BN68-01007Y-00
Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
PC DISPLAY
PICTURE IN PICTURE (PIP)
TELETEXT
Register your product at www.samsung.com/global/register
LCD TV
LE46M5

Advertisement

Table of Contents
loading

Related Manuals for Samsung LE46M5

Summary of Contents for Samsung LE46M5

  • Page 1 Contact SAMSUNG WORLD-WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Center BELGIUM 02 201 2418 CZECH REPUBLIC 844 000 844 DENMARK 38 322 887 FINLAND 09 693 79 554 FRANCE 08 25 08 65 65 (€...
  • Page 2 IMPORTANT: Image retention issues are not covered by your Samsung® warranty. • Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention.

  • Page 3: Table Of Contents

    Contents CONNECTING AND PREPARING YOUR TV List of Parts ... 2 Installing the Wall Mount Kit ... 2 Viewing the Control Panel ... 3 Viewing the Connection Panel ... 4 Viewing the Remote Control ... 6 Installing Batteries in the Remote Control ... 6 Switching On and Off ...

  • Page 4: List Of Parts

    Wall Mount items. Contact a technician for assistance when installing the wall mounted bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own.

  • Page 5: Viewing The Control Panel

    Viewing the Control Panel The product colour and shape may vary depending on the model. SOURCE Toggles between all the available input sources (TV, Ext.1, Ext.2, AV, S-Video, Component, PC, HDMI, DTV). In the on-screen menu, use this button as you use the ENTERbutton on the remote control.

  • Page 6: Viewing The Connection Panel

    Viewing the Connection Panel [Rear Panel Jacks] Power Input Whenever you connect an external device to your TV, make sure that power on the unit is turned off. When connecting an external device, match the colour of the connection terminal to the cable. Connecting an Aerial or Cable Television Network To view television channels correctly, a signal must be received by the set from one of the following sources: - An outdoor aerial / A cable television network / A satellite network...
  • Page 7 Connecting HDMI/DVI - Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players, AV receivers and digital TVs). - No additional Audio connection is needed for an HDMI to HDMI connection. What is HDMI? - “High Definition Multimedia interface” allows the transmission of high definition digital video data and multiple channels of digital audio (5. 1 channels). - The HDMI/DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied).

  • Page 8: Viewing The Remote Control

    4. Is there a power outage, or is the power cord unplugged? 5. Is there a special fluorescent light or neon sign nearby? Selects a target device to be controlled by the Samsung remote control (TV, DVD, STB, CABLE, VCR) (Refer to page 31~35)

  • Page 9: Switching On And Off

    Switching On and Off The mains lead is attached to the rear of your set. 1. Plug the mains lead into an appropriate socket. The standby indicator lights up on the front of the set. 2. Press the button on the front of the set. You also can press the POWER button or the The programme that you were watching last is reselected automatically.

  • Page 10: Storing Channels Automatically

    Storing Channels Automatically You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated programme numbers may not correspond to actual or desired programme numbers. However, you can sort numbers manually and clear any channels you do not wish to watch. 1.

  • Page 11: Setting The Channel Manager

    Setting the Channel Manager You can select these options by simply pressing the CH MGR button on the remote control. Activating the Child Lock Set the channels according to your preference. You can easily delete, add, or lock the channel you want. Press the MENU button to display the menu.

  • Page 12: Sorting The Stored Channels

    Sorting the Stored Channels Assigning Channels Names Fine Tuning Channel Reception You can exchange the numbers of two channels, in order to: Modify the numeric order in which the channels have been automatically stored. Give easily remembered numbers to the channels that you watch most often. 1.

  • Page 13: Lna (Low Noise Amplifier)

    LNA (Low Noise Amplifier) Changing the Picture Standard You can also press the P.MODE button on the remote control to select one of the picture settings. Adjusting the Custom Picture Changing the Colour Tone If the TV is operating in a weak-signal area, the LNA function can improve the reception (a low-noise preamplifier boosts the incoming signal).

  • Page 14: Resetting The Picture Settings To The Factory Defaults

    Resetting the Picture Settings to the Factory Defaults Changing the Picture Size You can select these options by simply pressing the P.SIZE button on the remote control. Freezing the Current Picture Digital Noise Reduction You can return to the factory defaults picture settings. 1.

  • Page 15: Dnie Demo (Digital Natural Image Engine)

    "PIP". Samsung’s new technology brings you more detailed images with contrast and white enhancement. A new image compensation algorithm gives viewers brighter and clearer images. DNIe technology will match every signal to your eyes.

