KDL-20G30xx
© 2007 Sony Corporation
LCD Digital Colour TV
Operating Instructions
Before operating the TV, please read the "Safety information"
section of this manual. Retain this manual for future reference.
Инструкция по эксплуатации
Перед включением телевизора прочтите раздел "Сведения
по безопасности" этого руководства. Сохраняйте данное
руководство для справок в будущем.
For useful information about Sony products
Для получения полезной информации о продукции Сони
3-276-846-41(0)
K
GB
RU

Advertisement

Table of Contents
loading

Related Manuals for Sony KDL-20G30xx

Summary of Contents for Sony KDL-20G30xx

  • Page 1 Retain this manual for future reference. Инструкция по эксплуатации Перед включением телевизора прочтите раздел “Сведения по безопасности” этого руководства. Сохраняйте данное руководство для справок в будущем. For useful information about Sony products Для получения полезной информации о продукции Сони 3-276-846-41(0)

  • Page 2: Disposal Of The Tv Set

    • Some Digital TV functions may not be available in some countries. The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-0075 Japan. The Authorized Representative for EMC and product safety is Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany.

  • Page 3: Table Of Contents

    Table of Contents Start-up Guide Start-up Guide 4 Safety information ...8 Precautions ...9 Overview of the remote ...10 Overview of the TV buttons and indicators ...11 Watching TV Watching TV...12 Checking the Digital Electronic Programme Guide (EPG) Using the Digital Favourite list Using Optional Equipment Connecting optional equipment...17 Viewing pictures from connected equipment ...18...

  • Page 4: Start-Up Guide

    Start-up Guide 1: Checking the accessories Remote RM-ED005 (1) Size AA batteries (R6 type) (2) Support belt (1) and screws (2) Stand (1) Screws for stand (2) Hole Masks (2) To insert batteries into the remote Push and lift the cover to open. •...
  • Page 5 Place the TV set on the stand. Take care not to interfere with cables. Check the stopper to make sure the TV set is correctly fixed to the stand. Stopper Take out the screws from the accessory bag. Fix the TV to the stand using the supplied screws.
  • Page 6 4: Preventing the TV from toppling over 5: Bundling the cables 6: Selecting the language, country/region and location Connect the TV to your mains socket (220-240V AC, 50Hz). Press 1 on the TV. When you switch on the TV for the first time, the Language menu appears on the screen.

  • Page 7: Auto-Tuning The Tv

    Press to select the country/region in which you will operate the TV, then press Auto Start Up Language Country Location Back: Confirm: Select: If the country/region in which you want to use the TV does not appear in the list, select “-” instead of a country/region.

  • Page 8: Safety Information

    • Never cover the ventilation holes or insert anything in the cabinet. • Leave space around the TV set as shown below. • It is strongly recommended that you use a Sony wall- mount bracket in order to provide adequate air-circulation. Installed on the wall...

  • Page 9: Precautions

    If the following problems occur... Turn off the TV set and unplug the mains lead immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. When: – Mains lead is damaged.

  • Page 10: Overview Of The Remote

    Overview of the remote 1 "/1 – TV standby Turns the TV on and off from standby mode. 2 A/B – Dual Sound (page 22) 3 Coloured buttons (page 13, 14, 16) – Info / Text reveal • In digital mode: Displays brief details of the programme currently being watched.

  • Page 11: Overview Of The Tv Buttons And Indicators

    Overview of the TV buttons and indicators (page 19) – Input select / OK • In TV mode: Selects the input source from equipment connected to the TV sockets (page 18). • In TV menu: Selects the menu or option, and confirms the setting.

  • Page 12: Watching Tv

    Watching TV Watching TV Press 1 on the TV to switch on the TV. When the TV is in standby mode (the 1 (standby) indicator on the TV (front) is red), press "/1 on the remote to switch on the TV. Press DIGITAL to switch to digital mode or ANALOG to switch to analogue mode.
  • Page 13 To access Text Press /. Each time you press /, the display changes cyclically as follows: Text t Text over the TV picture (mix mode) t No Text (exit the Text service) To select a page, press the number buttons or PROG +/-.

  • Page 14: Checking The Digital Electronic Programme Guide (Epg)

    Checking the Digital Electronic Programme Guide (EPG) All Categories Select: +/- 1 day on/off: Options: Digital Electronic Programme Guide (EPG) * This function may not be available in some countries/regions. Watch a programme Turn off the EPG Sort the programme information by category –...
  • Page 15 Set the time and date of a programme you want to record – Manual timer REC Cancel a recording/reminder – Timer list • You can set VCR timer recording on the TV only for SmartLink compatible VCRs. If your VCR is not SmartLink compatible, a message will be displayed to remind you to set your VCR timer.

  • Page 16: Using The Digital Favourite List

    Using the Digital Favourite list Favourite Set-up Enter Programme number Favourites 1 SETenVEO Tienda en VEO 3/24 NET TV K3/300 CUATRO TVE 1 CNN+ TVE 2 40 LATINO 24H TVE la Sexta CLAN TVE Telecinco TELEDEPORTE T5 Estrellas T5 Sport Favourites 2 Store favourite: Back:...

