CL Series "e"
Thermal Tran fer Printers
Operator Manual for
CL408e, CL412e,
CL608e & CL612e
CL408e and CL412e Printer Users Please Refer To
Supplemental Operator Manual PN: 9001159
PN 9001074 Rev. B

Summary of Contents

  • Page 1

    CL Series “e” Thermal Tran fer Printers Operator Manual for CL408e, CL412e, CL608e & CL612e CL408e and CL412e Printer Users Please Refer To Supplemental Operator Manual PN: 9001159 PN 9001074 Rev. B...

  • Page 2

    All rights reserved. No part of this document may be reproduced or issued to third parties in any form whatsoever without the express permission of SATO America, Inc. The materials in this document is provided for general information and is subject to change without notice.

  • Page 3

    BEFORE CONNECTING A PRINTER TO ANY POWER SOURCE, ENSURE IT WAS FACTORY CONFIGURED FOR THE APPROPRIATE VOLTAGE. THE VOLTAGE FOR THE PRINTER DELIVERED MAY BE FOUND ON THE SHIPPING CONTAINER. CONTACT SATO AMERICA, INC. OR OUR AUTHORIZED RESELLER SHOULD A DISCREPANCY EXIST.

  • Page 4

    This section has been replaced by the “e” and PRO Printer Programming Reference, PN 9001096 on the Printer Utilities CD-ROM. It introduces the SATO printer programming language. It contains the commands that are used with the printer to produce labels with bar codes, alphanumeric data and graphics.

  • Page 5

    Preface APPENDICES APPENDIX A: Optional Features Page - ii PN 9001074 Rev. B SATO CL “e” Series Printers...

  • Page 6: Table Of Contents

    Operator Panel,CL408e and CL412e ....2-14 Rear Panel, CL608e and CL612e ....2-16 Rear Panel, CL408e and CL412e .

  • Page 7: Table Of Contents

    Cleaning the Sensors, CL608e and CL612e ... . . 4-5 Replacing the Fuse, CL608e and CL612e ....4-6 Cleaning the Print Head and Platen, CL408e and CL412e .

  • Page 8: Table Of Contents

    Label Dispense Option ..... . A-3 CL608e and CL612e ..... A-3 CL408e and CL412e .

  • Page 9

    Preface This page left intentionally blank. Page - vi PN 9001044 Rev. B SATO CL “e” Series Printers...

  • Page 10: Introduction, Introduction, Introduction

    It can print labels up to four inches wide. If a wider label is needed, the CL608e can print labels up to six inches wide at the same resolution. The CL412e provides a higher print resolution, 305 dpi, to give laser-quality printing. It is useful when higher resolution is needed for detailed graphic images.

  • Page 11: General Printer Specifications

    6.0 in. 6.5 in. 152 mm 164mm 49.2 in. 32.8 in. 1249 mm 833 mm 1.96 in. (50 mm) .78 in. (20 mm) 7 in. (178 mm) Fixed 6.75 in. (172 mm) 1345 ft (410 m) SATO CL Series “e” Printers...

  • Page 12

    SDRAM Receive Buffer Optional Flash ROM Optional PCMCIA Memory (1) Single two color (Red, Green) LED. All specifications subject to change without notice. SATO CL Series “e” Printers Section 1. Printer Overview CL408e CL412e Status = Green None Status = Red...

  • Page 13: Character Fonts

    Line Space control Journal Print facility 0°, 90°, 180° and 270° Rotation PN 9001074 Rev. B CL412e CL612e (22 dots W x 33 dots H) OCR A (30 dots W x 36 dots H) OCR B SATO CL Series “e” Printers...

  • Page 14: Bar Codes

    0°, 90°, 180° and 270° Sequential numbering of both numerics and bar codes RAM storage for special characters Full dot addressable graphics, SATO Hex/Binary, .BMP or .PCX formats Form overlay for high-speed editing of complex formats. PN 9001074 Rev. B Section 1.

