Summary of Contents

  • Page 2: Safety, Important Safety Instructions

    - TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. - TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE APPLIANCE TO RAIN OR MOISTURE. The lighting flash with arrowhead symbol within an equilateral triangle is intended to alert the user...

  • Page 3: Table Of Contents

    Safety ...2-3 Important Safety Instructions ...2 Table of Contents ...3 FCC Information...3 Battery/Charger...4 Battery Care ...4 Battery Disposal ...4 Functional Description and Specifications...5 LCD Displays...6 Setting the Clock ...6 PB360S & PB360S-C Controls ...7 Operating Instructions...8-9 Audio Settings ...8 Radio Function ...8 Aux Function ...8 FCC Information NOTE: This equipment has been tested and found to comply...

  • Page 4: Battery/charger, Battery Care, Battery Disposal

    Before using battery charger, read all instructions and cautionary markings on (1) battery charger, (2) battery pack, and (3) product using battery. Use only the charger which accompanied your product or direct replacement as listed in the catalog or this manual.

  • Page 5: Functional Description And Specifications

    Functional Description and Specifications Jobsite Stereo with 4-way outlet AUX 1 LINE Model number PB360S & PB360S-C Voltage rating 120 V Amperes 12 A Compatible batteries BAT607, BAT614, BAT609 & BAT618 Outlets Voltage 120 V Amperes 10 A DC power outlets 60 Hz Voltage Amperes...

  • Page 6: Lcd Displays, Setting The Clock

    11 12 13 1. JAZZ – Illuminates when Jazz is selected in Equalizer. 2. ROCK – Illuminates when Rock is selected in Equalizer. 3. POP – Illuminates when Pop is selected in Equalizer. 4. CLASSICAL – Illuminates when Classical is selected in Equalizer.

  • Page 7: Pb360s & Pb360s-c Controls

    PB360S & PB360S-C Controls – To switch between power-on and standby modes. 2. Volume/Bass Treb – To increase/decrease the audio volume at all modes Volume adjusts from 0-20 (min-max) in one full revolution. Dial spins 360-degrees. 3. Volume/Bass Treb – Adjusts custom Bass and Treble when unit is in “Custom”...

  • Page 8: Operating Instructions, Operating Instructions, Audio Settings, Radio Function, Aux Function

    Operating Instructions Audio Settings VOLUME Your Jobsite Stereo has 20 selectable preset volume settings. To adjust the VOLUME level, turn Volume/Bass/Treb Dial clockwise or counterclockwise to desired volume level. Equalizer Your Jobsite Stereo has 5 selectable preset equalizer settings and custom setting which allow you to custom select the level of Bass and Treble tones.

  • Page 9: Usb Function, Sd/mmc Card Function

    USB Function Your Jobsite Stereo has a powered USB port located inside the Digital Media Bay that can be used to play digital music files from a USB mass storage device as well as charge most USB-enabled devices. USB - PLAYING DIGITAL MUSIC The USB port is designed to work with USB mass storage devices only* and is compatible with mp3 and wma file types.

  • Page 10

    Releasing and Inserting Battery Pack To release or insert the battery pack from radio unit, open the charger door by unlocking the latch. To insert battery, align battery with terminals and slide battery pack onto terminal until it locks into position. Do not force. To release battery, depress battery release button and slide battery of the terminals.

  • Page 11: Important Charging Notes, To Power The Unit, Use Of The Convenient 4-way Outlets

    1. The charger was designed to fast charge the battery only when the battery temperature is between 32˚F (0˚C) and 113˚F (45˚C). If the battery pack is too hot or too cold, the charger will not fast charge the battery. (This may happen if the battery pack is hot from heavy use).

  • Page 12: Use Of 12v Outlet, Changing Fuse, Changing Clock Batteries, Trouble Shooting

    Use of 12V Outlet Note: Do not insert any device that pulls more than 1 Amp or else the fuse will open. 12V outlet will not operate from battery pack. 1. Lift the rubber lid marked with 12V of the jack and insert the plug of the device or the appliance.

  • Page 13: Maintenance, Accessories

    Service NO USER SERVICEABLE PARTS INSIDE. Preventive maintenance performed by unauthorized personnel may result in misplacing of internal wires and components which could cause serious hazard. We recommend that all tool service be performed by a Bosch Factory Service Center or Authorized Bosch Service Station.

  • Page 17

    AUX 1 LINE REPLACE AA BATTERY WHEN UNIT NO LONGER KEEPS CORRECT TIME 120V AC...

  • Page 18

    11 12 13 18 17...

  • Page 21

    AUX 1 LINE...

  • Page 22

    REPLACE AA BATTERY WHEN UNIT NO LONGER KEEPS CORRECT TIME...

  • Page 23

    120V AC...

  • Page 24

    AUX 1 LINE REPLACE AA BATTERY WHEN UNIT NO LONGER KEEPS CORRECT TIME...

  • Page 29

    AUX 1 LINE REPLACE AA BATTERY WHEN UNIT NO LONGER KEEPS CORRECT TIME 120V AC...

  • Page 30

    18 17 11 12 13...

  • Page 33

    AUX 1 LINE...

  • Page 34

    REPLACE AA BATTERY WHEN UNIT NO LONGER KEEPS CORRECT TIME...

  • Page 35

    120V AC...

  • Page 36

    AUX 1 LINE REPLACE AA BATTERY WHEN UNIT NO LONGER KEEPS CORRECT TIME...

  • Page 40

    2610008357 02/10 Printed in China...
