15-inch Diagonal LCD TV/DVD
*
COMBINATION
15DLV77
OWNER'S MANUAL
©2007 Toshiba Corporation
Before operating the unit, please read this manual thoroughly.
*Screen size is approximate.
Book 5Z0-01.indb 1
Book 5Z0-01.indb 1
Introduction
2
Connections
13
Basic setup
19
TV operation
22
Basic playback
38
Advanced playback
41
Function setup
54
Others
61
9/11/2549 16:14:50
9/11/2549 16:14:50

Advertisement

Table of Contents
loading

Related Manuals for Toshiba 15DLV77

Summary of Contents for Toshiba 15DLV77

  • Page 1 15-inch Diagonal LCD TV/DVD COMBINATION 15DLV77 OWNER’S MANUAL ©2007 Toshiba Corporation Before operating the unit, please read this manual thoroughly. *Screen size is approximate. Book 5Z0-01.indb 1 Book 5Z0-01.indb 1 Introduction Connections Basic setup TV operation Basic playback Advanced playback...

  • Page 2: Introduction

    Introduction CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION : TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi...
  • Page 4 28 on this page. Service expose you to dangerous voltage or other hazards. Refer all servicing to a Toshiba Authorized Service Center. 39) If you have the TV serviced: • Ask the service technician to use only replacement parts specifi...

  • Page 5: Precautions

    The following symptoms are technical limitations of LCD Display technology and are not an indication of malfunction; therefore, Toshiba is not responsible for perceived defects resulting from these symptoms. 1) An after image (ghost) may appear on the screen if a fi...

  • Page 6: Notes On Discs

    Introduction Prcautions (Continued)/Notes on discs Notes on moisture condensation Moisture condensation damages the unit. Please read the following carefully. Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day and drops of water form on the outside of the glass. In the same way, moisture may condense on this unit’s internal optical pick-up lens, one of the most crucial internal parts of the unit.

  • Page 7: Notes On Copyright

    Because of problems and errors that can occur during the creation of DVD and CD Software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that the DVD player contained in this TV will successfully play every disc bearing the DVD and CD logos.

  • Page 8: Table Of Contents

    Introduction Contents Introduction SAFETY INSTRUCTIONS ... 3 Precautions... 5 Notes on discs ... 6 Contents ... 8 Identifi cation of controls ... 9 Connections Antenna connections ... 13 Cable TV connections ... 14 Connecting to optional equipment ... 15 Power source... 18 Basic setup Starting setup ...

  • Page 9: Identifi Cation Of Controls

    Identifi cation of controls Front Speaker Book 5Z0-01.indb 9 Book 5Z0-01.indb 9 Remote sensor POWER indicator 9/11/2549 16:15:01 9/11/2549 16:15:01...
  • Page 10 Introduction Identifi cation of controls (Continued) Side Left Side S-VIDEO IN (LINE 1 IN) jack AUDIO IN (L/R) (LINE 1 IN) jacks VIDEO IN (LINE 1 IN) jack COAXIAL DIGITAL AUDIO OUT jack HEADPHONE jack CHANNEL ( VOLUME (+/-) buttons POWER ( ) button Rear Book 5Z0-01.indb 10...

  • Page 11: Remote Control

    Remote control The instructions in this manual describe the function on the remote control. See the page in EJECT button TV/DVD button Direct channel selection buttons (0-9) Numbered buttons (0-9) DISPLAY button SUBTITLE button button INPUT button ZOOM button PLAY MODE button FAV ( ) button MENU button SETUP button...

  • Page 12: Inserting Batteries

    Introduction Identifi cation of controls (Continued) Inserting batteries Open the battery compartment cover in the direction of the arrow. Operation • Aim the remote control at the remote sensor and press control buttons to operate. • Operate the remote control within 30° angle on either side of the remote sensor, up to a distance of approx. 5 meters. Caution: •...

  • Page 13: Connections

    Connections Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a cable TV service (CABLE), see page 14 for Cable TV connections. Combination VHF/UHF antenna (Single 75 ohm cable or 300 ohm twin-lead wire) Antenna jack 75 ohm coaxial cable...