  • Page 15: Physical

    Max 90% RH, non-condensing UL, CSA FCC Class A PN 9001074 Rev. B CL608e CL612e 13.8 in. (352 mm) 16.9 in. (429 mm) 11.7 in. (298 mm) 41.9 lbs (19 Kg) 50W Idle 210W Operating SATO CL Series “e” Printers...

  • Page 16: Optional Accessories

    USB Interface Module 10/100BaseT Interface Module Coax/Triax Interface Module. Coax I/F emulates an IBM 3287-2 printer with a standard Type A BNC connector. Twinax I/F emulates IBM 5224, 5225, 5226 or 4214 printers with auto-terminate/cable-thru capabilities. PN 9001074 Rev. B Section 1.

  • Page 17

    Section 1. Printer Overview This page left intentionally blank. Page 1-8 PN 9001074 Rev. B SATO CL Series “e” Printers...

  • Page 18: Unpacking And Parts Identification, Setting Up The Printer

    INTRODUCTION This section is provided to assist you in taking the CL Series Printer from the shipping container to the application environment. Where the physical differences between the printer models are significant (such as loading paper and ribbons), separate sections for each of the models are used for clarity.

  • Page 19

    Remove the accessory items from their protective containers. If the printer has been stored in a cold environment, allow it to reach room temperature before powering it on. Set the printer on a solid, flat surface. Inspect the shipping container and printer for any signs of damage that may have occurred during shipping.

  • Page 20

    SETTING UP THE PRINTER Consider the following when setting up the printer: Locate a solid flat surface with adequate room to set the printer. Make sure there is enough room at the top and right-hand (facing the printer) side to provide clearance for the label access door to swing open.

  • Page 21

    Label Supply Guide snugly against the outside of the label roll. 6. If using fanfold labels (or tags) set them on a flat surface behind the printer. Pass the labels (printing side up) through the slot and under the Label Supply Spindle.

  • Page 22

    12. If the ribbon is not loaded, see the following description for loading instructions. Media Knob Printed Labels Dispenser Routing SATO CL Series “e” Printers Label Guide Label Backing PN 9001074 Rev. By Section 2. Installation...

  • Page 23

    The Print Head Assembly is spring-loaded and will automatically open as soon as the Head Latch is disengaged. 3. Locate the Extra Ribbon Core supplied with the printer. Place the core on the Ribbon Rewind Spindle, pushing it all the way to the inside of the spindle.

  • Page 24

    It is possible to delay such damage by always ensuring that the ribbon used is wider than the label stock. This will help to protect the print head from label edge damage. SATO CL Series “e” Printers PN 9001074 Rev. B Page 2-7...

  • Page 25

    Outside Label Guide Page 2-8 Top Access Door Front Access Door Label Label Supply Spindle PN 9001074 Rev. B SATO CL Series “e” Printers CL408e and CL412e Front Access Door Latch Head Latch Outside Label Guide Feed Slot...

  • Page 26: Label Dispense Option

    12. Carefully feed several labels through the opening in the Front Access Door and close it. After the Front Access Door is closed, the Top Access Door may be closed. These covers have interlock switches and the printer will not operate if either is open.

  • Page 27

    See the “Test Print” section on page 3-22 for instructions on how to run test prints. Page 2-10 Tape PN 9001074 Rev. B SATO CL Series “e” Printers Ribbon Supply Roll Empty Core Head Latch...

  • Page 28: Cl608e And Cl612e, Cl408e And Cl412e, Cl608e And Cl612e, Cl408e And Cl412e

    LABEL SENSOR ADJUSTMENTS The Gap (transmissive) sensor on the CL608e and CL612e can be adjusted over a limited range. It is located in the Label Hold-Down Assembly and can be adjusted by loosening the Sensor Adjust Cap Screw on the front of the Label Hold-Down and sliding the Sensor Adjust Tab to the desired position.

  • Page 29

    POWER LINE Reserved The CL608e/CL612e Operator Panel consists of five LED indicators, two momentary contact switches, three DIP switches, four adjustment potentiometers and one LCD Display. All of these are accessible from the front of the printer. They are used to set the printer operating parameters and to indicate the status of the printer to the operator.

