Bernard Shortstub 40B Specification Sheet

Shortstub
Stick Electrode Holder
40B Shortstub ®
Bernard
®
An Illinois Tool Works Company
449 West Corning Road, Box 667
Beecher, Illinois 60401 USA
®
Bernard's Shortstub
maintained its time-tested
design for decades.
Capacity
400 Amps
at 60%
duty cycle
Phone: 800-946-2281 708-946-2281
(US Only)
Fax: 708-946-6726
For more information, visit us at BernardWelds.com
has
®
Specifications
Electrode Weight
Size
1/16" - 1/4" 17oz
(1.6 mm - 6.4 mm) (481 g)
(Outside US)
Issued July 2007 • SPEC SS-1.2
Time Tested Performance.
Our Manual Welding Products provide
high quality with a wide range of
styles, sizes and capacities to enhance
your welding applications.
Electrodes can be used to within one inch of
the high heat, high impact head compared with
the normal three inches of the electrode that is
leftover when using a typical tong-type holder.
Bernard Shortstub greatly improves
productivity because it is designed for quick,
easy installation of electrodes and it is built
to last with a proven high impact, high heat
replaceable head.
Bernard Shortstub models provide long life
because the replaceable head can be ordered
separately and installed quickly, eliminating total
replacement.
Over 2,000 pounds of gripping pressure
enables the electrode to be bent to a desired
shape for access to difficult welds.
Length Cable Cable
Connection Socket
8 3/4 Model "B" large 19/32"
(22 cm) ball point screw (1.5 cm)
connection
Made with
Pride and without
Compromise in the
USA
