Operator's Manual

SNOW THROWER

MODEL
13045
Polar Blast
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
WARNING:
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local
or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the
above is required by law (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on
federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service
department, P.O. Box 361131 Cleveland, Ohio 44136-0019.
TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
. 769-00381A.fm
FORM NO
PRINTED IN U.S.A.
(6/2003)

Advertisement

Table of Contents
loading

Summary of Contents for Troy-Bilt 13045

  • Page 1: Snow Thrower

    A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019. TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 . 769-00381A.fm FORM NO PRINTED IN U.S.A.
  • Page 2: Table Of Contents

    A sample model plate is explained below. For future reference, please copy the model number and the serial number of the equipment in the space below. (Model Number) (Serial Number) TROY-BILT LLC P. O. BOX 3 6 1 1 3 1 www.troybilt.com CLEVELAND, OH 44136...
  • Page 3: Important Safe Operation Practices

    SECTION 1: IMPORTANT SAFE OPERATION PRACTICES This symbol points out important safety instructions, which if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury.
  • Page 4: Maintenance And Storage

    Never operate with a missing or damaged discharge chute. Keep all safety devices in place and working. Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon monoxide, an odorless and deadly gas. Do not operate machine while under the influence of alcohol or drugs.
  • Page 5: Assembling Your Snow Thrower

    SECTION 2: ASSEMBLING YOUR SNOW THROWER NOTE: All references to right or left side of the snow thrower are determined from behind the unit in the operating position. The “operator’s position” is defined as standing directly behind the snow thrower, facing the handle panel.
  • Page 6 NOTE: If the connector is not properly assembled, the shift rod will pivot and you will not be able to change speeds or change directions. Attaching Chute Assembly • Place chute assembly over chute opening, with the opening in the chute assembly facing the front of the unit.
  • Page 7: Know Your Snow Thrower

    Connecting Alternator Lead • Unwrap the headlight wire which is attached to the headlights, beneath the handle panel. Wind the wire around the lower right handle until excess slack is removed. • Plug the wire from the headlight into the alternator lead located on the right side of the engine, beneath the fuel tank.
  • Page 8: Operating Your Snow Thrower

    Shift Lever The shift lever is located in the center of the handle panel and is used to determine ground speed and direction of travel. It can be moved into any of eight positions. See Figure 8. Always release traction the control before IMPORTANT: changing speeds.
  • Page 9 WARNING: Use extreme care when handling gasoline. Gasoline is extremely flammable and the vapors are explosive. Never fuel machine indoors or while the engine cigarettes, cigars, pipes and other sources of ignition. • A plastic cap is provided inside the fuel fill opening on the fuel tank.
  • Page 10 Recoil Starter • With engine running, pull starter rope with a rapid, continuous full arm stroke three or four times. Pulling the starter rope will produce a loud clattering sound, which is not harmful to the engine or starter. • Move throttle control to “stop”...
  • Page 11: Making Adjustments

    NEVER move the shift lever without first IMPORTANT: releasing the traction control. Doing so will cause premature wear to the drive system’s friction wheel. Wheel Steering Controls The left and right wheel steering controls are located on the underside of the handles. •...
  • Page 12 • With the traction control released, make sure there is clearance between the friction wheel and the drive plate in all positions of the shift lever. • With the traction control lever engaged, make sure the friction wheel solidly contacts the drive plate. See Figure 11.
  • Page 13: Maintaining Your Snow Thrower

    Adjust skid shoes as follows: • Loosen, but do not remove, the three hex nuts which fasten the skid shoe to the auger housing. • Raise or lower the skid shoe to desired position. • Retighten the hex nuts loosened earlier. •...
  • Page 14 To relieve pressure, always remove the IMPORTANT: vent plug before lubricating the gear case. See Figure 14. Failure to do so could result in damage to the gear case seals. Vent Plug Grease Fitting Bearings Shear Bolt Shear Bolt Figure 14 Discharge Chute The base of the discharge chute and the spirals on the chute crank should be lubricated at least every 25...
  • Page 15: Service