  • Page 30

    Momentary switch. Pressing this key toggles the printer between the on-line and off-line mode. When the printer is on-line, it is ready to receive data from the host. This key acts as a pause during a print job by taking the printer off-line. It can also be used as a function key to stop label during the printing process.

  • Page 31

    RS232 interface card), four adjustment potentiometers and one LCD Display. All of these are accessible from the front of the printer, however some are not accessible unless the front cover is open. They are used to set the printer operating parameters and to indicate the status of the printer to the operator.

  • Page 32

    Momentary switch. Pressing this key toggles the printer between the on-line and off-line mode. When the printer is on-line, it is ready to receive data from the host. This key acts as a pause during a print job by taking the printer off-line. It can also be used as a function key to stop label during the printing process.

  • Page 33

    Universal Serial Bus I/F Module Ethernet 10/100BaseT I/F Module Two connectors for optional PCMCIA Memory Cards. External signal connector, AMP 57-60140. PN 9001074 Rev. B SATO CL Series “e” Printers CL608e and CL612e PCMCIA Memory Expansion slot I/F Module Parallel Shown...

  • Page 34

    Memory Card Slot: EXT: Cover Plate Remove for access to Fan-Fold Slots SATO CL Series “e” Printers Switch to turn power On or Off. Input 115V 50/60 Hz connector. Use the cable provided. Input power protection. Type 3A/250V. Slot to plug in an interface adapter. An adapter must be connected before the printer is operational.The adapter...

  • Page 35

    Label Inside Edge CL608 and CL612 Label Sensor Positioning Page 2-18 This sensor is a motion detector that signals the printer when the ribbon supply is turning. When the print head is opened, this switch is activated and the printer will stop printing.

  • Page 36

    Paper Inside Edge CL408 and CL412 Label Sensor Positioning SATO CL Series “e” Printers This sensor is a motion detector that signals the printer when the ribbon supply is turning. When the print head is opened, this switch is activated and the printer will stop printing.

  • Page 37

    Section 2. Installation This page left intentionally blank. Page 2-20 PN 9001074 Rev. B SATO CL Series “e” Printers...

  • Page 38: Printer Dip Switch Configuration

    They will not become effective until the power is cycled. RS232 Transmit/Receive Setting (located on RS232 I/F Module) Data Bit Selection (DSW1-1). This switch sets the printer to receive either 7 or 8 bit data bits for each byte transmitted. DSW1-1...

  • Page 39

    Sensor Type Selection (DSW2-2). Selects between the use of a label gap or a reflective Eye-Mark detector. DSW2-2 SETTING Eye-Mark Page 3-2 SETTING 1 Stop Bit SETTING 9600 19200 38400 57600 SETTING Rdy/Bsy Xon/Xoff Bi-Com 3 Bi-Com 4* PN 9001074 Rev. B DSW1 DSW1 DSW1 DSW2 DSW2 SATO CL Series “e” Printers...

  • Page 40

    Head Check Selection (DSW2-3). When selected, the printer will check for head elements that are electrically malfunctioning. DSW2-3 SETTING Disabled Enabled Hex Dump Selection (DSW2-4). Selects Hex Dump mode. DSW2-4 SETTING Disabled Enabled Receive Buffer Selection(DSW2-5). Selects the operating mode of the receive buffer.

  • Page 41

    Line Feed commands. DSW3-3 Sensor Used Back-Feed Selection (DSW3-4). When Back-Feed is enabled, the printer will position the last printed label for dispensing and retract it before printing the next label. The amount of backfeed offset is adjustable . DSW3-4 External Signal Interface.

  • Page 42

    See Section 6: Interface Specifications for a description of the signal requirements. DSW3-8 SETTING Disabled Enabled Reserved for Future Use (DSW3-2) SATO CL Series “e” Printers SETTING Type 4 Type 3 Type 2 Type 1 PN 9001074 Rev. B Section 3.

