Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, Install in accordance with the manufacturer's instructions. 8) Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat.
• This DVD player is designed and manufactured to respond to the Region Management Information. If the Region number of a DVD disc does not correspond to the Region number of this DVD player, the DVD player cannot play the disc.
(Menu Off mode) • Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected DVD discs.
• MP3 disc Play Region Number Both the DVD player and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play.
Display Indicators Front Panel Display 1. Disc type indicators 2. Play/Pause/Forward play 3. Displays various messages concerning operations such as PLAY, STOP, LOAD ... no DISC : No disc loaded. OPEN : The disc tray is open. LOAD : Player is loading disc information. Description-Rear Panel Rear Panel 1.
Tour of the Remote Control DVD Function Buttons 1. DVD POWER Button • Turns the DVD player’s power on or off. 2. NUMBER Buttons 3. PROG Button • Allows you to program a specific order. 4. I.REPLAY Button • This function is used to replay the previous 10 seconds of the movie from the current position.
Choosing a Connection The following show examples of connections commonly used to connect the DVD player with a TV and other components. Before Connecting the DVD Player • Always turn off the DVD player, TV, and other components before you connect or disconnect any cables.
Page 9
• DVI (Digital Visual Interface) DVI is an interface to enable the digital transmission of video signals between various digital devices. Using DVI, the DVD player transmits a digital video signal and displays a vivid picture on a TV having a DVI jack.
Choosing a Connection PROGRESSIVE SCAN Specifications Progressive scanning creates an improved picture with double the scan lines of a conventional interlaced picture. When you press the PROGRESSIVE SCAN button; 1. The 480p will be enabled at the component output when the blue light comes on. 2.
Playing a Disc Step Motion Play (Except CD) Press the STEP button on the remote during play. - Each time the button is pressed, a new frame will appear. - No sound is heard during STEP mode. - Press PLAY/PAUSE ( ) to resume normal play.
Using the Display Function When Playing a DVD/VCD/CD During play, press the INFO button on the remote. Use the UP/DOWN buttons to select the desired item. Use the LEFT/RIGHT buttons to make the desired setup, then press ENTER. • You may use the number buttons of the remote control to directly access a title, chapter or to start playback from a desired time.
Using the Function Menu Using the Function Menu Press the MENU button during playback. Use the UP/DOWN buttons to highlight Function, then press the RIGHT or ENTER button. Function selection screen appears : Info, Screen Fit, Zoom, Bookmark, Repeat and 3D Sound. - Info (See Page 22) - Screen Fit (See Page 28) - Zoom (See Page 31)
Selecting the Audio Language You can select a desired language quickly and easily with the AUDIO button. Using the AUDIO button Press the AUDIO button. Use the LEFT/RIGHT buttons to select the desired language on a DVD. - The audio languages are represented by abbreviations. Use the LEFT/RIGHT buttons to select Stereo, LEFT or RIGHT.
Changing the Camera Angle, S.FIT Play When a DVD contains multiple angles of a particular scene, you can select the Angle function. Using the ANGLE button Press the ANGLE button to see if an ANGLE ) mark is present at the upper left hand corner of the screen.
Using the Bookmark Function This feature lets you bookmark sections of a DVD or VCD so you can quickly find them at a later time. Using the Bookmark Function (DVD/VCD) During play, press the BOOKMARK button on the remote. The Bookmark (--) icons will be displayed. Use the LEFT/RIGHT buttons to move to the desired bookmark icon.
MP3 Play When an MP3 Disc is inserted into the DVD player, the first song file of the first folder plays. • If more than two file extensions are present, select the media of your choice by pressing UP/DOWN, then ENTER.
Program Play & Random Play Program Play (CD/MP3) Press the PROG button. Use the UP/DOWN buttons to select Program. Press the ENTER button. Use the LEFT/RIGHT/UP/DOWN buttons to select the first track to add to the program. Press the ENTER button. The selection numbers appear in the Program Order box.
• A maximum of 500 images can be stored on a single CD. Using the Setup Menu The Setup menu lets you customize your DVD player by allowing you to select various language preferences, set up a parental level, even adjust the player to the type of television screen you have.
Setting Up the Language Features If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time you watch a movie. Using the Player Menu Language With the unit in Stop mode, press the MENU button. Select Setup using UP/DOWN buttons, then RIGHT or ENTER button.
Page 21
Setting Up the Language Features Using the Audio Language With the unit in Stop mode, press the MENU button. Select Setup using UP/DOWN buttons, then RIGHT or ENTER button. Select Language Setup using UP/DOWN buttons, then press the RIGHT or ENTER button. Select Audio using UP/DOWN buttons, then press the RIGHT or ENTER button.
Setting Up the Audio Options Using the Audio Options With the unit in Stop mode, press the MENU button. Select Setup using UP/DOWN buttons, then RIGHT or ENTER button. Select Audio Setup using UP/DOWN buttons, then press the RIGHT or ENTER button. Use the UP/DOWN buttons to select the desired item.
Setting Up the Parental Control The Parental Control function works in conjunction with DVDs that have been assigned a rating - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc. With the unit in Stop mode, press the MENU button.
• 5.1 channel sound is reproduced only when the following conditions are met. : 1) The DVD player is connected with the proper amplifier 2) The disc is recorded with 5.1 channel sound. • Check whether the disc being played has the “Dolby 5.1 ch” mark on the outside.
*Frequency Response Audio Output *S/N Ratio *Dynamic Range *Total Harmonic Distortion • Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. • Weight and dimensions are approximate. Specifications AC 120 V, 60 Hz 18 W 5.4 lbs W 16.9 in x D 9.4 in x H 2.4 in...
Memo Warranty LIMITED WARRANTY TO ORIGINAL PURCHASER Samsung Electronics Canada Inc.(SECA), warrants that this product is free from defective material and workmanship. SECA further warrants that if this product falls to operate properly within the specified warranty period and the failure is due to improper workmanship or defective materials, SECA will repair or replace the product at its option.
