Summary of Contents for Kenwood KTC-1000R
- Page 1 KTC-1000R HIDEAWAY TUNER AMPLIFIER INSTRUCTION MANUAL B64-1449-00 (E) (DT) ‘99/6...
-
Page 2: Safety Precautions
“O” . • It is possible to interconnect 2 CD/MD changers via the MZ-BUS and 5L interface. • Cannot be connected to Kenwood disc changers (those that went on sale from 1997) or those manufactured by other companies, and without a “O-N” switch. - Page 3 7 . Reconnect the - terminal of the battery. 8. Press the reset button. 2CAUTION • If your car is not prepared for this special connection-system, consult your KENWOOD dealer. • Only use antenna conversion adapters (ISO- JASO) when the antenna cord has an ISO plug.
-
Page 4: Installation
When using the optional power amplifier, connect to its power control terminal. Connect to the terminal that is grounded when either the telephone rings or during conversation. NOTE To connect the KENWOOD navigation system, consult your navigation manual. English PREOUT REAR/NON-FAD FRONT Do not put anything into the fuse holder. - Page 5 2WARNING Connecting the ISO Connector The pin arrangement for the ISO connectors depends on the type of vehicle you drive. Make sure to make the proper connections to prevent damage to the unit. The default connection for the wiring harness is described in 1 below.
- Page 6 UNIT MONITOR 2WARNING gS h Extention cable (5.5 m) (Accessory7) Changer control cable (Provided with the C907) CD auto changer (optional) English DAB control cable (Provided with the KTC-959DAB) KTC-1000R FRONT REAR/NON-FAD POWER PREOUT INPUT ANTENNA UNIT SLAVE CHANGER WOOFER...
- Page 7 Do not connect the C907 and KDC-CPS81 at the same time. The equipment will cease functioning. TO 5L I/F TO 5L I/F TO MZ-BUS FM•AM TUNER 44W 4 AMPLIFIER HIDEAWAY UNIT KTC-1000R FM ANTENNA FRONT SPEAKER REAR SPEAKER TV MONITOR SUB WOOFER CHANGER...
-
Page 8: Troubleshooting Guide
Installation Installation for Hideaway unit Securing to audio board Attach the installation brackets to the sides of the hideaway unit using the sems bolts 8 mm). Installation brackets (Accessory1) Securing to pile carpet Peel the protective strips off of the velcro strips, attach them to the bottom of the hideaway unit, and secure to the pile carpet. -
Page 9: Specifications
Troubleshooting Guide PROBLEM The sound quality is poor or distorted. Radio reception is poor. The memory is erased when the ignition is turned off. The following indications are used to inform you that there is a problem with the connections of the system.