  • Page 17: Using Optional Equipment

    Using Optional Equipment Connecting optional equipment You can connect a wide range of optional equipment to your TV. Connecting cables are not supplied. Video game equipment DVD player Decoder DVD recorder Decoder DVD player with component output CAM card For service use only S VHS/Hi8/ camcorder...

  • Page 18: Viewing Pictures From Connected Equipment

    Viewing pictures from connected equipment Switch on the connected equipment, then perform one of the following operation. For equipment connected to the scart sockets using a fully-wired 21-pin scart lead Start playback on the connected equipment. The picture from the connected equipment appears on the screen.

  • Page 19: Using Menu Functions

    Using MENU Functions Navigating through menus “MENU” allows you to enjoy various convenient features of this TV. You can easily select channels or inputs sources and change the settings for your TV. Press MENU. Press to select an option, then press To exit the menu, press MENU.

  • Page 20: Picture Adjustment Menu

    “Standard”: For standard picture. Recommended for home entertainment. “Cinema”: For viewing film-based content. Most suitable for viewing in a theatre- like environment. This picture setting was developed in collaboration with Sony Pictures Entertainment to faithfully reproduce movies as intended by their creators.
  • Page 21 Adv. Contrast Automatically adjusts “Backlight” and “Contrast” to the most suitable settings judging from the brightness of the screen. This setting is especially effective for dark Enhancer images scenes. It will increase the contrast distinction of the darker picture scenes. Reset Resets all picture settings except “Picture Mode”...

  • Page 22: Sound Adjustment Menu

    Sound Adjustment menu Sound Adjustment Sound Effect Treble Bass Balance Reset Dual Sound Auto Volume Back: Select: Enter: Sound Effect Selects the sound mode. “ Sound System.” “Dynamic”: Intensifies clarity and sound presence for better intelligibility and musical realism by using the “BBE High definition Sound System.” “BBE ViVA”: BBE ViVA Sound provides musically accurate natural 3D image with Hi-Fi sound.

  • Page 23: Features Menu

    Features menu Features Power Saving AV2 Output RGB Centre Timer Back: Select: Enter: Power Saving Selects the power saving mode to reduce the power consumption of the TV. “Standard”: Default settings. “Reduce”: Reduces the power consumption of the TV. “Picture Off”: Switches off the picture. You can listen to the sound with the picture off.

  • Page 24: Set-Up Menu

    Set-up menu Set-up Auto Start Up Language Auto Tuning Programme Sorting AV Preset Sound Offset Manual Programme Preset Digital Set-up Back: Select: Enter: Auto Start Up Starts the “first time operation menu” to select the language, country/region and location, and tune in all available digital and analogue channels. Usually, you do not need to do this operation because the language and country/region will have been selected and channels already tuned when the TV was first installed (page 7).
  • Page 25 Sound Offset Sets an independent volume level to each equipment connected to the TV. Manual Programme Before selecting “Label”/“AFT”/“Audio Filter”/“Skip”/“Decoder”, press select the programme number you want to modify. Then, press Preset System Presets programme channels manually. Press Press press B/G: For western European countries/regions D/K: For eastern European countries/regions L: For France...
  • Page 26 Audio Filter Improves the sound for individual channels in the case of distortion in mono broadcasts. Sometimes a non-standard broadcast signal can cause sound distortion or intermittent sound muting when watching mono programmes. If you do not experience any sound distortion, we recommend that you leave this option set to the factory setting “Off”.

  • Page 27: Digital Set-Up Menu

    Digital Set-up menu Set-up Auto Start Up Language English Auto Tuning Programme Sorting AV Preset Sound Offset Manual Programme Preset Digital Set-up Back: Select: Enter: Digital Tuning Digital Auto Tuning Tunes in the available digital channels. This option allows you to retune the TV after moving house, or to search for new channels that have been launched by broadcasters).
  • Page 28 “Software Download”: Enables the TV to automatically receive software updates, free through your existing aerial (when issued). Sony recommends that this option is set to “On” at all times. If you do not want your software to be updated, set this option to “Off”.

  • Page 29: Additional Information

    Additional Information Specifications Display Unit Power Requirements: 220–240 V AC, 50 Hz Screen Size: 20 inches Display Resolution: 640 dots (horizontal) × 480 lines (vertical) Power Consumption: 50 W or less Standby Power Consumption*: 0,7 W or less * Specified standby power is reached after the TV finishes necessary internal processes.

  • Page 30: Troubleshooting

    Press 1 on the TV to turn it off, disconnect the mains lead, and inform your dealer or Sony service centre of how the indicator flashes (number of flashes). When it is not flashing Check the items in the tables below.
  • Page 32 Factory: Sony Spain S.A. Pol. Ind. Can Mitjans s/n 08232 Viladecavalls (Barcelona) Spain Sony Slovakia, spol. sr. o., Trnava Plant Trstínska cesta 8 917 58 Trnava Slovak Republic • Все функции, относящиеся к Цифровому ТВ ( будут действовать только в тех странах или регионах, в...
