Model No. WESY93190
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal (Under Seat)
QUESTIONS?
As a manufacturer, we are
committed to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
Patent Pending
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
9925
USERÕS MANUAL
Visit our website at: www.weiderfitness.com
Advertisement
Table of Contents
Related Manuals for Weider WESY93190
Summary of Contents for Weider WESY93190
- Page 1 9925 Model No. WESY93190 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (Under Seat) QUESTIONS? As a manufacturer, we are committed to providing complete customer satisfaction. If you have questions, or if there are...
-
Page 2: Table Of Contents
Table of Contents IMPORTANT PRECAUTIONS .............2 BEFORE YOU BEGIN . -
Page 3: Before You Begin
The model number is strength, or improve your cardiovascular system, the WESY93190. The serial number can be found on a WEIDER ¨ 9925 will help you to achieve the specific decal attached to the WEIDER results you want. -
Page 4: Assembly
Assembly Note: This introduction will save you more Identifying Parts time than it takes to read it! To help you identify the small parts used in assem- bly, we have included a PART IDENTIFICATION CHART located in the center of this manual. Place Making Things Easier for Yourself the chart on the floor or work table and use it to Everything in this manual is designed to ensure... - Page 5 FRAME ASSEMBLY 1. Before beginning assembly, be sure that you have read and understand the information in the box above. Locate and open the parts bags labeled ÒFRAME ASSEMBLY BAG ONEÓ and ÒFRAME ASSEMBLY BAG TWO.Ó Press two 2Ó Square Outer Caps (58) onto the indi- cated ends of the Weight Base (14).
- Page 6 3. Press a 2Ó Square Inner Cap (56) into the open end of the Top Frame (2). Press a 2Ó Square Inner Cap (56) into each side of the Butterfly Frame (3). Press two 1Ó Round Inner Caps (70) into the top of the Butterfly Frame.
- Page 7 7. Insert two Weight Guides (23) into one of the brack- ets on the Weight Base (14). Attach the lower ends of the Weight Guides with a 5/16Ó x 6Ó Bolt (67), two 1/2Ó x 3/4Ó Spacers (69), and a 5/16Ó Nylon Locknut (40).
- Page 8 10. Lubricate the insides of the holes in the Top Weights (24) as shown. Slide a Top Weight onto each set of Weight Guides (23). Lubricate 11. Attach the Top Frame (2) to the Ab Upright (1) with two 5/16Ó x 2 3/4Ó Bolts (55), two 5/16Ó Washers (20) and two 5/16Ó...
- Page 9 13. Attach the Leg Press Plate (11) to the Adjustment Tube (10) with a 5/16Ó x 2 1/2Ó Bolt (39), two 5/16Ó Washers (20) and a 5/16Ó Nylon Locknut (40). Make sure the Leg Press Plate and Adjustment Tube are oriented as shown.
- Page 10 17. Attach a Press Arm (7) to one side of the Press Frame (12) with two 5/16Ó x 2 1/2Ó Bolts (39) and two 5/16Ó Nylon Locknuts (40). Attach the other Press Arm (7) to the Press Frame (12) in the same manner. 18.
- Page 11 20. Press a 1 3/4Ó Square Inner Cap (48) into the lower end of the Left Arm (6) and the Right Arm (5). CABLE ASSEMBLY 21. Locate and open the parts bags labeled ÒCABLE ASSEMBLYÓ and ÒPULLEYS.Ó During steps 19 through 50, refer to the CABLE DIA- GRAMS on pages 26 and 27 of this manual to verify proper cable routing.
- Page 12 23. Wrap the Butterfly Cable (89) around a 3 1/2Ó Pulley (82) as shown. Attach the Pulley and two Pulley Covers (94) to the bracket on the Wide Tab Leg Press Upright (4) with a Stress-point 3/8Ó x 2 1/4Ó Bolt (99), a 3/8Ó on Cable Washer (38) and a 3/8Ó...
- Page 13 27. Locate the Rear Cable (87)Ñthis is the shortest Cable. Slide one end of the Rear Cable onto the 5/16Ó x 3Ó Bolt (92). Thread another 5/16Ó Nylon Jam Nut (91) onto the Bolt, but do not fully tighten it. Leave enough room between the two Jam Nuts for the Cable to pivot.
- Page 14 31. Locate the Press Cable (88)Ñthis is the longest Cable. Attach the end of the Press Cable (88) to the Large ÒUÓ Bracket (84) with a 1/4Ó Nylon Locknut (44) and a 1/4Ó Washer (37). Do not completely tighten the Nylon Locknut. It should be threaded onto the end of the Cable so only a couple of threads are showing above the Nylon Locknut, as shown in the inset drawing.
- Page 15 34. Wrap the Press Cable (88) around a 3 1/2Ó Pulley (82) in the direction shown. Attach the Pulley and two Pulley Covers (94) to the lower set of holes in the Pulley Plates (31) with a 3/8Ó x 2 1/4Ó Bolt (99) and a 3/8Ó...
- Page 16 38. Wrap the Press Cable (88) around a 3 1/2Ó Pulley (82) in the direction shown. Attach the Pulley and two Pulley Covers (94) to the indicated hole in the Press Frame (12) with a 3/8Ó x 3 3/4Ó Bolt (76), two 3/8Ó Washers (38) and a 3/8Ó...