  • Page 43: Default Settings

    Once the default operation is completed, a DEFAULT COMPLETED message will be displayed on the LCD panel or a single beep will be heard if the printer does not have an LCD panel. The printer should be powered off while this message is being displayed (or after the beep is heard.

  • Page 44: Potentiometer Adjustments

    1. While depressing the FEED key on the front panel, power the printer on. 2. When you hear one beep from the printer, release the FEED key and the printer will display on the LCD panel a message asking what type of Test Label you want to print.

  • Page 45: Procedures

    NOTE: The PRINT potentiometer adjustment will affect the darkness in all of the command code speed and darkness ranges. Page 3-8 PN 9001074 Rev. B SATO CL Series “e” Printers...

  • Page 46: Lcd Panel Printer Configuration

    If you load a label job that includes software settings and then enter a new setting via the LCD panel, the manually set values will be used by the printer. If you set the values manually and then download a job with software settings, the software settings will be used.

  • Page 47: Normal Mode

    Section 3. Configuration NORMAL MODE The printer initially powers on in the ONLINE mode. The user can access the User Settings using the following procedures. ONLINE QTY:000000 OFFLINE 000000 PRINT DARKNESS PRINT SPEED Page 3-10 The LCD will display the ONLINE status on the top line and the bottom line will contain the label quantity (QTY) status.

  • Page 48

    Section 3. Configuration The label Pitch is the distance from the leading edge (the edge that comes out of the printer first) of a label and the leading edge of the next label. The leading edge position of the label can be adjusted relative to the print head +/- 49mm in increments of 1mm.

  • Page 49: Advanced Mode

    ADVANCED MODE An Advanced Mode is provided to make adjustments that require only occasional changes. Since they affect the basic operation of the printer, the procedure for entering this mode is designed to prevent someone from accidently changing the settings.

  • Page 50

    Section 3. Configuration Vertical Offset is the distance down from the leading edge (the edge of the label that comes out of the printer first) to the first vertical print position. A positive setting moves the first print position down the length of the label while making it negative moves it up the length of the label.

  • Page 51

    (CRLF ) from the data stream, including graphics and 2D bar codes. It is used primrily to maintain compatibility with earlier models of SATO printers. 1. Use the LINE key to step the cusor to either the YES or NO selection.

  • Page 52: Card Mode

    The Card Mode is entered from the Advanced Mode display by pressing the LINE key once. The Card Mode display indicates that the printer is in the Card Mode. To advance to the first selection, press the FEED key. This selection determines which type of optional expanded memory will be addressed as “CC1"...

  • Page 53

    Mem Full Error Indicates that there is insufficient memory available. This selection allows you to copy SATO fonts from the PCMCIA Memory card installed in the Memory Card slot on the rear of the printer to the optional Flash ROM.

  • Page 54

    This selection allows you to copy the entire contents of the optional Expanded Memory to the PCMCIA Memory card installed in the Memory Card slot on the rear of the printer. 1. Use the LINE key to step the cursor to desired setting. If Yes is selected, the printer will enter the Card Copy mode.

  • Page 55: Service Mode

    If No is selected, the display will advance to the mode display. To exit the Card Mode, power the printer off and then back on. The Service Mode is entered from the Advanced Mode display by pressing the LINE key twice.

  • Page 56

    “0.0V”, then the printer will automatically calculate the setting when the first label is fed after the printer is powered on or the head is closed. There are some instances where the automatically...

  • Page 57

    1. Use the LINE key to step the cursor to desired setting. If Yes is selected, the printer will feed a blank label anytime it enters the Online mode. If No is selected, the display will advance to the mode display.

  • Page 58

    1. Use the LINE key to step the cursor to desired setting. If Yes is selected, the printer will reprint the last label when the FEED key is pressed when the printer is Online. If the printer is Offline, pressing the FEED key will feed a blank label.

