INSTALLATION INSTRUCTION
GENERAL
YORK Model DEG units are single package air conditioners with
gas heat designed for outdoor installation on a rooftop or a slab.
The units are completely assembled on rigid, permanently
attached base rails. All piping, refrigerant charge, and
electrical wiring is factory-installed and tested. The units
require only electric power, gas piping and duct connections
at the point of installation.
The gas-fired heaters have aluminized steel tubular heat
exchangers and spark ignition with intermittent pilot.
This appliance is not to be used for temporary heating of
buildings or structures under construction.
INSPECTION
As soon as a unit is received, it should be inspected for possible
damage during transit. If damage is evident, the extent of the
damage should be noted on the carrier's freight bill. A separate
request for inspection by the carrier's agent should be made in
writing. Refer to Form 50.15-NM for additional information.
REFERENCE
Additional information on the design, installation, operation
and service of this equipment is available in the following
reference forms:
•
55.70-N1
•
55.70-N2
•
530.18-N1.2V
•
530.18-N1.13V -Man. Outdoor Air Damper Accy 0-35%
Installer should pay particular attention to the words: NOTE, CAUTION and WARNING. Notes are intended to clarify or make
the installation easier. Cautions are given to prevent equipment damage. Warnings are given to alert installer that personal in-
jury and/or equipment damage may result if installation procedure is not handled properly.
THIS PRODUCT MUST BE INSTALLED IN STRICT COMPLIANCE WITH THE ENCLOSED INSTALLATION INSTRUC-
TIONS AND ANY APPLICABLE LOCAL, STATE, AND NATIONAL CODES INCLUDING, BUT NOT LIMITED TO, BUILDING,
ELECTRICAL, AND MECHANICAL CODES
INCORRECT INSTALLATION MAY CREATE A CONDITION WHERE THE OPERATION OF THE PRODUCT COULD
CAUSE PERSONAL INJURY, PROPERTY DAMAGE AND/OR DEATH.
DE-ENERGIZE THE ELECTRICAL POWER AND TURN OFF THE GAS SUPPLY TO THE UNIT BEFORE ATTEMPTING TO
INSPECT, REPAIR OR PERFORM MAINTENANCE TO THE UNIT.
®
Supersedes: 035-14832-002-A-0302
MODELS D2EG 048 & 060 and D3EG 036
-General Installation
-Pre-start & Post-start Check List
-Economizer Accessory
SUNLINE PLUS™
GAS / ELECTRIC
SINGLE PACKAGE AIR CONDITIONERS
(11 SEER)
•
530.18-N1.14V -Man. Outdoor Air Damper Accy 0-100%
•
530.18-N1.12V -Motorized Outdoor Air Damper Accy.
•
530.18-N1.8V
•
530.18-N2.11V -Low NOx Accessory
•
530.18-N8.2V
•
530.18-N8.3V
•
530.18-N8.4V
•
530.18-N8.12V
•
690.15-N25V
Renewal Parts:
•
Refer to Parts Manual for complete listing of replacement
parts on this equipment.
All forms referenced in this instruction may be ordered from:
Standard Register
Toll Free Tel.: 877-318-9675
Fax: 877-379-7920
APPROVALS
Design certified by CGA and UL listed as follows:
1. For use as a forced air furnace with cooling unit.
2. For outdoor installation only.
3. For installation directly on combustible flooring or, in the U.S.A.,
on wood flooring or Class A, B, or C roof covering material.
4. For use with natural gas and/or propane (LP) gas.
Not suitable for use with conventional venting systems.
CAUTION
WARNING
WARNING
035-14832-003-A-0204
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors or liquids
in the vicinity of this or any other
appliance.
