Model WG-2424G
Do not store gasoline or other flammable liquids
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read the installation, operating and mainte-
nance instructions thoroughly before installing or servicing this equipment.
The purchaser of this equipment must post in a prominent location instructions to be followed in the
event the user smells gas. This information shall be obtained by consulting the local gas supplier.
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
45324
p/n
Rev. D
ECN-13352
2 ERIK CIRCLE, P. O. Box 280 Verdi, NV 89439
FOR YOUR SAFETY
in the vicinity of this or any other appliance.
WARNING:
IMPORTANT:
IMPORTANT: DO NOT DISCARD THIS MANUAL
PRINTED IN UNITED STATES OF AMERICA
WELLS BLOOMFIELD, LLC
telephone: 775-689-5703
fax: 775-689-5976
www.wellsbloomfield.com
OPERATION MANUAL
COUNTERTOP
GAS
GRIDDLES
MODELS
WG-2424G
WG-2436G
WG-3036G
WG-3048G
Includes
INSTALLATION
USE & CARE
07
M225
1018 cps
121
Advertisement
Table of Contents
Related Manuals for Wells WG-2424G
Summary of Contents for Wells WG-2424G
- Page 1 Model WG-2424G Do not store gasoline or other flammable liquids in the vicinity of this or any other appliance. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and mainte- nance instructions thoroughly before installing or servicing this equipment.
-
Page 2: Limited Warranty Statement
Unless otherwise specified, all commercial cooking equipment manufactured by WELLS BLOOMFIELD, LLC is warranted against defects in materials and workmanship for a period of one year from the date of original installation or 18 months from the date of shipment from our factory, whichever comes first, and is for the benefit of the original purchaser only. -
Page 3: Specifications
This manual contains the information needed to properly install this appliance, and to use and care for the appliance in a manner which will ensure its optimum performance. COOKING MODEL SURFACE 23 7/8” x 20 1/2” WG-2424G 2 BURNER 35 7/8” x 20 1/2” WG-2436G 3 BURNER 35 7/8” x 24”... -
Page 4: Features & Operating Controls
FEATURES & OPERATING CONTROLS GREASE TROUGH GREASE DRAWER FRONT ACCESS PANEL GAS SAFETY VALVE THERMOSTAT ADJUSTABLE LEGS Fig. 1 Countertop Gas Griddle - Features & Operating Controls FRONT ACCESS PANEL THERMOSTAT TEMP. CONTROL KNOB GAS SAFETY VALVE GAS CONTROL VALVE GREASE TROUGH GREASE DRAWER REMOVABLE SPLASH... -
Page 5: Precautions And General Information
This appliance is intended for use in commercial establishments only. This appliance is intended to prepare food for human consumption. No other use is recommended or authorized by the manufacturer or its agents. This griddle must be installed by a technician qualified and certified or licensed to install gas-fired equipment. -
Page 6: Installation
INSTALLATION NOTE: DO NOT discard the carton or other packing materials until you have inspected the appliance for hidden damage and tested it for proper operation. Refer to SHIPPING DAMAGE CLAIM PROCEDURE on the inside front cover of this manual. DANGER: HEALTH HAZARD... - Page 7 GAS APPLIANCE CODE COMPLIANCE The installation of gas piping from the outlet side of the gas meter or service regulator to the griddle must be performed by a technician qualified and certified or licensed to install gas-fired equipment. A licensed and qualified technician must perform the initial startup and adjustment of this appliance.
- Page 8 INSTALLATION (continued) DANGER: FIRE AND EXPLOSION HAZARD NEVER use an open flame to check for gas leaks. Fire and explosion may result. IMPORTANT: All pipe joints must be checked for leaks before lighting. Leak checks should be performed with a soap and water solution. WARNING: FIRE HAZARD This griddle is supplied with a...
