Power Light
The Power light displays the Router's current status. If the Power light glows
steadily green, the Router is receiving power and fully operational. When the
Power light flashes rapidly, the Router is initializing. If the Power light is not illu-
minated or glows red when the Power cord is plugged in and the Power switch is
turned on, the Router has suffered a critical error and technical support should
be contacted.
Broadband Light
The Broadband light illuminates when the Router is connected to a the Internet
via Ethernet. If flashing, data traffic is passing across the port.
Internet Light
When the Internet light glows steadily green, the Router is connected to the
ISP
(Internet Service Provider). If it glows amber, there is a physical connection to
the (Optical Network Terminator), but authentication has not taken place
ONT
(i.e., no address is present).
IP
Ethernet Lights (1 - 8)
The Ethernet lights illuminate when the Router is connected to a local network
via one or more of its Ethernet ports. If flashing, data traffic is passing across
the port(s).