  • Page 59: Counter Mode, Test Print Mode

    Section 3. Configuration SERVICE MODE COUNTER MODE The Counter Mode is provided to allow the user to access the internal printer cousters. ADVANCED MODE COUNTER MODE SELECT COUNTER HD DSP CUT LIFE HEAD COUNTER XXXXX M HD CNTR CLEAR COUNTERS MODE TEST PRINT MODE The Test Print Mode offers four different printer status labels for troubleshooting.

  • Page 60: Default Setting Mode

    PRESS FEED KEY TO STOP PRINTING DEFAULT SETTING MODE Occassionally it is desirable to reset all printer configuration settings to their original default conditions. This allows the operator to start reconfiguration of the printer starting from a know set of conditions.

  • Page 61: Clear Non-standard Protocol Codes, Download User Defined Protocol Codes

    , ENQ = 40 ALT.PROTOCOL DEFAULT COMPLETE DOWNLOAD USER DEFINED PROTOCOL CODES The user can define a set of custom protocol codes and download them to the printer using the <ESC>LD command. USER DOWNLOAD PRESS THE LINE KEY USER DOWNLOAD...

  • Page 62: Hex Dump Mode

    HEX DUMP MODE In addition to the Test Print Labels, the printer can print the contents of the receive buffer in a hexadecimal format to allow the data stream to be examined for errors and troubleshooting. ONLINE QTY:000000 SATO CL Series “e” Printers Section 3.

  • Page 63

    Section 3. Configuration This page left intentionally blank. Page 3-26 PN 9001074 Rev. B SATO CL Series “e” Printers...

  • Page 64: Adjusting The Print Quality, Darkness

    Print Darkness software command. The darkness ranges for the printer are displayed on the LCD panel. The lightest print is represented by the smaller value and the darkest print by the highest value. Once the range has been selected, the PRINT Potentiometer on the front panel can be used to make finer adjustments.

  • Page 65: Print Speed

    Head Latch is disengaged. Remove the ribbon. 4. Apply SATO Thermal Print Head Cleaner to a cotton swab. 5. The Print Head faces downward along the front edge of the assembly. Pass the end of the dampened swab along the entire width of the Print Head (you may need to move the ribbon out of the way to do this).

  • Page 66

    2. Open the Label Access Door. 3. Open the Print Head Assembly by pushing the Head Latch toward the rear of the printer. The Print Head Assembly is spring-loaded and will automatically open as soon as the Head Latch is disengaged. Remove the labels.

  • Page 67

    Section 4: Cleaning and Maintenance 7. There is one metal roller used in guiding the labels through the printer. It should be cleaned of any residue or foreign material. 8. Repeat if necessary. The platen and rollers should be cleaned whenever foreign matter such as dust or adhesive is present.

  • Page 68

    When a printed black Eye-Mark passes through the beam, the light is no longer reflected back to the sensor detector, indicating to the printer that it should use this position as the start of a new label. When dust, dirt or other foreign matter interferes with the light path of either of these sensors, the results is erratic label positioning.

  • Page 69

    Supplies needed: 1. Turn the printer power off and remove the power cable. 2. On the back of the printer, locate the Fuse Cap directly above the AC connector. 3. Unscrew the cap and remove the defective fuse. 4. Replace with a new 250V 3A fuse.

  • Page 70

    Head Latch is disengaged. Remove the labels. 3. Apply SATO Thermal Print Head Cleaner to one of the cotton swabs. 4. The Platen is the rubber roller directly below the Print Head. It should be cleaned of any ribbon or label residue.

  • Page 71

    The print head on the CL4XXe printers is a user-replaceable item. If it becomes damaged for any reason, it can be easily removed and replaced. Contact your local SATO representative for information on obtaining a new print head. Supplies needed: 1.

  • Page 72

    Head Latch is disengaged. 4. Apply SATO Thermal Print Head Cleaner to one of the cotton swabs. 5. Insert the cotton swab between the top and bottom pieces of the Sensor Unit and move back and forth to clean any foreign matter from the exposed surface of the sensors.

  • Page 73

    Section 4: Cleaning and Maintenance This page left intentionally blank. Page 4-10 9001074 Rev. B SATO CL Series “e” Printers...

