Chapter 1. Introduction

Thank you for choosing the TD-8840 ADSL2+ Modem Router.

1.1 Product Overview

With the excellent circuit design and high quality production, we guarantee the ADSL2+ Modem
Router's high performance, great stability and easy to use.
The TD-8840 uses integrated ADSL2+ transceiver. The AFE supports full-rate ADSL connectivity
conforming to the ITU and ANSI specifications.
In addition to the basic DMT physical layer functions, the ADSL PHY supports dual latency ADSL
framing (fast and interleaved) and the I.432 ATM Physical Layer.
The TD-8840 is a complete plug-and-play solution. With standard Ethernet interface, it can be
directly connected to any 10M/100M Ethernet devices, and support Auto-MDIX.
The TD-8840 uses not only html (web mode through Ethernet port) but also external utility
software to configure the Router. You can download it from our website (http://www.tp-link.com).

1.2 Conventions

The Router or TD-8840, or device mentioned in this User guide stands for TD-8840 ADSL2+
Modem Router without any explanations.
Parameters provided in the pictures are just references for setting up the product, which may
differ from the actual situation.
You can set the parameters according to your demand.
Note:
The two devices of TD-8840 and TD-8840B are sharing this User Guide. For simplicity, we will
take TD-8840 for example throughout this Guide.

1.3 Main Features

High speed and asymmetry data transmit mode, built-in 4-port switch realize multi-user to
share wide-band internet access
Supports All ADSL2+ industrial standards
Compatible with all mainstream DSLAM (CO)
Firmware upgradeable
Provides integrated access of internet and route function which face to SOHO user