If you smell gas:
1. Open windows
2. Don't touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
-Coil Guard
-High Altitude Accy. (Natural Gas)
-High Altitude Accy. (Propane)
-Gas Piping Accessory
-Propane Conversion Accessory
-Low Ambient Accessory
Advertisement
Table of Contents
Related Manuals for York SUNLINE PLUS D2EG 048
Summary of Contents for York SUNLINE PLUS D2EG 048
-
Page 1: General
INSTALLATION INSTRUCTION GENERAL YORK Model DEG units are single package air conditioners with gas heat designed for outdoor installation on a rooftop or a slab. The units are completely assembled on rigid, permanently attached base rails. All piping, refrigerant charge, and electrical wiring is factory-installed and tested. -
Page 2: Table Of Contents
General...1 Inspection ...1 Reference ...1 Approvals ...1 Nomenclature ...2 INSTALLATION Limitations ...3 Location ...3 Rigging and Handling ...3 Clearances ...3 Ductwork ...3 Filters...4 Condensate Drain ...4 Service Access ...4 Thermostat ...4 Power and Control Wiring ...4 Blower Speed Selection ...4 Compressors ...4 Combustion Discharge ...4 Disconnect Switch Bracket For Optional Belt-Drive ...5... -
Page 3: Installation
Unitary Products Group INSTALLATION CAUTION: If a unit is to be installed on a roof curb or special frame other than a YORK roof curb, gasketing must be applied to all surfaces that come in contact with the unit underside. -
Page 4: Ductwork 3
The supply and return air duct systems should be designed for the CFM and static requirements of the job. They should NOT be sized to match the dimensions of the duct connections on the unit. CAUTION: When fastening ductwork to the side duct flanges on the unit, insert the screws through the duct flanges only. -
Page 5: Disconnect Switch Bracket For Optional Belt-Drive
035-14832-003-A-0204 COOLING / HEATING (24 VOLT THERMOSTAT) REFER TO THE ELECTRICAL DATA TO SIZE THE DISCONNECT SWITCH, THE WIRING AND THE OVERCURRENT PROTECTION FIG. 3 - TYPICAL FIELD WIRING DISCONNECT SWITCH BRACKET FOR UNITS WITH OPTIONAL BELT-DRIVE BRACKET A special bracket for mounting a field-supplied disconnect switch is provided in each unit ordered with an optional belt- drive supply air blower. -
Page 6: Gas Connection
FIG. 4 - EXTERNAL SUPPLY CONNECTION EXTERNAL SHUT-OFF GAS CONNECTION The gas supply line can be routed through the knockouts located on the front of the unit or through the opening provided in the unit's base. Refer to Figure 9 to locate these access openings. -
Page 7: Vent And Combustion Air Hoods
035-14832-003-A-0204 VENT AND COMBUSTION AIR HOODS The vent and combustion air hoods are shipped attached to the blower housing in the blower compartment. These hoods must be installed on the outside of the gas heat panel to ensure proper unit function. The necessary mounting screws are provided in a bag that is also attached to the blower housing. -
Page 8: Physical Data
NOTE: Install filters so that “Air Flow” arrows point toward the unit. 8. Install filter cover over the end of the hood with one screw (center of hood), securing filters into position. CAUTION: When proceeding with Steps 9 and 10, extreme care must be exercised while turning both the set point and minimum position adjusting screws to prevent twisting them off. -
Page 9: Supply Air Perf.3 & 4Ton Belt-Drive Units
035-14832-003-A-0204 TABLE 6 - SUPPLY AIR PERFORMANCE - 3 & 4 Ton w/Belt-Drive Blower 3TON - SIDE DUCT CONNECTIONS @ 230/460/575 Volts MODEL AIR FLOW 0.20 Watts 2000 1900 1800 1700 1600 1500 1400 1300 1200 MODEL AIR FLOW 0.90 Watts 2000 1103... -
Page 10: Supply Air Perf.5 Ton Belt-Drive Units
TABLE 7 - SUPPLY AIR PERFORMANCE - 5 Ton w/Belt-Drive Blower 5 TON - SIDE DUCT CONNECTIONS @230/460/575 Volts MODEL AIR FLOW 0.20 Watts 2500 1059 1560 2400 1032 1405 2300 1005 1260 2200 1160 2100 1060 2000 1900 1800 1700 1600 1500... -
