MINI COMPONENT SYSTEM

OPERATION MANUAL

Thank you for purchasing this SHARP product.
To obtain the best performance from this product,
please read this manual carefully.
It will guide you in operating your SHARP product.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated "dangerous
voltage" within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
Caution - use of controls or adjustments or per-
formance of procedures other than those specified
herein may result in hazardous radiation exposure.
Note:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harm-
ful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a par-
ticular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the inter-
ference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING
FCC Regulations state that any unauthorized changes or modifications
to this equipment not expressly approved by the manufacturer could void
the user's authority to operate this equipment.
C A U T I O N
R I S K O F E L E C T R I C S H O C K
D O N O T O P E N
CAUTI ON:
TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NO T
REM OVE
COVER
BACK).
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSON-
NEL.
For your assistance in reporting this unit in case of loss
or theft, please record below the model number and serial
number which are located on the rear of the unit.
Please retain this information.
CD-BA2100
CD-BA2100 Mini Component System consisting of
CD-BA2100 (main unit) and CP-BA2100 (speaker sys-
tem).
The exclamation point within an equi-
lateral triangle is intended to alert the
user to the presence of important
(OR
operating and maintenance (servic-
ing) instructions in the literature ac-
companying the appliance.
WARNING: TO REDUCE THE RISK OF
FIRE OR ELECTRIC SHOCK, DO NOT EX-
POSE THIS APPLIANCE TO RAIN OR
MOISTURE.
Note:
It is the intent of Sharp that this product be used in
full compliance with the copyright laws of the United
States and that prior permission be obtained from co-
pyright owners whenever necessary.

FOR YOUR RECORDS

Model number _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Serial number _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Date of purchase _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Place of purchase _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
MODEL

Advertisement

Table of Contents
loading

Summary of Contents for Sharp CD-BA2100

  • Page 1: Operation Manual

    POSE THIS APPLIANCE TO RAIN OR MOISTURE. Note: It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be obtained from co- pyright owners whenever necessary.
  • Page 2: Table Of Contents

    IMPORTANT SAFEGUARDS CAUTION All the safety and operating instructions should be read before the appliance is operated, and should be retained for future reference. Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety.
  • Page 3: Precautions

    Using this product with a higher voltage other than which is specified is dangerous and may result in a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.
  • Page 4: Preparation For Use

    Model CP-BA2100 is the exclusive speaker for the CD- BA2100. Do not use it for other models. Besides, do not connect other speakers to the CD-BA2100 speaker terminals. Such connections can damage the main unit. Do not mistake the right channel for the left channel when connecting the speakers to the unit.
  • Page 5: Antenna Connection

    (Continued) Left speaker AM loop FM antenna antenna AC 120 V, 60 Hz Removing the speaker grilles Remove the lower part of the speaker grille first. Remove the upper part of the speaker grille. Only the grills on the woofers are removable. Caution: When the speaker grilles are removed, the speaker diaphragms are exposed.
  • Page 6 (Continued) (Main unit operation) (Main unit operation) 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar) Batteries are not included. 8" - 20’ (0.2 m - 6 m) Demo mode When the AC power cord is first connected, the unit will enter the demonstration mode.
  • Page 7: Setting The Clock

    SETTING THE CLOCK (Main unit operation) MEMORY/SET POWER STAND-BY CLOCK TUNING/ TIME AM 12:00 AM 0:00 In this example, the clock is set for the 12-hour (AM 12:00) sys- tem. Press the ON/STAND-BY button to enter the stand-by mode. Press the CLOCK button. Within 5 seconds, press the MEMORY/SET button.
  • Page 8: Sound Control

    SOUND CONTROL (Main unit) (Remote control) 0 1 2 29 30 MAXIMUM (Remote control) (Main unit) X-BASS indicator (Main unit) (Remote control) Volume (Main unit operation) When the VOLUME control is turned clockwise, the volume will increase. When it is turned counterclockwise, the volume will decrease.
  • Page 9: Compact Disc Operation

    COMPACT DISC OPERATION More tracks indicator Music schedule Total number of tracks Total playing time CD playback 5" (12 cm) Press the ON/STAND-BY button to turn the power on. Press the CD button. 3" (8 cm) Press the OPEN/CLOSE button to open the disc tray. Place the CD(s) on the disc tray, label side up.
  • Page 10 (Continued) DISC SKIP RANDOM Caution: Do not carry the unit with discs left in the disc trays. The discs may come loose inside the unit and they may be damaged or cause damage to the unit. This may also cause mal- functions.
  • Page 11 (Continued) Selected disc number Selected track number Playback order CLEAR Repeat play indicator APMS (Automatic Programmable Music Selector) You can playback the tracks on the CDs in the disc 1 - 3 positions in any order desired. By specifying the disc numbers from 1 to 3, and the track numbers from 1 to 99, you can choose up to 32 selections for playback in the order you like.
  • Page 12: Radio Operation

    RADIO OPERATION (Main unit operation) 2,3,5,6 (Main unit operation) PRESET( MEMORY/ Tuning Press the ON/STAND-BY button to turn the power on. Press the TUNER (BAND) button. Press the TUNER (BAND) button to select the desired fre- quency band. (FM ST, FM or AM) Press the TUNING/TIME ( desired station.
  • Page 13: Cassette Operation

    (Continued) To recall a memorized station: Press the PRESET ( ) button for less than 0.5 seconds to select the desired station. The stations (preset channel number, frequency and frequency band) which have been stored in memory will appear in the display in numerical order, irrespec- tive of the frequency bands.
  • Page 14: Recording

    RECORDING When recording important selections, be sure to make a preliminary test to ensure that the desired material is being properly recorded. The VOLUME, X-BASS and EQUALIZER controls may be adjusted with no effect on the recorded sig- nal (Variable Sound Monitor). REC PAUSE POWER STAND-BY...
  • Page 15: How To Use The Built-In Timer

    HOW TO USE THE BUILT-IN TIMER Before setting the timer, make sure that the clock setting is correct. (Page 6) (Main unit operation) TIMER/ POWER Timer set indicator SLEEP STAND-BY TUNER (BAND) TAPE (1 2) VIDEO/ TUNING/ TIME Timer playback Press the ON/STAND-BY button to turn the power Press the CD, TUNER (BAND), TAPE (1 VIDEO/AUX button to select the desired function.
  • Page 16: Using External Units

    USING EXTERNAL UNITS To the line output jack RESETTING THE MICROCOMPUTER POWER STAND-BY TRANSPORTING THE UNIT POWER STAND-BY Video/Auxiliary (Audio signal) input To listen to or record signals from external sources through this unit: Use a separately available RCA cord to connect the desired external unit to the VIDEO/AUX jacks.
  • Page 17: Maintenance

    TAPE 2 SPECIFICATIONS As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
  • Page 18: Consumer Limited Warranty

    Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage.
