Schlage B-Series Manual

Schlage b-series commercial grade auxiliary locks.


B-S
ERIES
Commercial Grade Auxiliary Locks

Summary of Contents

  • Page 1

    ERIES Commercial Grade Auxiliary Locks...

  • Page 2

    All B-Series standard strikes come with wood frame reinforcer anchored with two heavy 3” screws to resist kick-in attacks and free-spinning solid or reinforced collars to resist cylinder wrenching.

  • Page 3

    Specifications Handing: B250-Series deadlatches are reversible. All other B-Series locksets are non-handed. Door Thickness: BC100-Series, 5-pin: 1 ˝ to 1 ˝ thick (35mm to 44mm) standard. Available to 2 ˝ (57mm), assembled to order. B250-Series, 5-pin: 1 ˝ to 1 ˝ (35mm to 44mm) standard.

  • Page 4

    Free-spinning solid cylinder collar resists wrenching and prying. Large inside thumbturn makes it easy to throw and retract deadbolt. Metal shield protects bolt from ice-pick attack through door. Hardened steel balls protect mounting bolts from drill attack. Cylinder retaining screw screws.

  • Page 5

    *Caution: Double cylinder locks on doors that are used for exits are a safety hazard in times of emergency. Schlage does not recommend double cylinder locks in these situations. Installation should comply with local life safety codes. B600-SERIES Schlage’s toughest heavy duty Grade 1 commercial deadlock.

  • Page 6

    Exclusive wood frame reinforcer protects wood jamb against kick-in attacks. Reinforcer is concealed under the strike and anchored to jamb by two 3" (76mm) screws. Available in three cylinder formats: standard 6-pin, Schlage interchangeable core and small format (Best and Falcon style) interchageable core for maximum flexibility and versatility.

  • Page 7

    *Caution: Double cylinder locks on doors that are used for exits are a safety hazard in times of emergency. Schlage does not recommend double cylinder locks in these situations. Installation should comply with local life safety codes.

  • Page 8

    Cylinder collar reinforced with security inserts to resist wrenching and prying. Thumbturn "holdback" feature retains the deadlatch in a retracted position when desired. Wood frame reinforcer With #12 x 3´´ wood screws, standard for all B-Series deadbolts Strike Door Preparation See templates.

  • Page 9

    Holdback feature standard. No holdback. *Caution: Double cylinder locks on doors that are used for exits are a safety hazard in times of emergency. Schlage does not recommend double cylinder locks in these situations. Installation should comply with local life safety codes.

  • Page 10

    Primus high security cylinders are available to add patented key control and varying degrees of geographical exclusivity to either Everest or Classic Schlage 6-pin key systems. In addition to a conventional pin tumbler mechanism, Primus cylinders incorporate a patented finger pin and sidebar design providing a “dual-locking”...

  • Page 11

    625, 626 Available in BC100, B250, B600 and B700-Series, full size inter- changeable cores can be integrated into any 5 or 6-pin Schlage key with no adverse affects on keying capacity. To order complete locks with full size cores, change suffix from P to R.

  • Page 12

    S E R I E S Latches and Bolts B-Series bolt and latch fronts are adjustable for flt or beveled edge doors and furnished in brass, bronze or chrome finishes compatible with the lock finish. When ordering separately, speci- fy quantity, part number and finish.

  • Page 13

    Strikes All B-Series strikes are fully reversible for right handed and left handed doors and are furnished complete with screws. Strike boxes are also included with all standard strikes. B-Series deadbolt strikes are also packed with our exclusive wood frame reinforcer for added protection against "kick-in"...

  • Page 14

    ” collar with insert / ” collar B661/761/861, B664/764/864 / ” security insert / ” collar with insert Two each required for double cylinder locks B-Series Interchangeable Core Tailpieces Function BC160BD BC160J, B660J, B661J, B663J BC162BD BC162J, B662J (two tailpieces required)

  • Page 15

    Additional details (e.g. key symbol, keyway, bitting) and other special requirements. Example Line Outside Product Item Finish B660P Note: Schlage order forms are available at no charge by contacting your IR Security & Safety Consultant or Customer Service. Left Hand Left Hand Reverse Bevel Inside Door Latch Strike...

  • Page 16

    (888) 805-9837 International Division Ingersoll-Rand Architectural Hardware 1076 Lakeshore Road East Mississauga, Ontario, L5E 1E4, Canada (905) 278-6128 FAX (905) 278-1413 Internet http://www.schlage.com Fax-On-Demand (888) 321-3228 IR Security & Safety Americas 111 Congressional Boulevard STE 200 Carmel, IN 46032 800-847-1864 800-452-0663 Fax www.irsecurityandsafety.com...