  • Page 74

    SECTION 5. PROGRAMMING REFERENCE Information on programming the Cle Series printers can be found in the “e” and PRO Printer Programming Reference, PN 9001096 found on the Printer Utilities CD-ROM. SATO CL Series “e” Printers PN 9001074 Rev. B Page 5-1...

  • Page 75

    This page left intentionally blank. SATO CL Series “e” Printers PN 9001074 Rev. B Page 5-2...

  • Page 76: Interface Types, Introduction

    PCs and compatibles. The RS232C Serial interface allows connectivity to a number of other hosts. The USB interface allows the printer to be connected to a computer that supports peripherals attached to a USB bus. Up to 127 peripherals can be connected to a single USB port.

  • Page 77: The Receive Buffer

    The multiple job buffer, on the other hand prints all jobs in the order they are received by the printer, and the order of printing cannot be changed.

  • Page 78: Ieee1284 Parallel Interface, Electrical Specifications

    “low” (or an X-Off is sent) indicating the printer can no longer receive data. will go “low” (or an X-Off is sent) indicating the printer can no longer receive data. will go “low” (or an X-Off is sent) indicating the printer can no longer receive data.

  • Page 79: Data Streams, Interface Pin Assignments

    DATA 6 Return Reference DATA 7 Return Reference DATA 8 Return Reference ACK Return Reference BUSY Return Reference PE Return Reference INIT From Host FAULT To Host Not Used Not Used Not Used SELECTIN From Host SATO CL Series “e” Printers...

  • Page 80: Rs232c Serial Interface, General Specifications, Electrical Specifications, Pin Assignments

    ELECTRICAL SPECIFICATIONS Connector Cable Signal Levels PIN ASSIGNMENTS Pin 13 Pin 25 SATO CL Series “e” Printers Section 6. Interface Specifications Half-duplex communication Ready/Busy Hardware Flow Control Pin 20, DTR Control Pin 4, RTS Error Condition X-On/X-Off Software Flow Control...

  • Page 81: Ready/busy Flow Control

    By raising/lowering the voltage level on Pin 20 of the RS232 port, the printer notifies the host when it is ready to receive data. Pin 4 (RTS) and pin 20 (DTR) are the important signals on the printer for this method of flow control. The...

  • Page 82: X-on/x-off Flow Control, Universal Serial Bus (usb) Interface

    If an error occurs during printing (paper out, ribbon out), the printer sends an X-Off as soon as an error condition is detected. When the error is cleared and the printer is placed back on-line, it transmits an X-On indicating it is again ready to accept data.

  • Page 83: Local Area Network (lan) Interface, Bi-directional Communications

    16 characters, the field will be padded with leading zeroes. If an ENQ is received after the print job specified in the ID bytes has been completed, or there is no data in the buffer, the printer will respond with two “space” characters Page 6-8 PN 9001074 Rev.

  • Page 84: Enq/ack/nak

    ACK (06 hexadecimal) is returned if there are no errors and a NAK (16 hexadecimal) if a printer error exists. (1) To provide compatibility with older SATO printers, the RS232 interface can be configured to use an earlier Bi-Com 3 ENQ/ACK/NAK protocol selected via DSW2-8 and DSW1-7/8 (on the RS232 Interface module).The earlier protocol did not have...

  • Page 85

    Print Stop (without error) OFF-LINE, ERROR CONDITION Head Open Paper End Ribbon End Media Error Sensor Error Head Error Cutter Error Other Error Condition (1) Not supported by legacy Bi-Com protocols Page 6-10 DEFINITION PN 9001074 Rev. B SATO CL Series “e” Printers...

  • Page 86: Status Response

    This allows the controlling application to determine the status of a printer when it is located in a remote location. Details on the Status Response mode are found in the “e” and PRO Printer Programming Reference, PN 9001096, found on the Printer Utilities CD-ROM.

