Congratulations on owning a Scag mower! This manual contains the operating
instructions and safety information for your Scag mower. Reading this manual
can provide you with assistance in maintenance and adjustment procedures to
keep your mower performing to maximum effi ciency. The specifi c models that
this book covers are listed on the inside cover. Before operating your machine,
please read all the information enclosed.
© 2010
Scag Power Equipment
Division of Metalcraft of Mayville, Inc.
OPERATOR'S
MANUAL
Turf Tiger
Models:
STT52V-27CH
STT61V-27CH
STT61V-27KA
STT61V-29DFI
STT61V-29DFI-LE
STT61V-35BVAC
STT-29DFI
STT-35BVAC
PART NO. 03274 Rev. 2
PRINTED 12/2010
PRINTED IN USA