    SECTION 7: SERVICING YOUR SNOW THROWER WARNING: Before servicing, repairing, or inspecting, disengage all clutch levers and stop engine. Wait until all moving parts have come to a complete stop. Disconnect spark plug wire and ground it against the engine to prevent unintended starting.
  • Page 16 • Remove the large shoulder bolt and washer on the left hand side of the engine pulley. See Figure 19. Engine Pulley Shoulder Bolt Figure 19 Auger Belt • Remove the cotter pin and washer from the ferrule in order to disconnect the auger idler rod from the brake bracket assembly.
  • Page 17 • Replace belt and reassemble in reverse order. • Reassemble the two halves of the unit hooking the lower portion of the auger housing over the stationary shoulder bolts in the frame assembly. • Secure the two halves with the two bolts and lock washers removed earlier.
  • Page 18: Troubleshooting

    Auger control cable in need of adjustment. Auger belt loose or damaged. Shear bolt(s) sheared. NOTE: For repairs beyond the minor adjustments listed above, contact an authorized Troy-Bilt service dealer. • Always store the snow thrower in a clean, dry area.
  • Page 19: Parts List

    SECTION 9: PARTS LIST FOR MODEL 13045 Ref. 710-0276 710-0458 710-0805 710-0895 710-3015 712-0429 712-3027 731-0846C 731-0851A 731-1313C 731-0903D 784-5680 736-0159 736-0231 736-0506 746-0902 746-0903 784-5594 784-5604 684-0102 710-0459A 710-0599 711-0653 712-0116 784-5682 714-0104 732-0145 732-0193 732-0746 735-0199A 736-0105 784-5681...
  • Page 20 Model 13045 REAR VIEW 34 26 32...
  • Page 21 Model 13045 Ref. Part No. Part Description 05244A Bearing Housing 618-0281A Auger Brake Bracket Assembly 684-0090A 16” Impeller Assembly 710-0371 Hex Lock Bolt 5/16-18 x.875” 710-0451 Carriage Bolt 5/16-18 x .750” 710-0459A Hex Screw, Special 3/8-24 x 1.5” 710-0528 Hex Screw 5/16-18 x 1.25”...
  • Page 22 Model 13045 27 75...
  • Page 23 Model 13045 Ref. Part No. Part Description 741-0225 Hex Flange Bearing 750-1302A Spacer,.6725 x 1.125 x 2.485 618-0279 Dogg Assembly LH 618-0280 Dogg Assembly RH 618-0282D Shaft Assembly 618-0296A Friction Wheel Assembly 684-0162 Support Bracket Assembly 684-0161 Shift Arm Assembly...
  • Page 24 Model 13045 21 13 22 11...
  • Page 25 Model 13045 Ref. Part No. Part Description 646-0012 Auger/Drive Cable Assembly 684-0053B Lower Chute Crank Assembly 705-5266 Chute Crank Bracket 710-1879 Hex Screw, 3/8-16 x.88” 710-1878 Hex Screw, 3/8-16 x 1.75” 710-0458 Carriage Bolt 5/16-18 x 1.75” 710-0572 Carriage Bolt 5/16-18 x 2.5”...
  • Page 26 Model 13045 6 15 Ref. Part No. 07386 Washer 684-0123A Belt Cover Bracket Assembly 710-0191 Hex Screw 3/8-24 x 1.25” 710-0237 Hex Screw 5/16-24 x .625” 710-0502A Self-tapping Sems Screw 710-0607 TT Screw 5/16-18 x 0.5” 710-1245B Hex Lock Screw 5/16-24 x 1.25”...
  • Page 27 Model 13045 Ref. NOTE: When rebuilding a gearbox assembly, include 3 oz. of Shell Alvania EP Lead-Free Grease (Part No. 737-0168). Part No. Description 618-0246 Housing Assembly, RH 618-0435 Housing Assembly, LH 710-1260A Screw, 5/16-18 x 0.75 738-0492 Spiral Axle...
  • Page 28 MANUFACTURER’S LIMITED WARRANTY FOR: The limited warranty set forth below is given by Troy-Bilt LLC with respect to new merchandise purchased and used in the United States, its possessions and territories. “Troy-Bilt” warrants this product against defects in material and workmanship for a period of two (2) years commencing...