  • Page 14: Cable Tv Connections

    Connections Cable TV connections This TV/DVD has an extended tuning range and can tune most cable channels without using a Cable TV converter box. Some cable companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the cable company.

  • Page 15: Connecting To Optional Equipment

    Connecting to optional equipment You can enjoy VCR, camcorder or TV game with connection to external input. Using the audio/video inputs Press INPUT to view a signal from another device connected to your TV, such as a VCR or DVD player. You can select ANT, VIDEO1 (on the left side), VIDEO2 (on the back panel) or ColorStream HD (on the back panel) depending on which input jacks you used to connect your devices.
  • Page 16 Note: When the S-VIDEO cable and the standard video cable are connected at the same time, the S-video cable takes precedence. Connecting an optional equipment with ColorStream Your TV/DVD is capable of using ColorStream video compatible DVD player, such as a Toshiba DVD player with ColorStream quality and performance. Select the “ColorStream HD” by pressing INPUT repeatedly.
  • Page 17 You can enjoy high quality dynamic sounds by connecting the TV/DVD to optional audio equipment. Connecting to an amplifi er equipped with a Dolby Dolby Digital Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home.

  • Page 18: Power Source

    Connections Connections Connecting to optional equipment (Continued)/Power source Connecting to an amplifi er equipped with an MPEG audio decoder MPEG2 sound You can enjoy motion picture and live concert DVD video discs encoded via the MPEG2 recording system with dynamic realistic sound by connecting an amplifi...

  • Page 19: Basic Setup

    Basic setup Starting setup The STARTING SETUP function helps to install your unit easily. It leads you the Language selection, TV/CABLE selection and auto channel memory automatically. IMPORTANT: Make sure that the antenna or cable TV system connection is made! Starting setup To turn on the TV/DVD, press POWER.

  • Page 20: Setting The Language

    Basic setup Setting the language This TV/DVD can display the on screen language in English, Spanish or French in the TV mode. Select the language you prefer fi rst, then proceed with the other menu options. Setting the language Press MENU in the TV mode, then press to display the “SETUP”...

  • Page 21: To Memorize Channels

    To memorize channels This TV/DVD is equipped with a channel memory feature which allows channels to skip up or down to the next channel set into memory, skipping over unwanted channels. Before selecting channels, they must be programmed into the TV/DVD’s memory. To use this TV/DVD with an antenna, set the TV/CABLE selection to the TV position.

  • Page 22: Tv Operation

    TV operation TV operation TV operation To turn on the TV/DVD, press POWER. The power indicator on the front of the main unit will light. Adjust the volume level by pressing VOL +/–. The volume level will be indicated on the screen by white bars.
  • Page 23 TV operation ■ DISPLAY Press DISPLAY to display the information on the TV screen. To cancel the display, press DISPLAY again. (Digital channel) (Analog channel) ■ CH RETURN This button allows you to go back to the last channel selected by pressing CH RTN. Press CH RTN again to return to the last channel you were watching.

  • Page 24: Programming Your Favorite Channels

    TV operation Programming your favorite channels You can preset up to 12 of your favorite channels using the Favorite Channel Programming feature. Because this feature scans through only your favorite channels, it allows you to skip other channels you do not normally watch. You can still use CH programmed in the TV’s memory or the Channel Numbers to directly tune a channel.

  • Page 25: Setting The Closed Captions (Analog Caption/ Digital Caption)

    Setting the closed captions (analog caption/ digital caption) WHAT IS CLOSED CAPTIONING? This television has the capability to decode and display closed captioned television programs. Closed captioning will display text on the screen for hearing impaired viewers or it will translate and display text in another language.

  • Page 26: Setting The Cc Advanced

    TV operation Setting the CC advanced This feature is designed to customize digital captions only. To set the CC advanced feature Press MENU in the TV mode, then press to display the “SETUP” menu. Press to highlight “CC ADVANCED”, then press or .