  • Page 87: Pin Assignments

    Reprint - A duplicate of the last label in a print job will be reprinted when this signal is received. Print Start - The printer will print one label when this pin is pulled to ground. This signal must be enabled by placing switch DSW3-5 on the Control Panel in the OFF position.

  • Page 88: Standard Operation

    Type 1 Print End Type 2 Print End Type 3 Print End Type 4 SATO CL Series “e” Printers Section 6. Interface Specifications Pin 13 330 ohm, 1/4W Signal Out Start of Print Cycle 20 milliseconds PN 9001074 Rev. B...

  • Page 89: Repeat Print, Error Signals

    Print End Type 3 Print End Type 4 Page 6-14 Start of Print Cycle 20 milliseconds Paper or Ribbon End Head Moving Open Stopped PN 9001074 Rev. B End of Print Cycle Paper/Ribbon Replinished Head Closed SATO CL Series “e” Printers...

  • Page 90: Initial Checklist, Using The Ieee1284 Parallel Interface

    Parallel Interface module will not work correctly in the “e” printers. 5. When you send the print job to the printer, and it does not respond, do you get an error message on your PC that says “Device Fault” or something similar? SATO CL Series “e”...

  • Page 91

    5. When you send the print job to the printer and it does not respond, and there is no error message on the PC: a.

  • Page 92: Using The Rs232c Serial Interface

    7. From the Hex Dump, if you are seeing extra 0D characters, and are using BASIC, refer to the beginning of the Command Code section. It provides hints for writing a SATO program in BASIC. SATO CL Series “e” Printers Section 7.

  • Page 93: Error Signals

    Cycle power on/off Cycle power on/off Cycle power on/off Open/close Head Lever Open/close Label Hold- down Open/close Head Lever Open/close Label Hold- down Open/close Head Lever Replace ribbon with full roll Slow down transmission rate SATO CL Series “e” Printers...

  • Page 94

    Installation 1. Position the Rewinder at the front of the printer and align it with the label slot. (The Rewind Wheel/Spindle should be positioned away from the printer.) 2. Connect the built-in cable from the Rewinder to the EXT connector at the rear of the printer.

  • Page 95

    Section 3: Configuration. General Operation The data stream to be sent to the printer may need to be altered to add the Cutter Command. If this command is not used, the cutter will default to cut after every label assuming it has been enabled in the printer configuration. For more details, see the “e”...

  • Page 96

    LABEL DISPENSE OPTION The CL608e and CL612e Label Dispense Option is an external mechanism that provides the ability to print labels in the “demand” mode. It is attached to rear of the printer with two screws and is connected to the internal drive mechanism of the printer.

  • Page 97

    3. The printer must be configured to used the Label Dispense Option. Switches DSW3-1 and DSW3-2 on the front panel are used to configure the printer. To enable the dispenser, both DSW3-1 and DSW3-2 should be in the ON position.

  • Page 98

    General Operation Send your data stream in the normal manner to the printer. Labels should print one at a time, even if your print quantity command requests more than one label. As the labels are printed and presented for the operator to remove, the backing paper will be...

  • Page 99

    (b) through (c). 4. Press the FEED key and the printer will print a test label. Press the FEED key again to stop the printing and turn the printer OFF.

  • Page 100

    Warning 1. Duplicate number. 2. Data not in print area. 3. Data overflows card memory. SATO CL Series “e” Printers Appendix A: Optional Features SRAM or Flash PCMCIA Version 2.1 (JEIDA Version 4.1) Up to 4MB SRAM or 16MB Flash...

  • Page 101

    The Expanded Memory is selected using the <ESC>CC Memory Area Select command. This option requires the installation of an Expanded Memory pcb and is a factory-only installed option. Page A-8 PN 9001074 Rev. B ALL MODELS SATO CL Series “e” Printers...

  • Page 102

    A qualified technician should perform the upgrade as it requires modifications to the main PCB assembly. Please call SATO Technical Support if you need to add this option to an existing printer in the field.

  • Page 103

    Appendix A: Optional Features This page left intentionally blank. Page A-10 PN 9001074 Rev. B SATO CL Series “e” Printers...
