SA10085 User Guide Satellite Radio Receiver Important: This manual contains important safety and operating information. Please read and follow the instructions in this manual. Failure to do so could result in personal injury, death, and/or damage to your Roady2 and/or to your vehicle.
FCC ID: RS2SA10085 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
Welcome Thank you for purchasing a Delphi XM Your Roady2 gives you access to over 120 XM Satellite Radio channels of music, news, and information from coast-to-coast.* Your Roady2 must be used with the enclosed connecting devices (or other approved accessories) to ensure maximum performance and safety.
Delphi has a broad portfolio of products to answer a wide variety of information and entertainment needs. About XM One big idea can change everything. And XM Satellite Radio is one big idea: Radio to the Power of X ®...
Getting Started: Activating Roady2 To quickly begin enjoying Delphi XM Satellite Radio, follow these simple steps: 1. Set up your Roady2 using the installation instructions in Section 5 of this guide (see page 17) or with the help of a professional installer.
Roady2 Receiver Roady2 Display Screen While tuned to an XM channel, the Roady2 default display contains information about that channel and the Roady2 settings. See figure 1. Signal-strength indicator (zero to three bars) Channel name and number Artist name Roady2 Controls Power button Number keys Display mode...
The Roady2 unit has seven function buttons, a Tuning Wheel, and 10 number keys. Turns the Roady2 on or off. The display button toggles between four display options: display 1. Channel name, channel number, artist name 2. Channel name, channel number, song title 3.
Basic Operations Turning Roady2 On and Off Press on the Roady2. When first turned on, the receiver will automatically tune in to the last channel listened to and recall the previous settings. Basic Channel Selection Select a channel by number 1.
3. Press and hold the number key corresponding to the preset you would like to set. The receiver will beep to indicate that the preset is registered. 4. When you first get Roady2, all presets go to Channel 1. Preview and select channels using the Tuning Wheel You can use your Roady2 to preview the XM channel lineup, see what is currently playing, and then decide if you want to leave your current channel.
Display Option 1 Display Option 2 Changing the Display display Pressing lets you change what is shown on your two-line Roady2 display during normal listening from among four options: • Display mode 1 (factory default): Shows the channel name and channel number on the first line and the artist name on the second line.
Menu menu Press to enter the menu section of Roady2. Here, you can change each of the following options using the Tuning Wheel pressing the Tuning Wheel button, allowing you to back out of existing sections. Following are the settings that can be changed: FM Frequency (only available when FM modulator is turned on) Roady2’s internal FM modulator can be used to send the audio to a nearby...
each available frequency until you have found an optimal frequency. In the rare circumstance that you cannot find an acceptable open frequency, change to a hard-wired FM modulator configuration using the separately available FM Modulator Direct Wiring Adaptor described in the Available Accessories section on page 29.
Antenna Aiming When using the optional home kit, you can optimize the position of your home antenna using this screen. For optimal performance, your home anten- na should be positioned to maximize the satellite signal received by your Roady2. TuneSelect™ Using this function, you can program your Roady2 to alert you with a tone when a favorite song is playing on a channel other than the one you are listening to.
Stock Ticker This feature lets you track your favorite stocks and indices by “Scroll” (default) or by “Pages”*, selectable in the “Display Mode” option of the “Stock Ticker” menu. You can enter up to 20 favorite stock symbols and indices, tracking the price and daily movement**. You can track any stock symbols and most indices listed on the NYSE, NASDAQ, or AMEX.
Auto-On Once you have installed your Roady2 and the power has been turned on using the power button set to be turned off and back on again using the ignition key in your vehicle. To change this factory-set condition and always power your Roady2 on and off with the power button then select “Off.”...
Installation Roady2 Kit Set-up Your Roady2 Kit contains the following components: Car mount XM antenna Cell phone mount adaptor Figure 4. Roady2 Kit components. Hooking up your Roady2 Receiver (Optional) Figure 5. Connect accessories to your Roady2 as shown. 12V power adaptor Cassette audio Your kit also includes: •...