  • Page 16: Pip Settings

    PIP Settings Ext.1 Main Ext.1 Ext.2 S-Video Component HDMI Changing the Sound Standard You can also select these options by simply pressing the S.MODE button on the remote control. Adjusting the Sound Settings Connecting Hheadphones Ext.2 S-Video You can select the type of the special sound effect to be used when watching a given broadcast.

  • Page 17: Setting The Trusurround Xt (Srs Tsxt)

    Setting the TruSurround XT (SRS TSXT) You can also set these options simply by pressing the SRS button on remote control. Adjusting the Volume Automatically Selecting the Internal Mute Listening to the Sound of the Sub Picture TruSurround XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers.

  • Page 18: Resetting The Sound Settings To The Factory Defaults

    Resetting the Sound Settings to the Factory Defaults Setting and Displaying the Current Time Setting the Sleep Timer Press the SLEEP button on the remote control repeatedly until the appropriate time interval appears. Switching the Television On and Off Automatically If Game Mode is On, the Reset Sound function is activated.

  • Page 19: Choosing Your Language

    Choosing Your Language Using Game Mode Setting the Blue Screen Mode / Selecting the Melody 4. Press the button to adjust "Hour", then press the move to the next step. Set other items using the same method as above. When finished, press the ENTER button to return. 5.

  • Page 20: Using The Energy Saving Feature

    Using the Energy Saving Feature Selecting the Source Editing the Input Source Names This function adjusts the brightness of the TV so as to reduce power consumption. When you watching TV at night, set the "Energy Saving " mode option to "High" so as to reduce the dazzling of your eyes as well as the power consumption.

  • Page 21: Previewing The Dtv Menu System

    Previewing the DTV Menu System You can select these options by simply pressing the D.MENU button on the remote control. Updating the Channel List Automatically To help you navigate around the on-screen menu system and adjust the various settings available, refer to the following illustration. Available in the Digital TV mode.

  • Page 22: Updating The Channel List Manually

    Updating the Channel List Manually Editing Your Favourite Channels You can specify the channel or frequency for a fast channel search. Press the D.MENU button to display the DTV menu. Press the button to select "Channel", then press the ENTER button. Press the button to select "Manual Store", then press the ENTER button.

  • Page 23: Selecting Channel Manager

    Selecting Channel Manager You can select these options by simply pressing the CH MGR button on the remote control. Move Press the D.MENU button to display the DTV menu. Press the button to select "Channel", then press the ENTER button. Press the button to select "Edit Favourite Channels", then press the ENTER button.

  • Page 24: Displaying Programme Information

    Displaying Programme Information Viewing the EPG (Electronic Programme Guide) Information While viewing a channel, additional information about the current programme may be displayed. While viewing a programme, press the INFO button. The programme information is displayed. To exit from banner information, press the INFO button. The EPG (Electronic Programme Guide) information is provided by the broadcasters.

  • Page 25: Using The Scheduled List

    Using the Scheduled List Setting the Default Guide You can select these options by simply pressing the GUIDE button on the remote control. If you make a scheduled viewing list of programs you may like to see, the channel will be automatically switched to the scheduled program at the scheduled time even if you are watching another program.

  • Page 26: Viewing All Channels And Favourite Channels

    Viewing All Channels and Favourite Channels Setting the Preferred Languages In the EPG menu, you can display all channels or favourite channels. Press the D.MENU button to display the DTV menu. Press the ENTER button again, to select "Guide". Select the your required guide ("Now & Next Guide" or "Full Guide") by pressing the button.

  • Page 27: Choosing Your Language

    Choosing Your Language Adjusting the Translucency Level Setting up the Parental Lock When you start using your set for the first time, you must select the language which will be used for displaying menus and indications. Press the D.MENU button to display the DTV menu. Press the button to select "Preference", then press the ENTER button.

  • Page 28: Setting The Subtitle

    Setting the Subtitle Selecting the Preferred Language (Subtitle or Audio) Setting the Digital Text You can activate and deactivate the subtitles. Press the D.MENU button to display the DTV menu. Press the button to select "Feature", then press the ENTER button. Press the ENTER button again, to select "Subtitle".

  • Page 29: Viewing Product Information

    Viewing Product Information Checking the Signal Information Upgrading the Software (Option) You can view your product information. For service or repair, please contact a Samsung approved dealer. Press the D.MENU button to display the DTV menu. Press the button to select "System", then press the ENTER button.