- Page 17 42. Remove the 3/8Ó Nylon Locknut (42) from the 3/8Ó x 5Ó Bolt (74) attached in step 40. Wrap the Press Cable (88) around a 3 1/2Ó Pulley (82) in the direction shown. Attach the Pulley and two Pulley Covers (94) to the Leg Press Arm (9) with the 3/8Ó...
- Page 18 46. Locate one of the preassembled pairs of Pulley Plates (31) and remove both 3 1/2Ó Pulleys (82). Route the High Cable (85) around a 3 1/2Ó Pulley (82) in the direction shown. Attach the Pulley and two Pulley Covers (94) to the Pulley Plates (31) with a 3/8Ó...
- Page 19 50. Wrap the Low Cable (86) around a 3 1/2Ó Pulley (82) in the direction shown. Attach the Pulley and two Pulley Covers (94) to the welded tube on the Ab Upright (1) with a 3/8Ó x 3 3/4Ó Bolt (76), a 3/8Ó Washer (38) and a 3/8Ó...
- Page 20 53. Wrap the Low Cable (86) around a 3 1/2Ó Pulley (82) in the direction shown. Attach the Pulley and two Pulley Covers (94) to the indicated hole in the Leg Lever (15) with a 3/8Ó x 3 3/4Ó Bolt (76), two 3/8Ó Washers (38) and a 3/8Ó...
- Page 21 57. Insert a 1/4Ó x 2Ó Carriage Bolt (61) through the cen- ter hole in a Seat Plate (41). Attach the Seat Plate to the Seat (17) with two 1/4Ó x 1/2Ó Screws (59). Insert the 1/4Ó x 2Ó Carriage Bolt (61) through the indi- cated hole in the Rear Seat Frame (16).
-
Page 22: How To Use The Home Gym System
61. Attach a Butterfly Pad (22) to the Left Fly Arm (6) with two 1/4Ó x 2Ó Machine Screws (63). Repeat this step for the Right Fly Arm (5). 62. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in HOW TO USE THE HOME GYM SYSTEM, beginning on page 22 of this manual. - Page 23 ATTACHING THE AB STRAP TO THE AB PULLEY STATION Attach the Lat Bar (36) to the Low Cable (86) at the ab pulley station with a Cable Clip (33). ATTACHING THE LAT BAR OR NYLON STRAP TO THE HIGH PULLEY STATION Attach the Lat Bar (36) to the High Cable (85) with a Cable Clip (33).
-
Page 24: Weight Resistance Chart
USING THE CURL PAD To use the Curl Pad (77), remove the 2Ó Square Inner Cap (56) from the Rear Seat Frame (16) and insert the Curl Post (51) into the Seat Frame. Weight Resistance Chart This chart shows the approximate weight resistance at each weight station. ÒTopÓ refers to the 6.5 lb. top weight. The other numbers refer to the 12.5 lb. -
Page 25: Trouble-Shooting And Maintenance
Trouble-shooting and Maintenance Inspect and tighten all parts each time you use the home gym system. Replace any worn parts immediately. The home gym system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the home gym system, can stretch slightly when it is first used. -
Page 26: Cable Diagrams
Cable Diagrams The cable diagrams on this page and the next page show the proper routing of the High Cable (85), the Low Cable (86), the Rear Cable (87), the Press Cable (88), and the Butterfly Cable (89). Use the diagrams to be sure that the Cables have been assembled correctly. - Page 27 High Cable (85) Rear Cable (87) 1ÑTop Frame High PulleyÑ1 4ÑWeight Stack Weight StackÑ5...
- Page 28 1/2" x 3/4" Spacer (69) 1" x 7/8" Plastic Bushing (54) 1" Round Inner Cap (70) 1 1/8" x 2 1/2" Plastic Bushing (47) 1 1/2" Square Inner Cap (57) 3/4" Round Inner Cap (78) 1" Round Outer Cap (46) 1 3/4"...
- Page 29 1/4" Washer (37) 5/16" x 1" Bolt (97) 5/16" Washer (20) 1" Retainer (45) 3/8" x 2" Bolt (50) 3/8" Washer (38) 5/16" x 2 1/4" Bolt (62) 1/4" Nylon Locknut (44) 5/16" x 2 1/2" Bolt (39) 5/16" Nylon Locknut (40) 5/16"...
- Page 30 1/4" x 2" Machine Screw (63) Cable Clip (33) 1/4" x 2" Carriage Bolt (61) 1/4" x 2 1/2" Machine Screw (64) "V" Pulley (81) (Not shown to scale) 1/4" x 2 1/2" Carriage Bolt (60) 3 1/2" Pulley (82) (Not shown to scale) 5/16"...
- Page 31 Part ListÑModel No. WESY93190 Key No. Qty. Description Key No. Qty. Ab Upright Top Frame Butterfly Frame Leg Press Upright Right Fly Arm Left Fly Arm Press Arm Front Seat Frame Leg Press Arm Adjustment Tube Leg Press Plate Press Frame...
- Page 32 Exploded DrawingÑModel No. WESY93190...
-
Page 33: Ordering Replacement Parts
4. The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING attached at the center of this manual). WEIDER is a registered trademark of ICON Health & Fitness, Inc. Limited Warranty ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and mate- rial, under normal use and service conditions, for a period of ninety (90) days from the date of purchase.