  • Page 27: To Change Password

    Setting the V-Chip An age limitation can be set to forbid children to see and hear violent scenes or pictures for adults, etc. The TV/DVD corresponds to “TV RATING” and “MOVIE RATING”. To use the V-Chip function, you must register a password. Notess: If you forget the password, press DISPLAY four times within fi...
  • Page 28 TV operation Setting the V-Chip (Continued) To set the V-Chip Repeat steps 1 ~ 3 in “To register password” on page 27, then press “V-CHIP SET”. Press to display “V-CHIP” menu. Press to select the desired rating. : TV RATING is not set TV-Y : All children TV-Y7 : 7 years old and above TV-G : General audience...
  • Page 29 As a supplement to the standard V-Chip rating system, your Toshiba Television will be able to download an additional rating system, if such a system becomes available in the future. To download the additional V-Chip rating system (when available) Repeat steps 1~3 in “To register password” on page 27, then press to higlight “V-CHIP...

  • Page 30: Viewing The Wide-Screen Picture Formats

    TV operation Viewing the wide-screen picture formats You can view programs in a variety of picture sizes—NATURAL (4:3), COMPRESSION (16:9), ZOOM. The way the image displays in any of the picture sizes will vary depending on the format of the program you are viewing. Select the picture size that displays the current program the way that looks best to you.
  • Page 31 About the picture size COMPRESSION (16:9) picture size • If receiving a 4:3 format (analog or digital) program, select COMPRESSION PIC SIZE will typically display the image stretched wider with bars at the top and bottom. • If receiving a 16:9 format (analog or digital) program, select COMPRESSION PIC SIZE will typically display the image in its original formatted proportion with bars at the top and...

  • Page 32: Selecting The Cinema Mode

    TV operation Selecting the cinema mode When you view a DVD movie (3:2 pulldown processed) smoother and more natural motion can be obtained by setting the CINEMA MODE to FILM. If you view a DVD movie from a DVD player connected to the ColorStream (component video) inputs on the TV/DVD, the CINEMA MODE feature may not work.

  • Page 33: Picture Control Adjustment

    Picture control adjustment/ Adjusting the picture mode Picture controls are factory preset but you can adjust them individually as follows: And also you can select four picture modes— Sports, Standard, Movie, and Memory—as described in the following table: Picture control adjustment Press MENU in the TV mode, then press to display the “PICTURE”...

  • Page 34: Using The Cableclear Feature

    TV operation Using the CableClear Selecting the color temperature CableClear ® reduces visible interference in your TV picture. This is useful when receiving a broadcast with a weak signal (especially a Cable channel) or playing a video cassette or disc damaged by repeated use.

  • Page 35: Sound Control Adjustment

    Sound control adjustment/ Stereo and Second Audio Program (SAP) Sound controls are factory preset but you can adjust them individually as follows: The TV/DVD is equipped with a feature known as multi-channel TV sound or MTS. MTS broadcasts greatly enhance TV viewing by bringing you programs with high fi...

  • Page 36: Selecting The Audio Languages

    TV operation Selecting the audio languages/ Selecting the digital output To select the audio languages When two or more audio languages are included in a digital signal, you can select one of the audio language. Press MENU in the TV mode, then press to display the “AUDIO”...

  • Page 37: Checking The Signal Meter

    Checking the signal meter/ Using the auto shut off feature To check the signal meter You can check the strength of the digital signal by viewing the digital signal meter. Press MENU in the TV mode, then press to display the “SETUP” menu. Press to highlight “SIGNAL METER”.

  • Page 38: Basic Playback

    Basic playback Playing a disc This section shows you the basics on how to play a disc. CAUTION Keep your fi ngers well clear of the disc slot when disc is loading or unloading. Neglecting to do so may cause serious personal injury.
  • Page 39 To obtain a higher quality picture Occasionally, some picture noise may appear on the TV screen while playing a DVD video disc because the high resolution pictures on these discs include a lot of information. In such case, you may reduce the SHARPNESS with the Picture control adjustment menu (see page 33).

  • Page 40: Playing Frame By Frame

    Basic playback Playing a disc (Continued) Playing in fast reverse or fast forward directions Press REV or FF during playback. REV: Fast reverse playback Fast forward playback Each time you press REV or FF button, the playback speed changes. Playing frame by frame Press PAUSE during still playback.