  • Page 30: Viewing Common Interface

    Viewing Common Interface Selecting the CI (Common Interface) Menu Resetting This contains information on CAM inserted in the CI slot and displays it. Press the D.MENU button to display the DTV menu. Press the button to select "System", then press the ENTER button. Press the button to select "Common Interface", then press the ENTER button.

  • Page 31: Teletext Decoder

    Teletext Decoder Displaying the Teletext Information Most set channels carry " Teletext ", pages of written information that provide information such as: Television programme times. News bulletins and Weather forecasts. Sports results. Subtitles for the hard of hearing. The Teletext pages are organized according to six categories: Contents Part Selected page number.

  • Page 32: Selecting A Specific Teletext Page

    Selecting a Specific Teletext Page Using Fastext to Select a Teletext Page Press the number buttons on the remote control to enter the page number directly: Enter the three-digit page number listed in the contents by pressing the corresponding numeric buttons. If the selected page is linked with several secondary pages, the secondary pages are displayed in sequence.

  • Page 33: Setting Up Your Remote Control

    Setting Up Your Remote Control After it has been set up properly, your remote control can operate in five different modes: TV, DVD, Cable, Set-Top Box, VCR. Pressing the corresponding button on the remote control allows you to switch between these modes, and control whichever piece of equipment you choose. The remote control might not be compatible with all DVD Players, VCRs, Cable boxes, and Set-Top Boxes.
  • Page 34 Setting Up the Remote to Operate Your DVD 1. Turn off your DVD. 2. Press the DVD button on your TV’s remote control. 3. Press the SET button on your TV’s remote control. 4. Using the number buttons on your remote control, enter three digits of the DVD code listed on page 34~35 of this manual for your brand of DVD.

  • Page 35: Remote Control Codes

    Remote Control Codes Brand Code SAMSUNG 000 001 002 003 004 005 077 078 079 ADMIRAL AIWA AKAI 004 027 032 AUDIO DYNAMICS 007 026 BELL&HOWELL BROKSONIC CANDLE 002 003 006 008 015 055 CANON 021 056 CITIZEN 002 003 006 008 015 055...
  • Page 36 019 023 028 PANASONIC 003 022 027 037 044 PHILIPS 019 021 023 028 PIONEER 004 018 020 044 014 022 040 REGAL SAMSUNG DVD Product Code 000 001 002 DVDR 003 004 BD Record 005 006 VCR COMBO 007 008 009 010 011...
  • Page 37 026 029 126 127 128 129 130 141 SHERWOOD 039 041 SYLVANIA 043 093 SHARP SANSUI SANYO 062 090 SHINSONIC SAMSUNG SET-TOP BOX Product Ground wave STB Satellite STB CABLE STB STB DVD COMBO Satellite STB HDD COMBO Standard SET-TOP BOX Brand Code...

  • Page 38: Setting Up Your Pc Software (Based On Windows Xp)

    Windows and your particular video card. Even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) 1. First, click on "Control Panel" on the Windows start menu.

  • Page 39: Setting The Pc

    Setting the PC Coarse and Fine Tuning of the Image (Image Lock): The purpose of picture quality adjustment is to remove or reduce picture noise. If the noise is not removed by Fine-tuning alone, then adjust the frequency as best as possible (coarse) and Fine-tune again.

  • Page 40: Using The Anti-Theft Kensington Lock

    Using the Anti-Theft Kensington Lock The Kensington lock is a device used to physically fix the system when using it in a public place. The locking device has to be purchased separately. The appearance and locking method may differ from the illustration depending on the manufacturer.

  • Page 41: Technical And Environmental Specifications

    Response Sound Output 3D Surround Stereo This device is a Class B digital apparatus. LE46M5 46 inch 1360 x 768 @ 60 Hz H/V Separate, TTL, P. or N. 0.7 Vp-p @ 75 ohm PAL, SECAM-B/G, D/K, I, I/I, L/L’ , NTPB (AV3.58, 4.43)

  • Page 42: Warning! Important Safety Instructions

    Warning! Important Safety Instructions Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).

  • Page 43: Wiring The Mains Power Supply Plug (Uk Only)

    Warranty Card This Samsung product is warranted for a period of twelve (12) months from the original date of purchase, against defective materials and workmanship. In the event that warranty service is required, you should return the product to the retailer from whom it was purchased.
  • Page 44 This page is intentionally left blank.
  • Page 45 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.

This manual is also suitable for:
