BEC 7800(N) Quick Start Manual

Billion (802.11n) dual wan adsl2+ firewall router quick start guide.


BEC 7800(N)
(802.11n) Dual WAN
ADSL2+ Firewall Router
Quick Start Guide

Summary of Contents

  • Page 1

    BEC 7800(N) (802.11n) Dual WAN ADSL2+ Firewall Router Quick Start Guide...

  • Page 3

    PLEASE READ THE QUICK START GUIDE AND FOLLOW THE STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE. IF YOU NEED MORE INFORMATION ON THIS SOFTWARE CONFIGURATION, PLEASE REFER TO THE USER’S MANUAL ON CD-ROM.

  • Page 4

    Quick Start Guide Place the router on a stable surface. Only use the power adapter that comes with the package. Using a different voltage rating power adaptor may damage the router. Attention...

  • Page 5

    Hardware Overview The Front LEDs When power on, it will lit green. When the system is booting, it will blink orange at the same time. While the system is ready, it will only lit green. When system booting failed or in the emergency mode, it will only lit orange.

  • Page 6

    Hardware Connection Users will not be able to connect to the internet through EWAN if DSL is already connected to the internet. Only one connection type (EWAN or DSL) is allowed to connect to the internet at one time. ADSL Router Mode Broadband Router Mode Hardware Installation Power Connection...

  • Page 7

    Billion BEC 7800(N) (802.11n) Dual WAN ADSL2+ Firewall Router 2. LAN Connection Connect the supplied RJ-45 Ethernet cable to one of the Giga Ethernet ports, and the other side to the PC’s Ethernet interface. 3. EWAN Connection Connect the supplied RJ-45 Ethernet cable to the Ethernet WAN port (EWAN), and connect the other side to another alternative broadband device, such as Cable Modem, VDSL, Fiber Modem or PON optic lines.

  • Page 8

    4. ADSL Connection Connect the supplied RJ-11 phone cable to the router’s ADSL port, and the other side to the phone jack on the wall. 5. Splitter/ Micro-filter Connection Splitter / Micro-filter are important for ADSL installation. It helps high-frequency signals are directed to the ADSL modem, and low-frequency signals are directed to the telephone or other analog voice-channel device to prevent inter-modulation distortion and get good speed and stable ADSL sync rate.

  • Page 9

    Billion BEC 7800(N) (802.11n) Dual WAN ADSL2+ Firewall Router b) Micro-filter connection If the installation has several telephones or other analog devices, then an internal micro-filter can be employed at each analog device.

  • Page 10

    Troubleshooting 1. None of the LEDs are on when you turn on the router. Check the connection between the adapter and the router. If the error persists, you may have a hardware problem. In this case you should contact technical support. 2.