  • Page 41: Advanced Playback

    Advanced playback Zooming/Locating desired scene Zooming This unit will allow you to zoom in on the frame image. You can then make selections by switching the position of the frame. Press ZOOM during playback. The center part of the image will be zoomed in.

  • Page 42: Marking Desired Scenes

    Advanced playback Marking desired scenes The unit stores the points that you want to watch again up to 3 points. You can resume playback from each scene. Marking the scenes Press MARKER during playback. Select the blank Marker using Then press ENTER to mark the desired scene. •...

  • Page 43: Repeat Playback

    Repeat playback/A-B Repeat playback Repeat playback Press PLAY MODE during playback or stop mode. [DVD] Press ENTER repeatedly to select “Chapter” or “Title”. The unit automatically starts repeat playback after fi nishing the current title or chapter. Repeat [Video CD] Press to select “Repeat”.

  • Page 44: Program Playback

    Advanced playback Program playback/Random playback You can arrange the playback order of tracks on the disc. And the unit can also select tracks at random and playback them. These features work for Video CD. For Audio CD and MP3/WMA CD, please see “Random playback (CD)”...

  • Page 45: Changing Angles

    Changing angles/Title selection/DVD menu Changing angles When playing back a disc recorded with multi-angle facility, you can change the angle that you are viewing the scene from. Press ANGLE during playback. The current angle will appear. Title selection Two or more titles are recorded on some discs. If the title menu is recorded on the disc, you can select the desired title. Press TOP MENU during playback.

  • Page 46: Changing Soundtrack Language

    Advanced playback Changing soundtrack language/Subtitles Changing soundtrack language You can select the language when you play a multilingual disc. Press AUDIO SELECT during playback. The current soundtrack language will appear. Press AUDIO SELECT repeatedly until the desired language is selected. •...

  • Page 47: Disc Status

    Disc status/To turn off the PBC Disc status With press of DISPLAY, the status of the disc will appear on the screen. To cancel the display, press DISPLAY again. ELAPSED DISC OPERATION TIME TITLE NO. 00:15:25 01:41:39 Title 1/3 Chapter 2/24 1/1 Eng Dolby Digital 1/2 Eng ANGLE NO.

  • Page 48: Mp3/Wma/Jpeg/Divx And Audio Cd Operation

    Use of CD-RW for MP3 fi les is not recommended. You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission. Audio CD/MP3/WMA/JPEG/DivX Limitations on MP3/WMA/JPEG/DivX •...
  • Page 49 MP3/WMA CD playback Load a disc on which MP3 or WMA fi les have been recorded in the disc slot. A fi le browser screen will appear on the screen. Press to select fi le. /MP3-2.MP3 • In case the current directory includes more than 8 fi...

  • Page 50: Jpeg Cd Playback

    Advanced playback Advanced playback MP3/WMA/JPEG/DivX operation (Continued) You can select your desired JPEG fi le on the fi le menu and picture menu. The selected JPEG fi le is automatically adjusted to the TV screen. (When the aspect ratio of the JPEG fi le is different to the TV screen, the black bar will appear at the top and bottom, or the both sides of the TV screen.) JPEG CD playback Load a JPEG disc in the disc slot.
  • Page 51 DivX ® CD playback Load a disc on which DivX ® recorded in the disc slot. A fi le browser screen will appear on the TV screen. /Movie-01.DIVX Movie-01 Movie-02 Movie-03 Movie-04 Movie-05 Movie-06 Movie-07 Movie-08 Press to select fi le. •...

  • Page 52: Repeat, Random And Program Playback Using Fi Le Browser

    Advanced playback Repeat, random and program playback using fi le browser Repeat playback (CD) In the fi le browser, press “Repeat” during stop mode. Folder-1 Folder-2 MP3-1 MP3-2 MP3-3 Press ENTER repeatedly to select “Track” or “All”. Folder-1 Folder-2 MP3-1 MP3-2 MP3 3 Press PLAY.
  • Page 53 Program playback (CD) In the fi le browser, press “Edit Mode”, then press ENTER. Folder-1 Folder-2 MP3-1 MP3-2 MP3 3 When “Edit Mode” is black color, you can mark the fi les which you want to add into Program list. Press to select fi...

  • Page 54: Function Setup

    Function setup Customizing the function settings You can change the default settings of the DVD mode to customize performance to your preference. Setting procedure Press SETUP during stop mode. The following on-screen display appears. Press to select the desired section, then press .
  • Page 55 Setting details Section Option Menu Subtitle Audio TV Screen Display Picture Mode JPEG Interval Parental Password DivX(R) VOD Book 5Z0-01.indb 55 Book 5Z0-01.indb 55 Details To select the language of “Menu”, “Subtitle” and “Audio” if more than one language are available on the disc. To select a picture size according to the aspect ratio of your TV.
  • Page 56 Function setup Customizing the function settings (Continued) Setting details E.B.L. Menu Parental Subtitle TV Screen QSound Display Audio Output Picture Mode JPEG Interval Screen Saver Menu, Subtitle, Audio You can select the language of “Menu”, “Subtitle” and “Audio” if more than one languages are recorded onto the disc.
  • Page 57 Setting details Picture Mode There are two types of source content in pictures recorded in DVD video discs: fi lm content (pictures recorded from fi lms at 24 frames per second) and video content (video signals recorded at 30 frames per second).
  • Page 58 Function setup Customizing the function settings (Continued) Setting details Parental E.B.L. TV Screen Output Display Picture Mode JPEG Interval Screen Saver DRC (Dynamic Range Control) enables you to control the dynamic range so as to achieve a suitable sound for your equipment. Off: It plays back at the recording level on the disc.
  • Page 59 Setting details ■ Set the new password 1) Press to select “Password”, then press ENTER. “Enter Current Password” screen will appear. 2) Press Number buttons (0–9) to input the current password (If the password has not been set yet after you purchase this unit, it is “0000”). 3) Then press ENTER.

  • Page 60: Temporary Cancel The Rating Level By Dvd Disc

    Function setup Temporary cancel the rating level by DVD disc Depending on the DVD disc, the disc may try to temporarily cancel the rating level that you have set. It is up to you to decide whether to cancel the rating level or not. Temporary cancel the rating level by DVD disc Load a DVD disc.

  • Page 61: Others

    Others Language code list Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” Language Name Code Language Name Abkhazian 1112 Fiji Afar 1111 Finnish Afrikaans 1116 French Albanian 2927 Frisian Amharic 1123 Galician Arabic 1128 Georgian Armenian 1835 German...

  • Page 62: Troubleshooting

    Others Troubleshooting Use the following check list for troubleshooting when you have problems with your unit. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POWER TV/DVD does not operate.
  • Page 63 SYMPTOMS • No disc is loaded. Playback doesn’t start. • The disc may be dirty. Clean up the disc. • The unit cannot play CD-ROMs, etc. No picture. • TV/DVD selector is not set correctly. • Check the input selector of the amplifi er is set properly. No sound.

  • Page 64: Reception Disturbances

    Others Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV/DVD is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

  • Page 65: Specifi Cations

    Specifi cations General Power supply Power consumption Weight Dimensions Operating temperature Operating humidity Television LCD panel Display method Number of pixels Television system Receiving channels Antenna input Speaker Audio output power DVD/CD Player Signal system Applicable disc Pickup Input/Output S-Video input ColorStream video input Video input Audio input...

  • Page 66: Limited United States Warranty

    Limited United States Warranty LCD TV/DVD Combination - Depot Repair Warranty Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS LCD TV/DVD COMBINATION AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.
  • Page 67 Combination to the Depot Warranty Repair Center specifi ed by the TACP Consumer Solutions Center. For additional information, visit TACP’s website: www.tacp.toshiba.com ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF THE U.S.A., INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY...
  • Page 68 CableClear, ColorStream and StableSound are registered trademarks of Toshiba America Consumer Products, L.L.C. is a trademark of Toshiba America Consumer Products, L.L.C. J5Z00101A SH 06/11 N Book 5Z0-01.indb 68 Book 5Z0-01.indb 68 Printed in Thailand 9/11/2549 16:15:27 9/11/2549 16:15:27...