Audio Quality Direct Connect: Cassette Adaptor: FM Modulator: Wireless FM Modulator: Direct Connect For vehicles with radio head-units equipped with auxiliary audio inputs, connecting the audio directly to the auxiliary inputs of the head-unit (in a limited number of vehicles and aftermarket head units these inputs are locat- ed on the dash) provides maximum audio quality.
the XM audio signal wirelessly to the vehicle’s FM radio. This FM modulator is automatically turned on whenever the cassette adaptor (or other audio jack) is unplugged from the side of the Roady2. One of 12 different frequencies can be selected, as described on page 12. In order to ensure optimum perform- ance, the signal is broadcast to your car’s FM radio from both inside the Roady2, and from the included XM antenna.
(a) Flat mount: Use the included Velcro back of Roady2 and the identified flat surface in your vehicle. (b) Vent mount: Your Roady2 kit includes an optional vent mount that can be used in place of the more permanent Velcro easily move your Roady2 and mount from car to car.
adhere to the vehicle’s surface. Make sure you accurately place the pad on the first try since in many cases it will bond almost immediately. 3M recommends a 72-hour curing time for maximum adhesion. 3. Clip the Roady2 onto the swivel or vent mount (figure 7).
XM Antenna Set-up Antenna Installation • Best reception is achieved with the antenna mounted on the metal surface of the vehicle roof in the center of an area with at least 12" x 12" of surface area and a minimum of 6" from a window or sunroof. Figure 8 shows three typical mounting locations.
Cable Routing • Once you have mounted the antenna in the correct location, plan how to route the cable from this location to the receiver, avoiding blocked passages and any obstructions that could kink, crimp, twist, or chafe the cable. Figure 9 shows typical routing configurations. If the cable will come into contact with a rough metal opening, use a rubber grommet to prevent damage.
• For antenna mounting locations at the rear of the roof, the antenna cable can be routed into the vehicle through the trunk, as shown in figure 10. Always route the cable under the weather seal near the lowest part of the trunk to help reduce possible water leaks. •...
Reference Taking Care of Your Roady2 (Failure to follow these instructions may result in personal injury or damage to your Roady2 or to your vehicle.) Important: • Use only a soft, dry cloth to clean the outside of your Roady2 and any peripherals.
Troubleshooting Your Roady2 is designed and built to provide you with trouble-free performance without the need for service. If it does not appear to be functioning correctly, please follow these troubleshooting steps: 1. Make sure all connectors are properly attached. 2.
If you see this on the display: NO SIGNAL Cause: The XM signal is being blocked. ANTENNA Cause: The antenna jack that plugs into your Roady2 has probably come loose. OFF AIR Cause: The channel selected is not currently broadcasting. You should: The message should disappear as soon as you move out of an...
If this happens: You do not receive all XM channels you have subscribed to. Cause: Your Roady2 is not activated. The audio sounds distorted The audio level is too low You cannot tune to a channel No song title or artist name displays The audio has static The audio on the XM instant...
Contacting Product Technical Support and Customer Service For additional information in solving problems with your Roady2, contact Delphi at 1.877.GO DELPHI (1.877.463.3574) Monday—Friday. • Customer Service: 8:00 am—4:30 pm Eastern Standard Time • Technical Support: 8:00 am—8:00 pm Eastern Standard Time Customer Service and Technical Support is also available at www.delphi.com.
Radio Products sold by Delphi (“Products”) to be free of defects in material and workmanship, subject to the following conditions. The duration of Delphi’s warranty with respect to Delphi XM Satellite Radio Products is limited to one (1) year from the date of sale to the original consumer purchaser.
How you (the Customer) can get service: To obtain warranty service during the first thirty (30) days after the date of purchase, you must return the defective Product with the original receipt to the original place of purchase. To obtain warranty service during the remainder of the warranty period, you must contact Delphi by phone at 1.877.GO DELPHI (1.877.463.3574).
