Instruction Manual
Manuel d'utilisation
Manual de instrucciones
LCD Monitor
Moniteur d'affichage à cristaux liquides
Monitor de LCD
Please read this Instruction book before using your LCD monitor. We wish you many hours of pleasure from your new LCD monitor.
Veuillez lire attentivement ce mode d'emploi avant d'utiliser votre moniteur d'affichage à cristaux liquides. Nous espérons que votre
nouveau dispositif d'affichage vous procurera de nombreux instants de bonheur.
Lea este manual de instrucciones antes de usar su nuevo monitor. Deseamos que disfrute de él muchas horas.
52LH1R
CE
English
GB
Français
F
Español
E
Page
2~15
Page
16~28
29 ~ 41
Página

Advertisement

Table of Contents
loading

Related Manuals for Sanyo CE-52LH1R

Summary of Contents for Sanyo CE-52LH1R

  • Page 1 Instruction Manual Manuel d'utilisation Manual de instrucciones LCD Monitor Moniteur d'affichage à cristaux liquides Monitor de LCD Please read this Instruction book before using your LCD monitor. We wish you many hours of pleasure from your new LCD monitor. Veuillez lire attentivement ce mode d’emploi avant d’utiliser votre moniteur d’affichage à cristaux liquides. Nous espérons que votre nouveau dispositif d'affichage vous procurera de nombreux instants de bonheur.

  • Page 2: Installation And Use

    CAUTION: Please read and retain for your safety. This unit has been designed and manufactured to assure your personal safety, but improper use can result in potential electric shock or fire hazards. In order not to defeat the safeguards incorporated in this monitor observe the following basic rules for its installation, use and servicing.
  • Page 3 Adjust only those controls that are covered in the operating instructions as improper adjustment of other controls may result in damage. This will often require extensive work by a qualified technician to restore the monitor to normal operation. Important recycling information. Your SANYO product is designed and manufactured with high quality materials and components which can be recycled and reused.

  • Page 4: Ac Power Cord Requirement

    Software (the software applications, utilities and modules embedded within the Product) which is owned by Sanyo or its licensors. Before using the product, please read the End-User License Conditions detailed below. If you do not agree to the terms and conditions of the End-User License,...

  • Page 5: Installation

    Step : 1 Mains Connection Connect the display unit to VGA, BNC and Scart connector as required. LD-Net Mains Inlet 1. Connect the in-line power connector to the Mains Inlet as shown above. 2. Connect the power cord of the LCD monitor to a suitable wall outlet.

  • Page 6: Remote Control Battery Installation

    The symbol mark and recycling systems described below apply to EU countries and do not apply to countries in other areas of the world. Your SANYO product is designed and manufactured with high quality materials and components which can be recycled and/or reused.

  • Page 7: Controls And Menus

    Controls and Menus 1. The LCD display has a Standby light to show there is power. Switching into/from standby mode The Standby mode is used for switching the LCD monitor off for short periods of time. In standby mode the monitor is switched off but is still receiving mains power.

  • Page 8: Sound Menu

    Picture menu Advanced settings Use the 5 or 6 button to select Advanced settings and press the 1 or 2 button to enter the sub menu as follows. DCDi(Directional Correlational Deinterlacing) is used to process moving angled edge in deinterlacing to get the smoothest and most natural image.

  • Page 9: Menu Operation

    Setup menu PIP/POP Setup Use the 5 or 6 button to select PIP/POP Setup and press the 1 or 2 button to enter the sub menu. PIP/POP Mode: Using the 1 or 2 button select the most suitable mode PIP1, PIP2, POP or Off. (Please refer to page 12.) When Mode is set to Off, Sub Source and PIP Position will not work.

  • Page 10: Installation Mode

    Installation Mode Installation Mode Network Initial Temperature Error This LCD monitor allows you to set up the following: SETTING PROCEDURE 1 . Press and hold the GREEN button on the remote control for 5 seconds. (Installation Mode will appear) 2. Use the 5 or 6 button to highlight each option, use the 1 or 2 button to adjust each option.
  • Page 11 Selecting of picture size Select screen size from FULL, FULL ALL, ZOOM 16:9, TITLE IN 16:9, ZOOM 14:9, TITLE IN 14:9, NORMAL or NATURAL WIDE by pressing the WIDE button repeatedly on the Remote Control. When in AV2 (RGBHV) orPC mode FULL or NORMAL can be selected.

  • Page 12: Pip/Pop Operation

    PIP/POP Operation Using this function, you can enjoy a DVI or Network program and an image (AV1, AV2, AV3 or PC input) at the same time. Press the ON/OFF button on the Remote Control repeatly to select PIP1, PIP2, POP or OFF mode. During the PIP/POP mode, press the Main/Sub Picture Swap but- ton will switch the location for main and sub picture.

  • Page 13: Teletext Operation

    Teletext Operation Teletext is only available via external sources. Teletext mode can be operated by the following buttons on the Remote Control. Some buttons have dual functions TXT/TV Press TXT/TV button to select teletext. Press again will display: AV mode: AV/ TEXT mode/ MIX mode/ AV Note: MIX mode: AV (broadcast image) screen and the contents of TEXT (superimposed) are displayed simultaneously.

  • Page 14: Specification

    Specification Common specification Power source 100~240V 50Hz / 60Hz Colour system PAL / NTSC / NTSC4.43/ SECAM AV terminal AV1: Scart CENELEC Standard Input: Composite video, RGB (5V RGB with 5V sync to pin 14) and audio-L/R Output: composite video from AV3 and audio L/R AV2: BNC Input: RGB, H and V / Y, Pb, Pr and audio L/R Output: RGB, H and V / Y, Pb, Pr...

  • Page 15: Pc/Dvi-D / Component Signal Support Timing List

    PC/DVI-D / COMPONENT SIGNAL SUPPORT TIMING LIST PC signal support timing Resolution 720_400 640_480 640_480 640_480 640_480 640_480 640_480 800_600 800_600 800_600 800_600 800_600 800_600 832_624 1024_768 1024_768 1024_768 1024_768 1024_768 1024_768 1024_768 1024_768 1280_720 1280_960 1280_1024 1280_1024 1280_1024 1280_1024 1280_1024 1280_1024 1280_1024...

  • Page 16: Rs232C Command T Ables

    Functional Execution Command Table Command CF PSAVE ON CF PSAVE OFF CF CLOK ON CF CLOK OFF CF DEA RMCY CF DEA RMCN Image control Read Command Table Status read command CR BRIGHT CR CONT CR COLOR CR TINT CR SHARP CR WBAL CR WBAL-R CR WBAL-G...
  • Page 17 RS232C Command T RS232C Command T Time Read Command Table Status read command Status of accumulated lifetime of panel. CR PANELH The same as CR_LAMPH Command Status of accumulated lifetime of monitor CR MONH The same as CR_PROJH Command Sound control Read Command Table Status read command CR VOLUME Status of volume value.
  • Page 18 Part No. 1KA6P1P0423-C N5VV (1) Printed in U.K.
