and FAQ on our Website. We are trying to expand and make the FAQs more helpful and information rich. Let us know if you have any suggestions.
  • Page 86 They should have reasonable return or refund policies. How they serve you is also a good reference for your next purchase. 6. Contacting ABIT. If you feel that you need to contact ABIT directly you can send email to the ABIT technical support department. First, please contact the support team for the branch office closest to you.
  • Page 87 ABIT Computer (U.K.) Corporation Ltd. Unit 3, 24-26 Boulton Road, Stevenage, Herts SG1 4QX, UK Tel: 44-1438-228888 Fax: 44-1438-226333 E-mail: sales@abitcomputer.co.uk AMOR Computer B.V. (ABIT's European Office) Jan van Riebeeckweg 15, 5928LG, Venlo, The Netherlands Tel: 31-77-3204428 Fax: 31-77-3204420 Sales: sales@abit.nl Web Site: http://www.abit.nl...
  • Page 88 8. Reporting Compatibility Problems to ABIT. Because of tremendous number of email messages we receive every day, we are forced to give greater weight to certain types of messages than to others. For this reason, any compatibility problem that is reported to us, giving detailed system configuration information and error symptoms will receive the highest priority.
