VTech 2101 User Manual

Vtech communications cordless telephone user's manual 2101.
Hide thumbs

Introduction
Parts Check List:
To purchase replacement batteries,
1.
Handset
2101
call VTech Communications at 1-800-
2.
Base Unit
595-9511. In Canada, call VTech
3.
Telephone line cord
Electronics at 1-800-267-7377.
4.
Battery
5.
Power Adapter
6.
User' s manual
1
I
mportant Safety Instructions
Installing/Replacing the Battery
When using your telephone equipment, basic safety precautions should always be
1. Slide the battery cover off by gently
followed to reduce the risk of fire,electric shock and injury, including the following:
pressing on the recessed area with
1. Read and understand all instructions.
a downward motion.
2. Follow all warnings and instructions marked on the product.
2. Unplug and remove the old battery.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or
Do not dispose of the old battery in a
aerosol cleaners. Use a damp cloth for cleaning.
trash compactor or fire - it could
4. Do not use this product near water (for example, near a bath tub, kitchen sink
explode.
or swimming pool).
5. Do not place this product on an unstable surface, such as a table, shelf or
3. With the red and black wires at the
stand. The product may fall, causing serious damage.
bottom of the battery, angle the top of
6. Slots and openings in the back or bottom of the base unit and handset are
the battery into the compartment,
provided for ventilation. To protect them from overheating, these openings
under the claws. Next, press the
must not be blocked by placing the product on a soft surface such as a bed,
lower end of the battery down, so it
sofa or rug. This product should never be placed near or over a radiator or heat
is held in place by the lower claw.
register. This product should not be placed in any area where proper ventilation
Now, plug the connector into the
is not provided.
socket, located below the battery. Slip
7. This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply in your
the battery wires into the guide,
home, consult your dealer or local power company.
located below and to the left of the
8. Do not allow anything to rest on the power cord. Do not install this product
socket.
where the cord may have anyone walking on it.
4. Replace the battery cover by sliding
9. Never push objects of any kind into this product through slots in the base or
it into place.
handset as they may touch dangerous voltage points or short out parts that
5. The new battery must be charged before using your telephone. Place the
could result in a risk of fire or electric shock. Never spill liquid of any kind on the
handset in the base unit to allow it to charge for over 16 hours. Maximum
product.
battery life between charges is approximately 3.75 hours of talk time or 3.75
10. To reduce the risk of electric shock, do not disassemble this product, but take
it to an authorized service facility. Opening or removing parts of the base or
days of standby.
handset other than specified access doors may expose you to dangerous
CAUTION: To reduce the risk of fire or injury, read and follow these instructions:
voltages or other risks. Incorrect reassembling can cause electric shock when
the product is subsequently used.
1. Use only the VTech battery supplied, or equivalent.
11. Do not overload wall outlets and extension cords as this can result in the risk of
2. Do not open or mutilate the battery. Released electrolyte is corrosive and
fire or electric shock.
may cause damage to the eyes or skin. It may be toxic if swallowed.
12. Unplug this product from the wall outlet and refer servicing to an authorized
3. Exercise care in handling batteries in order not to short the battery with
service facility under the following conditions:
conducting materials such as rings, bracelets, and keys. The battery or
A. When the power supply cord or plug is damaged or frayed.
conductor may overheat and cause burns.
B. If liquid has been spilled onto the product.
4. Do not dispose of the battery in a fire. The cell may explode.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as improper adjustment of other controls may result in
damage and often requires extensive work by an authorized technician
to restore the product to normal operation.
E. If the product has been dropped and the base and/or handset has been
damaged.
F. If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than cordless) during an electrical storm. There
is a remote risk of electric shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
15. Only put the handset of your telephone next to your ear when it is in normal talk
mode.
2
3
OFF KEY
Press the OFF key to exit all
modes of operation.
REDIAL / PAUSE KEY
When you hear the dial tone, press
REDIAL to call the last number
dialed on your phone.
It can also be used to store the
last number dialed into speed dial
memory. See Storing a Redial
Number into Speed Dial for
ON LED
details.
Lit when the handset is on an
You can store pauses into your
active call.
speed dial numbers. See Storing
Setting Up Your 2101
Flashes in unison with an incoming
Pauses in Memory for details.
1. Choose an area near an electrical outlet and a telephone wall jack.
ring.
CHAN KEY
2. Plug the AC power adapter into an electrical outlet and the DC connector to
Flashes quickly during program-
Pressing the CHAN key when the
the power jack on the bottom of the base unit. Insert the cord in the channel
ming mode.
handset is in use will activate a
guide.
Flashes slowly when the battery
channel change to the next free
CAUTION: Use only the AC adapter shipped with your 2101. It is specifically
is low.
channel.
designed for this product.
Illuminates steadily when the
This is used if you are
NOTE:
Connect power to the base unit before placing the handset in the
handset is charging in the base.
experiencing noise or interference
cradle.
on the current channel.
3. CHARGE THE HANDSET BATTERY BEFORE USE. The battery recharge
ON/ FLASH KEY
automatically whenever the handset is in the base unit cradle. The battery
Press the ON key to make a call.
MEM/PROG KEY
must be charged for 15 hours before using your phone for the first time.
If you are currently on a call, and
Press the MEM key to enter
4. Connect the telephone line cord. Insert one end of the telephone line cord into
hear a call waiting tone, press ON
MEMORY mode.
the phone jack on the bottom of the base unit. Plug the other end into a
to switch to the second call.
The sequence for dialing out a
telephone wall jack. Make sure the plugs snap securely into place. Insert
Press ON again to return to the
speed dial number in memory is:
the cord in the channel guide.
original call.
ON, MEM, number button (0-9).
5. CHECK FOR A DIAL TONE. After the battery is charged, pick up the
Press MEM/PROG to enter
handset and press the ON key. You should hear a dial tone. If not, see IN
VOLUME CONTROL
programming
mode.
See
CASE OF DIFFICULTY.
Adjusts the volume of what you
Programming Speed Dial
hear through the handset.
Numbers for more details.
While on a call, press the
or
TONE/ * KEY
key to adjust the listening
In PULSE dialing mode, this key
volume. The handset will emit a
is used to switch to temporary
double beep when the maximum
TONE dialing mode.
or minimum volume level has been
reached.
4
5
t2101Eng.p65
1
2004/12/29, ¤W¤È 10:54
