Universal Security Instruments 3304 Instructions Manual

Smoke & fire alarm with silence feature and alarm origination feature
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SECURITY INSTRUMENTS, INC.
SMOKE & FIRE ALARM WITH SILENCE FEATURE
Smoke Alarm Limitations and Functions ................................. 2
Recommended Location of Alarms ......................................... 3
Avoid These Locations ........................................................... 4
Early Warning ......................................................................... 4
Installation Instructions ........................................................... 4
Electrical Shock Hazard ......................................................... 4
Locking/Tamper Feature ......................................................... 4
Wiring Instructions .................................................................. 5
Operation, Testing & Maintenance .......................................... 6
Cautions/Warnings ................................................................. 7
Backup Battery Replacement ................................................. 7
Develop and Practice a Plan of Escape .................................. 8
Operational Summary ............................................................. 9
Warranty ................................................................. Back Cover
MODEL 3304, 3304L
MODEL 3895, 3895L
AND ALARM ORIGINATION FEATURE
READ ALL INSTRUCTIONS

Table of Contents:

®
Page #

Advertisement

Table of Contents
loading

Related Manuals for Universal Security Instruments 3304

Summary of Contents for Universal Security Instruments 3304

  • Page 1: Table Of Contents

    ® Cautions/Warnings ... 7 Backup Battery Replacement ... 7 Develop and Practice a Plan of Escape ... 8 Operational Summary ... 9 Warranty ... Back Cover MODEL 3304, 3304L MODEL 3895, 3895L READ ALL INSTRUCTIONS Table of Contents: Page #...

  • Page 2: Smoke Alarm Limitations And Functions

    SMOKE ALARM LIMITATIONS AND FUNCTIONS There are three basic smoke alarm types: IoPhic , Ionization and Photoelectric.  ® IoPhic is an ionization alarm containing a patent-pending Universal Smoke Sensing Technology. ® IoPhic alarms are very effective at detecting fast flaming fires and also respond very quickly to slow smoldering fires - up to 87% faster than the maximum allowable alarm limit (UL217 Smoldering Smoke Test on 5/26/2010, Underwriters Laboratories Project #09CA38078).

  • Page 3: Recommended Location Of Alarms

    RECOMMENDED LOCATION OF ALARMS • Locate the first smoke alarm in the immediate area of the bedrooms. Try to protect the escape route as the bedrooms are usually farthest from an exit. If more than one sleeping area exists, locate additional smoke alarms in each sleeping area. If a hall is more than 40 feet (12 meters) long, install a smoke alarm at each end.

  • Page 4: Avoid These Locations

    • the garage – products of combustion are produced when you start your vehicle. • near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces, gas hot water heaters). Use smoke alarms with photoelectric sensors or smoke alarms with Silence Feature for these areas.

  • Page 5: Wiring Instructions

    Insert the pin into the hole for the feature you are activating. Refer to the diagram below for correct placement. INSERT ALARM LOCKING PIN HERE TO DEACTIVATE THE LOCKING FEATURES: To remove the smoke alarm for cleaning or servicing or to replace the battery, you must first remove the appropriate locking pin, if it has been installed. Turn off AC power to the circuit.

  • Page 6: Operation, Testing & Maintenance

    The yellow wire is used only for multiple station operation with USI ELECTRIC or UNIVERSAL Model alarms only. Connecting this yellow wire to any other circuits may result in damage and smoke alarm malfunction. When alarms are interconnected, all smoke alarms must be powered from a single AC branch circuit.

  • Page 7: Quick Find Alarm Originating Feature & Reset

    Interconnected alarms will sound and then stop. The originating smoke alarm will continue to sound 60 seconds to allow ample time to quickly find originating alarm. RESET: To reset the QUICK FIND on any alarm for at least 10 seconds and then release. Reset after each alarm. The reset feature will reset all interconnected units.

  • Page 8: Develop And Practice A Plan Of Escape

    OPTIONAL BATTERY DRAWER TAMPER LOCKING PIN: To make your battery drawer tamper resistant, a locking pin has been provided (breakaway part on mounting bracket). NOTE: If this feature has been activated, you will need to deactivate it by removing the battery drawer tamper pin located at side of battery drawer.

  • Page 9: Operational Summary

    CONDITION OF ALARM AUDIBLE & VISUAL SIGNALS BEFORE SOLUTION / RECOMMENDATION HORN RED LED Silent Blinks On once approx every 40-45 seconds Silent Blinks On once approx every 40-45 seconds Horn does not Blinks On once sound when other approx every alarms are active 40-45 seconds or horn does not...

  • Page 10: Warranty

    USI ELECTRIC, INC./UNIVERSAL SECURITY INSTRUMENTS, INC. ("USI") warrants your USI product to be free from defects in material and workmanship for a period of five (5) years from the date of purchase. This warranty shall not apply to any batteries used in the product or to any damage which may be caused by such batteries.