-
Page 9: Gas Pipe Pressure Testing
GAS PIPE PRESSURE TESTING The main piping system must be capable of supplying the griddle with sufficient volume/flow of fuel to satisfy the maximum operational input requirements. Make sure the supply piping system has been pressure tested before the regulator and griddle are connected. If the system must be re-tested, be sure the regulator is isolated by a manual shut-off valve, in order to prevent damage to the regulator and gas griddle valves. -
Page 10: Initial Adjustment
INITIAL ADJUSTMENT IMPORTANT: PRESSURE ADJUSTMENT MUST BE PERFORMED BY A QUALIFIED TECHNICIAN ONLY. Fig. 3 Adjust gas pressure IMPORTANT: FLAME ADJUSTMENT MUST BE PERFORMED BY A QUALIFIED TECHNICIAN ONLY. 3/8“ to 1/2” THERMOCOUPLE Fig. 4 Adjust pilot flame IMPORTANT: FLAME ADJUSTMENT MUST BE PERFORMED BY A QUALIFIED TECHNICIAN ONLY. -
Page 11: Chrome Plated Griddles
PREPARING THE GRIDDLE SURFACE SEASONING STANDARD GRIDDLES As manufactured, the steel surface of your Wells griddle has microscopic pores. It is important to fill these pores with oil in order to provide a hard, non-stick cooking surface. a. Preheat the griddle surface to 375ºF (191ºC). b. -
Page 12: Operation
OPERATION WARNING: FIRE HAZARD IF YOU SMELL GAS: ¤ DO NOT try to light any appliance. ¤ DO NOT touch any electrical switch ¤ DO NOT use any telephone in your building. In the event a gas odor is detected, shut down the unit at the main gas shut- off valve and contact your local gas supplier from a... -
Page 13: Using The Griddle
USING THE GRIDDLE Check the chart below for recommended cooking temperatures. Turn temperature control knob to the desired temperature. For standard griddles: • Keep the griddle surface clean and well oiled during use. • Scrape cooking waste into the grease trough frequently during use. •... -
Page 14: Cleaning Instructions - Standard And Grooved Griddles
CLEANING INSTRUCTIONS - STANDARD AND GROOVED GRIDDLES CAUTION: BURN HAZARD Griddle will be hot during portions of this cleaning procedure. Always heat-protective gloves and apron. IMPORTANT: DO NOT spill or pour water into controls, control panel or wiring. DO NOT allow main or pilot burners to get wet. - Page 15 CLEANING INSTRUCTIONS - CHROME PLATED GRIDDLES PREPARATION Set temperature control to 220ºF. Allow griddle temperature to drop to 220ºF before proceeding. FREQUENCY Daily TOOLS 4” Razor-Style Scraper, Soft Bristle Brush Mild Detergent, Non-Abrasive Cleanser Clean Soft Cloth / Sponge CLEANING Pour a small amount of water on the griddle surface and let it “sizzle”.
-
Page 16: Troubleshooting
TROUBLESHOOTING DESCRIPTION Gas supply off Air in lines Pilot will not light Pilot valve not on or not depressed Pilot light not lit Burners won’t light Control not on Water in burner Individual burner won’t light Damaged temperature control, burner or other internal component Temperature control not set Shutter or nozzle out of adjustment Burner not hot enough... -
Page 17: Customer Service Data
DESCRIPTION LEGS, 4”, METAL, SET OF 4 SCRAPER, GROOVED GRIDDLE CUSTOMER SERVICE DATA please have this information available if calling for service RESTAURANT _____________________________ LOCATION _____________ INSTALLATION DATE ________________________ TECHNICIAN ___________ SERVICE COMPANY ________________________________________________ ADDRESS ___________________________ STATE ______ ZIP__________ TELEPHONE NUMBER (_____)_____-_________ EQUIPMENT MODEL NO. - Page 18 Commercial Food Equipment Service Association Wells Bloomfield proudly supports CFESA Commercial Food Equipment Service Association SERVICE TRAINING - QUALITY SERVICE SERVICE TRAINING - QUALITY SERVICE Genuine Parts Protect - YOU - All - Ways CUSTOMER SATISFACTION CUSTOMER SATISFACTION WELLS BLOOMFIELD, LLC 2 ERIK CIRCLE, P.