Page 11: Static Resistances
035-14832-003-A-0204 TABLE 8 - STATIC RESISTANCES DESCRIPTION 1, 2 Economizer Bottom Duct Connections Deduct these resistance values from the available external static pressure shown in the respective Blower Performance Table. The pressure thru the economizer is greater for 100% outdoor air than for 100% return air. If the resistance of the return air duct system is less than 0.25 IWG, the unit will deliver less CFM during full economizer operation. -
Page 12: Dimensions And Clearances
(Direct Drive Units) CLEARANCES Front 32" 12" (Less Economizer) Back 36" (With Economizer or Fixed Air/motorized Air Damper) 24" (Less Economizer) Left Side (Filter Access) 36" (With Economizer) Right Side (Cond. Coil) 24" Below Unit 20" Above Unit 72" (For Condenser Air Discharge) 1 Units may be installed on combustible floors made from wood or class A, B or C roof covering material. -
Page 13: Operation
035-14832-003-A-0204 COOLING SYSTEM The cooling section is a complete factory package utilizing an air-cooled condenser. The system is factory-charged with Refrigerant-22. The compressor is hermetically sealed and internally sprung. The compressors have inherent (internal) protection. If there is an abnormal temperature rise in the compressor, the protector will open to shut down the compressor. -
Page 14: Safety Controls (Heating)
SAFETY CONTROLS (Heating) The control circuit includes the following safety controls: 1. Limit Control (LS). This control is located inside the heat exchanger compartment and is set to open at the temperature indicated in Table 12. It resets automatically. The limit switch, operates when a high temperature condition, caused by inadequate supply air flow occurs, thus shutting down the ignition control and closing the main gas valve. -
Page 15: Pilot Checkout
035-14832-003-A-0204 PILOT CHECKOUT The pilot flame should envelope 3/8 inches of the end of the flame sensor. Refer to Figure 12. To adjust pilot flame, (1) remove pilot adjustment cover screw, (2) adjust the screw for the proper pilot flame, (3) be sure to replace cover screw after adjustment to prevent possible gas leakage. -
Page 16: Checking Gas Input
NOTE: The tubes must be inserted and held in a position per- pendicular to the air flow so that velocity pressure will not affect the static pressure readings. 3. Using an inclined manometer, determine the pressure drop across a dry evaporator coil. Since the moisture on an evaporator coil may vary greatly, measuring the pressure drop across a wet coil under field conditions would be inac- curate. -
Page 17: Normal Maintenance
035-14832-003-A-0204 NORMAL MAINTENANCE CAUTION: Prior to any of the following maintenance proce- dures, shut off all power to the unit to prevent per- sonal injury. Periodic maintenance normally consists of changing or cleaning filters and (under some conditions) cleaning the main burners. FILTERS - Inspect once a month. -
Page 18: Troubleshooting
WARNING: Troubleshooting of components necessarily re- quires opening the electrical control box with the power connected to the unit. Use extreme care when working with live circuits! Check the unit nameplate for the correct line voltage and set the volt meter to the correct range before making any connections with line terminals. - Page 19 035-14832-003-A-0204 TROUBLESHOOTING - Continued. 6. The pilot burner ignites but the sparker continues to spark and the main burners do not ignite. a. Make the same checks and adjustments as described in Item 5. b.Make sure that the pilot burner is not bent or damaged. c.
- Page 20 Unitary Products Group 5005 York Drive, Norman Oklahoma 73069 Subject to change without notice. Printed in U.S.A. 035-14832-003-A-0204 Supersedes: 035-14832-002-A-0302 Copyright © by York International Corporation 2004. All Rights Reserved.
